Avigilon 1.0-H3-D1 Manual de usuario

Installation Guide

Avigilon High Definition H.264 IP

Dome Camera Models:

1.0-H3-D1, 1.0-H3-D1-IR, 1.0-H3-D2, 1.3L-H3-D1, 2.0-H3-D1,

2.0-H3-D1-IR, 2.0-H3-D2, 3.0W-H3-D1, 3.0W-H3-D1-IR,

3.0W-H3-D2, 5.0-H3-D1, 5.0-H3-D1-IR and 5.0-H3-D2

920-0081A-Rev1

English

Important Safety Information

This manual provides installation and operation information and

precautions for the use of this dome camera. Incorrect installation

could cause an unexpected fault. Before installing this equipment read

this manual carefully. Please provide this manual to the owner of the

equipment for future use.

• Do not use near water or expose to dripping or splashing.

• Do not place objects filled with liquids above the device.

• Do not expose to rain or moisture.

• For indoor use only.

If used outdoors, an approved outdoor mounting adapter

or enclosure is required. Consult with Avigilon for more

information.

• Installation must be performed by qualified personnel only,

and must conform to all local codes.

• This product is intended to be supplied by a UL Listed

Power Unit marked “Class 2” or “LPS” or “Limited Power

Source” with output rated 12 VDC or 24 VAC, 6 W min.

The Warning symbol indicates the presence of

dangerous voltage within and outside the product

enclosure that may constitute a risk of electric shock,

serious injury or death to persons if proper precautions

are not followed.

The Caution symbol alerts the user to the presence of

hazards that may cause minor or moderate injury to

persons, damage to property or damage to the product

itself if proper precautions are not followed.

Warning — Failure to observe the following instructions may

result in severe injury or death.

English

(10 W min. for -IR model) or Power over Ethernet (PoE),

rated 48 VDC, 6 W min (10 W min. for -IR model).

• Any external power supply connected to this product may

only be connected to another Avigilon product of the same

model series. External power connections must be

properly insulated.

• Do not connect directly to mains power for any reason.

• Do not install near any heat sources such as radiators, heat

registers, stoves, or other sources of heat.

• Do not subject the cables to excessive stress, heavy loads

or pinching.

• Do not open or disassemble the device. There are no user

serviceable parts.

• Refer all servicing to qualified personnel.

Servicing may be required when the device has been

damaged (such as from a liquid spill or fallen objects), has

been exposed to rain or moisture, does not operate

normally, or has been dropped.

• Do not use strong or abrasive detergents when cleaning

the device body.

• Use only accessories recommended by Avigilon.

• Use of controls or adjustments or performance of

procedures other than those specified in this document

may result in hazardous radiation exposure.

Caution — Failure to observe the following instructions may

result in injury or damage to the dome camera.

iii

English

Regulatory Notices

This device complies with part 15 of the FCC Rules. Operation is

subject to the following two conditions: (1) This device may not cause

harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation.

This Class B digital apparatus complies with Canadian ICES-003.

FCC Notice

This equipment has been tested and found to comply with the limits for

a Class B computing device pursuant to Subpart B of Part 15 of FCC

rules, which are designed to provide reasonable protection against

such interference when operated in a commercial environment.

Operation of this equipment in a residential area is likely to cause

interference, in which case the user at his/her own expense will be

required to take whatever measures may be required to correct the

interference.

Changes or modifications made to this equipment not expressly

approved by Avigilon Corporation or parties authorized by Avigilon

Corporation could void the user’s authority to operate this equipment.

Disposal and Recycling Information

When this product has reached the end of its useful life, please dispose

of it according to your local environmental laws and guidelines.

Risk of fire, explosion, and burns. Do not disassemble, crush, heat

above 100 °C (212 °F), or incinerate.

English

European Union:

This symbol means that according to local laws and

regulations your product should be disposed of

separately from household waste. When this product

reaches its end of life, take it to a collection point

designated by local authorities. Some collection points

accept products for free. The separate collection and

recycling of your product at the time of disposal will help

conserve natural resources and ensure that it is recycled

in a manner that protects human health and the

environment.

English

Other Notices

Compilation and Publication Notice

This manual has been compiled and published covering the latest

product descriptions and specifications. The contents of this manual

and the specifications of this product are subject to change without

notice. Avigilon reserves the right to make changes without notice in

the specifications and materials contained herein and shall not be

responsible for any damages (including consequential) caused by

reliance on the materials presented, including but not limited to

typographical and other errors relating to the publication.

Intellectual Property Notice

No license is granted by implication or otherwise under any industrial

design, industrial design rights, patent, patent rights, or copyrights of

Avigilon Corporation or its licensors. Trademarks and registered

trademarks are the property of their respective owners.

English

Table of Contents

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Cover View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Bottom View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Front View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Rear View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

IR View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Required Tools and Materials . . . . . . . . . . . . . . . . . . . . 6

Camera Package Contents . . . . . . . . . . . . . . . . . . . . . . 6

Installation Steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Removing the Dome Cover . . . . . . . . . . . . . . . . 7

Mounting the Dome Camera . . . . . . . . . . . . . . . 7

Connecting Cables . . . . . . . . . . . . . . . . . . . . . . . 8

Assigning an IP Address . . . . . . . . . . . . . . . . . . 9

Accessing the Live Video Stream . . . . . . . . . . 9

Aiming the Dome Camera . . . . . . . . . . . . . . . . 10

(Optional) Configuring Onboard Storage . . . 10

Installing the Dome Cover . . . . . . . . . . . . . . . . . 11

Focusing the Dome Camera . . . . . . . . . . . . . . . 11

For More Information . . . . . . . . . . . . . . . . . . . . 12

Cable Connections . . . . . . . . . . . . . . . . . . . . . . . . .13

Connecting External Power . . . . . . . . . . . . . . . . . . . . . 13

Connecting to External Devices . . . . . . . . . . . . . . . . . 14

Connecting to Microphones, Speakers and Video

Monitors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

LED Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Reset to Factory Default Settings . . . . . . . . . . . .17

Setting the IP Address Through the

ARP/Ping Method . . . . . . . . . . . . . . . . . . . . . . . . . .18

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Limited Warranty & Technical Support . . . . . . . 20

English
