Avaya IP Office CTI Link Manual de usuario

IP Office CTI Link

Installation Manual

40DHB0002USCC – Issue 1 (10/09/2001)

Page 2 - Overview Introduction

Introduction ........................................................................................................................................ 3

Overview ..................................................................................................................................................................3

IP Office CTI Link Lite..........................................................................................................................................................3

IP Office CTI Link Pro..........................................................................................................................................................3

Installation and Configuration .......................................................................................................... 4

Overview ..................................................................................................................................................................4

Installing TAPILink and DevLink ..........................................................................................................................................4

Installing the CTI TAPILink Pro License ..............................................................................................................................5

Configuring the TAPI Driver.................................................................................................................................................5

Single User Mode...................................................................................................................................................6

Third Party Mode....................................................................................................................................................6

Configuring IP Office for TAPI .............................................................................................................................................6

Glossary.............................................................................................................................................. 7

Contents

Introduction Overview - Page 3

IP Office CTI Link Introduction - Page 3

Installation Manual 40DHB0002USCC – Issue 1 (10/09/2001)

Introduction

Overview

The IP Office CTI Link is available in Lite and Pro versions, which provide run-time

interfaces for applications to use. The Software Development Kit (SDK) provides

documentation on both Lite and Pro interfaces for software developers.

Both the Lite and Pro offerings are the same program. The additional functionality

provided by IP Office CTI Link Pro is enabled when the CTI Link Pro licence key is

installed (see page 5).

IP Office CTI Link Lite

IP Office CTI Link Lite is a free of charge offering, and contains the following

components:

•TAPILink Lite

This component implements Microsoft TAPI, and allows programs to control one

telephone line per PC. It provides simple CTI, including answer, hangup, make-

call, transfer, and screen-popping functionality. Please see the TAPILink

Developers Guide for more details on TAPILink Lite and TAPILink Pro.

•DevLink Lite

This component implements an interface for collecting CDR (Call Data Record)

or SMDR information from the IP Office system unit. This provides an event per

telephone call received or made, and is useful for call costing, call billing, and

call recording applications.

IP Office CTI Link Pro

IP Office CTI Link Pro includes all of the Lite functionality. It contains the following

components:

•TAPILink Pro

This component provides both first-party and third-party TAPI control of

telephony devices. In addition to the functionality provided by TAPILink Lite, it

also adds the ability to receive information on ACD queues, hunt groups, and

provides additional advanced functionality. Please see the TAPILink Developers

Guide for more details on TAPILink Lite and TAPILink Pro.

•DevLink Pro

This component provides a real-time event stream in addition to the CDR

interface. The real-time event stream provides information on telephone activity

as and when that activity occurs, and also provides information on trunk activity.

Page 4 - Overview Installation and Configuration

Page 4 - Installation and Configuration IP Office CTI Link

40DHB0002USCC – Issue 1 (10/09/2001) Installation Manual

Installation and Configuration

Overview

The IP Office CTI Link installation primarily concerns the installation and

configuration of the TAPI driver, both of which are detailed in the following

paragraphs. Installation of the DevLink files is also detailed. For programming

details, refer to the TAPI Link Developer's Guide and the DevLink Programmer's

Guide respectively.

Installing TAPILink and DevLink

The IP Office TAPI Service Provider and the DevLink files are both installed from the

IP Office User CD.

Perform the following:

1. Insert IP Office User CD (self installing).

2. The Workstation Installation Wizard - Welcome screen displayed.

3. Click on Next and Identifying Your Control Unit screen displayed.

4. Enter both your User Name (or select from existing) and User Password. Click

on Next.

5. The Ready to Install screen displayed. Click on Finish.

6. A progress bar is displayed and on completion the Welcome to the InstallShield

Wizard for IP Office User Suite screen is displayed. Click Next.

7. The Choose Destination screen displayed.

8. Either accept default or click Browse and select your own destination folder.

Click Next.

9. On the Select Components screen tick the TAPI box and, if required, the

DevLink box (see Notes below).

Do not change any other setting.

10. The Select Program Folder screen is displayed.

11. Either accept default or enter a new folder name. Click Next.

12. A progress bar is displayed and on completion the InstallShield Wizard

Complete screen is displayed.

13. Click Finish to exit from install routine.

Notes: 1. DevLink is installed and used in conjunction with 3rd party applications,

e.g. Call Costing software. For more information please refer to the IP

Office CTI Link DevLink Programmer's Guide.

Installation and Configuration Overview - Page 5

IP Office CTI Link Installation and Configuration - Page 5

Installation Manual 40DHB0002USCC – Issue 1 (10/09/2001)

Installing the CTI TAPILink Pro License

You do not need an IP Office TAPILink Pro license in order to use the TAPI driver.

The license provides the following additional functionality:

•Third Party mode

•ACD Queue monitoring

These are described in Configuring the TAPI Driver below. To install the TAPI

license, proceed as follows:

1. Run the IP Office Manager. This is installed from the IP Office Admin CD.

2. Load the configuration file for your IP Office.

3. Select License on the tree in the left hand window.

4. Right-click in the right hand window and select New.

5. Type in the 32 character license key.

6. The IP Office Manager will indicate whether the license is valid or not.

Configuring the TAPI Driver

TAPI Service Providers are configured using a Windows Control Panel applet. The

name of the applet is not the same across all versions of Windows. The following

table indicates the name of the applet and the tab that must be selected within the

applet:

Windows Version Control Panel Applet Tab

2000 Phone and Modem Options Advanced

ME Telephony Telephony Drivers

98 Telephony Telephony Drivers

NT4 Telephony Telephony Drivers

95 Telephony

Note: TAPI 2.1 must be installed on Windows 95 and can

be down laded from the Microsoft web site.

Telephony Drivers

Run the appropriate applet for your version of Windows and select the tab indicated

above. You will be presented with the list of TAPI Service Providers that you have

installed. The IP Office TAPI Service Provider will be in the list of installed TAPI

Service Providers. Select Avaya GSS TAPI Service Provider and press

Configure. You will be presented with the Avaya TAPI Configuration menu

screen.

Page 6 - Overview Installation and Configuration

Page 6 - Installation and Configuration IP Office CTI Link

40DHB0002USCC – Issue 1 (10/09/2001) Installation Manual

The IP Office TAPI Service Provider can operate in Single User mode or Third Party

mode. A license must be purchased to enable the Third Party mode. Note that the

unlicensed version will not prevent you from selecting this option but it will not work.

Single User mode means that the TAPI application can control and/or monitor a

single telephony device. Third Party mode means that the TAPI application can

control and/or monitor all telephony devices on a particular IP Office unit.

Single User Mode

Enter the IP address of the IP Office unit in the box labelled Switch IP Address.

Select the Single User option. Enter the user name and password for the extension

that is to be monitored and/or controlled by TAPI. Normally, the user name will be

the name of a person associated with a physical telephone extension.

Third Party Mode

Enter the IP address of the IP Office unit in the box labelled Switch IP Address.

Select the Third Party option. Enter the password for the switch. This is the same

password that is entered in Manager when loading the configuration of the switch.

By default, Third Party mode will provide a TAPI line for every physical extension

attached to the IP Office. The checkboxes associated with Third Party mode enable

additional entities to be monitored and/or controlled by TAPI.

ACD Queues

The IP Office can be configured to queue incoming calls, which are being presented

to a group of internal users. For example, if your IP Office were configured with a

group of call center agents, you would want to queue an incoming call until an agent

becomes available to take the call.

Checking the ACD Queues checkbox provides lines to monitor and/or control the

queue of calls against a group.

Configuring IP Office for TAPI

This section describes the configuration of the IP Office using the Manager

application. There are two ways in which you can use TAPI with IP:

1. If your application monitors telephones but does not control them, then there is

no configuration necessary.

2. If your application controls telephones, you should configure all users that will

be controlled as an off-hook station. This will cause the user’s phone to return

to the idle state when a call is hung up using TAPI. Without this option set, the

phone will remain in a disconnected state until the phone is hung up manually.

The off-hook station checkbox can be found on the Telephony tab of the User’s

setting in Manager.

Glossary Overview - Page 7

IP Office CTI Link Glossary - Page 7

Installation Manual 40DHB0002USCC – Issue 1 (10/09/2001)

Glossary

This section contains the list of all abbreviations and acronyms used in this

document.

ACD Automated Call Distributor

CD Compact Disk

ID Identifier

I/O Input / Output

IP Internet Protocol

ISDN Integrated Standard Digital Network

ME Millennium Edition (Windows)

MSDN Microsoft Developer Network

PSTN Public Switched Telephone Network

SDK Software Developer’s Kit

TAPI Telephony Applications Programming Interface

TSP Telephony Service Provider

TSPI Telephony Service Provider Interface

UUI User-to-User Information

Page 8 - Overview Glossary

Page 8 - Glossary IP Office CTI Link

40DHB0002USCC – Issue 1 (10/09/2001) Installation Manual

Performance figures and data quoted in this document are typical, and must be

specifically confirmed in writing by Avaya before they become applicable to any

particular order or contract. The company reserves the right to make alterations

or amendments to the detailed specifications at its discretion. The publication of

information in this document does not imply freedom from patent or other

protective rights of Avaya, or others.

Intellectual property related to this product (including trademarks) and registered

to Lucent Technologies has been transferred or licensed to Avaya.

This confidential document is the property of Avaya and without its prior written

consent may not be disclosed to a third party nor copied.

Sterling Court

15 - 21 Mundells

Welwyn Garden City

Hertfordshire AL7 1LZ

England

Tel: +44 (0) 1707 392200

Fax: +44 (0) 1707 376933

Email: [email protected]

Web: http://www.avaya.com

Otros manuales para IP Office CTI Link

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Software de Avaya

Avaya

Avaya M770 Manual de usuario

Avaya

Avaya IP Office Phone Manager Manual de usuario

Avaya

Avaya Communication Manager Manual de servicio

Avaya

Avaya Definity Enterprise Communications Server Manual de usuario

Avaya

Avaya Communication Manager Contact Center Manual de usuario

Avaya

Avaya Cajun P550 Manager 5.1 Manual de usuario

Avaya

Avaya Plantronics Blackwire C620 s Suplemento

Avaya

Avaya CPSEE_TSP500 Manual de usuario

Avaya

Avaya IP Office Phone Manager Manual de usuario

Avaya

Avaya one-X Quick Edition Manual de usuario

Avaya

Avaya 38DHB0002UKFD Manual de instrucciones

Avaya

Avaya IP Office SMDR Manual de instalación y funcionamiento

Avaya

Avaya IP Office (R3.0) Manual de usuario

Avaya

Avaya Sagemcom XMediusFAX s Suplemento

Avaya

Avaya IP Office Phone Manager Manual de usuario

Avaya

Avaya IP Office 3.2 Manual de usuario

Avaya

Avaya PARTNER ACS R5.0 Manual de usuario

Avaya

Avaya 16-300272 Manual de usuario

Avaya

Avaya Interaction Center Manual

Avaya

Avaya IP Office CTI Link Manual de usuario

Avaya

Avaya CCM 3.1 Manual de usuario

Avaya

Avaya Endpoint Access Control Agent Manual de usuario

Avaya

Avaya PARTNER ACS R7.0 Manual de usuario

Avaya

Avaya Wallboard Manual de usuario

Manuales populares de Software de otras marcas

COMPRO

COMPRO COMPROFM Manual de usuario

Muratec

Muratec OFFICEBRIDGE ONLINE Manual de usuario

Oracle

Oracle Contact Center Anywhere 8.1 Manual de usuario

Adobe

Adobe 65007312 - Photoshop Lightroom Manual

HP ProLiant BL420c Manual de usuario

PS Audio

PS Audio PowerPlay Manual del propietario

Brady

Brady LOCKOUT PRO 3.0 Manual de servicio

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manual

Novell

Novell GROUPWISE 8 - INTERNET AGENT Manual de usuario

Oracle

Oracle Application 9i Manual de usuario

Acer

Acer RDM Manual de usuario

Canon

Canon Vixia HF21 Manual de usuario

Canon

Canon ZR950 Manual de usuario

Samsung

Samsung Auto Backup Manual de usuario

Polycom

Polycom Vortex EF2201 Instrucciones de instalación y funcionamiento

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Manual de usuario

Novell

Novell SP2 - S Manual de instrucciones

Lexmark

Lexmark Apps Manual de servicio
