Avaya IP Office CTI Link Manual de usuario

IP Office CTI Link

Installation Manual

40DHB0002UKCC – Issue 4 (05/08/2002)

Page 2 - Contents

Page 2 - Introduction IP Office CTI Link

40DHB0002UKCC – Issue 4 (05/08/2002) Installation Manual

Introduction ........................................................................................................................................ 3

Contents

Overview ..................................................................................................................................................................3

IP Office CTI Link Lite........................................................................................................................................................3

IP Office CTI Link Pro........................................................................................................................................................3

Installation and Configuration .......................................................................................................... 4

Overview ..................................................................................................................................................................4

Installing TAPILink and DevLink ........................................................................................................................................4

Installing the Wave Driver..................................................................................................................................................5

Windows 2000......................................................................................................................................................5

Windows NT4.......................................................................................................................................................5

Installing the CTI TAPILink Pro and Wave Licenses .........................................................................................................6

Configuring the TAPI Driver...............................................................................................................................................7

Single User Mode.................................................................................................................................................8

Third Party Mode..................................................................................................................................................8

Configuring IP Office for TAPI ...........................................................................................................................................8

Glossary.............................................................................................................................................. 9

Introduction Overview - Page 3

Introduction

Overview

The IP Office CTI Link is available in Lite and Pro versions, which provide run-time

interfaces for applications to use. The Software Development Kit (SDK) provides

documentation on both Lite and Pro interfaces for software developers.

Both the Lite and Pro offerings are the same program. The additional functionality

provided by IP Office CTI Link Pro is enabled when the CTI Link Pro licence key is

installed (see page 6).

IP Office CTI Link Lite

IP Office CTI Link Lite is a free of charge offering, and contains the following

component:

• TAPILink Lite

This component implements Microsoft TAPI, and allows programs to control

one telephone line per PC. It provides simple CTI, including answer, hangup,

make-call, transfer, and screen-popping functionality. Please see the TAPILink

Developers Guide for more details on TAPILink Lite and TAPILink Pro.

IP Office CTI Link Pro

IP Office CTI Link Pro includes all of the Lite functionality. It contains the following

components:

• TAPILink Pro

This component provides both first-party and third-party TAPI control of

telephony devices. In addition to the functionality provided by TAPILink Lite, it

also adds the ability to receive information on ACD queues, hunt groups, and

provides additional advanced functionality. Please see the TAPILink

Developers Guide for more details on TAPILink Lite and TAPILink Pro.

• DevLink Pro

This component provides a real-time event stream. The real-time event stream

provides information on telephone activity as and when that activity occurs, and

also provides information on trunk activity.

IP Office CTI Link Introduction - Page 3

Installation Manual 40DHB0002UKCC – Issue 4 (05/08/2002)

Page 4 - Overview Installation and Configuration

Installation and Configuration

Overview

The IP Office CTI Link installation primarily concerns the installation and

configuration of the TAPI driver, both of which are detailed in the following

paragraphs. Installation of the DevLink files is also detailed. For programming

details, refer to the TAPI Link Developer's Guide and the DevLink Programmer's

Guide respectively.

Installing TAPILink and DevLink

The IP Office TAPI Service Provider and the DevLink files are both installed from the

IP Office User CD.

Perform the following:

1. Insert IP Office User CD (self installing).

2. The Workstation Installation Wizard - Welcome screen displayed.

3. Click on Next and Identifying Your Unit screen displayed.

4. Enter both your User Name (or select from existing) and User Password. Click

on Next.

5. The Ready to Install screen displayed. Click on Finish.

6. A progress bar is displayed and on completion the Welcome to the

InstallShield Wizard for IP Office User Suite screen is displayed. Click Next.

7. The Choose Destination screen displayed.

8. Either accept default or click Browse and select your own destination folder.

Click Next.

9. On the Select Components screen tick the TAPI box and, if required, the

DevLink box (see Notes below).

Do not change any other setting.

10. The Select Program Folder screen is displayed.

11. Either accept default or enter a new folder name. Click Next.

12. A progress bar is displayed and on completion the InstallShield Wizard

Complete screen is displayed.

13. Click Finish to exit from install routine.

Note: DevLink is installed and used in conjunction with 3rd party applications,

e.g. Call Costing software. For more information please refer to the IP

Office CTI Link DevLink Programmer's Guide.

Page 4 - Installation and Configuration IP Office CTI Link

40DHB0002UKCC – Issue 4 (05/08/2002) Installation Manual

Installation and Configuration Overview - Page 5

Installing the Wave Driver

The IP400 wave driver is called “nawave32.drv”. It is in the “wave32” directory on

the User CD. It is a 32bit WAVE driver, and therefore only works on Windows NT

and Windows 2000. Windows XP is not yet supported.

It is not plug-and-play as there is not actually any hardware associated. It is a soft

emulation. You therefore need to install it manually.

Windows 2000

In the control panel select Add/Remove Hardware. You have to wait for your PC to

do a Search for new Devices, which takes about 30 seconds, and does not actually

achieve anything.

Select “Add New Device”, then “No I want to select hardware from a list”, then

“Sound, video and game controllers”. Press the “Have Disk” button. Navigate to the

“wave32” directory on the CDROM. Select the oemsetup.inf file.

Once the wave driver is installed, you must ensure that it is only used by TAPI!

Otherwise, the system will start using it inappropriately, like playing “ding.wav” when

you receive e-mail. This will cause problems.

From the Control Panel, Select “Sounds and Multimedia”. Ensure that no preferred

devices use the WIDWOD32 driver.

This is not sufficient on it’s own, however. You need to prevent its use explicitly.

Go to: “Sounds and Multimedia Properties/Hardware/IP400 32 bit WIDWOD

Driver/ Properties/Properties”

Check the box labelled “Do not map through this device”.

Windows NT4

In the Control Panel select Multimedia/Devices/Audio Devices. Press Add. Select

Unlisted or Updated Driver. Browse to the “wave32” directory on the User CD.

Press OK to add the “IP400 32 bit WIDWOD driver”.

Once the wave driver is installed, you must ensure that it is only used by TAPI!

Otherwise, the system will start using it inappropriately, like playing “ding.wav” when

you receive e-mail. This will cause problems.

From the Control Panel, Select “Multimedia”. Ensure that no preferred devices use

the WIDWOD32 driver.

This is not sufficient on it’s own, however. You need to prevent its use explicitly.

Go to: “Multimedia/Devices/Audio Devices/Audio for IP400 32 bit WIDWOD

driver /Properties”

Check the box labelled “Do not map through this device”.

IP Office CTI Link Installation and Configuration - Page 5

Installation Manual 40DHB0002UKCC – Issue 4 (05/08/2002)

Page 6 - Overview Installation and Configuration

Installing the CTI TAPILink Pro and Wave Licenses

You do not need a license in order to use the TAPI driver, but the license provides

the following additional functionality:

• Third Party mode

• ACD Queue monitoring

• lineDevSpecific function enabled

These are described in “Configuring the TAPI Driver” on page 7.

In addition, to use the Wave functionality you need to install a Wave User’s Licence

for each Wave user.

To install the TAPI licenses, proceed as follows:

1. Run the IP Office Manager. This is installed from the IP Office Admin CD.

2. Load the configuration file for your IP Office.

3. Select License on the tree in the left hand window.

4. Right-click in the right hand window and select New.

5. Type in the 32 character license key.

6. The IP Office Manager will indicate whether the license is valid or not.

Page 6 - Installation and Configuration IP Office CTI Link

40DHB0002UKCC – Issue 4 (05/08/2002) Installation Manual

Installation and Configuration Overview - Page 7

Configuring the TAPI Driver

TAPI Service Providers are configured using a Windows Control Panel applet. The

name of the applet is not the same across all versions of Windows. The following

table indicates the name of the applet and the tab that must be selected within the

applet:

Windows Version Control Panel Applet Tab

XP Pro Network and Internet Connections,

Phone and Modem Options

Advanced

2000 Phone and Modem Options Advanced

ME Telephony Telephony Drivers

98 Telephony Telephony Drivers

NT4 Telephony Telephony Drivers

95 Telephony

Note: TAPI 2.1 must be installed on Windows 95. After

installing IP Office TAPI, TAPI 2.1 installation,

tapi2195.exe, can be found in the IP Office

installation directory, e.g. Program File/Avaya/IP

Office/TAPI/Win95.

Telephony Drivers

Run the appropriate applet for your version of Windows and select the tab indicated

above. You will be presented with the list of TAPI Service Providers that you have

installed. The IP Office TAPI Service Provider will be in the list of installed TAPI

Service Providers. Select Avaya IP Office TAPI Service Provider and press

Configure. You will be presented with the Avaya TAPI Configuration menu

screen.

The IP Office TAPI Service Provider can operate in Single User mode or Third Party

mode. A license must be purchased to enable the Third Party mode. Note that the

unlicensed version will not prevent you from selecting this option but it will not work.

Single User mode means that the TAPI application can control and/or monitor a

single telephony device. Third Party mode means that the TAPI application can

control and/or monitor all telephony devices on a particular IP Office unit.

Note that on some versions of Windows it will be necessary to reboot the PC (or just

restart the telephony service) in order for configuration changes to take effect.

IP Office CTI Link Installation and Configuration - Page 7

Installation Manual 40DHB0002UKCC – Issue 4 (05/08/2002)

Page 8 - Overview Installation and Configuration

Single User Mode

Enter the IP address of the IP Office unit in the box labelled Switch IP Address.

Select the Single User option. Enter the user name and password for the extension

that is to be monitored and/or controlled by TAPI. Normally, the user name will be

the name of a person associated with a physical telephone extension.

Third Party Mode

Enter the IP address of the IP Office unit in the box labelled Switch IP Address.

Select the Third Party option. Enter the password for the switch. This is the same

password that is entered in Manager when loading the configuration of the switch.

By default, Third Party mode will provide a TAPI line for every physical extension

attached to the IP Office. The checkboxes associated with Third Party mode enable

additional entities to be monitored and/or controlled by TAPI.

WAV Users

If you are using the Wave Driver in Third Party mode then you will need to check the

WAV User checkbox to provide access to the TAPI lines associated with WAV

Users.

ACD Queues

The IP Office can be configured to queue incoming calls that are being presented to

a group of internal users. For example, if your IP Office was configured with a group

of call center agents, you would want to queue an incoming call until an agent

becomes available to take the call.

Checking the ACD Queues checkbox provides lines to monitor and/or control the

queue of calls against a group.

Configuring IP Office for TAPI

This section describes the configuration of the IP Office using the Manager

application. There are two ways in which you can use TAPI with IP:

1. If your application monitors telephones but does not control them, then there is

no configuration necessary.

2. If your application controls telephones, you should configure all users that will

be controlled as an off-hook station. This will cause the user’s phone to return

to the idle state when a call is hung up using TAPI. Without this option set, the

phone will remain in a disconnected state until the phone is hung up manually.

The off-hook station checkbox can be found on the Telephony tab of the User’s

setting in Manager.

Page 8 - Installation and Configuration IP Office CTI Link

40DHB0002UKCC – Issue 4 (05/08/2002) Installation Manual

Glossary Overview - Page 9

Glossary

This section contains the list of all abbreviations and acronyms used in this

document.

ACD Automated Call Distributor

CD Compact Disk

ID Identifier

I/O Input / Output

IP Internet Protocol

ISDN Integrated Standard Digital Network

ME Millennium Edition (Windows)

MSDN Microsoft Developer Network

PSTN Public Switched Telephone Network

SDK Software Developer’s Kit

TAPI Telephony Applications Programming Interface

TSP Telephony Service Provider

TSPI Telephony Service Provider Interface

UUI User-to-User Information

IP Office CTI Link Glossary - Page 9

Installation Manual 40DHB0002UKCC – Issue 4 (05/08/2002)

Performance figures and data quoted in this document are typical, and must be

specifically confirmed in writing by Avaya before they become applicable to any

particular order or contract. The company reserves the right to make alterations

or amendments to the detailed specifications at its discretion. The publication of

information in this document does not imply freedom from patent or other

protective rights of Avaya, or others.

Intellectual property related to this product (including trademarks) and registered

to Lucent Technologies has been transferred or licensed to Avaya.

All trademarks identified by the ® or TM are registered trademarks or trademerks,

repecively, of Avaya Inc. All other trademarks are the property of their respective

owners.

This document contains propietary information of Avaya and is not to be

disclosed or used except in accordance with applicable agreements.

Any comments or suggestions regarding this document should be sent to

[email protected].

Avaya SMBS

Sterling Court

15 - 21 Mundells

Welwyn Garden City

Hertfordshire

AL7 1LZ

England

Tel: +44 (0) 1707 392200

Fax: +44 (0) 1707 376933

Email: [email protected]

Web: http://www.avaya.com.

IP Office CTI Link - Installation Manual 40DHB0002UKCC – Issue 4 (05/08/2002)

Otros manuales para IP Office CTI Link

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Software de Avaya

Avaya

Avaya IP Office Phone Manager Manual del operador

Avaya

Avaya IP Office CTI Link Manual de usuario

Avaya

Avaya IP Office Phone Manager Manual de usuario

Avaya

Avaya Unified Messenger Manual de usuario

Avaya

Avaya IP Office Phone Manager Manual de usuario

Avaya

Avaya 38DHB0002UKFD Manual de instrucciones

Avaya

Avaya Polycom SpectraLink 8400 Series s Suplemento

Avaya

Avaya ONE-X 3.1.0 Manual de usuario

Avaya

Avaya IP Office Phone Manager Suplemento

Avaya

Avaya Plantronics Blackwire C420 s Suplemento

Avaya

Avaya one-X Deskphone Edition Manual del producto

Avaya

Avaya C360 Manager Manual de usuario

Avaya

Avaya IP Office Phone Manager Manual de usuario

Avaya

Avaya IP Office 3.2 Manual de usuario

Avaya

Avaya Customer Interaction Express 1.0 Manual de usuario

Avaya

Avaya CPSEE_TSP500 Manual de usuario

Avaya

Avaya CCM 3.1 Manual de usuario

Avaya

Avaya IP Office Phone Manager Manual de usuario

Avaya

Avaya NULL One-X for RIM Blackberry Manual de usuario

Avaya

Avaya NN44400-120 Manual de usuario

Avaya

Avaya M-MLS Manual de usuario

Avaya

Avaya Aura Communication Manager Manual técnico

Avaya

Avaya CCM 3.1 Manual de usuario

Avaya

Avaya Customer Interaction Express 1.0 Manual de usuario

Manuales populares de Software de otras marcas

COMPRO

COMPRO COMPROFM Manual de usuario

Muratec

Muratec OFFICEBRIDGE ONLINE Manual de usuario

Oracle

Oracle Contact Center Anywhere 8.1 Manual de usuario

Adobe

Adobe 65007312 - Photoshop Lightroom Manual

HP ProLiant BL420c Manual de usuario

PS Audio

PS Audio PowerPlay Manual del propietario

Brady

Brady LOCKOUT PRO 3.0 Manual de servicio

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manual

Novell

Novell GROUPWISE 8 - INTERNET AGENT Manual de usuario

Oracle

Oracle Application 9i Manual de usuario

Acer

Acer RDM Manual de usuario

Canon

Canon Vixia HF21 Manual de usuario

Canon

Canon ZR950 Manual de usuario

Samsung

Samsung Auto Backup Manual de usuario

Polycom

Polycom Vortex EF2201 Instrucciones de instalación y funcionamiento

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Manual de usuario

Novell

Novell SP2 - S Manual de instrucciones

Lexmark

Lexmark Apps Manual de servicio
