Avalue Technology APC-18W9 Manual de usuario

Part No. E2017A890A0R

APC-18W9

18" WXGA TFT Fanless Plastic Multi-Touch Full Flat Panel

PC with J1900

Quick Reference Guide

1st Ed –09 January 2015

APC-18W9

2 APC-18W9 Quick Reference Guide

FCC Statement

THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS

SUBJECT TO THE FOLLOWING TWO CONDITIONS:

(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.

(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING

INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS

FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.

THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST

HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A

COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN

RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTATLLED AND USED IN

ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL

INTERFERENCE TO RADIO COMMUNICATIONS.

OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE

HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO

CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.

A Message to the Customer

Avalue Customer Services

Each and every Avalue’s product is built to the most exacting specifications to ensure

reliable performance in the harsh and demanding conditions typical of industrial

environments. Whether your new Avalue device is destined for the laboratory or the factory

floor, you can be assured that your product will provide the reliability and ease of operation

for which the name Avalue has come to be known.

Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To

ensure you get the full benefit of our services, please follow the instructions below carefully.

Technical Support

We want you to get the maximum performance from your products. So if you run into

technical difficulties, we are here to help. For the most frequently asked questions, you can

easily find answers in your product documentation. These answers are normally a lot more

detailed than the ones we can give over the phone. So please consult the user’s manual

first.

To receive the latest version of the user’s manual; please visit our Web site at:

http://www.avalue.com.tw/

Quick Reference Guide

APC-18W9 Quick Reference Guide

Content

1. Getting Started ........................................................................................................4

1.1 Safety Precautions....................................................................................................4

1.2 Packing List...............................................................................................................4

1.3 System Specifications...............................................................................................5

1.4 System Overview......................................................................................................7

1.4.1 Front View................................................................................................................................ 7

1.4.2 Rear View................................................................................................................................ 8

1.5 System Dimensions ..................................................................................................9

2. Hardware Configuration .......................................................................................10

2.1 APC-18W9 connector mapping...............................................................................11

2.1.1 Serial port connector (COM).................................................................................................. 11

2.2 Stand Installation.....................................................................................................12

APC-18W9

4 APC-18W9 Quick Reference Guide

1. Getting Started

1.1 Safety Precautions

Warning!

Always completely disconnect the power cord from your

chassis whenever you work with the hardware. Do not

make connections while the power is on. Sensitive

electronic components can be damaged by sudden power

surges. Only experienced electronics personnel should

open the PC chassis.

Caution!

Always ground yourself to remove any static charge before

touching the CPU card. Modern electronic devices are very

sensitive to static electric charges. As a safety precaution,

use a grounding wrist strap at all times. Place all electronic

components in a static-dissipative surface or static-shielded

bag when they are not in the chassis.

1.2 Packing List

1 x APC-18W9 18" WXGA TFT Fanless Plastic Multi-Touch Full Flat

Panel PC with J1900

1 x DVD-ROM contains the followings:

—Quick Reference Guide (this manual in PDF file)

—Ethernet driver and utilities

—VGA drivers and utilities

—Audio drivers and utilities

—WiFi drivers and utilities

—Touch controller drivers and utilities

1 x Power Adapter

1 x Stand for Panel PC (with 6 screws & 5 rubber feet)

Quick Reference Guide

APC-18W9 Quick Reference Guide

1.3 System Specifications

Component

Mother Board

EBM-BYT

CPU

Onboard Intel® Atom Quad-Core J1900 2.0GHz with Integrated Chipset

Memory

One 204-pin DDR3L SODIMM Socket Supports Up to 8GB DDR3L 1333

SDRAM

Adapter

+12 Vdc / 5 A (60W)

Wireless LAN

Optional MPCIe WiFi module

Storage

Hard Disk Drive

One 2.5" SATA HDD

Solid State Drive

Optional 2.5" SATA SSD

Other Storage Device

Optional mSATA

Panel

LCD Panel

18.5", WXGA

B/L Inverter/Converter

Built in LED backlight

Touch Screen

P-cap

Touch Controller

EETI

External I/O

Serial Port

1 x RS-232/422/485

USB Port

1 x USB 2.0, 1 x USB 3.0

Audio Port

1 x Line-out

LAN Port

2 x RJ-45 (Dual Intel I211AT PCI-E Gigabit LAN)

Wireless LAN Antenna

Reserved 1 for WiFi

Indicator Light

LED for Power, HDD

Expansion Slots

2 x Mini PCIe

Mechanical

Power Type

AT/ATX

Power Connector

Type

DC in

Dimension

443mm x 290mm x 59mm

Weight

4.54kg

Color

Black

Fanless

Yes

Reliability

EMI Test

Class B

Safety

CE FCC

Dust and Rain Test

Follow standard ones

APC-18W9

6 APC-18W9 Quick Reference Guide

Vibration Test

Follow standard ones

Mechanical Shock

Test

Follow standard ones

Drop Test

Follow standard ones

Operating

Temperature

0 to 40°C

Operating Humidity

5%~90% relative humidity, non-condensing

Storage Temperature

-10 to 50°C

Note: Specifications are subject to change without notice.

Quick Reference Guide

APC-18W9 Quick Reference Guide

1.4 System Overview

1.4.1 Front View

Note: Programmable keys are available to be programmed by the user; they are

unable to work unless programmed.

APC-18W9

8 APC-18W9 Quick Reference Guide

1.4.2 Rear View

Connectors

Label

Function

Note

COM

Serial port connector

DB-9 male connector

DC in

DC-in power connector

HDD

HDD LED

LAN1

RJ-45 Ethernet connector 1

KBMS/LAN2

PS/2 keyboard & mouse

RJ-45 Ethernet connector 2

LINE OUT

Line-out audio jack

PWR

Power LED

Reset

Rest button

USB

1 x USB 2.0 connector

1 x USB 3.0 connector

HDMI

HDMI connector

Quick Reference Guide

APC-18W9 Quick Reference Guide

1.5 System Dimensions

(Unit: mm)

APC-18W9

10 APC-18W9 Quick Reference Guide

2.Hardware

Configuration

For advanced information, please refer to:

1- EBM-BYT User’s Manual

Note: If you need more information, please visit our website:

http://www.avalue.com.tw
