INSTALLATION & OPERATING GUIDE

DANTE® | AES67 INTEGRATED MICROPHONE SYSTEM

Thank you for choosing Audix. The Audix M70WD is part of an integrated microphone

system that is the fast, trouble-free way to stream Audix audio performance through

Ethernet networks. Like all Audix products, it is designed to provide many years

of reliable service. Please read this user guide prior to installation and use for

optimal performance.

AIMING THE MICROPHONE

The patented swivel mounting system on the M70 can

be rotated in any direction and angled up to 30 degrees

toward a sound source.

1. To access the microphone capsule, remove the

microphone grill by rotating counter-clockwise.

2. Aim the capsule as needed and reinstall the

microphone grill.

INSTALLATION

1. Determine microphone placement, remove

ceiling tile, and drill 2-inch (51mm) hole in the

desired location

2. Remove the knurled ring from the M70

module and insert the module through the hole

3. Reinstall the knurled ring and hand-tighten

4. Connect one end of a CAT 5 - 7 cable to

the RJ45 jack at the top of the module

and one end to the single-element

RJ45 jack on the Audix DN4 or DN43

microphone interface

5. The M70WD is equipped with red and green

LED status indicators, which can be

controlled through available third-party

plugins for the Audix DN4 and DN43

Dante® | AES67 microphone interfaces.

IN THE BOX

• M70WD microphone

• Seismic / Fire restraint cable

SEISMIC/FIRE RESTRAINT INSTRUCTIONS

Attach the restraint cable to the module using the ring connector at one end of the cable.

Wrap the cable around a beam, eyebolt or hanger. Next, slip the cable through the top

of cable stay barrel pulling g excess cable until taut

To release cable, depress the cable release pin on either end to release the loop or to

extend cable length.

CABLE STAY

BEAM, EYEBOLT

OR WALL

CABLE

CABLE RELEASE PIN

CABLE STAY

BARREL

PUSH PIN IN

TO RELEASE

CABLE

SPECIFICATIONS

Transducer Type Condenser

Frequency Response 60 Hz - 10 kHz

Polar Pattern Cardioid

Output Impedance 150 ohms

Sensitivity 38 mV / Pa @ 1k

Signal to Noise Ratio 72 dB

Equivalent Noise Level 22 dB

Maximum SPL ≥130 dB

Dynamic Range 108 dB

Power Requirements 18 - 52V phantom

Connector RJ45

Required Cable CAT5-7*

Materials / Finish Brass, aluminum and

steel / white

AudixUSA.com | 800.966.8261

PRODUCT REGISTRATION: Please register your product online at AudixUSA.com/register

SERVICE: For service and warranty information, visit AudixUSA.com/service

ALL SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE.

v0.1 08.19

*Audix CAT7 cable is highly recommended. It consists

of four twisted pairs that are individually shielded

and is optimized for balanced audio and cross-talk

elimination. The cable is LS0H (low smoke zero halo-

gen) and available in prepackaged lengths or in bulk.
