Audiovox AS-9055T Manual de usuario

128-7183

1 of 2

3 Channel Remote

Car Starter

Model AS-9055T

Owner’sManual

FEATURES :

!2 Programmable RF Transmitters

!Three Channel Receiver (capable of accepting 4 transmitters)

!On-Board Start Relay

!On-Board Accessory Relay

!On-Board Ignition 1 Relay

!On-Board Ignition 2 Relay

!Ignition 2 Relay Selectable On or Off During Cranking

!On-Board Parking Light Relay

!Ignition 3 / Shock By-Pass / GM VAT Output (relay required)

!Tach Signal Learning Circuit

!Two ( + ) and Two ( - ) Safety Shutdown Circuits

!Alarm By-Pass Output

!AccessoryOutputs

(PulseBefore&AfterStart,DuringCrank&AfterShutDown)

!Selectable Steady or Flashing Parking Lights for Run Indication

!Selectable 5, 10, 15, 20 Minute Run Time

Released: 6-28-04

128-7183

2 of 2

REMOTE STARTING THE VEHICLE

This will not start the vehicle if any one of the following situations exists;

The vehicle's hood lid is opened.

The gear shift selector is not in Park.

The brake pedal is depressed.

The safety control switch is in the Off position.

1. To start the vehicle, press and release the transmitter button two times

within 2 seconds. The vehicle will start and remain running for the pre-

programmed 5,10,15,20 minute run cycle. As a visual indication, the

parking lights will flash or remain on depending on the setting by your

installation center.

2. When you arrive at the vehicle, turn the ignition key to the ON position

(not the spring loaded start position), then step on the brake pedal to disen-

gage the remote starter. The vehicle will continue to run, but now on it's own

power.

NOTE: The engine will stop running before the pre-programmed run cycle

has expired if you perform any one of the following functions;

-Press and the button on the keychain transmitter two times within 2 seconds.

-Depress the brake pedal.

-Open the vehicle's hood

-Move the safety control switch to the Off position.

SAFETY CONTROL SWITCH

The red handle control switch allows you to temporarily disable the remote starting function

of the system and moving this switch to the Off position is recommended whenever the

vehicle is being serviced. When the system is disabled, the remote door locks and optional

accessories will remain operational.

TELEMATIC UPGRADE:

This system has the ability to have a telematic upgrade module connected to it. This is an

upgrade that can give you control of certain functions of your vehicle from a Telephone, or

in some cases a computer interface. Please check with your installation center for most

recent Telematic Upgrades. If you had a Telematic Upgrade installed, the manual supplied

with the upgrade unit will provide a operators manual advising of the features of the system

and means available to control these features of your vehicle.

FUNCTION SETTING CHART

To be completed by installer

Run Time 5 Min "10 Min "15 Min "20 Min "

Door Lock Timer 1 Sec/1 Sec "3.5 "1 Sec/Dbl 1 Sec "

Lights Pulse "Steady "
