Audiovox Code Alarm PROFESSIONAL SERIES CA 5550SST Manual de usuario

12010AudiovoxElectronicsCorporation.Allrightsreserved.

PROFESSIONAL

SERIES

IMPORTANT NOTE: Theoperation ofthe Securityand ConvenienceSystem as describedin thismanual is

applicableto most vehicles.However, dueto the configurationof somevehicles, some functionsAND/OR

SAFETYPRECAUTIONS maynot apply. Please see your installingdealerfor moreinformation.

Deluxe Vehicle Remote Start

System with 900Mhz 2 Way

Confirming LCD Remote Control

CA 5550SST

Owner’s Guide

2 2010AudiovoxElectronicsCorporation.Allrightsreserved.

Table of Contents

Using Your Remote Control ...............................................................3

Using the Keyless Entry ...................................................................3

Two Stage Door Unlock (optional) ...................................................3

Activating Trunk Release (optional) ................................................3

Using the Progressive Car Finder Feature......................................3

Using the Personal Protection Alarm ...............................................3

Programmed Transmitter Notification ..............................................3

Valet Mode ........................................................................................4

Eliminating Lock / Unlock Notification Chirps ...................................4

Using Your Remote Vehicle Starter .................................................4

Remote Starting Your Vehicle ..........................................................4

Remote Start Shutdown ...................................................................4

Entering Your Vehicle while it is Running via Remote Start ...........4

Preheating or Precooling the Vehicle’s Interior ...............................5

User Programmable Run Time / Run Time Extension ......................5

Using the “Quick-Stop” Feature .......................................................5

Operating the 2 / 3 Hour Start Up Timer Mode ................................5

Operating the Daily Start Timer ........................................................6

Remote Start Safety Features .........................................................6

Transmitter Button Functions ...........................................................7

Replacing Remote Control Batteries...............................................7

Warranty Information...........................................................................8

32010AudiovoxElectronicsCorporation.Allrightsreserved.

Using Your Remote Control

Using the Keyless Entry

The button is used to lock the vehicle's doors, the button is used to unlock the

vehicle's doors. To lock or unlock the doors simply press and release the desired

function button one time. For your convenience, the parking lights will flash once

when the doors are unlocked and twice when the door are locked.

NOTE: The system is defaulted with Silent Choice enabled, which requires a

second press of the or button to activate an audible locking/unlocking

response from the vehicle. If your system is set up for 2 step unlock, a third press

of unlock will activate the audible response.

Using the Progressive Car Finder Feature

Press the button to locate your vehicle. The system will sound 5 times at low

volume, increasing in volume each time the button is pressed.

Using the Personal Protection Alarm (Panic)

Press and hold the button for 3 seconds to activate the personal protection

alarm. During panic mode, the normal function of the transmitter buttons will be

suspended. The transmitter’s and buttons can be used to lock and unlock the

door (if the option is installed). To stop the alarm, press and hold the button on

the transmitter again for 3 seconds. The system will automatically stop after 30

seconds.

Programmed Transmitter Notification

As a security precaution each time the vehicle’s ignition is turn on the status LED

light with flash the number of transmitters programmed into the system. This helps

to identify unauthorized transmitters from accessing your vehicle. If you believe an

unauthorized transmitter has been programmed to your system, contact your

installing dealer for assistance.

Activating the Trunk Release Feature (Optional)

The button is used to open the trunk of the vehicle. To open the vehicle's trunk

press and hold the button for 3 seconds.

Two Stage Door Unlock (Optional)

If this feature is enabled on your system, pressing the button one time will

unlock only the driver’s door. Press again within three seconds to unlock the

remaining doors.

4 2010AudiovoxElectronicsCorporation.Allrightsreserved.

Remote Starting Your Vehicle

To activate the remote vehicle start function, press and release the button 2

times within 2 seconds. The system will sound, the parking lights will flash 1 time

and the system will check the vehicle to ensure it is safe to start. If all safety

parameters are correct, the vehicle will start within 5 seconds. The vehicle’s

parking lights will turn on (or flash depending on system settings) as a visual

indication that the vehicle has started and is running.

If your vehicle stalls or does not start, the system will pause 5 seconds, then try 2

more times to start the vehicle (a total of 3 attempts). The system will pause 5

seconds between each start attempt. If the vehicle does not start after the 3rd

attempt, the system will abort the remote vehicle start process.

Remote Start Shutdown

Press and hold the button for 3 seconds to turn the vehicle off.

Entering the Vehicle while it is Running via Remote Vehicle Start

1. Unlock the vehicle’s doors.

2. Enter the vehicle. DONOT PRESSTHE BRAKE PEDAL!

3. Insert the key into the ignition switch and turn to the ON or RUN

position.

4. Press the brake pedal. The remote vehicle starter will disengage and

the vehicle will operate normally.

Eliminating Lock / Unlock Notification Chirps

System lock and unlock notification chirps can be toggled ON or OFF without

entering the programming feature banks.

1. Turn the ignition ON then OFF.

2. Press and release the valet/programming button 3 times. The system

will respond with 1 chirp for ON or 2 chirps for OFF.

Using Your Remote Control

Valet Mode

Valet Mode is used to disable the system from remote starting. To

enter or exit valet mode simply follow the 4 steps outlined below:

1. Turn the vehicle’s ignition ON.

2. Push and hold the programming/valet button.

3. The LED will turn on solid when valet mode is active

4. Release the programming/valet button.

52010AudiovoxElectronicsCorporation.Allrightsreserved.

Preheating or Precooling the Vehicle’s interior

Before exiting the vehicle, set the temperature controls to the desired setting and

operation. After the system starts the vehicle, the heater or air conditioner will

activate and heat or cool the vehicle’s interior to your setting.

User Programmable Run Time / Run Time Extension

The system has the ability to allow the user to extend the time the vehicle will be

running under control of the remote start. This will only extend the run time back to

the current run time setting during the current remote start cycle. If your system is

set to run 15 minutes and the time remaining is 4 minutes, extending the run time

will reset the countdown timer to 15 minutes and your vehicle will continue to run

for another 15 minutes. Follow the steps below to extend the vehicle’s run time.

1. The remote start must already be active.

2. Press and release the button 4 times.

3. The system will chirp to confirm that the run time has been reset.

Operating the 2 / 3 Hour Start Up Timer Mode

The system has the ability to start the vehicle every 2 or 3 hours for a 48 hour

period. This feature is especially useful in cold climates where the only means to

keep the engine and engine fluids warm is to periodically start the engine. The

default setting is 3 hour, selection between 2 or 3 hour is made in option

programming.

WARNING!

Be certain that the vehicle is outdoors before using this or any remote starting

device. A running engine produces dangerous carbon monoxide fumes which can

be harmful or fatal if prolonged exposure occurs. DO NOT remote start the vehicle

if it is garaged.

Using the “Quick-stop” Feature

If you want to make a short stop and keep your vehicle running (to keep the

interior warm or cool), the quick-stop feature allows you to do this while keeping

your vehicle secure and your keys with you.

To engage quick stop:

1. Stop the vehicle and place the transmission in PARK.

2. With your foot off the brake pedal, press and release the button 2

times within 2 seconds. The LED will flash 3 times to confirm quick

stop is entered.

3. Remove the keys from the ignition and exit the vehicle. Press the

button to lock the vehicle’s doors if desired.

Note: Do not leave children or animals unattended in the vehicle when using the

quick-stop feature.

6 2010AudiovoxElectronicsCorporation.Allrightsreserved.

Remote Start Safety Features

For safety and security reasons, the system will shutdown or prevent the remote

vehicle starter from activating if any of the following occur:

1. The vehicle hood is open.

2. The brake pedal is pressed prior to turning the ignition key to the ON

position.

3. The engine is over-reved (tach checking only).

4. Valet mode is active.

Operating the Daily Start Timer

The system has the ability to start your vehicle based on a 24-hour countdown

timer. This feature requires a two-part activation sequence. From the remote,

pressing both the & buttons together will activate the 24 hour countdown

timer (the vehicle will start 24 hours from this time). Next, When you are finished

operating the vehicle for the day, perform the following steps to complete the

process.

1. Turn the ignition ON/OFF (vehicle must be disarmed).

2. Within 10 seconds, while pressing the brake, press and release the

button twice.

3. The vehicle will emit 2 chirps.

To begin the 2 / 3 hour start up timer mode:

1. Turn the vehicle’s ignition ON then OFF.

2. Press and hold the valet button.

3. Press the button 4 times, the system will;

a. When set for 3 Hour (default) - chirp 2 times and flash the

parking lights 4 times.

b. When set for 2 Hour - chirp 1 time and flash the parking

lights 2 times.

To exit the 2 / 3 hour start up timer mode:

1. Turn the vehicle’s Ignition ON.

1. Activate the remote vehicle start feature using the remote

control.

72010AudiovoxElectronicsCorporation.Allrightsreserved.

Check Vehicle Status

Press and release 2 times then press within 3 seconds, the transmitter will

respond with one melody sound and display the current status of the vehicle.

Display Illumination

Press and hold the button for 1 second. The display will illuminate for 5

seconds.

Melody / Vibration Mode

To have the remote control vibrate, play a melody tone or both each time it receives

a response from the vehicle press and release then press and hold for 2

seconds.

Button Beeps

To toggle button beeps on or off press and release then press and hold for 2

seconds.

Battery Save Mode

While in POWER SAVE MODE the 2-way LCD transmitter will NOT look for any

incoming signals from the main unit until a button is pressed. The LCD screen will

display SAVE to indicate that power save mode is ON. To enter power save mode

press and hold for 5 seconds.

Clear Flashing Icons and Melody Sound

Press the button 3 times within 3 seconds. This will clear the melody sound and

flashing icons on the LCD screen.

Button Lock

Press and release then press hold the for 2 seconds to toggle the button lock

on or off. When the button lock is active, the remote control will beep/vibrate 2

times when a button is pressed indicating it is locked.

Illumination

Press and release 2 times then press and hold for 2 seconds to toggle

illumination on or off. When on, the display will illuminate when it receives or

sends a command.

Additional 2-Way LCD Remote Control Functions

8 2010AudiovoxElectronicsCorporation.Allrightsreserved.

2 Car Mode

To control a second security system enter 2 car mode by pressing then press

and together for 3 seconds. When the icon appears on the transmitter’s LCD

screen it will control the second security system. Use the same method to exit 2

car mode and resume control of the original vehicle’s security system.

NOTE: A second security system must be installed and the LCD transmitter must be

learned to it before this feature will operate the additional system.

Parking Meter Countdown

The parking meter countdown timer has 6 preset times, to access the preset times

and begin countdown press and release then press and hold for 2 seconds,

each additional press of will increase the countdown time.

Adjusting the Clock and Timer Settings

The clock, alarm clock and programmable countdown timer are accessed through

the Function Menu. Press and hold for 3 seconds to access the function menu,

once you have accessed the feature menu press and release to scroll through

each feature and follow the steps below to adjust the settings for each. Press and

hold for 2 seconds to exit the menu.

Clock Hour Press to increase or to decrease

ClockMinute Press to increase or to decrease

Alarm Clock Hour Press to increase or to decrease

Alarm Clock Minute Press to increase or to decrease

Alarm Clock ON / OFF Press to turn ON or to turn OFF

Countdown Timer Hour Press to increase or to decrease

Countdown Timer Minute Press to increase or to decrease

Countdown Timer ON / OFF Press to turn ON or to turn OFF

92010AudiovoxElectronicsCorporation.Allrightsreserved.

LOCK UNLOCK

VALET MODE

TRANSMITTING

TRUNK RELEASE

ENGINE RUNNING

2 CAR MODE

BATTERY INDICATOR BATTERY SAVE MODE

VIBRATE/SILENT MODE

PANIC

TIME COUNT DOWN

MELODY MODE

TIME DISPLAY

TIMER START MODES

ALARM CLOCK

LCD Remote Control ICON’s

10 2010AudiovoxElectronicsCorporation.Allrightsreserved.

Transmitter Button Functions

1 Way

Transmitter

Lock Unlock

Car Find /

Panic

Start N/A Operation Method

Lock X Press and Release

Unlock X Press and Release

Trunk X Push and Hold (3 Sec)

Car Finder X Press and Release

Panic X Push and Hold (3 Sec)

Remote Start X

Press and Release (1 or 2 times depending

on selectable option)

Remote Start

Shut Down

XPush and Hold (3 Sec)

Run Time

Extention

XPress and Release 4 times.

2 / 3 Hour Start X

Ignition ON/OFF, Press and Hold Valet

Button, Press Start 4 times

Daily Start Timer X X Press Lock + Start

2 Way

Transmitter

Lock Unlock

Car Find /

Panic

Start Function Operation Method

Lock X Press and Release

Unlock X Press and Release

Trunk X Push and Hold (3 Sec)

Car Finder X Press and Release

Panic X Push and Hold (3 Sec)

Remote Start X

Press and Release (1 or 2 times depending

on selectable option)

Remote Start

Shutdown

XPush and Hold (3 Sec)

Run Time

Extention

XPress and Release 4 times.

2 / 3 Hour Start X

Ignition ON/OFF, Press and Hold Valet

Button, Press Start 4 times

Daily Start Timer X X Press Lock + Start

Menu X Press and Hold

Otros manuales para Code Alarm PROFESSIONAL SERIES CA 5550SST

Tabla de contenidos

Otros manuales de Arranque remoto de Audiovox

Audiovox

Audiovox Pursuit PRO9051i Manual de usuario

Audiovox

Audiovox PURSUIT PRO9276TW Manual de usuario

Audiovox

Audiovox AS-9055T Manual de usuario

Audiovox

Audiovox Pursuit PRO-9556 Manual de usuario

Audiovox

Audiovox AA-RS10CS Manual de usuario

Audiovox

Audiovox car connection 2.0 Manual de usuario

Audiovox

Audiovox Prestige APS-55 Manual de usuario

Audiovox

Audiovox PurSuit PRO-9056TW Manual de usuario

Audiovox

Audiovox Prestige APS-920 Manual de usuario

Audiovox

Audiovox NPSWR Manual de usuario

Audiovox

Audiovox Pursuit PRO-9175FT Manual de usuario

Audiovox

Audiovox PRO-9556C Pursuit Series Manual de usuario

Audiovox

Audiovox Pursuit PRO 9246FT3 Manual de usuario

Audiovox

Audiovox Prestige Platinum APS 687 Manual de usuario

Audiovox

Audiovox AA-RS5CS Manual de usuario

Audiovox

Audiovox AS 9076N Manual de usuario

Audiovox

Audiovox Auto Security AS-9501a Manual de usuario

Audiovox

Audiovox Prestige APS-55LR Manual de usuario

Audiovox

Audiovox Prestige Platinum+ APS 675 Manual de usuario

Audiovox

Audiovox Professional Series CA 6150 Manual de usuario

Audiovox

Audiovox Pursuit PRO-9056 Manual de usuario

Audiovox

Audiovox Pursuit PRO 9232a Manual de usuario

Audiovox

Audiovox Patinum APS-997 Manual de usuario

Audiovox

Audiovox AX-45 Manual de usuario

Manuales populares de Arranque remoto de otras marcas

AstroStart

AstroStart 803U Manual de usuario

Durite

Durite 0-649-20 Manual

EINHELL

EINHELL BT-PS 1000 Manual

Linear

Linear ACCESS AK-21 Especificaciones técnicas

Soundstream

Soundstream TARANTULA RS.2 Manual de usuario

Jaycar Electronics

Jaycar Electronics MB3752 Manual de usuario

Ultra Start

Ultra Start 72 Series Manual de usuario

ADS

ADS FLASHLOGIC FLRSVW1 Manual de usuario

Selecta

Selecta JS012 Manual de usuario

Black Widow Security

Black Widow Security BW RAS 400 Manual de usuario

Vector

Vector Power City DK080706 Suplemento

Code Alarm

Code Alarm CA-535 Manual de usuario

Ozito

Ozito OJS-800 Manual de usuario

Profi-Partner

Profi-Partner 46387 Manual de usuario

EZ STARTER

EZ STARTER EZ-45 Manual de usuario

Viper

Viper 4204 Manual de usuario

Essex Electronics

Essex Electronics KE-1701 Manual de usuario

EINHELL

EINHELL EGS 3600 Manual
