Model AA-RS20CS

Owner's Manual

FEATURES:

2 Three Button Programmable RF Transmitters

Four Channel Code Learning Receiver

Anti Code Grabbing Technology

Remote Panic In All Modes

Protected Valet/Override

Remote Start Safety Control Switch

Safe Start RF Control (Double Push Of RF Transmitter)

Selectable Automatic Timed Start Mode

7 Function LED, Arming, Armed, Disarmed, Valet, Zones 1, 2, & 3

Intrusion Alert With Memory

Audible Arm, Disarm, Defect Zone, And Intrusion Indications

Instant Siren Activation All Entry Points

Starter Disable When Armed

True Last Door Arming

Defective Zone By-Pass

On Command RF Chirp Delete

6 Tone Multi-Tone Siren

Two Stage Shock Sensor

Selectable Run Time 10 or 15 Minutes

OPTIONS:

Remote Trunk Release

Remote Keyless Entry

Illuminated entry

Remote Power Window Control

Remote Garage Door Interface

Multiple Vehicle Capable

WARNING! Be certain that the vehicle is outdoors before using this or any remote

vehicle starting device. A running engine produces dangerous carbon

monoxide fumes which can be harmful or fatal if prolonged exposure

occurs. DO NOT remote start the vehicle if the car is garaged.

3 Button Remote Start Security System With

Plug-In Shock Sensor & Starter Disable

Your AA-RS20CS Remote Start Alarm System has many features and available options

some of which are selected at time of installation. For your reference, the list on the back

page of this manual show what features and options have been installed. Consult your

installing dealer for options that may have been installed and are not listed.

ARMING THE SYSTEM - ACTIVE:

1. Turntheengineoff,exitthevehicle,andclosealldoors,hoodandtrunk.

2. Press and release transmitter button 1 one time.

The parking lights will flash once, the siren will chirp once, and the dash

mounted LED will begin to flash slowly confirming the system is armed.

If you have the optional door lock/unlock circuit installed, thedoorswilllock.

Note: If the siren chirped three times, then you have left a door, hood, or

trunk ajar. Simply closing that opening will provide full protection. If the

siren did not sound when arming, then the chirps have been turned off.

Refer to the section on "Eliminating the Arm/Disarm Chirps" shown later

in this manual.

SILENT ARMING - ACTIVE:

1. Turn the engine off, exit the vehicle, and close all doors, hood and trunk.

2. Press and hold transmitter button 1 for two seconds.

The parking lights will flash once, and the dash mounted LED will begin to flash slowly

confirming the system is armed. The siren will not chirp. If you have the optional door

lock/unlock circuit installed, the doors will lock.

Note: If the siren chirps three times, then you have left a door, hood, or trunk ajar. Simply

closing that opening will provide full protection.

ARMING THE SYSTEM - PASSIVE (AUTOMATIC)

If the passive arming feature has been selected:

1. Turn the engine off, exit the vehicle, and close all doors, hood and trunk.

The dash mounted LED will begin to flash rapidly indicating that the 30 second passive

arming timer has begun. If the LED does not begin to flash rapidly, then you have left a

door, hood, or trunk ajar. Closing this entry point will allow the arming cycle will begin. If

any entry point is opened during the 30 second arming cycle, arming will be suspended.

When all entry points are closed, the arming cycle will begin again.

At the end of the 30 seconds, The parking lights will flash once, the siren will chirp once,

and the dash mounted LED will begin to flash slowly confirming the system is armed. If

the siren did not sound when arming, then the chirps have been turned off. Refer to the

section on "Eliminating the Arm/Disarm Chirps" shown later in this manual. Passive door

locking is a selectable feature. If you have the optional door lock/unlock circuit installed,

the doors may or may not lock passively dependent upon the setup during installation.

PROTECTION WHILE THE SYSTEM IS ARMED:

Opening any protected entry point, hood, trunk, or doors will cause the alarm to trigger

immediately. The siren will sound and the parking lights will flash for 30 seconds, then

stop and continue to monitor all protected entry points. If the thief left the door opened,

theunitwillsoundfor six 30 second cycles than shut down, isolate the triggered zone and

Page 2

123

continue to protect all other zones.

Whenever the system is armed, the dash mounted LED will slowly flash. This serves as

a visual deterrent to a potential thief. This LED is a very low current light emitting diode,

and will not cause the battery to drain even if left unattended for long periods of time.

Whenever the system is triggered, the vehicle parking lights will flash for the full siren

sounding period. Optional - whenever the system is triggered, the interior courtesy light

will flash for the full siren sounding period.

Whenever the system is armed, the vehicle starter circuit is disabled, even with the igni-

tion key the vehicle will not start.

Whenever the system is armed, any strong impact to the vehicle will cause the shock

detector to trigger the alarm. Any lesser impact will cause the pre-detect stage of the

shock sensor to emit a few short series of warning tones from the siren.

DISARMING THE SYSTEM

As you approach the vehicle, press and release transmitter button 1 one time.

The parking lights will flash two times, the siren will chirp twice, and dash mounted LED

will turn off.

If you have the optional door lock/unlock circuit installed, the doors will unlock. If you

have the optional entry illumination circuit installed, the interior light will turn on for 30

seconds or until the ignition key is switched on.

Note: If the passive arming mode was selected at time of installation, the dash mounted

LED will start flashing rapidly indicating that the system is rearming. Opening any

door will suspend the automatic arming.

If the parking lights flashed three times, and the siren chirps four times, this indicates that

the alarm system had been triggered in your absence. Before turning on the ignition key,

examine the dash mounted LED's flash pattern. The number of flashes identifies the

triggered zone. For additional information, refer to INTRUSION WARNING SIGNALS

found later in this manual.

If the siren did not sound upon disarm, then the chirps have been turned off. Refer to the

section titled ELIMINATING THE ARM/DISARM CHIRPS.

SILENT DISARMING

1. As you approach the vehicle, press and hold transmitter button 1 for two seconds.

The parking lights will flash twice, and the dash mounted LED will turn off confirming that

the system is disarmed. The siren will not chirp. If you have the optional door lock/unlock

circuit installed, the doors will unlock. If you have the optional entry illumination circuit

installed, the interior light will turn on for 30 seconds or until the ignition key is switched on.

Note: If the passive arming mode was selected at time of installation, the dash mounted

LED will start flashing rapidly indicating that the system is rearming. Opening any

door will suspend the automatic arming.

If the parking lights flashed three times, and the siren chirps four times, this indicates that

the alarm system had been triggered in your absence. Before turning on the ignition key,

examine the dash mounted LED's flash pattern. The number of flashes identifies the

triggered zone. For additional information, refer to INTRUSION WARNING SIGNALS

found later in this manual.

Page 3

INTRUSION WARNING SIGNAL

This system will inform you if an intrusion attempt has occurred while you were away

from the vehicle. Upon disarm, the siren will chirp 4 times and the parking lights will flash

3 times. Enter the vehicle and before turning on the ignition switch, observe the LED

flash pattern.

If the LED flashes one time...pause, one time...pause etc., then an intrusion attempt was

made by impact or a strong vibration that the shock sensor detected. Check the vehicle

for possible damage to the glass or body panels.

If the LED flashes two times...pause, two times...pause etc., then an intrusion attempt

was made to open the hood, trunk, or by an accessory triggering device. Check the

vehicle for indications of forced entry to these openings.

If the LED flashes three times...pause, three times...pause etc., then an intrusion attempt

was made to the vehicle doors. Check all doors for indications of forced entry.

Note: The LED intrusion warning indications are stored in the system's memory and will

be erased when the ignition switch is turned on.

VALET/SYSTEM OVERRIDE SWITCH

The valet switch allows you to temporarily by-pass all alarm functions, eliminating the

needto hand yourkeychaintransmitter to parkingattendantsor garage mechanics. When

the system is in the valet mode, all alarm functions are by-passed, however the remote

panic feature, and the optional remote door lock/unlock will remain operational. To enter

the valet mode:

1.Start with the valet switch in the "off" position

2.Turn the ignition switch to the "on" position.

3.Within 10 seconds of step 2, flip the valet switch to the "on" position.

The dash mounted LED will turn on solid indicating that the valet mode has successfully

been entered.

To return to the normal, (alarm mode), operation, move the valet switch to the "off"

position any time the ignition switch is in the on position.

Note: In the event that you lose your keychain transmitter or the transmitter fails to

operate the alarm system, the valet switch can be used to disarm the alarm. To

disarm the alarm:

1. Open the door with the vehicle door key. (The siren will sound)

2. Turn the ignition switch to the on position.

3. Flip the valet/override switch to the on position.

The system will disarm and the vehicle can be operated normally.

Always remember to move the valet switch to the off position to ensure the vehicle

remains protected at all times.

ELIMINATING THE NORMAL ARM/DISARM CHIRPS

You can selectively eliminate the normal arm & disarm chirps by holding the transmitter

button slightly longer when arming and disarming. This will prevent the siren chirps for

one arm or disarm cycle. If you find this inconvenient and wish to eliminate these chirps

permanently,

1. Start with the valet switch in the off position.

Page 4

Page 5

2. Turn the ignition switch on then off.

3. Within 10 seconds of turning off the ignition, flip the valet switch on, off, on, off, on, off.

4. If the chirps were on before you started, the siren will emit 2 short chirps indicating

that the chirps are now off. If the chirps were off before you started, the siren will emit

one short chirp indicating that the chirps are now on.

REMOTE PANIC OPERATION

Thearm/disarmbuttonofyourkeychain transmitter also serves as a panic switch and will

turn the alarm on from the maximum operating range of the transmitter. In an emergency

situation, to use the panic feature, press and hold the arm/disarm button of the transmitter

for 3 seconds. This will cause the lights to flash, the siren to sound, and if the optional

interior illumination circuit was installed, the interior light will flash.

To disengage the panic feature, press and release the arm/disarm button one time. If

you do not shut off the panic feature, the system will time out and shut off automatically

after 30 seconds.

During this mode, all normal transmitter functions are operational.

SAFETY (Red Handled ) CONTROL SWITCH

The control switch allows you to temporarily disable the remote starting function of your

AA-RS20CS. To disable the unit, move the red handled control switch to the off position.

The control switch also allows you to select between 2 hour start up and 4 hour start up

when using the automatic start up timer mode. The factory preset start up time for this

mode is every 4 hours. To select between 2 or 4 hour start up timer:

1. Begin with the control switch in the on position

2. Turn the ignition switch on then off

3. Within 10 seconds, move the control switch off, on, off, on (2 switch cycles) to select

a 2 hour start timer.

The parking lights will flash, and the siren will chirp 2 times confirming that the two hour

startcycleisset. Or, within 10 seconds move the control switch off,on, off,on,off,on, off,

on (4 switch cycles) to select a 4 hour start timer. The parking lights will flash, and the

siren will chirp 4 times confirming that the 4 hour start timer is set.

REMOTE STARTING THE VEHICLE

The AA-RS20CS WILL NOT start the vehicle if any one of the following conditions exists:

1. The Vehicle Hood Is Opened.

2. The Gear Selector Is In Any Gear Other Then Park.

3. The Brake Is Depressed.

4. The Safety Control Switch Is In The Off Position.

CAUTION! Becertainthatthevehicle is outdoors before using this or any remote vehicle

starting device. A running engine produces dangerous carbon monoxide

fumes which can be harmful or fatal if prolonged exposure occurs. DO NOT

remote start the vehicle if the car is garaged.

To Remote Start The Vehicle:

Press and release channel 2 of your keychain transmitter two times within 2 seconds.

The vehicle will start and remain running for the pre-programmed 10 or 15 minutes. As a

Page 6

visual indication, the parking lights will flash or turn on dependent on the programming

set up by your installation center.

When you arrive at your vehicle, disarm the alarm system by pressing and releasing the

arm/disarm button of your keychain transmitter. Enter the vehicle and turn the ignition

key to the on position.

CAUTION! Do not turn the key to the start position. This will cause the starter motor to

engage with the already running engine which could result in damage. Step

on the brake pedal to disengage the remote start unit. The vehicle will

continue to run but now on it's own power.

NOTE: The engine will stop running before the expiration of the pre-programmed run

timer if you complete any of the following:

1. Press and release channel 2 of your keychain transmitter two times within 2 seconds.

2. Depress the brake pedal.

3. Open the hood.

4. Move the red handled control switch to the off position.

5. Race the engine to above 4000 RPM.

OPERATING ON AUTOMATIC START UP TIMER MODE

The AA-RS20CS has the ability to automatically start the vehicle every 2 or 4 hours over

a 48 hour period. This feature is especially useful in cold climates where the only means

to keep the engine and engine fluids warm is to periodically start the engine.

WARNING! Be certain that the vehicle is outdoors before using this or any remote vehicle

startingdevice. A runningengineproducesdangerouscarbonmonoxidefumes

which can be harmful or fatal if prolonged exposure occurs. DO NOT remote

start the vehicle if the car is garaged.

TO BEGIN THE AUTOMATIC START UP TIMER

1. Turn the ignition key on then off.

2. Within 10 seconds, activate the RF start command two times. (Push the transmitter

button with the KEY icon on it 4 times).

The parking lights will flash and the siren will chirp 4 times indicating the timed start mode

is activated.

The vehicle, on a 2 or 4 hour interval basis, will automatically start, run for the pre-

programmed time (10 of 15 minutes), and then shut off. This will continue for 48 hours.

NOTE: The automatic start up timer can also be initiated from the keychain transmitter.

To do this:

1. Start the vehicle using the keychain transmitter by pressing and releasing transmitter

button 2 two times.

2. Shut off the vehicle using the keychain transmitter by pressing and releasing transmitter

button 2 two times.

3. Within 10 seconds of step 2, activate the RF start command two times. (Push button 2

four times).

The parking lights will flash and the siren will chirp 4 times indicating the timed start mode

is activated.

Page 7

CANCELING THE AUTOMATIC START UP TIMER

To cancel the automatic start up timer do one of the following;

1. Start the vehicle manually with the use of the ignition key and depress the brake pedal.

2. Remote start the vehicle using your keychain RF transmitter.

ADDITIONAL REMOTE FUNCTION CHANNEL 2

Thesystemhasanadditionalfeature,(Channel2),thatcanbeconnectedtoanumberof

different optional accessories. Some of the more common uses for this channel are:

qRemote Trunk Release

qRemote Window Close

qRemote Garage Door Interface

To operate the accessory associated with channel 2, press and hold transmitter button 2

for four seconds.

NOTE: The feature that has been added to channel 2 will always be operated using the

same transmitter button that controls the remote start unit. There is no way to

move the channel 2 function to a different channel.

ADDITIONAL REMOTE FUNCTION CHANNEL 3

Thesystemhasanadditionalfeature,(Channel3),thatcanbeconnectedtoanumberof

different optional accessories. Some of the more common uses for this channel are:

qRemote Trunk Release

qRemote Window Close

qRemote Garage Door Interface

To operate the accessory associated with channel 3, press and release transmitter

button 3.

Note: The channel 3 output will remain active for as long as the transmitter button(s) are

held. Certain accessories may take advantage of the extended output capability of this

channel. Check with your installation center for operation of the accessory that may be

connected to channel 3.

FEATURE AND FUNCTION SETTINGS

To Be Completed by Installing Technician

ALARM DASH LED INDICATORS

RAPID FLASHING = PASSIVE ARMING

SLOW FLASHING = ARMED

OFF = DISARMED

ON SOLID = VALET MODE

3 FLASH... PAUSE = INTRUSION ZONE 3

2 FLASH...PAUSE = INTRUSION ZONE 2

1 FLASH...PAUSE = INTRUSION ZONE 1

ALARM SIREN CHIRP INDICATION

1 CHIRP* = ARM

2 CHIRPS* = DISARMED

3 CHIRPS = ARMING WITH ENTRY POINT OPENED

4 CHIRPS = DISARM AFTER INTRUSION

5 CONTINUOUS = TRIGGERED/PANIC

ALARM PARKING LAMP INDICATIONS

1 FLASH = ARM

2 FLASH = DISARM

3 FLASH = DISARM AFTER INTRUSION

CONTINUOUS FLASH = TRIGGERED/PANIC

REMOTE START SIREN INDICATIONS

1 LONG/1SHORT = RF START COMMAND ISSUED (IF

SELECTED ON)

REMOTE START PARKING LAMP INDICATIONS

1 FLASH = RF START COMMAND ISSUED

ON = RUNNING UNDER REMOTE START

CONTROL (IF SELECTED)

CONTINUOUS FLASH = RUNNING UNDER REMOTE START

CONTROL (IF SELECTED)

AA-RS20CS

SYSTEM FUNCTIONS AT A GLANCE

Otros manuales para AA-RS20CS

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Alarma de coche de Audiovox

Audiovox

Audiovox Professional PS-330i Manual de usuario

Audiovox

Audiovox Car Security System APS-610 Manual de usuario

Audiovox

Audiovox APA-800a Manual de usuario

Audiovox

Audiovox Keyless Entry Alarm Upgrade Module APS-30 Manual de usuario

Audiovox

Audiovox APS-800 Manual de usuario

Audiovox

Audiovox Pursuit PRO 9842 Manual de usuario

Audiovox

Audiovox Pursuit PRO-9342WOS2 Manual de usuario

Audiovox

Audiovox Prestige 128-8146 Manual de usuario

Audiovox

Audiovox APS255A - Car 2 Prestige Platinum Code Learning 3 Button Security... Manual de usuario

Audiovox

Audiovox Car Security System AX-900 Manual de usuario

Audiovox

Audiovox APS25CH - Car Prestige 2 Button Remote Security... Manual de usuario

Audiovox

Audiovox Car Security System AX-900 Manual de usuario

Audiovox

Audiovox Prestige Platinum+ APS-25N Manual de usuario

Audiovox

Audiovox Prestige Platinum APS 995 Manual de usuario

Audiovox

Audiovox ca 6552 Manual de usuario

Audiovox

Audiovox Prestige Platinum 128-8537 Manual de usuario

Audiovox

Audiovox Pursuit PRO-9642 Manual de usuario

Audiovox

Audiovox Pursuit Pro 9544FT3 Manual de usuario

Audiovox

Audiovox PRO9342FT3 Manual de usuario

Audiovox

Audiovox APD-510 Manual de usuario

Audiovox

Audiovox Prestige Platinum APS-255 Manual de usuario

Audiovox

Audiovox Pursuit PRO-9675FT4 Manual de usuario

Audiovox

Audiovox Pursuit PRO-900 Manual de usuario

Audiovox

Audiovox Prestige Platinum APS-350-A Manual de usuario

Manuales populares de Alarma de coche de otras marcas

Clifford

Clifford 3606X Manual de usuario

Ultra Start

Ultra Start 2500M SERIES Manual de usuario

Ultra Start

Ultra Start 650 Series Manual de usuario

Sparkrite

Sparkrite SRA8 Manual de usuario

Viper

Viper 4708V Manual de usuario

Federal Signal Corporation

Federal Signal Corporation Pathfinder Siren Series Manual

Falcon

Falcon Predator XL3 Guía del usuario

Clifford

Clifford Sabre II Manual de usuario

CrimeStopper

CrimeStopper CS-8717 Guía de inicio rápido

Ultra Start

Ultra Start 450 SERIES Manual de usuario

Scytek electronic

Scytek electronic Vectra X3 Manual de usuario

Excalibur

Excalibur AL-1860-EDPB Manual de usuario

Clifford

Clifford CYBER 2 Manual de usuario

Gemini

Gemini 7057 Manual de usuario

FlashLogic

FlashLogic FLRSBA PRESTIGE Manual de usuario

Magicar

Magicar FAI-440 Manual de usuario

Clifford

Clifford Nova 3 Manual de usuario

Viper

Viper 560XV Manual de usuario
