AUDIOLINE PHONE EASY Manual de usuario

PHONE EASY

Telephone

User guide

VOL

M2 M3

1 2 3

456

7 8 9

STORE/MUTE MEMORY RECALL REDIAL

LOCATION OF CONTROLS

1Handset hanger hook 6Recall button

2Memory card 7Last number redial

3Direct memories M1, M2, M3 8Ring indicator

4Store/mute button and indicator 9Keypad 0-9, *, #

5Memory button (Indirect) 10 Volume controls

CONNECTING

#Connect the line cord to the telephone and to the telephone socket.

#Lift the handset and check for a dial tone.

WALL MOUNTING

Check for hidden cables, water pipes, etc., before drilling holes. Check that the

intended mounting point is within reach of a telephone socket.

#Mark the position of the two holes 83 mm apart, one above the other.

#Drill the holes.

#Fit the screws (not supplied) to the wall, leaving 5 mm protruding (use wall plugs if

necessary, not supplied).

#Place the telephone in position and locate the two holes on the base of the

telephone over the screws, then slide into place.

Note: When the phone is wall mounted the hanger hook (with serrated top) located on

the base directly below the circular earpiece resting point, must be removed, rotated

180 degrees (so that the lip protrudes) and replaced.

TO MAKE A CALL

PLift the handset and wait for dial tone.

PDial the phone number.

PReplace the handset to terminate the call.

LAST NUMBER REDIAL

To redial the number called, lift the handset and press the REDIAL button. The

number will be dialled automatically.

The number will be retained in memory until another number is dialled.

The Last Number Redial button will not operate if the number dialled was from

memory.

MUTE

To speak privately to a third party while on a call, press the MUTE button (the small

red light will flash). When you wish to resume your telephone conversation, press the

MUTE button again.

DIRECT MEMORY (M1-M3)

The telephone has 3 direct dial memories. When a phone number is stored into these

memories you need to press the M1 - M3 buttons only to make the call.

STORING DIRECT MEMORIES

PLift the handset and press STORE button (ignore any sound in the earpiece).

PSelect the desired direct memory button M1 - M3 by pressing the corresponding

button.

PDial the phone number (max 21 digits).

PReplace the handset. The number is now stored.

DIALLING DIRECT MEMORIES

PLift the handset and wait for a dial tone.

PSelect the desired direct memory M1-M3 by pressing on the corresponding

button. The telephone will automatically dial the stored number.

INDIRECT MEMORY (keypad 0-9)

The telephone has 10 indirect memories. When a phone number is stored in a memory

you need to press two buttons only to make the call.

STORE INDIRECT MEMORY

PLift the handset and press STORE (ignore any sound through the earpiece).

PPress MEMORY button.

PSelect the desired indirect memory (0-9) by pressing on the corresponding button.

PDial the phone number (max 21 digits).

PPress STORE button again.

PReplace the handset. The number is now stored.

DIALLING INDIRECT MEMORIES

PLift the handset and wait for a dial tone.

PPress MEMORY button.

PSelect the desired indirect memory (0-9) by pressing on the corresponding button.

The telephone will automatically dial the stored number.

VOLUME CONTROL

The volume level in the earpiece can be increased or decreased using the

volume buttons on the base unit during a call.

ADJUSTABLE RINGER

There are three different ringing tones available and three different volume settings for

each ringer

PLift the handset and press the STORE button .

PPress #.

PSelect a ring signal by pressing0-9 according to the table below.

PPress the STORE button again.

PReplace the handset. The ringer type is now selected.

Keypad digit Ringer type Setting

1Melody A Low

2Melody A Normal

3Melody A High

4Melody B Low

5Melody B Normal

6 (factory setting) Melody B High

7Melody C Low

8Melody C Normal

9Melody C High

Off *(see below)

*If setting 0 is selected, the ringer type will be turned off until the handset is lifted

again. After that, the ringer type reverts to the previous setting.

ADDITIONAL NETWORK SERVICES

Optional Network services such as call waiting, reminder calls, charge advice, etc., can

be accessed via the RECALL, #and *buttons. For further information, contact your

Network Operator.

HEARING AID COMPATIBLE

The phone is hearing aid compatible. When used with a suitable hearing aid set to the

T mode.

FAULT FINDING

In the unlikely event of a fault occurring, proceed as follows:

#Check that telephone is plugged into telephone socket.

#Check telephone operation in master telephone socket. There may be a fault with

the line in which case contact your Network Operator.

#Check that total of REN numbers does not exceed 4 (the PHONE EASY has a

REN of 1.)

#If the telephone does not ring, lift and replace the handset (the ringer may be

programmed off).

Technical Support: If you cannot resolve the fault using the fault finder section,

please call the Technical Helpline on: 0906 302 0114 between 9AM - 5PM Monday-

Friday. Please note that this is a Premium Line number and all calls are charged

at 50 pence per minute. Price correct at the time of going to press.

Alternatively, you can write to: Technical Support Group, Doro-Audioline Ltd., 22

Walkers Road, North Moons Moat, Redditch, Worcestershire, B98 9HE.

GUARANTEE

The AUDIOLINE PHONE EASY is guaranteed for a period of 12 months from the

date of purchase. In the unlikely event of a fault during this period, please return it with

a copy of the purchase receipt to your place of purchase.

The guarantee does not extend to damage caused by misuse, negligence, excessive

voltage, faults on the telephone line or lightning.

This guarantee in no way affects your statutory rights.

DECLARATION OF CONFORMITY

WE DORO AB

Of SKIFFERVÄGEN 80

SE-224 78 LUND

SWEDEN

AS THE EU/EES/EC/EEA AUTHORISED REPRESENTATIVE DECLARE

UNDER OUR SOLE RESPONSIBILITY THAT THE PRODUCT

MODEL: AUDIOLINE PHONE EASY

DESCRIPTION: ANALOGUE TELEPHONE

IS IN CONFORMITY WITH DIRECTIVE: 1999/5/EC

Authorised by:

Signed________________________________

Name (printed): PETER CULLIN

Position in company: R&D MANAGER

Date of issue:2000-05-02

Copies of this document will be held on file for a period of 10 years after the last production.

Supplier: DORO AB, Skiffervägen 80, SE-224 78 LUND, SWEDEN

Product: AUDIOLINE PHONE EASY

This product is intended for connection to analogue PSTN lines within the

following countries: Sweden, Norway, Denmark, Finland, United Kingdom,

Switzerland, France and Iceland.

However, due to differences between the individual PSTN’s provided in the

different countries, the approval does not, of itself, give an unconditional

assurance of successful operation on every PSTN network termination point.

ADDITIONAL INFORMATION

The register recall function will work in countries listed above, except France.

Tone-dialling only.
