Introduction

Universal wall speaker

The WXMK2 loudspeaker series is designed to be a universal performance speaker,

ensuring true-to-nature, high fidelity reproduction of music and speech in every

environement , ranging from modern residential applications to the most demanding

designer applications in environements such as retail stores, pubs, restaurants and

even clubs.

It features a stunningly designed and elegant looking ABS housing which is fitted with

high quality components. The speaker is available in three sizes, 3”, 5 1/4” and 8”. All

speakers are available in black and white, making them blend into every environement,

going from standard indoor home to special indoor design interiors. The included

mounting bracket allows horizontal and vertical mounting as well as focusing of the

speaker, and an integrated advanced protection network protects the tweeter against

overload.

Precautions

READ FOLLOWING INSTRUCTIONS FOR YOUR OWN SAFETY

• ALWAYS KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. NEVER THROW THEM

AWAY

• ALWAYS HANDLE THIS UNIT WITH CARE

• CLEAN ONLY WITH DRY CLOTH

• HEED ALL WARNINGS AND FOLLOW ALL INSTRUCTIONS

• NEVER EXPOSE THIS EQUIPMENT TO RAIN, MOISTURE, ANY DRIPPING OR SPLASHING

LIQUID. AND NEVER PLACE AN OBJECT FILLED WITH LIQUID ON TOP OF THIS DEVICE

• DO NOT INSTALL THIS UNIT NEAR ANY HEAT SOURCES SUCH AS RADIATORS OR

OTHER APPARATUS THAT PRODUCE HEAT

• DO NOT PLACE THIS UNIT IN ENVIRONMENTS WITH A HIGH LEVEL OF DUST, HEAT,

MOISTURE OR VIBRATION

• THIS UNIT IS DEVELOPED FOR INDOOR USE ONLY. DO NOT USE IT OUTDOORS

• ONLY USE ATTACHMENTS & ACCESSORIES SPECIFIED BY THE MANUFACTURER.

• ONLY INSTALL THE SPEAKER IN LOCATIONS THAT CAN STRUCTURALLY SUPPORT THE

WEIGHT OF THE SPEAKER. IGNORING THIS CAN BRING THE SPEAKER DOWN.

• DO NOT USE ANY OTHER METHOD THAN SPECIFIED TO MOUNT THE SPEAKER. IF

EXTREME FORCE IS APPLIED TO THE SPEAKER, IT COULD FALL DOWN

• ATTACH A SAFETY WIRE TO THE SPEAKER WHEN IT IS MOUNTED HIGH UP.

ONLY USE INDUSTRY-ACCEPTED RIGGING TOOLS AND METHODS

• CAREFULLY CHECK THE UNIT’S CONDITION AFTER UNPACKING.

IF THERE IS ANY DAMAGE TO THE CARTON BOX OR THE UNIT ITSELF, INFORM YOUR

VENDOR IMMEDIATELY.

• ALWAYS FOLLOW THE LOCAL REGULATIONS AND REQUIREMENTS REGARDING

INSTALLATION, SUSPENSION AND CONNECTION OF THIS LOUDSPEAKER. EVEN WHEN

OTHERWISE SPECIFIED IN THIS DOCUMENT.

• THE INSTALLATION OF THIS LOUDSPEAKER SHALL BE DONE BY QUALIFIED

PERSONNEL ONLY.

CAUTION

• USE CABLES OF THE RIGHT GAUGE TO CONNECT THE LOUDSPEAKER

• USE CABLES WITH CLEAR COLOUR CODING INDICATING THE POLARITY AND

MAINTAIN THE SAME POLARITY THROUGHOUT THE WHOLE SYSTEM.

• ONLY USE THE CORRECT AMPLIFIER OUTPUT VOLTAGE AND IMPEDANCE.

EXCEEDING THESE LIMITS COULD CAUSE FIRE OR OTHER FAILURES.

AVOID EXPLOSIONS: DO NOT USE THE SPEAKER AROUND GASOLINE,

THINNER OR OTHER COMBUSTIBLES

• AVOID ELECTRIC SHOCKS: SWITCH OFF THE AMPLIFIER WHEN CONNECTING

THE LOUDSPEAKER

• DO NOT USE THE LOUDSPEAKER FOR AN EXTENDED PERIOD OF TIME AT

DISTORTED SOUND. THIS COULD CAUSE PERMANENT DAMAGE.

CAUTION - SERVICING

This product contains no user serviceable parts. Refer all servicing

to qualified service personnel. Do not perform any servicing

(unless you are qualified to do so.)

EC DECLARATION OF CONFORMITY

This product conforms to all the essential requirements and further

relevant specifications described in following directives: 2014/30/

EU (EMC) and 2014/35/EU (LVD)

WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE)

The WEEE marking indicates that this product should not be

disposed with regular houshold waste at the end of its product

life. This regulation is created to protect both the environment

and human health.

This product is developed and manufactured with high quality

materials and components which can be recycled and/or reused.

Please dispose this product to your local collection point or

recycling centre for electrical and electronic waste. This will

make to sure that it will be recycled on an environmentally friendly

manner, and will help to protect the environment in which we all

live.

Installing the WXMK2

Step 1: Mount the loudspeaker

The loudspeaker can be mounted both horizontally and vertically by means of the sup-

plied mounting bracket. For mounting the loudspeaker on the desired mounting location,

the mounting bracket should be removed from the loudspeaker. This can be done by

loosening the thumbscrews on either side of the loudspeaker. After this is done, the

mounting holes should be indicated.

For a stable mounting of the loudspeaker it should always be fastened by two screws.

The position of the mounting holes depends on the mounting orientation, horizontally

or vertically. After this, the bracket can be mounted on the desired location. Always use

the proper fasteners depending of the mounting surface. Once the bracket is mounted

on the desired location, the loudspeaker can be fixed to the bracket.

Ø4,5

Ø10,3

A B

WX302MK2 174 mm 108 mm

WX502MK2 219 mm 160,4 mm

WX802MK2 280,5 mm 248 mm

Step 2: Power settings

On the rear side of the WXMK2 series loudspeakers, a recessed adjuster screw is

provided. Using this adjuster screw the power / impedance of the loudspeaker can be

set in 3 adjustable steps of impedance for 100V and 1 step for standard low imped-

ance applications.

WX302MK2 WX502MK2 WX802MK2

1 20W (500 Ohm) 40W (250 Ohm) 60W (167 Ohm)

2 10W (1000 Ohm) 20W (500 Ohm) 30W (333 Ohm)

3 5W (2000 Ohm) 10W (1000 Ohm) 15W (667 Ohm)

4 8 Ohm 8 Ohm 16 Ohm

When the loudspeaker is connected to 70.7V facilities, the power indicated in the table

above will be reduced to half the power, and when connected to 50V facilities, the power

will be reduced to a quarter.

WX502 MK2

50 Watt RMS / 100 Watt Max

Impedance: 8 Ω

Line transformer power taps (100V) :

40 Watt / 250 Ω

20 Watt / 500 Ω

10 Watt / 1000 Ω

−

−+ +

Step 3: Make the connections

A terminal block connector with linkthrough possibility is provided on the back of the

loudspeaker. The connection can be made by loosening the connection screws of the

terminals, inserting the wires according to the polarity as shown below. After tighten-

ing the screws, the connector can be insterted into its counterpart on the back of the

speaker.

Mind the polarity markings when wiring the loudspeaker cables.

Step 4: Enjoy the music

After the WX loudspeakers have been installed correctly, you deserve to have a short

break, relax and enjoy the sound of the speakers!

Additional information

WX302 WX502 WX802

RMS Power 30 W 50 W 70 W

Nominal Impedance 8 Ohm 8 Ohm 16 Ohm

Line transformer

power tappings

500 Ohm / 20 W

1000 Ohm / 10 W

2000 Ohm / 5 W

250 Ohm / 40 W

500 Ohm / 20 W

1000 Ohm / 10 W

167 Ohm / 60 W

333 Ohm / 30 W

667 Ohm / 15 W

Sound pressure level

1W / 1m

85 dB 87 dB 89 dB

Sound pressure max

W / 1 m @ 8 Ohm

100 dB 104 dB 108 dB

Sound pressure max

W / 1 m @ 100V

95 dB 102 dB 106 dB

Frequency response

-3 dB

90 Hz - 18 kHz 90 Hz - 18 kHz 60 Hz - 18 kHz

Frequency response

-10 dB

60 Hz - 20 kHz 70 Hz - 20 kHz 50 Hz - 20 kHz

Cross-over frequency 2500 Hz 2500 Hz 2400 Hz

Horizontal coverage 110° 110° 110°

Vertical coverage 110° 110° 110°

Drivers 1” HF + 3” LF 1” HF + 5 1/4” LF 1” HF + 8” LF

Connector 4-Pin terminal Block 4-Pin terminal Block 4-Pin terminal Block

Mounting Bracket Powder coated steel Powder coated steel Powder coated steel

Front finish Powder coated steel

grill

Powder coated steel

grill

Powder coated steel

grill

Dimensions (W x H x D) 199 x 129 x 120 mm 212 x 147 x 136 mm 270 x 360 x 215 mm

Weight 1,66 Kg 2,52 Kg 7,5 Kg

Construction ABS ABS ABS

Accessories included Wall bracket Wall bracket Wall bracket

Notes
