MTX Commands User Manual

Index

Introduction 2

Inputlist 2

Outputlist 2

Usingthecommands 3

SVx SetMasterVolume 4

SVU0x Set Master Volume Up 3dB 4

SVD0x Set Master Volume Down 3dB 4

SRx SetRouting 4

SRU0x Set Routing Up 5

SRD0x Set Routing Down 5

SB0x SetBass 5

ST0x SetTreble 6

SM0x SetMute 6

GVALL Get Volume info for all zones 6

GRALL Get Routing info for all zones 6

GMALL Get Mute info for all zones 7

GV0x Get Volume info for 1 zone 7

GR0x Get Routing info for 1 zone 7

GM0x Get Mute info for 1 zone 7

GB0x Get Bass info for 1 zone 7

GT0x Get Treble info for 1 zone 8

GZI0x Get Volume, Routing, Mute, Bass, Treble for 1 zone 8

SAVE SAVEsettings 8

DEF Loadfactorysettings 8

GSV Get Software Version 8

Introduction

Welcome to the command user manual of the AUDAC MTX48 and MTX48 . For more info

about the MTX48 and MTX88 see the user manual.

Input list

1 Mic 1

2 Mic 2

3 Line 3

4 Line 4

5 Line 5

6 Line 6

7 WLI/MWX65

8 WMI

Output list

1 Zone 1

2 Zone 2

3 Zone 3

4 Zone 4

5 Zone 5

6 Zone 6

7 Zone 7

8 Zone 8

Using the commands

The MTX has 3 communication ports which all accept the same commands:

- RS232 port

- RS485 ports

- TCP/IP

The RS232/RS485 ports must be configured with 19200 baud, 8 data bits, 1 stop bit, no

parity

The TCP/IP port accepts command’s at port 5001. The MTX accepts maximum 1

simultaneous TCP/IP connection.

Command overview

Example: Set volume zone 1 to -30dB

ASCII #|X001|web|SV1|30|U|return

Important:

- The address of the MTX is fixed at X001.

- The checksum is CRC-16 excluding the ‘#’. You can replace the checksum with

‘U’, this is always accepted as checksum.

- return = 0x0d 0x0a

- source address has a maximum length of 4 characters and cannot contain “|” or

“#”

Command flow

1) The client sends a command to the MTX

2) The MTX acknowledges the command by returning the same command and a ‘+’ as

Argument.

3) The MTX updates all client’s with the new information

All volume, routing and tone settings will be lost if the device is switched off. To keep

the changes you must save them with the “SAVE” command. All device settings that are

configured through the configuration page of the website are saved automatically with

every change.

SVx

Set output volume of a zone to a level

Command: SVx, with x the zone where the volume should be changed.

Arguments: Volume in neg db, 0 is maximum volume, 70 is minimum volume

Example

Set volume in zone 2 to -40dB

Command #|X001|web|SV2|40|U|return

Answer #|web|X001|SV2|+|U|return

Update #|ALL|X001|V02|40|7378|return

SVU0x

Set volume up with 3dB

Command: SVU0x, with x the zone where the volume should be changed.

Arguments: 0 (none)

Example

Current is Volume -30db, set volume up with 3dB in zone 1

Command #|X001|web|SVU01|0|U|return

Answer #|web|X001|SVU01|+|U|return

Update #|ALL|X001|V01|27|U|return

SVD0x

Set volume down with 3dB

Command: SVD0x, with x the zone where the volume should be changed.

Arguments: 0 (none)

Example

Current volume is -27db, set volume down with 3dB in zone 1

Command #|X001|web|SVD01|0|U|return

Answer #|web|X001|SVD01|+|U|return

Update #|ALL|X001|V01|30|U|return

SRx

Set routing in a zone (select input)

Command: SRx, with x the zone where the routing should be changed.

Arguments: input (0-8)

Example

Select Line 3 as input for zone1

Command #|X001|web|SR1|3|U|return

Answer #|web|X001|SR1|+|U|return

Update #|ALL|X001|R01|3|3dc5|return SRU0x

SRU0x

Set Routing up in a zone

Command: SRU0x, with x the zone where the routing should be changed.

Arguments: 0 (none)

Remark

The inputs that are disabled in the input selection menu on the website will be

skipped.

Example

Increase routing for zone 1

Command #|X001|web|SRU01|0|U|return

Answer #|web|X001|SRU01|+|U|return

Update #|ALL|X001|R01|5|U|return

SRD0x

Set Routing down in a zone

Command: SRD0x, with x the zone where the routing should be changed.

Arguments: 0 (none)

Remark

The inputs that are disable in the input selection menu on the website will be

skipped.

Example

Decrease routing in zone 1

Command #|X001|web|SRD01|0|U |return

Answer #|web|X001|SRD01|+|U |return

Update #|ALL|X001|R01|4|U |return

SB0x

Set bass in a zone

Command: SB0x, with x the zone where the bass should be changed.

Arguments: from 0 to 14. (from -14dB to +14dB in 2dB steps with 7 = 0dB)

Example

Set bass to +2dB in zone 1

Command #|X001|web|SB01|8|U|return

Answer #|web|X001|SB01|+|U|return

Update #|ALL|X001|B01|8|9dc0|return

ST0x

Set treble in a zone

Command: ST0x, with x the zone where the treble should be changed.

Arguments: from 0 to 14. (from -14dB to +14dB in 2dB steps with 7 = 0dB)

Example

Set treble to -4dB in zone 1

Command #|X001|web|ST01|5|U|return

Answer #|web|X001|ST01|+|U|return

Update #|ALL|X001|T01|5|fbc6|return

SM0x

Set mute state in a zone

Command: SM0x, with x the zone where the mute should be changed.

Arguments: 0 (disable) or 1 (output muted)

Example

Enable mute in zone 1

Command #|X001|web|SM01|1|U|return

Answer #|web|X001|SM01|+|U|return

Update #|ALL|X001|M01|1|32c6|return

GVALL

Get volume info for all zones

Command: GVALL

Arguments: 0 (none)

Example

Command #|X001|web|GVALL|0|U|return

Answer #|web|X001|VALL|40^40^20^20^20^20^20^20|U|return

GRALL

Get Routing info for all zones

Command: GRALL

Arguments: 0 (none)

Example

Command #|X001|web|GVALL|0|U|return

Answer #|web|X001| RALL|3^1^1^1^1^1^1^1|U|return

GMALL

Get Mute info for all zones

Command: GMALL

Arguments: 0 (none)

Example

Command #|X001|web|GMALL|0|U|return

Answer #|web|X001| MALL|0^0^0^0^0^0^0^0|U|return

GV0x

Get Volume info for a zone

Command: GV0x, with x the number of the zone

Arguments: 0 (none)

Example

Get routing info for zone 1

Command #|X001|web| GV01|0|U|return

Answer #|web|X001| V01|20|U|return

GR0x

Get Routing info for a zone

Command: GR0x, with x the number of the zone

Arguments: 0 (none)

Example

Get routing info for zone 1

Command #|X001|web| GR01|0|U|return

Answer #|web|X001| R01|3|U|return

GM0x

Get Mute info for a zone

Command: GM0x, with x the number of the zone

Arguments: 0 (none)

Example

Get routing info for zone 1

Command #|X001|web| GM01|0|U|return

Answer #|web|X001| M01|0|U|return

GB0x

Get bass info for a zone

Command: GB0x, with x the number of the zone

Arguments: 0 (none)

Example

Get bass info for zone 1

Command #|X001|web| GB01|0|U|return

Answer #|web|X001| B01|07|U|return

GT0x

Get Treble info for a zone

Command: GT0x, with x the number of the zone

Arguments: 0 (none)

Example

Get treble info for zone 1

Command #|X001|web| GT01|0|U|return

Answer #|web|X001| T01|07|U|return

GZI0x

Get volume, routing, mute, bass, treble info for 1 zone

Command: GZI0x, with x the number of the zone

Arguments: 0 (none)

Example

Get info for zone 1

Command #|X001|web| GZI01|0|U|return

Answer #|web|X001| ZI01|20^3^0^07^07|U|return

SAVE

Save’s the current zone settings (routing, volume, bass, treble)

Command: SAVE

Arguments: 0 (none)

Example

Command #|X001|web|SAVE|0|U|return

Answer #|web|X001|SAVE|+|U|return

DEF

All zone settings and device settings will be reset to factory default.

Command: DEF

Arguments: 0 (none)

Example

Command #|X001|web|DEF|0|U|return

Answer #|web|X001|DEF|+|U|return

GSV

Get the firmware version

Command: GSV

Arguments: 0 (none)

Example

Command #|X001|web|GSV|0|U|return

Answer #|web|X001|SV|V1.1|U|return
