INSTRUCTION MANUAL
Please read this manual thoroughly before use and keep it handy for future reference.
22X PTZ III DOME CAMERA
II
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECTS THROUGH THE VENTILATION GRILLS OR
OTHER OPENINGS ON THE EQUIPMENT.
EXPLANATION OF GRAPHICAL SYMBOLS
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to
alert the user to the presence of uninsulated "dangerous voltage" within the product's
enclosure that may be of sufficient magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instruction in the literature
WARNIN
G
CAUTION
accompanying the product.
III
FCC COMPLIANCE STATEMENT
CE COMPLIANCE STATEMENT
FCC INFORMATION: THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO
COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO
PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE
REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE WHEN
THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT. THIS
EQUIPMENT GENERATES, USES, AND CAN RADIATE RADIO FREQUENCY
ENERGY AND IF NOT INSTALLED AND USED IN ACCORDANCE WITH THE
INSTRUCTION MANUAL, MAY CAUSE HARMFUL INTERFERENCE TO RADIO
COMMUNICATIONS. OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL
AREA IS LIKELY TO CAUSE HARMFUL INTERFERENCE IN WHICH CASE THE
USER WILL BE REQUIRED TO CORRECT THE INTERFERENCE AT HIS OWN
EXPENSE.
CAUTION: CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY
THE PARTY RESPONSIBLE FOR COMPLIANCE COULD VOID THE USER'S
AUTHORITY TO OPERATE THE EQUIPMENT.
THIS CLASS A DIGITAL APPARATUS COMPLIES WITH CANADIAN ICES-003.
CET APPAREIL NUMÉRIQUE DE LA CLASSE A EST CONFORME À LA NORME
NMB-003 DU CANADA.
WARNING
THIS IS A CLASS A PRODUCT. IN A DOMESTIC ENVIRONMENT THIS
PRODUCT MAY CAUSE RADIO INTERFERENCE IN WHICH CASE THE USER
MAY BE REQUIRED TO TAKE ADEQUATE MEASURES.
IV
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized
plug has two blades with one wider than the other. A grounding type plug has two blades
and a third grounding prong. The wide blade or the third prong are provided for your
safety. If the provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by
the manufacturer, or sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus combination to avoid
injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for
long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is damaged,
liquid has been moisture, does not operate normally, or has been dropped.
15. CAUTION – THESE SERVICING INSTRUCTIONS ARE FOR USE BY QUALIFIED
SERVICE PERSONNEL ONLY. TO REDUCE THE RISK OF ELECTRIC SHOCK DO
NOT PERFORM ANY SERVICING OTHER THAN THAT CONTAINED IN THE
OPERATING INSTRUCTIONS UNLESS YOU QRE QUALIFIED TO DO SO.
16. Use Certified/Listed Class 2 power source only.
17. Apparatus shall not be exposed to dripping or splashing and no object filled with liquids,
such as vases, shall be placed on the apparatus.
V
Table of Contents
Chapter 1 — Introduction ..........................................................................................................1
1.1 Features .............................................................................................................................................1
Chapter 2 — Installation and Configuration.........................................................................2
2.1 Package Contents............................................................................................................................2
2.2 Installation.........................................................................................................................................3
2.3 Basic Configuration of Dome Camera System........................................................................4
2.4 Setting Dome Camera Termination.............................................................................................5
2.5 Setting Dome Camera Address (ID)............................................................................................5
2.6 Setting Dome Camera Protocol and Video.............................................................................12
2.7 Connections....................................................................................................................................12
2.8 Getting Started ...............................................................................................................................13
Chapter 3 — Program and Operation...................................................................................14
3.1 Dome Camera Selection ..............................................................................................................14
3.2 Accessing the On-Screen Menu Utility....................................................................................14
3.3 How to control the On-Screen Menu Utility............................................................................15
3.4 Auto Scan (Shortcut: SCAN) .....................................................................................................15
3.5 Preset (Shortcut: PRST) .............................................................................................................17
3.6 Shortcut of Preset Program........................................................................................................19
3.7 Tour (Shortcut: TOUR).................................................................................................................19
3.8 Pattern (Shortcut: PTRN).............................................................................................................21
3.9 Alarm.................................................................................................................................................22
3.10 Area Title........................................................................................................................................22
3.11 Privacy Zone.................................................................................................................................23
3.12 Camera Menu................................................................................................................................24
3.13 Dome Setup ..................................................................................................................................27
3.14 Function Run................................................................................................................................33
3.15 Factory Setup...............................................................................................................................34
Appendix A — Specifications.................................................................................................35
Appendix B — Troubleshooting ............................................................................................37
Appendix C — Glossary...........................................................................................................37
Appendix D — Short Cut Key .................................................................................................40
Appendix E — Wall Mount.......................................................................................................41
Appendix F — Ceiling Mount..................................................................................................42
1
Chapter 1 — Introduction
1.1 Features
The dome camera and the keyboard controller make up the building blocks for any
surveillance/security system. Using multiple keyboard controllers and multiple dome cameras, no
place is too large for monitoring. Extensible and flexible architecture facilitates remote control
functions for a variety of external switching devices such as multiplexers and DVRs.
•Built-in optical power zoom camera with True Night Shot function.
•120 Preset positions with the individual Camera AE setup.
•4 Tours consist of Presets, Patterns, Auto Scans and other Tours can be programmed with
over 150 functions and Preset locations. While moving, each Preset scan can be watched in
smooth Vector Scan mode.
•4 Auto Scans with the normal, the vector, and the random mode and the Endless Auto-Pan
with 13 speed steps.
•4 Patterns (up to 200 second) and 4 Privacy Zones.
•8 Area Titles.
•1 Alarm input / 1 Alarm output (TTL ON/OFF)
•Variable speed from 0.1°/sec to 380°/sec.
Three Variable speed (SLOW, NORMAL, TURBO).
Turbo speed is 380°/sec with Ctrl key pressed.
•Pan / Tilt speed is inversely proportional to the zoom ratio with the option.
•Maximum speed is 380°/sec when Preset command.
•Auto Calibration from 0.1°to 6°(Tilt range is 0°to 180°).
•Programmable user preferences (alarm, preset, title, etc.).
•180°Digital Flip.
•Up to 255 selectable camera addresses.
•Multi-language Menu Display, Password Confirmation.
•Function Run menu using DVR without function key (Pattern, Scan,..)
•Built-in RS-485 receiver driver.
•AC 24V or DC 12V for Dome.
•AC 24V for Heater & Fan.
•Use Certified/Listed Class 2 power source only.
2
Chapter 2 — Installation and Configuration
2.1 Package Contents
The dome camera is design to a compact, small size, hard dome camera housing.
The housing is constructed of aluminum, steel and plastic. The housing is designed to be
mounted both wall and ceiling type.
The housing meets the Protection Classification IP66 standards for dust and moisture resistance.
* Dome Camera ................................................................1
* Instruction Manual (This Document) ...........................1
* Accessory kit & connector............................................1
1) Torx wrench .......................................(1)
2) 2Pin Terminal Block ...........................(1)
3) 3Pin Terminal Block ...........................(2)
4) 4Pin Terminal Block ...........................(1)
3
2.2 Installation
You need one optional mount kit of the wall mount and the ceiling mount to install.
The wall or ceiling mount must be attached to a structural object such as hard wood, concrete
that will support the weight of the mount and dome camera.
The use of a solid backboard is recommended when attaching to gypsum walls.
1. Remove the Protection pad and the tape from attached the dome camera.
2. Attach the mounting base to wall using the supplied M8 tapping screw and plastic
bushing. (Ceiling using the supplied M6 tapping screw and bushing)
3. Wind the both thread of the pipe end with Teflon tape about 20times for sealing.
Then use a silicone rubber sealant to seal the area where the wall (ceiling) mount
and the pipe meet.
4. Place a bead of silicone sealant around the wall and ceiling mount mounting flange,
press it to the surface and line up the flange hole with drilled holes.
5. Refer to the Appendix E and F.
CAUTION : A silicone rubber sealant must be applied to seal the housing to secure
waterproofing
4
2.3 Basic Configuration of Dome Camera System
Figure 1 – Basic Installation Diagram
The dome camera must be installed by qualified service personnel in accordance with all local
and federal electrical and building codes.
5
Figure 2 – Layout of DIP Switches
NOTE: Open the switch cover (position “a”) and change the setting of DIP switches.
The cover should be closed after setting DIP switches.
2.4 Setting Dome Camera Termination
The device which is connected at end of line, whether it is a dome camera or keyboard controller,
must have the cable for communication terminated by setting the appropriate DIP switch.
Without proper termination, there is potential for control signal errors. Total length of the cable for
communication should not exceed 4000ft (1.2km).
S3
Figure 3 – Setting Dome Camera Termination
2.5 Setting Dome Camera Address (ID)
To prevent damage, each dome camera must have a unique address (ID).
When installing multiple dome cameras using a multiplexer, it is suggested that the dome camera
address match the multiplexer port number.
The factory default setting is 1.
Refer to Figure 4.1 ~ 4.6 for setting the dome camera address (ID).
S3 D1
Terminated ON
Not terminated OFF
Tabla de contenidos
Otros manuales de Cámara de seguridad de ATV
ATV
ATV HDV2212MB Manual de usuario
ATV
ATV NVW2212M Manual de usuario
ATV
ATV 22X MINITRAX III Manual de usuario
ATV
ATV IPSDMV22D1 Manual de usuario
ATV
ATV BHR212MR Manual de usuario
ATV
ATV NFE5360 Manual de usuario
ATV
ATV NVW4212M Manual de usuario
ATV
ATV NBW4212M Manual de usuario
ATV
ATV IPFD2TI Manual de usuario
ATV
ATV LD72BI Manual de usuario
ATV
ATV CZ6T2812UWC Manual de usuario
ATV
ATV IPB2TWI Manual de usuario
ATV
ATV NV237 Manual de usuario
ATV
ATV CZ7T2812UWCI Manual de usuario
ATV
ATV IPC560TDN Manual de usuario
ATV
ATV IPSDMV122 Manual de usuario
ATV
ATV NVW4K311M Manual de usuario
ATV
ATV NBW436 Manual de usuario
ATV
ATV IPSD202MT Manual de usuario
ATV
ATV IPVD3RWI Manual de usuario
