ATV FD540VA Manual de usuario
540TV Lines
SUPER HIGH RESOLUTION
COLOR CAMERA
INSTRUCTION MANUAL
SUPER HIGH RESOLUTION
COLOR CAMERA
ATV
FD540VA
LIMITATION OF LIABILITY
ISSUE 4 - JANUARY 2008
THE INFORMATION IN THIS PUBLICATION IS BELIEVED TO BE ACCURATE IN ALL
RESPECTS, HOWEVER, WE CANNOT ASSUME RESPONSIBILITY FOR ANY
CONSEQUENCES RESULTING FROM THE USE THEREOF. THE INFORMATION
CONTAINED HEREIN IS SUBJECT TO CHANGE WITHOUT NOTICE. REVISIONS OR
NEW EDITIONS TO THIS PUBLICATION MAY BE ISSUED TO INCORPORATE SUCH
CHANGES.
I 1 I
THREE AXIS DOME CAMERA
1/3" Color CCD Image Sensor : Provides high quality imaging.
Super high resolution(540TV Lines)
Allows a large area to be monitored from a single camera.
EI, FF(Flicker Free), BLC, AGC, SYNC adjustment.(DC12V/AC24V model)
Electronic Iris :
Automatically adjusts the camera for changes in lighting to ensure an optimal
picture at all times.[1/60(1/50) ~ 1/100,000]
Camera Mount : Camera mounts directly to the wall or ceiling.
FEATURES
CAMERA CONNECTIONS
1
2
3
4
Lens : 3.6mm / 4-9mm Vari-focal lens for wide area monitoring.
Power input : Use certified / Listed class 2 power supply only.
Video output : BNC video output connects to monitor or accessory equipment.
When a Camera's Video output is connected(BNC or RJ12) and the service
jack cable is used (J3) with a spot monitor, the spot monitor's video input must
be set to high impedance.
REMINDER:
Never aim the camera directly into the sun.
123
DC12V/AC24V model
I 2 I
THREE AXIS DOME CAMERA
D. Service jack cable with BNC connector
BASE INSTALLATION
Housing Ass'y
Liner
Bubble
Fig. 1
Tapping screw
M2.6 x 5.0
Fig. 3
Torx screws
M6 x 3.5 (3x) Wall / Ceiling
Plastic Anchors (3x)
Rubber Grommet
Fig. 2
CAUTION : When installing the camera, the following instructions must be
followed closely.
PACKAGE INSIDE
1. Loosen the bubble( ), the liner( ). (Fig. 1)
2. Drill three holes for the plastic anchors( ) using the bottom of the housing ( )
as a template, insert the plastic anchors( ) into the holes, attach the housing( )
to the plastic anchors( ) using the mounting screws( ). (Fig. 2)
3. Rest the liner( ) on a groove of the housing( ). (Fig. 3)
4. Fasten the bubble( ) to the housing( ).
5. Fasten the set screw( ) tightly.
6. Take off the protective nylon.
Note: Plastic anchors is not supplied.
FUNCTION SWITCH continued
LINE LOCK (only HCG-x51AxxA2)
This mode is necessary for the opration of multi cameras because it synchronizes
the camera phase by using the external signal.(AC signal)
Adjust the camera phase control with the volume RV1 (See Figure A) unitil there is
no vertical flip or roll on the monitor white using an auto swcher.
DC12V/AC24V model : HCG-x51AxxA2
1. E/I (on/off)
When set to the ON position, the electronic iris switch automatically varies the
camera's shutter to mimic auto-iris control, allowing fixed or manual iris lenses to
be used in a wider range. When this switch is set to ON, turn the F/F switch OFF.
2. FF (on/off)
This function is used for removing flicker, when camera signal format does not
coincide with power source frequency being used.
3. BLC (on/off)
This on/off switch controls backlight compensation. When set to ON, the camera
will automatically try to maintain proper exposure in the specific area even if the
lighting level changes.
4. AGC (off/on)
The auto gain control switch allows the video signals to maintain a constant level.
This switch is useful when using the camera at low-light levels and when lighting
levels change over time. For best low light conditions, this switch should set to ON.
6. N.C (no function)
5. SYNC (INT/LL)
Use this switch to set the camera synchronization mode internal(ON) or Line-Lock(OFF)
I 3 I
THREE AXIS DOME CAMERA
J3
ON
1 2 3 4
EI AGC
FF
BLC
5
SYNC
6
N.C.
DC AUTO IRIS ADJUSTMENT
DC AUTO IRIS LENS
LENS ADJUSTMENT (OPTIONAL VARIFOCAL LENS)
Field of view : Adjust setting from Telephoto (T)
to wide (W) field of View.
Focus : Adjust lens focus from near
(N) to infinity ( ).
N
TW
Adjust Focus
Adjust Angular Field View
Image Size 1/3" CCD
Focal Length
Aperture Ratio
Angular
Field of View
4-9mm
DIAGONAL
o
4mm : 92.4
o
9mm : 39.2
4.0-9.0mm 5%
1 : 1.6~2.4 5%
I 4 I
THREE AXIS DOME CAMERA
J3
IRIS LEVEL
If you experience difficulties operating your camera, refer to the following. If the
guidelines do not enable you to solve the problem, contact an authorized
technician.
Following the preventive maintenance schedule allows detection and correction
of minor faults before they become serious and cause equipment failure.
Every three months, perform the following:
1. Inspect all connecting cables for deterioration or other damage.
2. Clean components with a clean damp cloth.
3. Verify that all the mounting hardware is secure.
TROUBLESHOOTING
PREVENTIVE MAINTENANCE
PROBLEM CHECK
Nothing appears on
the screen.
Is the cable connected between the
camera and monitor?
Is there power to the monitor?
The image on the screen
is dim.
Is the lens dirty? If so, clean the lens
with a soft, clean cloth.
The contrast on the
screen is too weak.
Adjust the contrast feature of the monitor.
Is the camera exposed to strong light?
If so, change the camera position.
The image on the screen
flickers.
Does the camera face directly into the
sun or fluorescent lighting?
If so, reposition camera.
I 5 I
THREE AXIS DOME CAMERA
Power source
Power consumption
Image sensor
Total pixels
Scanning system
Scanning frequency
Sync. system
Electronic shutter
Resolution
Min. illumination
Video output
Power input
Lens
2:1 interlace
NTSC : 15.734KHz(H), 59.94Hz(V), PAL : 15.625KHz(H), 50Hz(V)
Internal / Line lock
NTSC : 1/60 ~ 1/100,000 sec.
540 TV lines
0.5 Lux @ F1.2, 50 IRE
More than 50dB (AGC OFF)
2-pin wire
8.0 Watts
811(H) x 508(V) : NTSC, 795(H) x 596(V) : PAL
MODEL
S/N ratio
Power
PAL : 1/50 ~ 1/100,000 sec.
External dimension
Weight
Connector
&
etc.
Video output
Operating temperature
Operating humidity
1.0 Vp-p (75 ohm, composite)
BNC connector / Spot Cable
0 ~ 96% (non-condencing)
General
Lens mount Fixed mount
o o
-10 C ~ +40 C
410g
E/I
AGC
Flickerless
BLC
White Balance
Dip Switch
ON/OFF
ON/OFF
ATW Fixed
F
U
N
C
T
I
O
N
F
U
N
C
T
I
O
N
Camera Control
ON/OFF
ON/OFF
146.0 x 105.0 mm (Bubble Diameter 113.0)
390g 420g
SPECIFICATIONS
DC12V / AC24V
SYNC Internal / Line lock
I 6 I
THREE AXIS DOME CAMERA
NTSC
