Atlona AV128128 Manual de usuario

Atlona Technologies www.atlona.com

AV SWITCHER USER GUIDE

AT-AV0404 to AV128128

Atlona Technologies www.atlona.com 2

Contents

1.0 Safety Operation Guide......................................................................3

1.1 Notice.................................................................................................3

2.0 Introduction........................................................................................4

2.1 Installation..........................................................................................5

3.0 Connector Types...............................................................................14

3.1 Connecting the AV Switcher.............................................................15

4.0 Operation Controls for AV0404.......................................................16

4.1 Operation Controls for AV1616.......................................................17

4.2 Additional Controls for AV32, AV48, AV64, AV96, AV128.............19

4.3 Remote Control Operation................................................................21

5.0 Operation of Application Software...................................................21

5.1 Keyboard Tab...................................................................................23

5.2 Auto Tab...........................................................................................23

5.3 Custom Code Tab.............................................................................24

5.4 Code Group Tab...............................................................................25

5.5 Send / Recieve Code List Tab..........................................................26

6.0 RS-232 Operation.............................................................................26

7.0 Technical Specications....................................................................28

8.0 Troubleshooting................................................................................31

Atlona Technologies www.atlona.com 3

1.0 Safety Operation Guide

***************************************************************

In order to ensure the credibility and the user’s safety, please comply with the fol-

lowing items during installation, maintenance and operation of the switch.

1) The switch must be in stable position. Use only the power supply that

comes with unit. Do not use an alternate as it may damage it.

2) Do not place the switcher near hot or cold surfaces or sources.

3) To avoid any damage by over heating, please keep the environment in good

ventilation to radiate the heat when running the switcher.

4) The switcher should be turned off when it is not used.

5) Please do not attempt to take cover off the switcher for there is a high-volt

age component inside that could cause electric shock.

6) Do not splash any liquid or chemical on or near the equipment.

7) Please make sure all the wiring are in working condition and are not cut or

damaged.

1.1 Notice

*******************************************************************

This VGASwitchers User Manual can be used for other VGA matrix switcher

models. This manual is only an instruction for operators, not for any maintenance

usage. Any changes of functions and parameters since then will be informed sepa-

of this publication may be copied or reproduced without the prior written consent of

Atlona Technologies.

Please check Atlona website updates.

http://www.Atlona.com

Atlona Technologies www.atlona.com 4

2.0 Introduction

The AV series switcher is a high-performance professional computer and audio signal switcher that

can be used for cross switching multiple computer and audio signals. The AV series switcher mostly ap-

ply in broadcasting TV engineering, multi-media meeting room, big screen display engineering, television

education, command control center or for other like applications. It provides power-fail locale protection

function, LCD displaying, shortcut selecting and saving function. With RS232 interface, it can be controlled

with PC, remote control system and any other 3rd party control systems. This user manual takes VGA0808

as the example; other models can take reference from it too.

Specications

Models A/V Input A/V Output RS232 Interface LCD Display

MATRIX AV0404 4 4 √×

MATRIX AV0802 8 2 √ √

MATRIX AV0804 8 4 √ √

MATRIX AV0808 8 8 √ √

MATRIX AV1604 16 4 √ √

MATRIX AV1608 16 8 √ √

MATRIX AV1616 16 16 √ √

MATRIX AV2408 24 8 √ √

MATRIX AV2416 24 16 √ √

MATRIX AV2424 24 24 √ √

MATRIX AV3208 32 8 √ √

MATRIX AV3216 32 16 √ √

MATRIX AV3224 32 24 √ √

MATRIX AV3232 32 32 √ √

MATRIX AV4832 48 32 √ √

MATRIX AV4848 48 48 √ √

MATRIX AV6432 64 32 √ √

MATRIX AV6448 64 48 √ √

MATRIX AV6464 64 64 √ √

MATRIX AV9664 96 64 √ √

MATRIX AV9696 96 96 √ √

MATRIX AV12864 128 64 √ √

MATRIX AV12896 128 96 √ √

MATRIX AV128128 128 128 √ √

Atlona Technologies www.atlona.com 5

2.1 Installation

The VGASwitchers can be easily rack mounted using the rack mount ears located in the front of the unit.

Secure the Switch with standard rack-hole screws. It is recommended to leave a 1U space between the units

to have easy access for installation of the cables. When connecting the cables make sure all cables are con-

nected correctly if not it could cause color loss or will not output a display signal.

Packaging Includes

• VGA Matrix Switcher

• RS-232 Communication Cord

• Power Supply Cord

• CD with Application SWITCHER 2.0

• User Manual and Quality Guarantee

• Remote Control

Atlona Technologies www.atlona.com 6

Atlona Technologies www.atlona.com 7

Atlona Technologies www.atlona.com 8

Atlona Technologies www.atlona.com 9

Atlona Technologies www.atlona.com 10
