Model

ModelModel

Model

ATI FireGL V5600 512 MB PCIe Graphics Card

GT346AA

Introduction

IntroductionIntroduction

Introduction

Unified Shader Architecture, enabling real-time realistic rendering of more complex datasets

Performance & Features

Performance & FeaturesPerformance & Features

Performance & Features

Unified Shader Architecture, enabling real-time realistic rendering of more complex datasets

High Performance Stream Computing, to leverage the GPU parallel processing capability for compute intensive tasks such as

physics, structural analysis and fluid dynamics

Support for DirectX 10 and OpenGL 2.1 advanced

HDR rendering support with 16-bit per RGB component, enabling a wider spectrum of colour creating natural lighting and

shading effects

Two Dual Link DVI outputs, capable of driving ultra high resolution widescreen monitors generating a multi-monitor desktop

of over 5000 pixels width

Multi-display productivity with independent display resolutions and refresh rates

Compatibility

CompatibilityCompatibility

Compatibility

The ATI FireGL V5600 is supported on the following HP Personal Workstations: xw4550, xw4600, xw6600 and xw8600.

Service and Support

Service and SupportService and Support

Service and Support

The ATI FireGL V5600 has a one-year limited warranty or the remainder of the warranty of the HP product in which it is installed.

Technical support is available seven days a week, 24 hours a day by phone, as well as online support forums. Parts and labour are

available on-site within the next business day. Telephone support is available for parts diagnosis and installation. Certain restrictions

and exclusions apply.

QuickSpecs

ATI FireGL V5600 512 MB PCIe Graphics Card

ATI FireGL V5600 512 MB PCIe Graphics CardATI FireGL V5600 512 MB PCIe Graphics Card

ATI FireGL V5600 512 MB PCIe Graphics Card

Overview

DA - 12819 Canada — Version 3 — March 30, 2009

Page 1

Form Factor

Form FactorForm Factor

Form Factor

ATX

Graphics Controller

Graphics ControllerGraphics Controller

Graphics Controller

R520

Bus Type

Bus TypeBus Type

Bus Type

PCI Express x16

Memory

MemoryMemory

Memory

512 MB f unified frame buffer, Z-buffer and Texture storage and a 128-bit Ring-Bus memory controller

Connectors

ConnectorsConnectors

Connectors

Two dual-link DVI connectors with analog/digital outputs

Maximum Resolution

Maximum ResolutionMaximum Resolution

Maximum Resolution

Dual Link digital support for 3840 x 2400 @ 60Hz. Ideal for 30-inch widescreen displays.

RAMDAC

RAMDACRAMDAC

RAMDAC

Dual 10-bit per channel 400MHz

Ring Bus Memory

Ring Bus MemoryRing Bus Memory

Ring Bus Memory

Controller

ControllerController

Controller

512-bit internal ring bus for highly efficient memory reads

Programmable intelligent arbitration logic

Display Output

Display OutputDisplay Output

Display Output

Up to 16-bit per RGB colour component High Dynamic Range output (HDR)

Programmable piecewise linear gamma correction, colour correction, and colour space conversion

(10-bits per colour)

Shading Architecture

Shading ArchitectureShading Architecture

Shading Architecture

Supports Full Shader Model 4.0

120 shader processing unit

Supported Graphics APIs

Supported Graphics APIsSupported Graphics APIs

Supported Graphics APIs

DirectX 10 and OpenGL 2.1 advanced

Available Graphics

Available GraphicsAvailable Graphics

Available Graphics

Drivers

DriversDrivers

Drivers

Microsoft Windows XP Professional qualified drivers may be preloaded or available from the HP support

Web site:

http://welcome.hp.com/country/us/en/support.html

HP-tested Windows XP and

Microsoft Windows Vista 32 and 64, Microsoft Windows XP.

HP qualified drivers may be preloaded or available from the HP support Web site:

http://welcome.hp.com/country/us/en/support.html

CUDA™ Parallel

CUDA™ ParallelCUDA™ Parallel

CUDA™ Parallel

Processor Cores

Processor CoresProcessor Cores

Processor Cores

PCA with ATX bracket, DVI to VGA converters, CD and manual.

The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and

services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial

errors or omissions contained herein. The information contained herein is subject to change without notice.

QuickSpecs

ATI FireGL V5600 512 MB PCIe Graphics Card

ATI FireGL V5600 512 MB PCIe Graphics CardATI FireGL V5600 512 MB PCIe Graphics Card

ATI FireGL V5600 512 MB PCIe Graphics Card

Technical Specifications

DA - 12819 Canada — Version 3 — March 30, 2009

Page 2
