ATI Technologies V3300 - Firegl Tm Pcie Manual de usuario

FireGLTM V3300

FireGLTM V3400

FireGLTM V5200

User’s Guide

P/N 137-50061-10

ii User’s Guide

ATI, the ATI logo, andATI product and product-feature names are trademarks and/or registered

trademarks of ATI Technologies Inc. All other company and/or product names are trademarks and/or

registeredtrademarksoftheirrespectiveowners.Features,performanceand specificationsaresubject

to change without notice. Product may not be exactly as shown in diagrams.

Reproductionof thismanual,orpartsthereof,inanyform, withouttheexpresswrittenpermissionof ATI

Technologies Inc. is strictly prohibited.

Disclaimer

While every precaution has been taken in the preparation of this document, ATI Technologies Inc.

assumes no liability with respect to the operation or use of ATI hardware, software or other products

and documentation described herein, for any act or omission of ATI concerning such products or this

documentation, for any interruption of service, loss or interruption of business, loss ofanticipatory

profits, or for punitive, incidental or consequential damages in connection with the furnishing,

performance, or use of the ATI hardware, software, or other products and documentation provided

herein.

ATI TechnologiesInc. reservesthe right to make changes without further notice to a product or system

described herein to improve reliability, function or design. With respect to ATI products which this

document relates, ATI disclaims all express or implied warranties regarding such products, including

but not limited to, the implied warranties of merchantability, fitness for a particular purpose, and non-

infringement.

Documentation Updates

ATI is constantly improving its product and associated documentation. To maximize the value of your

ATI product, you should ensure that you have the latest documentation. ATI’s documentation contains

helpful installation/configuration tips and other valuable feature information.

User’s Guide iii

Note: This graphics card is for use only with compatible UL Listed

personal computers that have Installation Instructions detailing user

installation of card cage accessories.

LIMPORTANT SAFETY INSTRUCTIONS

•Read Instructions - All the safety and operating instructions should

be read before the product is operated.

•Retain Instructions - The safety and operating instructions should

be retained for future reference.

•Heed Warnings - All warnings on the product and the operating

instructions should be adhered to.

•Compatibility - This option card is for use only with IBM AT or

compatible UL Listed personal computers that have Installation

Instructions detailing user installation of card cage accessories.

•Grounding - For continued protection against risk of electric shock

and fire, this accessory should be installed only in products equipped

with a three-wire grounding plug, a plug having a third (grounding)

pin. This plug will only fit into a grounding-type power outlet. This is a

safety feature. If you are unable to insert the plug into the outlet,

contact your electrician to replace the obsolete outlet. Do not defeat

the safety purpose of the grounding-type plug.

•Secure Attachment - All card securement pins shall be completely

tightened as to provide continuous bonding between the option card

and the PC chassis.

•Lightning - For added protection for this product during a lightning

storm, or when it is left unattended and unused for long periods of

time, unplug it from the wall outlet, and disconnect the antenna or

cable system. This will prevent damage to the product due to

lightning and power-line surges.

•Power Lines - An outside antenna system should not be located in

the vicinity of overhead power lines or other light or power circuits, or

where it can fall into such power lines or circuits.

•Antenna Installation - When installing an outside antenna system,

extreme care should be taken to keep from touching such power lines

or circuits, as contact with them may be fatal.

iv User’s Guide

Table of Contents

Getting Started. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

FireGL™ Features 1

System Requirements 2

Before You Begin 3

Record Your Serial and Part Numbers 3

Uninstall Previous Graphics Card Drivers 3

Quick Installation 4

Installing Hardware . . . . . . . . . . . . . . . . . . . . . . . . . 5

Detailed Installation 5

Connecting Display Devices 6

Display Configurations 8

Installing Software and Drivers . . . . . . . . . . . . . . 11

HydraVision™ Multi-monitor Management 11

Installing Drivers and Software in Windows® 11

Software Installation Prerequisites 12

Monitor Configuration 13

Clone Display Mode 14

Span Display Mode 14

Reinstalling Drivers 15

Display Properties. . . . . . . . . . . . . . . . . . . . . . . . . 17

ATI Displays Tab 17

Dynamic Display Reassignment 19

ATI Color Tab 19

Hotkeys 22

ATI Options Tab 24

ATI Configuration Tab 25

ATI Advanced Settings Tab 27

ATI HDTV Component Video Adapter . . . . . . . . . 29

Installing Your ATI HDTV Component Video Adapter 29

Setting the ATI HDTV Component Video

Adapter DIP Switches 31

Display Modes 31

Aspect Ratio 31

Using Your ATI HDTV Component Video Adapter 32

Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Troubleshooting 35

General Problems 36

Customer Care 38

Disclaimer 40

Warranty Information 40

Hardware Warranty Service Statement 40

Warranty Service 40

Limitations 41

Additional Accessories 41

Compliance Information 42

FCC Compliance Information 42

Industry Canada Compliance Statement 42

CE Compliance Information 43

Informations de conformité de la CE 43

Electrical Safety 43

VCCI Class B ITE Compliance Information 44

MIC Certification Information 44

BSMI Certification Information 44

Waste Electrical and Electronic Equipment

(WEEE) Directive Compliance 44

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

FireGL™ Features 1

CHAPTER 1:

Getting Started

Your ATI FireGL™ card is an advanced workstation 3D graphics card

based on a high-bandwidth, parallel pipeline geometry and rendering

architecture.The carddeliversworkstation-classperformance todesigners,

engineers, and animators, and runs the latest OpenGL® and Microsoft®

DirectX® applications.

FireGL™ Features

Features of your FireGL™ workstation graphics card include:

• ATI FireGL™ Graphics Processor Unit (GPU) with Avivo™

technology.

• Scalable ultra-threaded architecture with fast dynamic branching

and high performance parallel processing.

• Native high-bandwidth PCI Express™ x16 lane support.

• 128-bit full floating point precession.

ATI Avivo™ WORKSTATION TECHNOLOGY

• True 64-bit per pixel floating point High Dynamic Range (HDR)

rendering support.

• High fidelity display engine capable of producing over one trillion

colors.

• Advanced support for 8-bit, 10-bit, and 16-bit per RGB color

component.

DISPLAY OUTPUT

• Dual DVI-I output supports any combination of digital and analog

displays.

• Independent resolution and refresh rate selection with multi-monitor

configurations.

• Dual VGA analog support (DVI-I-to-VGA adapter included).

2 System Requirements

• Dual-link DVI output (offered on the FireGL™ V3400 and V5200)

allows support of monitors with resolutions up to 3840 x 2400.

System Requirements

Make sure you meet the following system requirements before installing

your FireGL™ card.

Hardware • Intel® Pentium® 4/Xeon®; AMD Athlon® 64/K7/XP or

compatible.

• 512 MB or more for best performance.

• Motherboard with available X16 lane PCI Express™

slot and correct chipset driver.

• Optical drive for installation software (CD-ROM or

DVD-ROM drive).

• 350 watt or greater power supply (recommended).

Operating

System • Windows® 2000 with Service Pack 1 (or higher).

• Windows® XP Home or Pro with Service Pack 1 (or

higher).

• Linux® XFree86 4.X.0.

Monitor • High-resolution MultiSync or multi-frequency monitors

or other VGA monitors.

• Digital flat-panel displays or digital CRT displays.

Before You Begin 3

Before You Begin

Before you begin installing your new graphics card, please do the

following.

Record Your Serial and Part Numbers

The serial number and 102 part number on the graphics card are required

for registration. They are located on a sticker on the back of the card.

Write these numbers down before installing your new ATI product.

Uninstall Previous Graphics Card Drivers

To ensure the successful installation of your new FireGL™ card, you must

uninstall the drivers for the existing graphics card before removing it from

your computer.

To uninstall previous drivers

With your current graphics card still in your computer:

1Close all applications that are currently running.

2Navigate to the Control Panel and select Add/Remove Programs.

3Select your current graphics card drivers and select Add/Remove.

The wizard will help you remove your current display drivers.

Serial and Part Numbers

XSerial number (S/N)

Y102 part number (P/N)

4 Quick Installation

Note: If the previously installed graphics card has any additional

software installed, it should also be removed at this point.

4Turn off your system and remove the old graphics card.

Quick Installation

Experienced users and system administrators can follow these brief

instructions for installing the FireGL™ card in the shortest possible time.

Detailed hardware and software installation instructions are given in the

next two sections.

To perform a quick installation

1Uninstall the drivers and software for your old graphics card if you

have not already done so.

Note: If you are using a motherboard containing an on-board

graphics solution and do not intend to use it as part of a multiple-

monitor setup, disable it.

2Shut down and disconnect your computer system.

3Remove any previously installed card.

4Install your new FireGL™ card.

5Reassemble and connect your computer system.

6Install the FireGL™ drivers and configuration software from the ATI

Installation CD-ROM by doing one of the following:

• Run through the automatic ATISETUP utility; or

•Start > Run > X:\SETUP.EXE (where Xis the drive letter of

your CD-ROM drive).

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Tarjeta de video de ATI Technologies

ATI Technologies

ATI Technologies 9800PRO - 128MB Dell - Radeon AGP 8x Vga DVI Tv-out DDR... Instrucciones de montaje

ATI Technologies

ATI Technologies 9000 - Radeon Pro Manual de usuario

ATI Technologies

ATI Technologies RADEON X800 PCIe Series Manual de usuario

ATI Technologies

ATI Technologies ALL-IN-WONDER Manual de usuario

ATI Technologies

ATI Technologies 9550 - X Radeon 256MB Agp Manual de usuario

ATI Technologies

ATI Technologies RADEON 137-40225-20 Manual de usuario

ATI Technologies

ATI Technologies All-in-Wonder X800 PCI Express Manual de usuario

ATI Technologies

ATI Technologies RAGE FURY Guía de configuración

ATI Technologies

ATI Technologies FireGL V5100 Manual de usuario

ATI Technologies

ATI Technologies FIRE GL 8700 Manual de usuario

ATI Technologies

ATI Technologies V7100 - 100-505090 FireGL 256MB GDDR3 SDRAM PCI Express x16 Graphics... Manual de usuario

ATI Technologies

ATI Technologies 9200 - Radeon 128MB Video Graphics Card Manual de usuario

ATI Technologies

ATI Technologies 100-505103 - Firegl V5000 128MB Pcie 2PORT Dvi-i... Manual de usuario

ATI Technologies

ATI Technologies RADEON 8500 Manual de usuario

ATI Technologies

ATI Technologies V7300 - Firegl 512MB Pcie Bulk Manual de usuario

ATI Technologies

ATI Technologies 9000 - Radeon Pro Manual de usuario

ATI Technologies

ATI Technologies X700 - Radeon Pro 256 MB PCIe Manual de usuario

ATI Technologies

ATI Technologies Workstation x1000 Manual de usuario

ATI Technologies

ATI Technologies FIRE GL X1-256 Manual de usuario

ATI Technologies

ATI Technologies Radeon 9200 Manual de usuario

ATI Technologies

ATI Technologies Radeon Guía de configuración

ATI Technologies

ATI Technologies 9800XT - 100-505076 FireGL 256MB DDR SDRAM AGP 8x Graphics... Manual de usuario

ATI Technologies

ATI Technologies Radeon X1950 Pro Manual de usuario

ATI Technologies

ATI Technologies ALL-IN-WONDER 9200 Manual de usuario

Manuales populares de Tarjeta de video de otras marcas

Gainward

Gainward GeForce GTX 690 4GB Manual de usuario

MSI

MSI N220GT series Manual de usuario

SIIG

SIIG aurora Manual de usuario

ClearSpeed

ClearSpeed ClearSpeed Advance e720 Manual de usuario

MSI

MSI R7850 series Manual de usuario

DVS

DVS Atomix HDMI Manual de usuario

Aztech

Aztech VGS3D-AGP Manual de usuario

Advoli

Advoli TB4 Standard Manual de usuario

ELSA

ELSA ERAZOR III LT Manual de usuario

Gigabyte

Gigabyte GV-R7500L Manual de usuario

Themis

Themis TGA-7000 PMC Manual de usuario

EMS

EMS XtremeRGB-Ex1 Manual de usuario

Nvidia

Nvidia Quadro Workstation Manual de usuario

Pioneer

Pioneer PDA-5003 Manual de usuario

QDI

QDI N2 Manual de usuario

NEC

NEC N8116-48 Manual de usuario

MSI

MSI R7770 PoweR Edition Manual de usuario

Gigabyte

Gigabyte GV-N68T256D Manual de usuario
