ATI Technologies RADEON 9200 MAC EDITION Manual de usuario

ATI

RADEON™ 9200 MAC

EDITION

User’s Guide

P/N 137-40722-10

ATI and ATI product and product feature names are trademarks and/or registered trademarks of ATI

Technologies Inc. All other company and/or product names are trademarks and/orregistered

trademarksoftheirrespectiveowners.Features,performanceandspecificationsaresubjecttochange

without notice. Product may not be exactly as shown indiagrams.

Reproductionofthismanual,orpartsthereof,inanyform,withouttheexpresswrittenpermissionofATI

Technologies Inc. is strictly prohibited.

Disclaimer

While every precaution has been taken in the preparation of this document, ATI Technologies Inc.

assumes no liability with respect to the operation or use of ATI hardware, software or other products

and documentation described herein, for any act or omission of ATI concerning such products or this

documentation, for any interruption of service, loss or interruption of business, loss of anticipatory

profits, or for punitive, incidental or consequential damages in connection with the furnishing,

performance, or use of the ATI hardware, software, or other products and documentation provided

herein.

ATI Technologies Inc. reserves the right to make changes without further notice toa product or system

described herein to improve reliability, function or design. With respect to ATI products which this

document relates, ATI disclaims all express or implied warranties regarding such products, including

but not limited to, the implied warranties of merchantability, fitness for a particular purpose, and non-

infringement.

Product Notices

Dolby* Laboratories, Inc.

Manufactured under license from Dolby Laboratories. Confidential Unpublished Works.

Macrovision

Apparatus Claims of U.S. Patent Nos. 4,631,603, 4,577,216, 4,819,098, and 4,907,093 licensed for

limited viewing uses only.

This product incorporates copyright protection technology that is protected by method claims of certain

U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights

owners. Use of this copyright protection technology must be authorized by Macrovision Corporation,

and is intended for home and other limited viewing uses only unless otherwise authorized by

Macrovision Corporation. Reverse engineering or disassembly is prohibited.

iii

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

System Requirements 1

External Connections 1

Related Documentation 2

Multimedia Features 2

Viewing 3D Graphics 2

ATI Displays Control Panel. . . . . . . . . . . . . . . . . . . 5

Introduction 5

Open the ATI Displays control panel using

Mac OS® X 5

ATI Displays Control Panel 6

Mac2TV™ Video Out 6

Connect your computer to a TV/VCR 7

Enabling Mac2TV™ 8

Set Up Tab 8

Optimizing Mac2TV™ 9

Controls Tab 10

Ratio/Size Tab 11

Using a TV as your only display 12

Viewing Text on Television 12

ATI Displays Preferences 12

Advanced Display Options 13

VERSAVISION™ Tab 13

Display Control Tab 14

Advanced DFP Tab 15

Performance Tab 16

ATI HELP 16

Using DVD and QuickTime® Playback 17

Using Digital Flat Panel (DVI) 17

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Video Mode Table 19

Digital Flat Panel 20

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Compliance Information . . . . . . . . . . . . . . . . . . . . 25

FCC Compliance Information 25

Industry Canada Compliance Statement 25

CE Compliance Information 26

L’Information de conformité de la CE 26

CE-befolgungInformationen 26

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

CHAPTER 1:

Introduction

The RADEON™ 9200 MAC EDITION represents the next generation in

3D and video acceleration for your Power Macintosh® computer. It

includes flexible dual-display support for multiple combinations of CRT

and Digital Flat Panel monitors. Your new graphics accelerator provides:

• Flexible dual-display support enabling many combinations utilizing

VGA and DVI connectors for analog and digital displays.

• OpenGL® accelerator providing superior 3D rendering

performance and advanced imaging and filtering techniques.

• Industry leading DVD acceleration for High Bitrate, low CPU

usage, playback of the latest movies at any resolution.

• QuickTime® playback accelerator for full screen, full motion, DVD

quality video.

• TV-Out support via S-Video connector.

System Requirements

External Connections

• 15-pin D-shell (female) VGA output.

• DVI-I output.

• S-Video output.

Note: Connecting a second VGA monitor requires a DVI-to-VGA

Hardware • Any Power Macintosh® computer with an PCI

expansion slot.

• QuickTime® 6 or higher.

• Minimum 128MB of system memory required for Mac

OS® X version 10.x.

Operating

System • Mac OS® X version 10.2.8 and 10.3.3 or higher.

Monitor • VGA-style monitor (see note below), DVI style digital

flat panel, Apple® ADC style digital flat panel (using a

third party powered adapter) or Apple® multi-

frequency monitor.

2 Related Documentation

adapter (included) to connect to the RADEON™ 9200 MAC

EDITION graphics accelerator.

Note: Future references to Mac OS® X in this manual are intended

to be generic and inclusive of their respective versions of the

Macintosh® operating systems.

Related Documentation

The README file summarizes the latest product revisions. Click the

README icon on the installation disk to open this file.

Help is available by clicking on the button in the ATI Displays control

panel or through the Apple® Help Center. You can browse through the

Help or search for a specific topic.

Multimedia Features

Your RADEON™ 9200 MAC EDITION turns your Mac computer into a

3D and 2D graphics powerhouse. You can use your new graphics

accelerator card to:

• Enjoy true-color 32-bit 2D or 3D graphics up to 2048 x 1536.

• Watch full screen, full motion, DVD quality video using the

Apple® DVD Player or QuickTime® playback acceleration.

• Output your Mac’s display to digital flat panels and digital

projectors.

• Output your Mac’s display to a TV.

The following information describes these features in more detail and

suggests ways you can optimize your machine to get the most out of your

new card.

Viewing 3D Graphics

RADEON™ 9200 MAC EDITION’s 3D Acceleration features supports

the following advanced 3D graphics capabilities:

• 4 pixel pipeline architecture.

• 128 bit memory interface.

• Hardware accelerated vertex and pixel shaders.

• Hardware accelerated Transform and Lighting.

Viewing 3D Graphics 3

• 62.5 million triangles per second transform rate.

• Full Scene Antialiasing.

• Bilinear, Trilinear, and Anisotropic filtering.

In addition, the RADEON™ 9200 MAC EDITION brings new and

exciting graphics technologies to the Macintosh® platform:

SMOOTHVISION™

is an anti-aliasing solution that raises the bar for

image quality using programmable multi-sampling methods to post-

process graphics before they are displayed.

SMARTSHADER™ is a new technology which revolutionizes the

graphics pipeline by making both the geometry processing and pixel

processing stages more programmable than ever before. Developers can

easily create amazing new graphics effects while maintaining a high level

of performance.

HYPER Z™ makes Z-buffer bandwidth usage more efficient by

decreasing the amount of information sent to the frame buffer.

RADEON™ 9200 MAC EDITION only displays 3D graphics in thousands

and millions of colors. When you set your display to 256 colors, this will

affect Finder™, OpenGL®, Quartz® Extreme, and QuickTime®

acceleration.

4 Viewing 3D Graphics

Introduction 5

CHAPTER 2:

ATI Displays Control Panel

Introduction

The ATI Displays control panel provides access to the advanced features

that the RADEON™ 9200 MAC EDITION has to offer.

Open the ATI Displays control panel using

Mac OS® X

Open the Apple® System Preferences.

Click the ATI Displays icon.

Click the Hard Disk icon.

Click Applications folder.

Click Utilities folder.

Click ATI Utilities folder.

Double-click ATI Displays.

For detailed instructions on how to set up and use these features, please

refer to ATI Help, which can be accessed through the ATI Displays control

panel.

6 Mac2TV™ Video Out

ATI Displays Control Panel

Display Info dialog shows the current display settings of the specific

monitor ATI Displays is running on.

Detect Displays button detects all connected displays. This feature is

useful when a second VGA monitor is connected to your graphics adaptor.

Detect Display removes the need to restart your computer.

Note: Your display will momentarily go blank while all connected

devices are being detected.

The Profile dialog presents information on the specific RADEON™

graphics card and video driver installed in your computer. Even if ATI

Displays cannot identify your ATI product it will still provide display

configuration, driver version and other related information. A warning

dialog will display if no ATI product is installed in your computer.

The Support dialog provides an internet link to ATI Technologies’ web

site.

Click Create Apple® System Profiler Report button to generate a

detailed report of the computer’s installed hardware and software.

Mac2TV™ Video Out

The RADEON™ 9200 MAC EDITION’s Mac2TV™ Video Out feature

allows you to output your computer’s display to your TV or VCR.

Anything you can display on your monitor can be output to TV.
