CS-82A / CS-84A

USER MANUAL

PS/2 KVM Switch

FCC Information

This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy, and if not

installed and used in accordance with the instruction manual, may

cause interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or

more of the following measures:



Reorient or relocate the receiving antenna;



Increase the separation between the equipment and receiver;



Connect the equipment into an outlet on a circuit different from

that which the receiver is connected;



Consult the dealer or an experienced radio/television technician

for help.

RoHS

This product is RoHS compliant.

- 3 -

CS-82A / CS-84A User Manual

Online Registration

You can register your product at our online support center:

Online Support

International

Telephone Support

For telephone support, call this number:

International http://support.aten.com

North America http://www.aten-usa.com/product_registration

Email Support [email protected]

Online

Support

Technical Support http://eservice.aten.com

Product Information http://www.aten.com

Telephone Support 886-2-8692-6959

International 886-2-8692-6959

China 86-400-810-0-810

Japan 81-3-5615-5811

Korea 82-2-467-6789

North America 1-888-999-ATEN ext 4988

1-949-428-1111

- 4 -

Package Contents

The CS-82A / CS-84A KVM Switch package contains the

following items:



1 CS-82A or CS-84A KVM Switch



2 Custom KVM Cable Sets (CS-82AC package only)



4 Custom KVM Cable Sets (CS-84AC package only)



1 User Manual*

Check to make sure that all the components are present and that

nothing got damaged in shipping. If you encounter a problem,

contact your dealer.

Read this manual thoroughly and follow the installation and

operation procedures carefully to prevent any damage to the unit,

and/or any of the devices connected to it.

*Features may have been added to the CS-82A / CS-84A since

this manual was printed. Please visit our website to download

the most up-to-date version of the manual.

International Co., Ltd.

Manual Part No. PAPE-1217-4ATG

Printing Date: 2019-04-19

ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd. All rights

reserved. All other trademarks are the property of their respective owners.

- 5 -

Overview

The CS-82A / CS-84A 2/4-Port PS/2 KVM (Keyboard, Video,

Mouse) Switch is a control unit that allows access to two/four

computers from a single PS/2 console (keyboard, monitor and

mouse). Before the development of the Master View, the only

way to control multiple computer configurations from a single

console was through a complex and costly network system. Now,

with the CS-82A / CS-84A, you can easily access two/four

computers in a cost effective manner.

Setup is fast and easy; plugging cables into their appropriate

ports is all that is entailed. There is no software to configure; there

are no installation routines, and no incompatibility problems.

Since the CS-82A / CS-84A intercepts keyboard input directly, it

works on any hardware platform and with all operating systems.*

The CS-82A / CS-84A provides two convenient methods to

access the computers connected to the system: 1) Port selection

pushbuttons located on the unit's front panel; and 2) Hotkey

combinations entered from the keyboard.

There is no better way to save time and money than with a CS-

82A / CS-84A installation. Since a single console manages all of

the computers, the CS-82A / CS-84A setup: 1) eliminates the

expense of having to purchase a separate keyboard, monitor,

and mouse for each computer; 2) saves all the space those extra

components would take up; 3) saves on energy costs; and 4)

eliminates the inconvenience and wasted effort involved in

constantly moving around from one computer to another.

Note: Mac and Sun systems may require an additional adapter.

Please see www.aten.com or contact your dealer for

details.

- 6 -

Features



One PS/2 console controls two (CS-82A) or four (CS-84A)

computers



Easy to install – no software required – connecting cables is

all it takes



Computer selection via front panel pushbuttons and hotkeys



Multiplatform support – Windows 2000/XP/Vista, Linux,

FreeBSD, Mac*, and Sun*.



Superior video quality – up to 1920 x 1440; DDC2B



Compact, sturdy, durable metal housing



Keyboard and mouse emulation for error-free booting



Supports Microsoft Intellimouse and the scrolling wheel on

most mice



Auto Scan function to monitor computer operation



Non-powered*

Note: 1. Mac and Sun systems may require an additional

adapter. Please see www.aten.com or contact your

dealer for details.

2. The CS-82A / CS-84A can get its power from the

computer. Therefore, use of a power adapter is optional

and requires a separate purchase. A power adapter is

only required if your installation exceeds 10 m.

- 7 -

System Requirements

Console



A VGA, SVGA, or multisync monitor capable of the highest

resolution you will be using on any computer on the

installation.



A PS/2 keyboard



A PS/2 mouse

Computers

The following equipment must be installed on each computer that

is to be connected to the system:



A VGA, SVGA, or multisync port



A PS/2 keyboard port



A PS/2 mouse port

Cables

Two or four custom KVM cable sets are provided with the CS-

82AC or CS-84AC packages only, as follows:



CS82AC includes 2 x 1.2 m cables



CS84AC includes 2 x 1.2 m and 2 x 1.8 m cables.

If you have purchased the CS-82A or CS-84A package, note that

only custom KVM cable sets specifically designed to work with

this switch may be used. KVM cable sets are available in 1.2, 1.8,

3, 5, 10, and 20 meter lengths.

Please please www.aten.com or contact your dealer for further

details.

Optional Accessories



USB-to-PS/2 Converter – to connect to computers that do not

have PS/2 ports.



Sun Console Converter – to connect to Sun systems



Power Adapter (DC9V, 300mA) – required if your installation

exceeds 10 m.

- 8 -

Components

Front View

Note: The component diagrams show the 4-port CS-84A. The

CS-82A has two ports.

No. Component Description

1 Port Selection

Pushbuttons

Press a pushbutton to access the computer attached

to the corresponding port.

2 Port LEDs The Port LEDs are built into the Port Selection

Pushbuttons. The upper ones are the On Line LEDs;

the lower ones are the Selected LEDs:

On Line

Lights ORANGE to indicate that the computer

attached to the corresponding port is up and running.

Selected

Lights GREEN to indicate that the computer attached

to its corresponding port is the one that has the KVM

focus.

Note: Depending on the port’s status, the LED may

flash according to a specific pattern. See the table

under Troubleshooting, page 19.

3Console

Keyboard and

Mouse ports

The cables from your PS/2 keyboard and PS/2

mouse plug in here. Each port is color-coded and

identified with an appropriate icon.

1 & 2 3

- 9 -

Rear View

Note: Since the KVM cables come with PS/2 connectors,

certain hardware configurations (such as notebooks)

that don’t have two PS/2 ports may require the use of a

USB-to-PS/2 converter. Please see www.aten.com or

contact your dealer for details.

No. Component Description

1 Console Video

Connector

The cable from your monitor plugs in here.

2 KVM Port

Section

The KVM cables that connect to the computer’s

monitor, keyboard, and mouse ports plug in here.

Each port is color-coded and identified by an

appropriate icon.*

- 10 -

Installation

To set up your CS-82A / CS-84A installation, refer to the

installation diagram on the next page (the numbers in the

diagram corresponds to the steps, below), and do the following:

1. Plug your PS/2 keyboard, and PS/2 mouse into the Console

ports located on the unit’s front panel.

2. Plug your monitor into the Console port located on the unit’s

back panel.

3. Using the Custom KVM cable sets provided, plug the monitor,

keyboard, and mouse connectors into the KVM Port sections

of the CS-82A / CS-84A.

4. At the other end of the cable, plug the corresponding monitor,

keyboard, and mouse connectors into their respective ports

on the computers you are connecting.

Note: Verify that all plugs are in the same KVM Port sockets (all

in Port 1, all in Port 2, etc.). Each socket is marked with an

appropriate icon.

5. If you choose to use external power (which is optional if your

installation does not exceed 10 m), plug the power adapter

into an AC power source, then plug the power adapter cable

into the CS-82A / CS-84A’s power jack.

6. Power on the computers.

Note:



The CS-82A / CS-84A’s power on default is to link to the first

computer that is powered on.

1. Make sure that the power to any device that you

connect to the installation has been turned off. You

must unplug the power cords of any computers that

have the Keyboard Power On function.

2. To prevent damage to your installation from power

surges or static electricity. It is important that all

connected devices are properly grounded.
