Asus RT-AX55 Manual de usuario
Quick Start Guide / 快速使用指南
RT-AX55RT-AX55
RT-AX1800 PlusRT-AX1800 Plus
RT-AX56U V2RT-AX56U V2
Wireless-AX1800 Dual Band WiFi 6 RouterWireless-AX1800 Dual Band WiFi 6 Router
Wireless-AX1800Wireless-AX1800
雙頻 雙頻
WiFi 6WiFi 6
無線路由器無線路由器
Wireless-AX1800Wireless-AX1800
雙頻雙頻
WiFi 6WiFi 6
無線路由器無線路由器
A17103 / Second Edition / July 2020
Table of contentsTable of contents
Package contents .............................................................................................................3
A quick look at RT-AX55 / RT-AX1800 Plus / RT-AX56U V2.................................3
Position your wireless router........................................................................................4
Preparing your modem..................................................................................................5
Setting up your RT-AX55 / RT-AX1800 Plus / RT-AX56U V2...............................5
FAQ ........................................................................................................................................8
Networks Global Hotline Information.......................................................................57
This QSG contains these languages:
English, 繁體中文, 簡體中文, Bahasa Indonesia, 한국어,
Bahasa Melayu, ไทย, Tiếng Việt
3
English
A quick look at RT-AX55 / RT-AX1800 Plus /A quick look at RT-AX55 / RT-AX1800 Plus /
RT-AX56U V2RT-AX56U V2
Package contentsPackage contents
RT-AX55 / RT-AX1800 Plus / RT-
AX56U V2 Wireless Router AC adapter
Network cable (RJ-45) Quick Start Guide
5GHz LED WPS button
2.4GHz LED Power switch
LAN 1~4 LEDs Power (DCIN) port
WAN (Internet) LED WAN (Internet) port
Power LED LAN 1 ~ 4 ports
Reset button
4
English
Positioning your wireless routerPositioning your wireless router
For optimal wireless transmission between the wireless
router and connected wireless devices, ensure that you:
• Place the wireless router in a centralized area for a maximum
wireless coverage for the network devices.
• Keep the wireless router away from metal obstructions and away
from direct sunlight.
• Keep the wireless router away from 802.11g or 20MHz only Wi-Fi
devices, 2.4GHz computer peripherals, Bluetooth devices, cordless
phones, transformers, heavy-duty motors, uorescent lights,
microwave ovens, refrigerators, and other industrial equipment to
prevent signal interference or loss.
• Always update to the latest rmware. Visit the ASUS website at
http://www.asus.com to get the latest rmware updates.
• To ensure the best wireless signal, orient the four non-detachable
antennas as shown in the drawing below.
90°
45° 45°
NOTES:
• Use only the adapter that came with your package. Using other
adapters may damage the device.
• Specications:
DC Power
adapter DC Output: +12V with 1A current
Operating
Temperature 0~40oC Storage 0~70oC
Operating
Humidity 50~90% Storage 20~90%
5
English
1. Unplug the power cable/DSL modem. If it has a battery backup,
remove the battery.
NOTE: If you are using DSL for
Internet, you will need your
username/password from your
Internet Service Provider (ISP) to
properly congure the router.
2. Connect your modem to the router with
the bundled network cable.
3. Power on your cable/DSL modem.
4. Check your cable/DSL modem LED lights to
ensure the connection is active.
Unplug
Setting up your RT-AX55 / RT-AX1800 Plus /Setting up your RT-AX55 / RT-AX1800 Plus /
RT-AX56U V2RT-AX56U V2
You can set up your router via wired or wireless
connection.
A. Wired connection
1. Plug your router into a power outlet and power it on. Connect the
network cable from your computer to a LAN port on your router.
Preparing your modemPreparing your modem
6
English
2. The web GUI launches automatically when you open a web
browser. If it does not auto-launch, enter http://router.asus.com.
3. Set up a password for your router to prevent unauthorized
access.
RT-AX55
Wall Power Outlet Modem
LINE LAN RESET PWR
Laptop
Power
WAN
LAN
a
d
c
b
Laptop
Tablet
Smart phone
RT-AX55
Wall Power Outlet
Modem
LINE LAN RESET PWR
Power
WAN
a
c
b
B. Wireless connection
1. Plug your router into a power outlet
and power it on.
7
English
2. Connect to the network with SSID shown on the product label on
the back side of the router. For better network security, change to
a unique SSID and assign a password.
ASUS router
* XX refers to the last two digits of the
MAC address. You can nd it on the label
on the back of your router.
Wi-Fi Name (SSID): ASUS_XX
3. You can choose either the web GUI or ASUS Router app to set up
your router.
a. Web GUI Setup
• Once connected, the web GUI launches automatically when
you open a web browser. If it does not auto-launch, enter
http://router.asus.com.
•
Set up a password for your router to prevent unauthorized
access.
8
English
b. App Setup
Download ASUS Router App to set up your router via your
mobile devices.
•
Turn on Wi-Fi on your mobile devices and connect to your
router’s network.
•
Follow ASUS Router App
setup instructions to
complete the setup.
ASUS Router
ASUS
Router
Remembering your wireless router settings
• Remember your wireless settings as you complete the router
setup.
Router Name: Password:
2.4 GHz network SSID: Password:
5GHz network SSID: Password:
FAQFAQ
1. Where can I nd more information about the wireless router?
• Technical support site:
https://www.asus.com/support
• You can get the user manual online at
https://www.asus.com/support
9
繁體中文
認識您的無線路由器認識您的無線路由器
產品包裝內容產品包裝內容
RT-AX55 / RT-AX1800 Plus /
RT-AX56U V2 無線路由器
電源變壓器
RJ-45 網路線 快速使用指南
5GHz 指示燈 WPS 按鈕
2.4GHz 指示燈 電源開關
LAN 1~4 指示燈 電源（DCIN）連接埠
WAN（網際網路）指
示燈 WAN（網際網路）連接埠
電源指示燈 LAN 1 ~ 4 網路連接埠
重置按鈕
10
繁體中文
放置您的路由器放置您的路由器
為獲得無線路由器與所連線的網路裝置之間傳送最佳無線訊號，
請確認以下幾點：
• 建議將路由器放置在中心區域，以獲得最佳無線訊號覆蓋範
圍。
• 請勿將裝置放在靠近金屬物品與陽光直射的地方。
• 請遠離其它 802.11g 或 20MHz Wi-Fi 裝置、2.4GHz 電腦周邊
裝置、 藍牙裝置、無線室內電話、傳送器、重型發動機、日
光燈、微波爐、電冰箱與其他工業裝置，以防止訊號干擾或
減損。
• 請經常更新至最新版本韌體。您可以登入華碩官網 https://
www.asus.com/tw/ 獲得最新韌體。
• 請依據下圖所示擺放路由器上的四根非可拆式天線以獲得最
佳無線訊號覆蓋範圍。
90°
45° 45°
注意：
• 請僅使用包裝中的電源變壓器。使用其他類型的電源變壓器可
能會造成裝置損毀。
• 規格：
直流電源變壓器 DC 輸出： +12V 電壓，支援最大 1A 電
流
運作溫度 0~40°C 儲存溫度 0~70°C
運作濕度 50~90% 儲存濕度 20~90%
