Asus RT-AX53U Manual de usuario
Table of contents
Table of contents
This QSG contains these languages:
English, 繁體中文, Bahasa Indonesia, Bahasa Melayu, ไทย,
Tiếng Việt
Package contents .............................................................................................................3
A quick look at RT-AX53U .............................................................................................3
Positioning your wireless router.................................................................................4
Preparing your modem..................................................................................................5
Setting up your RT-AX53U ............................................................................................6
You can set up your router via wired or wireless connection. .........................6
FAQ ........................................................................................................................................8
Networks Global Hotline Information.......................................................................43
..
3
English
A quick look at RT-AX53U
A quick look at RT-AX53U
Package contents
Package contents
RT-AX53U Wireless Router AC adapter
Network cable (RJ-45) Quick Start Guide
Power LED Power switch
LAN 1~3 LEDs Power (DCIN) port
WAN (Internet) LED WPS button
2.4GHz LED USB 2.0 port
5GHz LED WAN (Internet) port
USB 2.0 LED LAN 1 ~ 4 ports
Reset button
..
4
English
Positioning your wireless router
Positioning your wireless router
For optimal wireless transmission between the wireless
router and connected wireless devices, ensure that you:
• Place the wireless router in a centralized area for a maximum
wireless coverage for the network devices.
• Keep the wireless router away from metal obstructions and away
from direct sunlight.
• Keep the wireless router away from 802.11g or 20MHz only Wi-Fi
devices, 2.4GHz computer peripherals, Bluetooth devices, cordless
phones, transformers, heavy-duty motors, uorescent lights,
microwave ovens, refrigerators, and other industrial equipment to
prevent signal interference or loss.
• Always update to the latest rmware. Visit the ASUS website at
http://www.asus.com to get the latest rmware updates.
• To ensure the best wireless signal, orient the four non-detachable
antennas as shown in the drawing below.
45° 45°
NOTES:
• Use only the adapter that came with your package. Using
other adapters may damage the device.
• Specications:
DC Power adapter DC Output: +12V with 1.5A current
Operating
Temperature 0~40oC Storage 0~70oC
Operating
Humidity 50~90% Storage 20~90%
..
5
English
1. Unplug the power cable/DSL modem. If it has a battery backup,
remove the battery.
2. Connect your modem to the router with the bundled network
cable.
3. Power on your cable/DSL modem.
4. Check your cable/DSL modem LED lights
to ensure the connection is active.
Unplug
Preparing your modem
Preparing your modem
NOTE: If you are using DSL for
Internet, you will need your username/
password from your Internet Service
Provider (ISP) to properly congure
the router.
..
6
English
2. The web GUI launches automatically when you open a web
browser. If it does not auto-launch, enter http://router.asus.com.
3. Set up a password for your router to prevent unauthorized
access.
Wall Power Outlet
RT-AX53U
Modem
LINE LAN RESET PWR
Laptop
Power
WAN
LAN
a
d
c
b
Setting up your RT-AX53U
Setting up your RT-AX53U
You can set up your router via wired or wireless
connection.
A. Wired connection
1. Plug your router into a power outlet and power it on. Connect the
network cable from your computer to a LAN port on your router.
..
7
English
Wall Power Outlet
RT-AX53U
Modem
LINE LAN RESET PWR
Power
WAN
a
c
b
Laptop
Tablet
Smart phone
B. Wireless connection
1. Plug your router into a power outlet and power it on.
2. Connect to the network with SSID shown on the product label on
the bottom side of the router. For better network security, change
to a unique SSID and assign a password.
ASUS router
* XX refers to the last two digits of the
MAC address. You can nd it on the label
on the bottom of your router.
Wi-Fi Name (SSID): ASUS_XX
3. You can choose either the web GUI or ASUS Router app to set up
your router.
a. Web GUI Setup
• Once connected, the web GUI launches automatically when
you open a web browser. If it does not auto-launch, enter
http://router.asus.com.
•
Set up a password for your router to prevent unauthorized
access.
..
8
English
b. App Setup
Download ASUS Router App to set up your router via your mobile
devices.
•
Turn on Wi-Fi on your mobile devices and connect to your
router’s network.
•
Follow ASUS Router App
setup instructions to
complete the setup.
ASUS Router
ASUS
Router
Remembering your wireless router settings
• Remember your wireless settings as you complete the router
setup.
Router Name: Password:
2.4 GHz network SSID: Password:
5GHz network SSID: Password:
FAQ
FAQ
Where can I nd more information about the wireless router?
• Technical support site: https://www.asus.com/support
• You can get the user manual online at
https://www.asus.com/support
..
9
繁體中文
認識您的無線路由器
認識您的無線路由器
產品包裝內容
產品包裝內容RT-AX53U 無線路由器電源變壓器RJ-45 網路線快速使用指南電源指示燈電源開關LAN 1~3 指示燈電源（DCIN）連接埠WAN（網際網路）指示燈WPS 按鈕
2.4GHz 指示燈USB 2.0 連接埠5GHz 指示燈WAN （網際網路）連接埠USB 2.0 指示燈LAN 1 ~ 4 網路連接埠重置按鈕..
10
繁體中文
放置您的路由器
放置您的路由器為獲得無線路由器與所連線的網路裝置之間傳送最佳無線訊號，請確認以下幾點：
• 建議將路由器放置在中心區域，以獲得最佳無線訊號覆蓋範圍。• 請勿將裝置放在靠近金屬物品與陽光直射的地方。• 請遠離其它802.11g 或20MHz Wi-Fi 裝置、2.4GHz 電腦周邊裝置、
藍牙裝置、無線室內電話、傳送器、重型發動機、日光燈、微波爐、電冰箱與其他工業裝置，以防止訊號干擾或減損。• 請經常更新至最新版本韌體。您可以登入華碩官網https://www.
asus.com/tw/ 獲得最新韌體。• 請依據下圖所示擺放路由器上的四根非可拆式天線以獲得最佳無線訊號覆蓋範圍。
45° 45°
注意：
• 請僅使用包裝中的電源變壓器。使用其他類型的電源變壓器可能會造成裝置損毀。• 規格：直流電源變壓器DC 輸出：+12V，最大電流1.5A
運作溫度0~40°C儲存溫度0~70°C
運作濕度50~90% 儲存濕度20~90%
..
