Asus Wireless-N300 Manual de usuario
User Guide
Wireless-N300
Wireless N300 Router
2
Copyright © 2015 ASUSTeK Computer Inc. All Rights Reserved.
No part of this manual, including the products and software described
in it, may be reproduced, transmitted, transcribed, stored in a retrieval
system, or translated into any language in any form or by any means, except
documentation kept by the purchaser for backup purposes, without the
express written permission of ASUSTeK Computer Inc. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired,
modified or altered, unless such repair, modification of alteration is authorized
in writing by ASUS; or (2) the serial number of the product is defaced or
missing.
ASUS PROVIDES THIS MANUAL “AS IS”WITHOUT WARRANTY OF ANY KIND,
EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED
WARRANTIES OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS,
EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL,
OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS
AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL OR
PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE
FURNISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE
AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A
COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY
FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL,
INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be
registered trademarks or copyrights of their respective companies, and are used
only for identification or explanation and to the owners’benefit, without intent
to infringe.
E10377
First Edition
May 2015
3
Table of contents
1 Getting to know your wireless router 6
1.1 Package contents.........................................................................6
1.2 Your wireless router.....................................................................7
1.4 Positioning your router..............................................................9
1.5 Setup Requirements ................................................................ 10
1.6 Router Setup............................................................................... 11
1.6.1 Wired connection..................................................................11
1.6.2 Wireless connection.............................................................12
2 Getting started 14
2.1 Logging into the Web GUI ..................................................... 14
2.2 Quick Internet Setup (QIS) with Auto-detection ........... 15
2.3 Connecting to your wireless network................................ 19
3 Configuring the General settings 20
3.1 Using the Network Map ......................................................... 20
3.1.1 Setting up the wireless security settings......................21
3.1.2 Managing your network clients.......................................22
3.2 Creating a Guest Network...................................................... 23
3.3 Using the Traffic Manager ...................................................... 25
3.3.1 Managing QoS (Quality of Service) Bandwidth..........25
3.3.2 Monitoring Traffic .................................................................28
3.4 Setting up Parental Control................................................... 29
4 Configuring the Advanced Settings 30
4.1 Wireless......................................................................................... 30
4.1.1 General......................................................................................30
4.1.2 WPS ............................................................................................33
4.1.3 WDS............................................................................................35
4.1.4 Wireless MAC Filter...............................................................37
4
Table of contents
4.1.5 RADIUS Setting ......................................................................38
4.1.6 Professional.............................................................................39
4.2 LAN................................................................................................. 41
4.2.1 LAN IP ........................................................................................41
4.2.2 DHCP Server............................................................................42
4.2.3 Route .........................................................................................44
4.2.4 IPTV ...............................................................................................45
4.3 WAN ............................................................................................... 46
4.3.1 Internet Connection.............................................................46
4.3.2 Port Trigger..............................................................................49
4.3.3 Virtual Server/Port Forwarding........................................51
4.3.4 DMZ............................................................................................54
4.3.5 DDNS .........................................................................................55
4.3.6 NAT Passthrough...................................................................56
4.4 IPv6................................................................................................. 57
4.5 VPN Server................................................................................... 58
4.6 Firewall.......................................................................................... 59
4.6.1 General......................................................................................59
4.6.2 URL Filter ..................................................................................59
4.6.3 Keyword filter .........................................................................60
4.6.4 Network Services Filter .......................................................61
4.7 Administration ........................................................................... 63
4.7.1 Operation Mode ....................................................................63
4.7.2 System.......................................................................................64
4.7.3 Firmware Upgrade................................................................65
4.7.4 Restore/Save/Upload Setting ...........................................65
5
Table of contents
4.8 System Log .................................................................................. 66
5 Utilities 67
5.1 Device Discovery....................................................................... 67
5.2 Firmware Restoration .............................................................. 68
6 Troubleshooting 70
6.1 Basic Troubleshooting............................................................. 70
6.2 Frequently Asked Questions (FAQs) .................................. 73
Appendices 83
Notices ....................................................................................................... 83
ASUS Contact information.................................................................... 97
Networks Global Hotline Information............................................... 98
6
1 Getting to know your wireless
router
NOTES:
• Ifanyoftheitemsaredamagedormissing,contactASUSfor
technical inquiries and support, Refer to the ASUS Support Hotline
list at the back of this user manual.
• Keeptheoriginalpackagingmaterialincaseyouwouldneedfuture
warranty services such as repair or replacement.
Wireless-N300 Router Network cable (RJ-45)
Power adapter Quick Start Guide
1.1 Package contents
7
1.2 Your wireless router
Wireless-N300 300Mbps Wireless N Router
Power LED
Off: No power.
On: Device is ready.
2.4GHz LED
Off:No 2.4GHz signal.
On:Wireless system is ready.
Flashing:Transmitting or receiving data via wireless connection.
WAN (Internet) LED
Off:No power or no physical connection.
On: Has physical connection to a wide area network (WAN).
LAN 1~4 LED
Off:No power or no physical connection.
On: Has physical connection to a local area network (LAN).
WPS / Reset button (2-in-1)
This button launches the WPS Wizard or resets / restores the system to its factory
default settings.
LAN 1 ~ 4 ports
Connect network cables into these ports to establish LAN connection.
8
NOTES:
• Useonlytheadapterthatcamewithyourpackage.Usingother
adapters may damage the device.
• Specifications:
DC Power adapter DC Output: +19V with max 1.75A current;
Operating
Temperature 0~40oCStorage 0~70oC
Operating Humidity 50~90% Storage 20~90%
WAN (Internet) port
Connect a network cable into this port to establish WAN connection.
Power (DC-IN) port
Insert the bundled AC adapter into this port and connect your router to a power source.
Power button
Press this button to power on or off the stystem.
On
Off
9
Bottom panel
NOTE: Mounting the wireless router to a wall is not recommended as it
reduces wireless performance.
Item Description
Mounting hooks
Use the mounting hooks to mount your router on concrete
or wooden surfaces using two round head screws.
Air vents
These vents provide ventilation to your router.
10
1.4 Positioning your router
For the best wireless signal transmission between the wireless
router and the network devices connected to it, ensure that you:
• Placethewirelessrouterinacentralizedareaforamaximum
wireless coverage for the network devices.
• Keepthedeviceawayfrommetalobstructionsandawayfrom
direct sunlight.
• Keepthedeviceawayfrom802.11gor20MHzonlyWi-Fi
devices, 2.4GHz computer peripherals, Bluetooth devices,
cordlessphones,transformers,heavy-dutymotors,fluorescent
lights, microwave ovens, refrigerators, and other industrial
equipment to prevent signal interference or loss.
• Alwaysupdatetothelatestfirmware.VisittheASUSwebsiteat
http://www.asus.com to get the latest firmware updates.
• Toensurethebestwirelesssignal,orientthethreedetachable
antennas as shown in the drawing below.
45°45°
