Astell & Kern PPS11 Manual de usuario

INSTRUCTION BOOK

PPS11

User Guide

Package Contents

Part Names

Power Management

Charging

Connections

Updating Firmware

Getting Started _01

Basic Operations

Home Screen

Notification Panel

Purchasing or Streaming Music from Store

AK Connect

Listening to Music

Playlist Management

USB DAC Installation

How to Use USB Audio

Settings

Connecting to a Wireless Network

Using Bluetooth

Equalizer Setup

Using the Device _02

CONTENTS

Safety Precautions

Troubleshooting

Registered Trademarks

Disclaimers

Specifications

Miscellaneous _03

User Guide

Contents may be changed without prior notice to improve the

performance or quality of the product.

Package

Contents

Getting Started

5-Pin Micro-USB Cable: Connects the product to a computer

or utilize to charge the product.

Quick Start Guide: Basic overview of using the product.

Warranty Card: This card is required for customer service

and technical support. Please keep this card.

User Guide: The User Guide can be downloaded from the

Activo website:

[http://www.activostyle.com].

Quick Start Guide

& Warranty Card

5-Pin Micro

-USB Cable

PPS11

5-Pin Micro-USB Port: - DC Power symbol.

Connect to a computer or recharge the device.

Earphones: - Earphone symbol.

Output sound to connected earphones.

3.5mm Unbalanced: - 3.5mm Unbalanced Port symbol.

Connects earphones or headphones with a 3.5mm unbalanced

jack to output sound.

Power: - Power symbol.

Short-press- Turns the screen on or off.

Long-press - Turn the device on and off.

Previous/Rewind:

Short-press - Plays the previous song or restarts the song.

Long-press - Rewind.

Play/Pause: Play/pause current track.

Next/Fast Forward: Short-press - Plays the next track.

Long-press - Fast-forward current track.

microSD Card Slot: - MicroSD card slot symbol.

Insert a microSD card in the device to access the files on the

microSD card.

Volume: Turn the wheel to adjust volume.

LCD Touchscreen: Activate the screen and touch it to start.

Home Button: Press to return to Home Screen.

Getting Started

User Guide

The appearance of the product, as well as the printed and

engraved information, may vary depending on the model.

Part

Names

Previous/Rewind

Next/Fast-

Forward

Play/Pause

microSD

Card Slot

Touchscreen

LCD

Home

Button

Volume

Power

5-Pin Micro-USB Port Earphone Jack 3.5mm Unbalanced

9V 1.67A

User Guide

Getting Started

Resetting the device will not affect the stored data or time setting.

Do not use the reset function while the product is in use. Doing so

may corrupt the data on the device.

Reset Function

1. In cases of unexpected device failure or if the device becomes

unresponsive, press [Power] for 7 seconds to force a shutdown.

The device can be restarted after the shutdown is complete.

This device has an automatic screen timeout feature to reduce

battery consumption. The screen will turn off when there is no

user input during the period defined in [Menu - Settings - Power

- Screen Off]. (See Page 34.)

Turning on/off the Screen

1. While the screen is on, short-press the [Power] button to

turn off the screen.

2. Short-press [Power] button again to turn it on.

This device has an automatic power saving function to conserve

battery power. The device will turn off if there is no user input

during the period defined in [Menu - Settings - Power -

Automatic Shutdown]. (See Page 34.)

Turning on/off Power

1. Long-press the [Power] button of the device to turn it ON.

2. While the device is on, long-press the [Power] button to

shut down the device. A confirmation message will appear.

3. Press [OK] to turn off the device.

Power

Manage-

ment

Getting Started

User Guide

Depending on computer specifications, the device will charge

only when the computer is turned on.

When charging via computer connection, the charging time may

vary depending on whether the device is turned on or off.

Some computers in power-saving mode may not charge the

device.

The built-in battery will gradually lose capacity over time with

repeated charging/discharging.

Do not use any cables other than the 5-pin micro-USB cable that

is included in the package. Using an unauthorized cable may

cause a malfunction.

Charging via Computer

1. The device will charge automatically when connected to a

computer via the 5-pin micro-USB cable.

Charging Time: Up to 4 hours (When the device is fully discharged

and turned off and a 5V 2A adapter is used)

A 5V 2A charger may be used. Using a fast charging adapter will

not charge the product and may cause malfunctions.

Charging via Adapter

1. Charging is possible by using a 5V 2A output adapter

(sold separately).

Charging

User Guide

Getting Started

Connec-

tions

Connecting to a 3.5mm Unbalance Port

1. Connect earphones or headphones to the 3.5mm unbalanced

port.

Connecting to a Computer

1. Turn on the device and your computer.

2. Connect the product to the computer with the 5-pin micro

-USB cable to transfer media files.

For an optimal connection, quit any unnecessary programs

before connecting the device to the computer.

Do not use any 5-pin micro-USB cable other than the one

supplied with the device. Using an unauthorized cable may cause

a malfunction.

Mac users need to download and install the MTP program from

the Activo website in order for the device to pair with a Mac OS.

[http://www.activostyle.com]

Both Windows and Mac, the device is only compatible with USB

2.0.

Getting Started

User Guide

Disconnecting from the Computer

1. Disconnect the 5-pin micro-USB cable after the transfer

between the product and computer is completed.

Disconnecting the device from the computer during an operation

(e.g., file transfer) may corrupt data on the device.

Safely remove/eject the device from your computer, if applicable.

Copy Files/Folders to the Device

1. To copy files/folders from your computer, select the desired

files/folders and drag & drop them into the device folder.

Make sure that the 5-pin micro-USB cable is securely connected.

Note that removing the 5-pin micro-USB cable or turning off the

device or computer during a file transfer may corrupt data on the

device.

File transfer speeds may be affected by the computer and/or the

OS environment.

Getting Started

User Guide

Delete Files (or Folders) from the Device via Computer

1. Right-click the desired file/folder and then select [Delete].

2. Select [Yes] in the [Confirm File/Folder Deletion] window

to delete the selected files/folders.

Insert/Remove a microSD Card

1. Refer to the diagram and

gently insert a microSD

card into the microSD

card slot.

2. To safely remove a microSD

card, on the Home Screen,

select [Safely remove SD

card] from the Notification

Panel or select [Unmount SD

card] from [Menu - Settings -

System Information].

3. Gently press in the microSD card

to release it from the slot.

Getting Started

User Guide

Maximum Capacity: 400GB

Notes on Inserting a microSD Card

Do not force the microSD card into the slot.This may cause

malfunction of the product and damage to the card.

Do not repeatedly insert/remove the microSD card.

If not inserted properly, the microSD card may cause product

malfunctions and may get stuck in the product.

Notes on Removing a microSD Card

Be sure to safely remove the microSD card from the device.

Not following the proper procedure may corrupt data and

cause serious damage to the system.

Do not remove the microSD card during use. Doing so may cause

malfunction, delete data and damage the microSD card.

Notes on Using a microSD Card

If the microSD card is not recognized or functions improperly,

format the card, preferably in the FAT32 system.

Using cards other than the recommended microSD card may

cause malfunctions.

A microSD card is not included in the product package.

microSD card must be purchased separately.

Recommended microSD cards

SanDisk, Transcend
