Astell & Kern PPF33 Manual de usuario

INSTRUCTION BOOK

PPF33

User Guide

Package Contents

Product Overview

Power Management

Charging

Connections

Firmware Updates

Getting Started _01

Basic Operations

Home Screen

Notification Bar

Using Open APP Service

AK CONNECT

Listening to Music

Playlist Management

USB DAC Installation

How to Use USB Audio

CD Ripping

Settings

Connecting to Wi-Fi

Using Bluetooth

Equalizer Setup

Using the Device _02

Safety Pre-Cautions

Troubleshooting

Certifications

Registered Trademarks

Disclaimers

Specifications

Miscellaneous _03

CONTENTS

User Guide

Contents may be changed without prior notice to improve the

performance or quality of the product.

Package

Contents

Getting Started 02

Case & Protective Film: Protect the device and its screen.

microSD Card Slot Cover: The cover is used to protect the

microSD card slot when not in use. It is installed in the

product by default.

USB Type-C Cable: For charging and data transfer.

Quick Start Guide: Basic overview of device functionality.

Warranty Card: Provides warranty details for your device.

Maintain a copy of this card since it may be required for

future technical support requests.

User Guide: The User Guide can be downloaded from the

Astell&Kern website.

[http://www.astellnkern.com Support > Download].

Quick Start Guide

& Warranty Card

USB Type-C CablemicroSD Card

Slot Cover

Case &

Protective Film

PPF33

Previous/

Rewind

Play/Pause

Next/

Fast-Forward

3.5mm Unbalanced Port/

OPTICAL OUT terminal

LCD

Touchscreen

Home

Button

Power/

Volume

2.5mm Balanced Port

microSD Card Slot

USB Type-C Port

3.5mm Unbalanced Port/ OPTICAL OUT terminal:

- 3.5mm Unbalanced / S/PDIF Port symbol.

For audio output, connect earphones or headphones that

utilize a 3.5mm jack. Music can be played back on an S/PDIF

-capable external device via an optical cable.

Getting Started

User Guide

The appearance of the product, as well as the printed and

engraved information, may vary depending on the model.

Product

Overview

User Guide

Getting Started

2.5mm Balanced Port: - 2.5mm Balanced Port symbol.

For audio output, connect earphones or headphones that

utilize a 2.5mm jack.

microSD Card Slot: - microSD Card Slot symbol.

Insert a microSD card to access its files.

Power/Volume: - Power symbol.

Short press - Turns the screen on or off.

Press and hold - Turns the device on or off.

Turn the wheel to adjust the playback output volume level.

LCD Touchscreen: Display screen with touch control features.

Play/Pause: Play or pause the current song.

Previous/Rewind:

Short press - Play the previous song or restart the current

song.

Press and hold - Rewind the current song.

Next/Fast-Forward: Short press - Play the next song.

Press and hold - Fast-forward the

current song.

Home Button: Press to return to the Home Screen.

USB Type-C Port: - DC Power symbol.

For charging and data transfer.

Getting Started

User Guide

Resetting the device will not affect stored data or time settings. Do

not use the reset function while the product is in use. Doing so may

corrupt the data on the device.

This device has an automatic timeout feature to save battery power.

The screen will turn off if there is no user input during the period

defined in [Menu - Settings - Timer Settings - Screen Timeout]. (See

Page 44)

Reset Function

1. In case of unexpected device failure or freeze, press and

hold [Power] for 7 seconds to force a shutdown. The device

can then be restarted after the shutdown is complete.

Turning the Screen On/Off

1. While the screen is on, press the [Power] button to turn

off the screen.

2. Press [Power] button again to turn it on.

This device has an automatic shutdown feature to save battery

power. The device will turn off if there is no user input during the

period defined in [Menu - Settings - Timer Settings - Auto Power

Off] (See Page 44)

Powering the Device On/Off

1. Press and hold the [Power] button to turn on the device.

2. While the device is on, press and hold the [Power] button

to shut down the device. A confirmation message will

appear.

3. Press [OK] to turn off the device.

Power

Manage-

ment

User Guide

Getting Started

Fast charging time: Approx. 2 hours 20 minutes (Fully discharged,

Power-off, 9V 1.67A adapter) / Normal charging: Maximum 5 hours

(Fully discharged, Power-off, 5V 2A adapter)

A fast charger of 9V 1.67A may be used. Using a 12V adapter will not

charge the device and may cause malfunctions.

Charging via USB Wall Adapter

1. Commercially available 9V 1.67A output adapters may be

used for charging.

Charging

Getting Started

User Guide

Connec-

tions

3.5mm Unbalanced Port

1. Connect earphones or headphones to the 3.5mm

unbalanced port.

2.5mm Balanced Port

Connect earphones or headphones to the 2.5mm balanced port.

Connecting to Balanced Audio Device

1. Connect to an external audio device by using the 3.5mm

unbalanced port and 2.5mm balanced port.

Unbalanced

Port (Ground)

Balanced Port (LR)

Getting Started

User Guide

Connecting S/PDIF OUT

At S/PDIF OUT, the DSD format is converted to PCM and played back.

PCM can select output bit rate (16/24bit) and sample rate

(48/96/192kHz).

The volume will be fixed at the maximum level.

The output format of connected external devices may differ so refer

to the specifications of each device.

1. Listen to music through an external device by connecting

the S/PDIF-IN-compatible external device using the optical

cable and operating the product. Turn on the output format

conversion function in [Menu-Settings-S/PDIF Conversion],

to convert to the format that is set when S/PDIF connection

is made and output.

Getting Started

User Guide

Connecting to Computer

1. Turn on the device and your computer.

Use the USB Type-C cable to connect the device to a computer

in accordance with settings in [Menu - Settings - USB Mode].

[Default] Media Device (USB Drive): Transfer files from a

computer to the device.

DAC Input: Listen to music on a connected computer

through the device. (See Page 37)

Mac users need to download and install Android File Transfer from

the Astell&Kern website. [http://www.astellnkern.com > Support >

Download]

For an optimal connection, quit any unnecessary programs before

connecting the device to the computer.

Do not use cables other than the USB Type-C cable provided with the

device. Doing so may cause malfunctions.

Use USB 2.0 only on Mac.

Type-C-to-Type-C cable is recommended when connecting with a

MAC that supports Type-C port.
