Z-Wave+ System Integrators Guide

Yale nexTouch Sectional Mortise Keypad Lock

NTM 610/615/620/625/630/635/640/645

Contents

Yale Z-Wave+ Info .........................................................................................................................................3

Supported Command Classes ....................................................................................................................... 3

Association Table .......................................................................................................................................... 4

Notifications Table ........................................................................................................................................4

Configurable Parameters .............................................................................................................................. 7

Yale Z-Wave+ Info

Manufacturer ID: Assa Abloy (0x0129)

Z-Wave Device Type: Door Lock Keypad

Z-Wave Role Type: Listening Sleeping Slave (LSS)

Product ID: 0x0A00

Product Type ID:

0x8008 –NTM620/625/640/645-ZW2 (Touch Screen interface)

0x8008 –NTM610/615/630/635-ZW2 (Push Button Interface)

Supported Command Classes

Command Class Z-Wave+ Info

Command Class Manufacturer Specific

Command Class Security

Command Class Device Reset Locally

Command Class Power Level

Command Class Version

Command Class Battery*

Command Class Door Lock*

Command Class Door Lock Logging*

Command Class Schedule Entry Lock*

Command Class User Code*

Command Class Time Parameters*

Command Class Time*

Command Class Association*

Command Class Association Group Info*

Command Class Notification*

Command Class Configuration*

Command Class Firmware Update Md*

* Command Class Requires Security

Association Table

Group ID

Maximum Nodes

Description

Commands

Lifeline

Command_Class_Battery, Battery_Report ;

Command_Class_Notification, Notification_Report;

Command_Class_Configuration, Configuration_Report;

Command_Class_Device_reset_locally,

Device_Reset_locally_notification

Notifications Table:

Alarm Reports

Alarm

type

Alarm Level

Description

Notification

Type

Event

Master Code

changed.

0x70

0x00

Master code was

changed at keypad

0x06

0x12

0xFB

Master code was

changed over RF

0x06

0x0E

User added

0x(01-max

users)

User added. Alarm

level = user slot

number

0x06

0X0E

User deleted

0x21

0x(01-max

users)

User was deleted.

Alarm level = user slot

number

0x06

0X0D(0X0C)

Tamper Alarm

0xA1

0x01

keypad attempts

exceed code entry

limit

0x06

0X10

0x02

front escutcheon

removed from main

0x06

0xFE

RF Operate Unlock

0x19

0x01

by RF module

0x06

0X04

Keypad Unlock

0x13

0x(01-max

users)

Where Alarm level

represents user slot

number (0xFB =

Master Code)

0x06

0X06

Manual Lock

0x15

0x01

by key cylinder or

inside thumb-turn

0x06

0x01

0x02

by touch function

(lock and leave)

0x06

0x01

0x03

By inside button

0x06

0x01

RF Operate Lock

0x18

0x01

by RF module

0x06

0x03

Keypad Lock

0x12

0x (01 –max

users)

Where Alarm level

represents user slot

number

0x06

0x05

Non Access

0x26

0x(01-max

users)

A Non Access Code

was entered at the

lock.

Where alarm level

represents user slot

number

0x06

0xFE

Low Battery

Alarms**

0xA8

0x (Current %)

Critical Battery Level

(Starting at 4.6V)

0x08

0x0B

0xA7

0x (Current %)

Low Battery

(Starting at 4.4V)

0x08

0x0A

Auto Lock Operate

Locked

0x1B

0x01

Auto re-lock cycle

complete, locked.

0x06

0x09

Duplicate Pin-code

error

0x71

0x (01-max

users)

Where Alarm level

represents user slot

number

Alarm generated in

response to add user

RF cmd.

This alarm is not

generated when

attempting to add

duplicate pin at the

keypad. The lock

simply denies it and

plays the “Denied”.

Trying to duplicate the

master code will result

in a 0x71 0x00 alarm

report.

0x06

0x0F

RF Module Power

Cycled

0x82

0x00

Power to RFM was

restored, sent by RF

module. The lock

doesn’t send any

alarm to the RF

module when power

is cycled.

0x08

0x01

Disabled user

entered at keypad

0x83

0x(01-max

users)

A disabled user pin

code was entered at

the keypad

0x06

0xFE

Valid user but

outside of schedule

0x84

0x(01-max

users)

A valid user can be

both a normal user

and a Non-Access

user. If a non-access

0x06

0xFE

user is out of schedule

this alarm will be sent

instead of the non-

access alarm.

Door Position

Sensor

0x2B

0x00

Door Opened

0x06

0x16

0x01

Door Closed

0x06

0x17

0x02

Door Propped (Door

Open for longer than

configurable door

propped time)

0x06

0xFE

Daily Repeating

Schedule

Set/Erased

0x60

0x(01-max

users)

Schedule(s) has been

set/erased for

specified user ID

0x06

0xFE

Daily Repeating

Schedule

Enabled/Disabled

0x61

0x(01-max

users)

Schedule(s) has been

enabled/disabled for

specified user ID

0x06

0xFE

Year Day Schedule

Set/Erased

0x62

0x(01-max

users)

Schedule(s) has been

set/erased for

specified user ID

0x06

0xFE

Year Day Schedule

Enabled/Disabled

0x63

0x(01-max

users)

Schedule(s) has been

enabled/disabled for

specified user ID

0x06

0xFE

All Schedule Types

Erased

0x64

0x(01-max

users)

Schedule(s) has been

set/erased for

specified user ID

0x06

0xFE

All Schedule Types

Enabled/Disabled

0x65

0x(01-max

users)

Schedule(s) has been

enable/disabled for

specified user ID

0x06

0xFE

Deadbolt

Secured/Unsecured

0x2A

0x0000

Deadbolt Secure

0x06

0XFE

0x0001

Deadbolt

Extended/Secured

0x06

0xFE

Lever Rotated (Rx)

0x29

0x0000

Lever was rotated.

WGA10 does not

distinguish between

inside/outside levers

0x06

0xFE

** - The Yale lock also supports a 3rd low battery alarm, too low to operate. This alarm is sent out as a

Battery Report (with value = 0xFF) through the Battery Command Class. This is the last low battery

alarm level before the product stops functioning.

Configurable Parameters

Configuration

Parameters

Parameter

Number

Size

Description

Silent mode on/off

1 byte

Level control, 1 = High Volume, 2 = Low Volume, 3 =

Silent. Default is 1 or High Volume

Auto Relock on/off

1 byte

0x00 = OFF, 0xFF = ON default is 0x00 or OFF

Auto Relock time

1 byte

1 to 180 seconds default is 03 seconds

Wrong Code Entry Limit

1 byte

3 to 10 default is 5 times

Language

1 byte

1=English, 2=Spanish, 3=French default is 1= English

Shut down time (after

wrong code entries)

1 byte

10 to 180 seconds default is 60 seconds

operating mode

1 byte

00 = normal mode (this is the default mode)

01 = vacation mode, keypad lockout

02 = privacy mode, no keypad. RF Unlock will work

03 = passage mode, Lock is permanently unlocked.

One Touch Locking

1 byte

0x00 = OFF, 0xFF = ON default is 0xFF or ON.

Privacy Button

1 byte

0x00 = OFF, 0xFF = ON default is 0x00 or OFF

Lock Status LED

1 byte

0x00 = OFF, 0xFF = ON default is 0xFF or ON.

Reset To Factory

Defaults

1 byte

01 = Lock will execute Reset To Factory.

No default value

Escape Return Mode

1 byte

0x00 = OFF, 0xFF = ON default is 0x00 or OFF

Enables the Escape Return mode of operation for the

lock.

Door Propped Timer

1 byte

10 to 2540 second. This value is represented as

seconds X 10. (ie a value of 4 would mean a door

propped timer of 40 seconds) Set to 0x00 to disable

Door Propped Alarm. Default = 0x00 (OFF)

DPS Alarms(Ax sensor)

1 byte

0x00 = OFF, 0xFF = ON Default is 0xFF or ON.

Used to enable/disable door condition alarms for locks

that support a door position sensor. Any lock that does

not support DPS will always report 0x00.

Deadbolt Installed

1 byte

0x00 = NO deadbolt , 0xFF = YES deadbolt

Read only parameter. Some locks contain optional

deadbolt hardware. This parameter is used to

determine if one is installed.

Eco Mode On/Off

1 byte

0x00 = OFF, 0xFF = ON default is 0x00 or OFF

If supported switches lock to lower power mode of

operation with reduced sound and led brightness.

Privacy Mode with

Deadbolt

1 byte

0x00 = OFF, 0xFF = ON default is 0x00 or OFF

If enabled then extending the deadbolt will put the lock

into Privacy Mode.

Lock Body Alarms Mask

1 byte

Each bit controls one alarm. 1 = alarm enabled, 0 =

alarm disabled.

0xFF = All Alarms on, Default is 0xFF.

Bit 0: DPS Alarm (AX) (Duplicate of parameter 19.

Values should be tied together)

Bit 1: Deadbolt Alarm

Bit 2: Lever Rotated (Rx)

Bit 3 –7: Not Used

*** - Additional hardware required. These parameters are only active if the optional Door Position

Switch has been installed with the lock.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cerrar de Assa Abloy

Assa Abloy

Assa Abloy Abloy EL648 Manual de usuario

Assa Abloy

Assa Abloy OneSystem 819N Guía de instalación

Assa Abloy

Assa Abloy 840C-50 Manual de usuario

Assa Abloy

Assa Abloy Yale Easy Manual de usuario

Assa Abloy

Assa Abloy Yale Real Living Assure Lock YRD426 Manual de usuario

Assa Abloy

Assa Abloy Corbin Russwin CL3500 Series Manual de usuario

Assa Abloy

Assa Abloy Sargent IN100 Manual de usuario

Assa Abloy

Assa Abloy Sargent SE LP10 Manual de usuario

Assa Abloy

Assa Abloy Securitron EPT-SC Series Manual de usuario

Assa Abloy

Assa Abloy SECURITRON MORTISE UNLATCH MUNL-12 Manual de usuario

Assa Abloy

Assa Abloy Corbin Russwin FE6700 Series Manual de usuario

Assa Abloy

Assa Abloy OneSystem 319N Instrucciones de instalación

Assa Abloy

Assa Abloy HES 5000 Series Manual de usuario

Assa Abloy

Assa Abloy APERIO E100 Scand Manual de usuario

Assa Abloy

Assa Abloy Sargent KP Series Manual de instalación

Assa Abloy

Assa Abloy Corbin Russwin IN100 Manual de usuario

Assa Abloy

Assa Abloy 813C-50 Manual de usuario

Assa Abloy

Assa Abloy Securitron M38 Series Manual de usuario

Assa Abloy

Assa Abloy HES K20 Manual de usuario

Assa Abloy

Assa Abloy Yale Real Living Assure Lock SL YRD256 Especificaciones técnicas

Assa Abloy

Assa Abloy IKON eCLIQ N110 Manual de usuario

Assa Abloy

Assa Abloy Yale Real Living YRD210-ZW Especificaciones técnicas

Assa Abloy

Assa Abloy Yale inTouch Especificaciones técnicas

Assa Abloy

Assa Abloy IKON +CLIQ Manual de usuario

Manuales populares de Cerrar de otras marcas

Magic

Magic 105 Manual de usuario

Gantner

Gantner GAT NET.Lock 7020 System Guía rápida

Wittkopp

Wittkopp Insys 7202 Manual de usuario

Dorma

Dorma Studio Classic Manual de usuario

Securam

Securam ECSL-601 Manual de usuario

Sudhaus

Sudhaus 3003 Manual de usuario

Safety 1st

Safety 1st 48517 Manual de usuario

Pado

Pado FDS-10 Manual de usuario

Esco

Esco systeQ Series Manual de usuario

COMPX

COMPX National D8951 Manual de usuario

secureo

secureo Key Box Manual de usuario

Stock Loks

Stock Loks C8713 Manual de usuario

COMPX

COMPX 1T-058 Manual del propietario

Auslock

Auslock T11 Manual de usuario

ELCOM

ELCOM 7205 Manual de usuario

Stealth SAFES

Stealth SAFES ShadowVault Manual de usuario

Knox

Knox KeySecure 5 Manual de usuario

Kwikset

Kwikset 48334/01 Manual de usuario
