ASROCK H61M-HP4 Manual de usuario

H61M-HP4

User Manual

Version 1.0

Published May 2013

No part of this manual may be reproduced, transcribed, transmitted, or translated in

any language, in any form or by any means, except duplication of documentation by

the purchaser for backup purpose, without written consent of ASRock Inc.

Products and corporate names appearing in this manual may or may not be regis-

tered trademarks or copyrights of their respective companies, and are used only for

identication or explanation and to the owners’ benet, without intent to infringe.

Disclaimer:

Specications and information contained in this manual are furnished for informa-

tional use only and subject to change without notice, and should not be constructed

as a commitment by ASRock. ASRock assumes no responsibility for any errors or

omissions that may appear in this manual.

With respect to the contents of this manual, ASRock does not provide warranty of

any kind, either expressed or implied, including but not limited to the implied warran-

ties or conditions of merchantability or tness for a particular purpose.

In no event shall ASRock, its directors, ofcers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from

any defect or error in the manual or product.

This device complies with Part 15 of the FCC Rules. Operation is subject to the fol-

lowing two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

The Lithium battery adopted on this motherboard contains Perchlorate, a toxic

substance controlled in Perchlorate Best Management Practices (BMP) regulations

passed by the California Legislature. When you discard the Lithium battery in Cali-

fornia, USA, please follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see

www.dtsc.ca.gov/hazardouswaste/perchlorate”

ASRock Website: http://www.asrock.com

Contents

1 Introduction ........................................................ 5

1.1 Package Contents ......................................................... 5

1.2 Specications................................................................. 6

1.3 Unique Features ............................................................ 9

1.4 Motherboard Layout ...................................................... 13

1.5 I/O Panel ....................................................................... 14

2 Installation .......................................................... 16

2.1 Screw Holes................................................................... 16

2.2 Pre-installation Precautions ......................................... 16

2.3 CPU Installation ............................................................. 17

2.4 Installation of Heatsink and CPU fan ............................. 19

2.5 Installation of Memory Modules (DIMM) ........................ 20

2.6 Expansion Slots (PCI Express Slots)................................. 21

2.7 Jumpers Setup .......................................................... 22

2.8 Onboard Headers and Connectors ............................ 23

2.9 Driver Installation Guide ............................................ 28

2.10 Installing Windows®8 / 8 64-bit / 7 / 7 64-bit / VistaTM /

VistaTM 64-bit / XP / XP 64-bit Without RAID Functions . 28

2.10.1 Installing Windows®XP / XP 64-bit Without RAID

Functions............................................................ 28

2.10.2 Installing Windows®8 / 8 64-bit / 7 / 7 64-bit /

VistaTM / VistaTM 64-bit Without RAID Functions. 29

2.11 ASRock XFast 555 ..................................................... 30

2.11.1 ASRock XFast RAM ........................................... 31

2.11.2 ASRock XFast LAN ............................................ 34

2.11.3 ASRock XFast USB............................................ 38

3 UEFI SETUP UTILITY.......................................... 40

3.1 Introduction .................................................................... 40

3.1.1 UEFI Menu Bar .................................................... 40

3.1.2 Navigation Keys ................................................... 41

3.2 Main Screen................................................................... 41

3.3 OC Tweaker Screen ...................................................... 42

3.4 Advanced Screen........................................................... 46

3.4.1 CPU Conguration ............................................... 47

3.4.2 North Bridge Conguration................................... 49

3.4.3 South Bridge Conguration.................................. 50

3.4.4 Storage Conguration .......................................... 51

3.4.5 Intel(R) Rapid Start Technology ........................... 52

3.4.6 Intel(R) Smart Connect Technology ..................... 53

3.4.7 Super IO Conguration ........................................ 54

3.4.8 ACPI Conguration............................................... 55

3.4.9 USB Conguration ............................................... 56

3.5 Tool ................................................................................ 57

3.6 Hardware Health Event Monitoring Screen ................... 59

3.7 Boot Screen ................................................................... 60

3.8 Security Screen ............................................................. 62

3.9 Exit Screen .................................................................... 63

4 Software Support ............................................... 64

4.1 Install Operating System................................................ 64

4.2 Support CD Information ................................................. 64

4.2.1 Running Support CD............................................ 64

4.2.2 Drivers Menu........................................................ 64

4.2.3 Utilities Menu........................................................ 64

4.2.4 Contact Information.............................................. 64

Chapter 1: Introduction

Thank you for purchasing ASRock H61M-HP4 motherboard, a reliable motherboard

produced under ASRock’s consistently stringent quality control. It delivers excellent

performance with robust design conforming to ASRock’s commitment to quality and

endurance.

In this manual, chapter 1 and 2 contain introduction of the motherboard and step-

by-step guide to the hardware installation. Chapter 3 and 4 contain the conguration

guide to BIOS setup and information of the Support CD.

Because the motherboard specications and the BIOS software might be

updated, the content of this manual will be subject to change without no-

tice. In case any modications of this manual occur, the updated version

will be available on ASRock website without further notice. You may nd

the latest VGA cards and CPU support lists on ASRock website as well.

ASRock website http://www.asrock.com

If you require technical support related to this motherboard, please visit

our website for specic information about the model you are using.

www.asrock.com/support/index.asp

1.1 Package Contents

ASRock H61M-HP4 Motherboard (Micro ATX Form Factor)

ASRock H61M-HP4 Quick Installation Guide

ASRock H61M-HP4 Support CD

2 x Serial ATA (SATA) Data Cables (Optional)

1 x I/O Panel Shield

ASRock Reminds You...

To get better performance in Windows®8 / 8 64-bit / 7 / 7 64-bit / VistaTM /

VistaTM 64-bit, it is recommended to set the BIOS option in Storage Con-

guration to AHCI mode.

1.2 Specications

Platform - Micro ATX Form Factor

- All Solid Capacitor design

CPU - Supports 3rd and 2nd Generation Intel®CoreTM i7 / i5 / i3 /

Xeon®/ Pentium®/ Celeron®in LGA1155 Package

- Supports Intel®Turbo Boost 2.0 Technology

- Supports K-Series unlocked CPU

Chipset - Intel®H61

- Supports Intel®Rapid Start Technology and Smart Connect

Technology

Memory - Dual Channel DDR3 Memory Technology

- 2 x DDR3 DIMM slots

- Supports DDR3 1600/1333/1066 non-ECC, un-buffered

memory (DDR3 1600 with Intel®Ivy Bridge CPU, DDR3

1333 with Intel® Sandy Bridge CPU)

- Max. capacity of system memory: 16GB (see CAUTION 1)

- Supports Intel® Extreme Memory Prole (XMP) 1.3 / 1.2 with

Intel®Ivy Bridge CPU

Expansion Slot - 1 x PCI Express 3.0 x16 slot (blue @ x16 mode)

* PCIE 3.0 is only supported with Intel®Ivy Bridge CPU. With

Intel®Sandy Bridge CPU, it only supports PCIE 2.0.

- 1 x PCI Express 2.0 x1 slot

Graphics * Intel®HD Graphics Built-in Visuals and the VGA outputs can

be supported only with processors which are GPU

integrated.

- Supports Intel®HD Graphics Built-in Visuals: Intel®Quick

Sync Video 2.0, Intel®InTruTM 3D, Intel®Clear Video HD

Technology, Intel®InsiderTM, Intel®HD Graphics 2500/4000

with Intel®Ivy Bridge CPU

- Supports Intel®HD Graphics Built-in Visuals: Intel®Quick

Sync Video, Intel®InTruTM 3D, Intel®Clear Video HD

Technology, Intel®HD Graphics 2000/3000, Intel®Advanced

Vector Extensions (AVX) with Intel®Sandy Bridge CPU

- Pixel Shader 5.0, DirectX 11 with Intel®Ivy Bridge CPU.

Pixel Shader 4.1, DirectX 10.1 with Intel®Sandy Bridge

CPU.

- Max. shared memory 1760MB with Intel®Ivy Bridge CPU.

Max. shared memory 1759MB with Intel®Sandy Bridge

CPU.

- Dual VGA Output: support HDMI and D-Sub ports by

independent display controllers

- Supports HDMI Technology with max. resolution up to

1920x1200 @ 60Hz

- Supports D-Sub with max. resolution up to 2048x1536 @

75Hz

- Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

HBR (High Bit Rate Audio) with HDMI (Compliant HDMI

monitor is required)

- Supports HDCP function with HDMI port

- Supports Full HD 1080p Blu-ray (BD) playback with HDMI

port

Audio - 5.1 CH HD Audio (Realtek ALC662 Audio Codec)

LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s

- Realtek RTL8111E

- Supports Wake-On-LAN

- Supports LAN Cable Detection

- Supports Energy Efcient Ethernet 802.3az

- Supports PXE

Rear Panel I/O I/O Panel

- 1 x PS/2 Mouse Port

- 1 x PS/2 Keyboard Port

- 1 x Serial Port: COM1

- 1 x Parallel Port (ECP/EPP support)

- 1 x D-Sub Port

- 1 x HDMI Port

- 4 x USB 2.0 Ports

- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

- HD Audio Jack: Line in/Front Speaker/Microphone

Storage - 4 x SATA2 3.0 Gb/s connectors, support NCQ, AHCI and

Hot Plug functions

Connector - 1 x IR header

- 1 x Power LED header

- 1 x Chassis Intrusion header

- 1 x LPC/TPM header

- 1 x CPU Fan connectors (4-pin)

- 1 x Chassis Fan connector (4-pin)

- 1 x 24 pin ATX power connector

- 1 x 4 pin 12V power connector

- 1 x Front panel audio connector

CAUTION!

1. Due to the operating system limitation, the actual memory size

may be less than 4GB for the reservation for system usage

under Windows®8 / 7 / VistaTM / XP. For Windows®OS with 64-

bit CPU, there is no such limitation. You can use ASRock XFast

RAM to utilize the memory that Windows®cannot use.

- 1 x SPDIF Out connector

- 2 x USB 2.0 headers (support 4 USB 2.0 ports)

BIOS Feature - 32Mb AMI UEFI Legal BIOS with GUI support

- Supports “Plug and Play”

- ACPI 1.1 Compliance Wake Up Events

- Supports jumperfree

- SMBIOS 2.3.1 Support

Support CD - Drivers, Utilities, AntiVirus Software (Trial Version),

CyberLink MediaEspresso 6.5 Trial, Google Chrome

Browser and Toolbar

Hardware - CPU/Chassis Temperature Sensing

Monitor - CPU/Chassis Fan Tachometer

- CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by

CPU Temperature)

- CPU/Chassis Fan Multi-Speed Control

- CASE OPEN detection

- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore

OS - Microsoft® Windows®8 / 8 64-bit / 7 / 7 64-bit / VistaTM /

VistaTM 64-bit / XP / XP 64-bit compliant

Certications - FCC, CE, WHQL

* For detailed product information, please visit our website: http://www.asrock.com

WARNING

Please realize that there is a certain risk involved with overclocking,

including adjusting the setting in the BIOS, applying Untied Overclocking

Technology, or using third-party overclocking tools. Overclocking may

affect your system’s stability, or even cause damage to the components

and devices of your system. It should be done at your own risk and

expense. We are not responsible for possible damage caused by

overclocking.

1.3 Unique Features

ASRock Extreme Tuning Utility (AXTU)

ASRock Extreme Tuning Utility (AXTU) is an all-in-one tool to

ne-tune different system functions in a user-friendly interface,

which includes Hardware Monitor, Fan Control and XFast RAM.

In Hardware Monitor, it shows the major readings of your sys-

tem. In Fan Control, it shows the fan speed and temperature for

you to adjust. In XFast RAM, it fully utilizes the memory space

that cannot be used under Windows®OS 32-bit CPU.

ASRock Instant Boot

ASRock Instant Boot allows you to turn on your PC in just a few

seconds, provides a much more efcient way to save energy,

time, money, and improves system running speed for your sys-

tem. It leverages the S3 and S4 ACPI features which normally

enable the Sleep/Standby and Hibernation modes in Windows®

to shorten boot up time. By calling S3 and S4 at specic timing

during the shutdown and startup process, Instant Boot allows

you to enter your Windows®desktop in a few seconds.

ASRock Instant Flash

ASRock Instant Flash is a BIOS ash utility embedded in Flash

ROM. This convenient BIOS update tool allows you to update

system BIOS without entering operating systems rst like MS-

DOS or Windows®. With this utility, you can press the <F6> key

during the POST or the <F2> key to enter into the BIOS setup

menu to access ASRock Instant Flash. Just launch this tool and

save the new BIOS le to your USB ash drive, oppy disk or

hard drive, then you can update your BIOS only in a few clicks

without preparing an additional oppy diskette or other compli-

cated ash utility. Please be noted that the USB ash drive or

hard drive must use FAT32/16/12 le system.

ASRock APP Charger

If you desire a faster, less restricted way of charging your

Apple devices, such as iPhone/iPad/iPod Touch, ASRock has

prepared a wonderful solution for you - ASRock APP Charger.

Simply install the APP Charger driver, it makes your iPhone

charge much quickly from your computer and up to 40% faster

than before. ASRock APP Charger allows you to quickly charge

many Apple devices simultaneously and even supports continu-

ous charging when your PC enters into Standby mode (S1),

Suspend to RAM (S3), hibernation mode (S4) or power off (S5).

With APP Charger driver installed, you can easily enjoy the mar-

velous charging experience.

ASRock XFast USB

ASRock XFast USB can boost USB storage device perfor-

mance. The performance may depend on the properties of the

device.

ASRock XFast LAN

ASRock XFast LAN provides a faster internet access, which

includes the benefits listed below. LAN Application Prioritiza-

tion: You can congure your application’s priority ideally and/or

add new programs. Lower Latency in Game: After setting online

game’s priority higher, it can lower the latency in games. Trafc

Shaping: You can watch Youtube HD videos and download si-

multaneously. Real-Time Analysis of Your Data: With the status

window, you can easily recognize which data streams you are

transferring currently.

ASRock XFast RAM

ASRock XFast RAM is a new function that is included into AS-

Rock Extreme Tuning Utility (AXTU). It fully utilizes the memory

space that cannot be used under Windows®OS 32-bit CPU.

ASRock XFast RAM shortens the loading time of previously

visited websites, making web surfing faster than ever. And it

also boosts the speed of Adobe Photoshop 5 times faster. An-

other advantage of ASRock XFast RAM is that it reduces the

frequency of accessing your SSDs or HDDs in order to extend

their lifespan.

Otros manuales para H61M-HP4

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Placa madre de ASROCK

ASROCK

ASROCK X299 TAICHI CLX Manual de usuario

ASROCK

ASROCK SBC-220 Manual de usuario

ASROCK

ASROCK 4X4-4800U Manual de usuario

ASROCK

ASROCK IMB-185 Manual de usuario

ASROCK

ASROCK A75M Manual de usuario

ASROCK

ASROCK Z87E-ITX Manual de usuario

ASROCK

ASROCK P43DE3 Manual de usuario

ASROCK

ASROCK ALIVESATA2-GLAN Manual de usuario

ASROCK

ASROCK N68-S3 Manual de usuario

ASROCK

ASROCK Z77E-ITX Manual de usuario

ASROCK

ASROCK H61 Pro BTC Manual de usuario

ASROCK

ASROCK 990FX Extreme6 Manual de usuario

ASROCK

ASROCK IMB-171-D Instrucciones de uso

ASROCK

ASROCK P4V88-M Manual de usuario

ASROCK

ASROCK H81M-ITX Manual de usuario

ASROCK

ASROCK 4Core1333-Viiv Manual de usuario

ASROCK

ASROCK M3A785GMH 128M Manual de usuario

ASROCK

ASROCK A75M-HVS Manual de usuario

ASROCK

ASROCK 775Twins-HDTV Guía rápida

ASROCK

ASROCK WOLFDALE1333-GLAN Manual de usuario

ASROCK

ASROCK Z97M Pro4 Manual de usuario

ASROCK

ASROCK Z690 AQUA Manual de usuario

ASROCK

ASROCK CREATOR X299 Manual de usuario

ASROCK

ASROCK Z77 Extreme3 Manual de usuario

Manuales populares de Placa madre de otras marcas

DFI

DFI SD170 Manual de usuario

Asus

Asus P2L97A Manual de usuario

Winmate

Winmate IC70 Manual de usuario

Asus

Asus MES-B Manual de usuario

Grantech

Grantech SYS8F377VGGA-3OMN Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manual de usuario

Gigabyte

Gigabyte GA-9IVDT Manual de usuario

Texas Instruments

Texas Instruments ADS8372EVM Manual de usuario

Commell

Commell MS-C73 Manual de usuario

IBT Technologies

IBT Technologies MB860 Manual de usuario

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manual de usuario

Biostar

Biostar M7VIT Bravo Instrucciones de funcionamiento e instalación

Intel

Intel D33217CK Manual de usuario

Asus

Asus F1A55-M LX PLUS R2.0 Manual de usuario

EPC

EPC EPC9147C Manual de usuario

Asus

Asus EX-B760M-V5 D4 Manual de usuario

EPOX

EPOX MU-8KHA0010 Manual de usuario

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manual de usuario
