ASROCK H310M-STX Manual de usuario

Version 1.0

Published April 2018

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

AUSTRALIA ONLY

Our goods come with guarantees that cannot be excluded under the Australian Consumer

Law. You are entitled to a replacement or refund for a major failure and compensation for

any other reasonably foreseeable loss or damage caused by our goods. You are also entitled

to have the goods repaired or replaced if the goods fail to be of acceptable quality and the

failure does not amount to a major failure.

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Motherboard Layout 6

1.4 Front Panel 9

1.5 Rear Panel 10

Chapter 2 Installation 11

2.1 Installing the CPU 12

2.2 Installing the CPU Fan and Heatsink 15

2.3 Installing Memory Modules (SO-DIMM) 16

2.4 Onboard Headers and Connectors 18

2.5 M.2 WiFi/BT Module and Intel® CNVi (Integrated WiFi/BT)

Installation Guide 21

2.6 M.2_SSD (NGFF) Module Installation Guide 23

2.7SD Card Installation Guide 25

Chapter 3 Software and Utilities Operation 26

Chapter 4 UEFI SETUP UTILITY 27

4.1 Introduction 27

4.2 EZ Mode 28

4.3 Advanced Mode 30

4.3.1 UEFI Menu Bar 30

4.3.2 Navigation Keys 31

4.4 Main Screen 32

4.5 OC Tweaker Screen 33

4.6 Advanced Screen 41

4.6.1 CPU Conguration 42

4.6.2 Chipset Conguration 44

4.6.3 Storage Conguration 46

4.6.4 Super IO Conguration 47

4.6.5 ACPI Conguration 48

4.6.6 USB Conguration 49

4.7 Tools 50

4.8 Hardware Health Event Monitoring Screen 53

4.9 Security Screen 54

4.10 Boot Screen 55

4.11 Exit Screen 58

PB 1

English

H310M-STX / H310M-STX/COM

Chapter 1 Introduction

ank you for purchasing H310M-STX / H310M-STX/COM motherboard. In this

documentation, Chapter 1 and 2 contains the introduction of the motherboard

and step-by-step installation guides. Chapter 3 contains the operation guide of the

soware and utilities. Chapter 4 contains the conguration guide of the BIOS setup.

1.1 Package Contents

• H310M-STX / H310M-STX/COM Motherboard (Mini-STX Form Factor)

• H310M-STX / H310M-STX/COM Quick Installation Guide

• H310M-STX / H310M-STX/COM Support CD

• 1 x I/O Panel Shield

• 2 x Serial ATA(SATA) Data with Power Cable (Optional)

• 1 x Screw for M.2 Socket (M2*2) (Optional)

• 1 x Screw for WiFi Module (M2*2) (Optional)

Because the motherboard specications and the BIOS soware might be updated, the

content of this documentation will be subject to change without notice.

2 3

English

1.2 Specications

Platform • Mini-STX Form Factor

CPU • Supports 8th Generation Intel® CoreTM Processors (Socket

1151)

• Supports CPU up to 65W

• 5 Power Phase design

• Supports Intel® Turbo Boost 2.0 Technology

Chipset • Intel®H310

Memory • Dual Channel DDR4 Memory Technology

• 2 x DDR4 SO-DIMM Slots

• Supports DDR4 2666/2400/2133 non-ECC, un-buered

memory

• Max. capacity of system memory: 32GB

• Supports Intel® Extreme Memory Prole (XMP) 2.0

• 15μ Gold Contact in DIMM Slots

Expansion

Slot

• 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module

and Intel® CNVi (Integrated WiFi/BT)

Graphics • Intel® UHD Graphics Built-in Visuals and the VGA outputs

can be supported only with processors which are GPU

integrated.

• Supports Intel® UHD Graphics Built-in Visuals : Intel® Quick

Sync Video with AVC, MVC (S3D) and MPEG-2 Full HW

Encode1,

• Intel® InTruTM 3D, Intel® Clear Video HD Technology, Intel®

InsiderTM, Intel® UHD Graphics

• DirectX 12

• HWAEncode/Decode: AVC/H.264, HEVC/H.265 8-bit,

HEVC/H.265 10-bit, VP8, VP9 8-bit, VP9 10-bit (Decode

only), MPEG2, MJPEG, VC-1 (Decode only)

2 3

English

H310M-STX / H310M-STX/COM

• Max. shared memory 1024MB

* e size of maximum shared memory may vary from dierent

operating systems.

• ree graphics output options: D-Sub, HDMI and DisplayPort

1.2

* Supports up to 2 displays simultaneously

• Supports HDMI with max. resolution up to 4K x 2K

(4096x2160) @ 30Hz

• Supports D-Sub with max. resolution up to 1920x1200 @

60Hz

• Supports DisplayPort 1.2 with max. resolution up to 4K x 2K

(4096x2304) @ 60Hz

• Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR

(High Bit Rate Audio) with HDMI Port (Compliant HDMI

monitor is required)

• Supports HDCP with HDMI and DisplayPort 1.2 Ports

• Supports 4K Ultra HD (UHD) playback with HDMI and

DisplayPort 1.2 Ports

Audio • Realtek ALC233 Audio Codec

• 1 x Headphone/Headset Jack

• 1 x MIC-In

• 1 x Audio Header

LAN • Gigabit LAN 10/100/1000 Mb/s

• Giga PHY Intel® I219V

• Supports Wake-On-LAN

• Supports Lightning/ESD Protection

• Supports Energy Ecient Ethernet 802.3az

• Supports PXE

Front

Panel I/O

• 1 x Headphone/Headset Jack

• 1 x USB 3.1 Gen1 Type-A Port (Supports ESD Protection)

• 1 x USB 3.1 Gen1 Type-C Port (Supports ESD Protection)

• 1 x Microphone Input Jack

4 5

English

Rear Panel

I/O

• 1 x DC Jack (Compatible with the 19V power adapter)*

* Please use 120W power adapter for 65W CPU and 90W power

adapter for 35W CPU.

• 1 x D-Sub Port

• 1 x HDMI Port

• 1 x DisplayPort 1.2

• 1 x USB 2.0 Port (Supports ESD Protection)

• 1 x USB 3.1 Gen1 Port (Supports ESD Protection)

• 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

Storage • 2 x SATA3 6.0 Gb/s with Power Connectors, support NCQ,

AHCI and Hot Plug

• 1 x Ultra M.2 Socket, support type 2280 M.2 SATA3 6.0 Gb/s

module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)*

* Supports NVMe SSD as boot disks

Connector • 1 x COM Port Header (for H310M-STX/COM only)

• 1 x Chassis Intrusion Header

• 2 x CPU Fan Connectors (2 x 4-pin)

• 1 x Internal Speaker Header

• 1 x Front Panel Header

• 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD

Protection)

• 1 x SD Card Socket

• 1 x Audio Header

BIOS

Feature

• AMI UEFI Legal BIOS with multilingual GUI support

• ACPI 6.0 Compliant wake up events

• SMBIOS 2.7 Support

• DRAM Voltage Multi-adjustment

Hardware

Monitor

• CPU temperature sensing

• CPU Fan Tachometer

• CPU Quiet Fan (Auto adjust chassis fan speed by CPU

temperature)

• CPU Fan multi-speed control

• CASE OPEN detection

• Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore

4 5

English

H310M-STX / H310M-STX/COM

OS • Microso® Windows® 10 64-bit

Certica-

tions

• FCC, CE

• ErP/EuP ready (ErP/EuP ready power supply is required)

Mini-STX Chassis Support List

Please realize that there is a certain risk involved with overclocking, including adjusting

the setting in the BIOS, applying Untied Overclocking Technology, or using third-party

overclocking tools. Overclocking may aect your system’s stability, or even cause damage to

the components and devices of your system. It should be done at your own risk and expense.

We are not responsible for possible damage caused by overclocking.

Vendor Model

SilverStone Technology Inc. VT01S

AKasa A-STX04-A1B / A-STX04-M1B
