ASROCK B650M-HDV/M.2 Manual de usuario

Contact Information

If you need to contact ASRock or want to know more about ASRock, you’re

welcome to visit ASRock’s website at http://www.asrock.com; or you may contact

your dealer for further information. For technical questions, please submit a

support request form at https://event.asrock.com/tsd.asp

ASRock Incorporation

e-mail: info@asrock.com.tw

ASRock EUROPE B.V.

e-mail: sales@asrock.nl

ASRock America, Inc.

e-mail: sales@asrockamerica.com

Scan the QR code to view more manuals and documents.

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Motherboard Layout 5

1.4 I/O Panel 7

1.5 Block Diagram 8

Chapter 2 Installation 9

2.1 Installing the CPU 10

2.2 Installing the CPU Fan and Heatsink 13

2.3 Installing Memory Modules (DIMM) 21

2.4 Connecting the Front Panel Header 23

2.5 Installing the Motherboard 24

2.6 Installing SATA Drives 25

2.7 Installing a Graphics Card 27

2.8 Connecting Peripheral Devices 29

2.9 Connecting the Power Connectors 30

2.10 Power On 31

2.11 Jumpers Setup 32

2.12 Onboard Headers and Connectors 33

2.13 Smart Switches 41

2.14 Post Status Checker 43

2.15 M.2 WiFi/BT PCIe WiFi Module Installation Guide 44

2.16 M.2 SSD Module Installation Guide (M2_1) 46

2.17 M.2 SSD Module Installation Guide (M2_2) 50

English

B650M-HDV/M.2

Chapter 1 Introduction

ank you for purchasing ASRock B650M-HDV/M.2 motherboard, a reliable

motherboard produced under ASRock’s consistently stringent quality control.

It delivers excellent performance with robust design conforming to ASRock’s

commitment to quality and endurance.

1.1 Package Contents

• ASRock B650M-HDV/M.2 Motherboard (Micro ATX Form Factor)

• ASRock B650M-HDV/M.2 User Manual

• 2 x Serial ATA (SATA) Data Cables (Optional)

• 2 x Screws for M.2 Sockets (Optional)

Because the motherboard specications and the BIOS soware might be updated, the

content of this documentation will be subject to change without notice. In case any

modications of this documentation occur, the updated version will be available on

ASRock’s website without further notice. If you require technical support related to

this motherboard, please visit our website for specic information about the model

you are using. You may nd the latest VGA cards and CPU support list on ASRock’s

website as well. ASRock website http://www.asrock.com.

English

1.2 Specications

Platform • Micro ATX Form Factor

• 2oz Copper PCB

CPU • Supports AMD Socket AM5 RyzenTM 7000 Series Processors

Chipset • AMD B650

Memory • Dual Channel DDR5 Memory Technology

• 2 x DDR5 DIMM Slots

• Supports DDR5 non-ECC, un-buered memory up to

6400+(OC)*

• Max. capacity of system memory: 64GB

• Supports Extreme Memory Prole (XMP) and EXTended

Proles for Overclocking (EXPO) memory modules

* Please refer to Memory Support List on ASRock's website for

more information. (http://www.asrock.com/)

Expansion

Slot

CPU:

• 1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode*

• 1 x PCIe 4.0 x16 Slot (PCIE3), supports x4 mode*

Chipset:

• 1 x PCIe 4.0 x1 Slot (PCIE2)*

• 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe

WiFi module

* Supports NVMe SSD as boot disks

• Supports AMD CrossFireTM

• 15μ Gold Contact in VGA PCIe Slot (PCIE1)

Graphics • Integrated AMD RDNATM 2 graphics (Actual support may

vary by CPU)

• 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR,

HDCP 2.3 and max. resolution up to 4K 120Hz

• 1 x DisplayPort 1.4 with DSC (compressed), supports HDCP

2.3 and max. resolution up to 4K 120Hz

English

B650M-HDV/M.2

Audio • 7.1 CH HD Audio (Realtek ALC897 Audio Codec)

• Nahimic Audio

LAN • 2.5 Gigabit LAN 10/100/1000/2500 Mb/s

• Dragon RTL8125BG

• Supports Dragon 2.5G LAN Soware

- Smart Auto Adjust Bandwidth Control

- Visual User Friendly UI

- Visual Network Usage Statistics

- Optimized Default Setting for Game, Browser, and

Streaming Modes

- User Customized Priority Control

USB • 1 x USB 3.2 Gen2 Type-C (Front)

• 1 x USB 3.2 Gen1 Type-C (Rear)

• 6 x USB 3.2 Gen1 Type-A (2 Rear, 4 Front)

• 8 x USB 2.0 (4 Rear, 4 Front)

* All USB ports support ESD Protection

Rear Panel

I/O

• 2 x Antenna Mounting Points

• 1 x HDMI Port

• 1 x DisplayPort 1.4

• 1 x USB 3.2 Gen1 Type-C Port

• 2 x USB 3.2 Gen1 Type-A Ports

• 4 x USB 2.0 Ports

• 1 x RJ-45 LAN Port

• 1 x BIOS Flashback Button

• HD Audio Jacks: Line in / Front Speaker / Microphone

Storage CPU:

• 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280

PCIe Gen5x4 (128 Gb/s) mode*

Chipset:

• 1 x Hyper M.2 Socket (M2_2, Key M), supports type

2260/2280 PCIe Gen4x4 (64 Gb/s) mode*

• 4 x SATA3 6.0 Gb/s Connectors

* Supports NVMe SSD as boot disks

English

RAID • Supports RAID 0, RAID 1 and RAID 10 for SATA storage

devices

• Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe

storage devices*

* Requires additional M.2 NVMe expansion cards to support

RAID 10

Connector • 1 x SPI TPM Header

• 1 x Power LED and Speaker Header

• 1 x CPU Fan Connector (4-pin)*

• 3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan

Speed Control)**

• 1 x 24 pin ATX Power Connector

• 1 x 8 pin 12V Power Connector

• 1 x Front Panel Audio Connector

• 1 x underbolt AIC Connector (5-pin) (Supports ASRock

underbolt 4 AIC Card)

• 2 x USB 2.0 Headers (Support 4 USB 2.0 ports)

• 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports)

• 1 x Front Panel Type C USB 3.2 Gen2 Header

* CPU_FAN1 supports the fan power up to 1A (12W).

** CHA_FAN1~3/WP support the fan power up to 2A (24W).

** CHA_FAN1~3/WP can auto detect if 3-pin or 4-pin fan is in

use.

BIOS

Feature

• AMI UEFI Legal BIOS with GUI support

OS • Microso® Windows® 10 64-bit / 11 64-bit

Certica-

tions

• FCC, CE

• ErP/EuP ready (ErP/EuP ready power supply is required)

Please realize that there is a certain risk involved with overclocking, including

adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using

third-party overclocking tools. Overclocking may aect your system’s stability, or

even cause damage to the components and devices of your system. It should be done

at your own risk and expense. We are not responsible for possible damage caused by

overclocking.

* For detailed product information, please visit our website: http://www.asrock.com

English

B650M-HDV/M.2

1.3 Motherboard Layout

English

No. Description

1 8 pin 12V Power Connector (ATX12V1)

2 CPU Fan Connector (CPU_FAN1)

3 2 x 288-pin DDR5 DIMM Slots (DDR5_A1, DDR5_B1)

4 Chassis/Water Pump Fan Connector (CHA_FAN1/WP)

5 ATX Power Connector (ATXPWR1)

6 Front Panel Type C USB 3.2 Gen2 Header (USB32_TC2)

7 USB 3.2 Gen1 Header (USB32_3_4)

8 SPI TPM Header (SPI_TPM_J1)

9 USB 3.2 Gen1 Header (USB32_5_6)

10 SATA3 Connectors (SATA3_2)(Upper), (SATA3_1)(Lower)

11 SATA3 Connectors (SATA3_4)(Upper), (SATA3_3)(Lower)

12 System Panel Header (PANEL1)

13 Power LED and Speaker Header (SPK_PLED1)

14 Clear CMOS Jumper (CLRCMOS1)

15 Post Status Checker (PSC)

16 USB 2.0 Header (USB_7_8)

17 USB 2.0 Header (USB_5_6)

18 Chassis/Water Pump Fan Connector (CHA_FAN3/WP)

19 Chassis/Water Pump Fan Connector (CHA_FAN2/WP)

20 5-pin underbolt AIC Connector (TB1)

21 Front Panel Audio Header (HD_AUDIO1)
