Asante 10Base2 Mini MAU Manual de usuario
Mini MAU
Installation Guide
Copyright Notice
Copyright 1993 by Asanté Technologies, Inc.
All rights reserved. No part of this manual, or any
associated artwork, software, product design or
design concept, may be copied, reproduced or
stored, in whole or in part, in any form or by any
means mechanical, electronic, optical,
photocopying, recording or otherwise, including
translation to another language or format, without
the express written consent of Asanté
Technologies, Inc.
Trademarks
Asanté Technologies AsantéHub 2072 are
trademarks of Asanté Technologies, Inc.
Apple, AppleTalk, A/UX, EtherTalk, AppleShare, and
Macintosh are registered trademarks of Apple
Computer, Inc.
Ethernet is a registered trademark of the Xerox
Corporation, Inc.
All brand names and products are trademarks or
registered trademarks of their respective holders.
Asanté Warranty
Asanté Technologies, Inc. warrants that its
Ethernet interface products will be free from
defects in title, materials and manufacturing
workmanship for a period of one (1) year from the
date of purchase. If a Mini MAU is found to be
defective, then, as your sole remedy and as the
manufacturer’s only obligation, Asanté
Technologies, Inc. will repair or replace the
product provided that (1) you call Asanté
Technologies, Inc. for a Returned Merchandise
Authorization (RMA) number, that (2) you clearly
write the RMA number on the outside of the
package, and that (3) you return it, postage
prepaid, during the warranty period. This warranty
is exclusive and is limited to Asanté Ethernet
network interface products.
This warranty shall not apply to Asanté Ethernet
interface products that have been subjected to
abuse, misuse, abnormal electrical or
environmental conditions, or any condition other
than what can be considered normal use.
Asanté Warranty Disclaimer
Asanté Technologies, Inc. makes no other
warranties, express, implied or otherwise,
regarding Asanté Mini MAU products, and
specifically disclaims any warranty for
merchantability or fitness for a particular purpose.
The exclusion of implied warranties is not
permitted in some States and the exclusions
specified herein may not apply to you. This warranty
provides you with specific legal rights. There may be
other rights that you have which vary from State to
State.
Mini MAU
Page
1
Introduction
Thank you for purchasing a Mini MAU
from Asanté Technologies.
The Asanté Mini MAU is an ideal network
solution for connecting computers and
other peripherals with an AUI port to a
10BaseT, 10Base2 or 10BaseFL Ethernet
network.
minimau Page 1 Monday, August 26, 1996 11:02 AM
Mini MAU
Page
2
Asking for assistance
To contact Asanté Technical Support for
help:
Technical Support Hours
6:00 AM to 6:00 PM Pacific Standard Time,
Monday—Friday
Telephone
(800) 622-7464
(408) 435-0706
Fax
(408) 432-6018
Applelink
mail
ASANTE.TECH
Internet mai
l
minimau Page 2 Monday, August 26, 1996 11:02 AM
Mini MAU
Page
3
Product Overview
Asanté Mini MAUs
The Asanté Mini MAU plugs directly onto
the back of your PC, Macintosh or any
other network device that has a AUI inter-
face.
Asanté offers three types of MAUs:
❏
AUI to Mini MAU Unshielded
Twisted Pair (UTP)
❏
AUI to Mini MAU Thin Coax
❏
AUI to Mini MAU Fiber
The Mini MAUs are compatible with any
Ethernet device that has an AUI Ethernet
port.
❖
Note:
They are also designed to
slide into the recessed MAU slots of
the AsantéHub 2072 repeater mod-
ules.
❖
minimau Page 3 Monday, August 26, 1996 11:02 AM
Mini MAU
Page
4
Summary of Mini MAU Features
• Standards based transceivers for
unshielded twisted pair (UTP), thin
and fiber-optic Ethernet.
• Full compatibility with IEEE 802.3
specifications for 10BaseT,
10Base2, and 10BaseFL Ethernet.
• Diagnostic LEDS
• Ability to turn HBE on or off.
• Can be used as an accessory to
AsantéHub 2072 Repeater mod-
ules.
• 10BaseT Mini MAU includes
switch to enable and disable Link
Integrity, allowing for compatibil-
ity with pre-10BaseT devices.
minimau Page 4 Monday, August 26, 1996 11:02 AM
Mini MAU
Page
5
Mini MAU Media and Connectors
Mini MAU Media Connector Port
10BaseT
Mini MAU
UTP
Unshielded
Twisted Pair
RJ-45 AUI
10BaseFL
Mini MAU
Fiber ST AUI
10Base2
Mini MAU
Thin Coax BNC AUI
minimau Page 5 Monday, August 26, 1996 11:02 AM
Mini MAU
Page
6
Figure 1
Mini MAU for 10BaseT
AUI connection
(15-pin)
RJ-45 connection
Six LEDs
Switches
minimau Page 6 Monday, August 26, 1996 11:02 AM
Mini MAU
Page
7
Installation Mini MAU
The installation of an Asanté Mini MAU is
very simple:
1
Locate the AUI port on the
device.
The AUI is on the rear of your
hub or computer. Externally it
consists of the 15 pin AUI con-
nector.
2
Connect the Mini MAU to the
AUI port.
3
Connect the Ethernet cable to
the Mini MAU.
Twisted-pair cable (10BaseT) with
Mini MAU
Connect the 10BaseT Mini
MAU to the device’s AUI port.
Plug one end of the cable into
the 10BaseT port on the Mini
MAU.
minimau Page 7 Monday, August 26, 1996 11:02 AM
