AP-270 Series Outdoor Access Point

Installation Guide

0511511-05 | February 2014 1

The Aruba AP-274 and AP-275 are environmentally hardened, outdoor rated, dual-radio IEEE 802.11ac

wireless access points. These access points use MIMO (Multiple-in, Multiple-out) technology and other

high-throughput mode techniques to deliver high-performance, 802.11ac 2.4 GHz and 5 GHz functionality

while simultaneously supporting existing 802.11a/b/g/n wireless services. The AP-270 Series access point

works only in conjunction with an Aruba Controller.

AP-270 Series Operations

Wireless transceiver

Wireless access point (IEEE 802.11 a/b/g/n/ac)

Wireless air monitor (IEEE 802.11 a/b/g/n/ac)

Protocol-independent networking functionality

Compatibility with IEEE 802.3at PoE

Central management configuration and upgrades with an Aruba Controller.

Guide Overview

"AP-270 Series Hardware Overview" on page3 provides a detailed hardware overview of the AP-274 and

AP-275.

"Before You Begin" on page7 provides key questions to ask and items to consider when deploying an

outdoor wireless network.

"Installing the AP" on page9 describes the multi-step process for a successful installation and

deployment of the AP-274 and AP-275.

"Safety and Regulatory Compliance" on page21 provides an overview of safety and regulatory

compliance information.

Package Contents

AP-274 or AP-275 Access Point

Cable Glands x2

Copper Lug x1

M4x6 Screw x1

USB Console Cable

Installation Guide (this document)

The weatherproof caps for Ethernet, Console, and power interfaces are connected to the AP, not loose in the

package.

Mounting kits for use with the AP-270 Series access points are sold separately. Contact your Aruba sales

representative for details.

2AP-270 Series Outdoor Access Point | Installation Guide

Inform your supplier if there are any incorrect, missing, or damaged parts. If possible, retain the carton, including

the original packing materials. Use these materials to repack and return the unit to the supplier if needed.

AP-270 Series Outdoor Access Point | Installation Guide 3

AP-270 Series Hardware Overview

Figure 1 AP-275 Front View

Figure 2 AP-274 Front View (Aesthetic Cover Removed)

LED

The AP-270 Series is equipped with one LED that indicates the system status of the AP.

System LED

The antenna connectors of AP-274 are covered by an aesthetic cover in the package. The aesthetic cover can be

removed when necessary.

4AP-270 Series Outdoor Access Point | Installation Guide

Table 1 AP-270 Series LED Meanings during Boot Up

Table 2 AP-270 Series LED Meanings during Operation

Figure 3 AP-275 Rear View

LED Color/State Meaning

System LED Off No power to AP

Red Initial power-up

Green - Flashing AP booting

Green - Steady AP ready and 1000Mbps Ethernet link established. The LED turns

off after 1200 seconds

Green - Yellow, 6 seconds

period AP ready and 10/100Mbps Ethernet link established. The LED

turns off after 1200 seconds

LED Color/State Meaning

System LED Solid Red General fault

One blink off every 3

seconds Radio 0 fault (5 GHz)

Two quick blink off 0.5

seconds apart cycled every

3 seconds

Radio 1 fault (2.4GHz)

AC Power Interface

LAN Port

WAN Port

Grounding Point

USB Console Port and Reset button

AP-270 Series Outdoor Access Point | Installation Guide 5

Figure 4 AP-274 Rear View

USB Console Port

The USB Micro-B console port allows you to connect the AP to a terminal or a laptop for direct local

management. Use the included USB console cable to connect the AP. You can download the necessary

driver for USB-UART adapter from support.arubanetworks.com under the Tools & Resources tab.

Use the following setting to access the terminal:

Ethernet Ports

AP-270 Series is equipped with two10/100/1000Base-T (RJ-45) Gigabit Ethernet ports (WAN and LAN port)

for wired network connectivity. The WAN port supports 802.3at Power over Ethernet (PoE), accepting 48

VDC (nominal) as a standard defined Powered Device (PD) from a Power Sourcing Equipment (PSE) such

as a PoE midspan injector.

These ports have RJ-45 female connectors with the pin-outs shown in Figure 5.

Figure 5 Gigabit Ethernet Port Pin-Out

Reset Button

The reset button can be used to return the AP to factory default settings. To reset the AP:

1. Power off the AP.

2. Press and hold the reset button using a small, narrow object, such as a paperclip.

3. Power-on the AP without releasing the reset button. The system LED will flash within 5 seconds.

4. Release the reset button.

The system LED will flash again within 15 seconds indicating that the reset is completed. The AP will now

continue to boot with the factory default settings.

Table 3 Console Settings

Baud Rate Data Bits Parity Stop Bits Flow Control

9600 8 None 1 None

AC Power Interface

LAN Port

WAN Port

Grounding Point

USB Console Port and Reset button

1000Base-T Gigabit

Ethernet Port

RJ-45 Female

Pin-Out

Signal Name

BI_DC+

BI_DC-

BI_DD+

BI_DD-

BI_DA+

BI_DA-

BI_DB+

BI_DB-

Function

Bi-directional pair +C, POE Positive

Bi-directional pair -C, POE Positive

Bi-directional pair +D, POE Negative

Bi-directional pair -D, POE Negative

Bi-directional pair +A, POE Negative

Bi-directional pair -A, POE Negative

Bi-directional pair +B, POE Positive

Bi-directional pair -B, POE Positive

6AP-270 Series Outdoor Access Point | Installation Guide

AC Power Interface

The AP-270 Series is capable of AC power in the range of 100 - 240 VAC. The power cord or power

connector kit is sold separately.

Grounding Point

Always remember to protect the AP by installing grounding lines. The ground connection must be complete

before connecting power to the AP enclosure.

Figure 6 AP-275 Top View

Figure 7 AP-274 Top View

At the top of the AP-270 Series, the solar shield with the mounting holder is fixed onto the AP before

shipping from the factory.

Solar Shield

Mounting Holder

Solar Shield

Mounting Holder

AP-270 Series Outdoor Access Point | Installation Guide 7

Figure 8 AP-275 bottom View

Figure 9 AP-274 bottom View

External Antenna Connectors

The AP-274 is equipped with six external antenna connectors. The connectors are labeled 2G0, 2G1, 2G2,

5G0, 5G1 and 5G2, and correspond to 2.4/5Ghz radio chains 0,1, and 2.

Air Vent

The bottom of the AP-270 Series has an air vent to balance the pressure and humidity inside and outside the

AP. It also allows air exchange between the AP and the environment in a controlled way that doesn’t allow

water to get into the AP.

Before You Begin

Air Vent

FCC Statement: Improper termination of access points installed in the United States configured to non-US model

controllers will be in violation of the FCC grant of equipment authorization. Any such willful or intentional violation

may result in a requirement by the FCC for immediate termination of operation and may be subject to forfeiture (47

CFR 1.80).

8AP-270 Series Outdoor Access Point | Installation Guide

Pre-Installation Network Requirements

After WLAN planning is complete and the appropriate products and their placement have been determined,

the Aruba controller(s) must be installed and initial setup performed before the Aruba APs are deployed.

For initial setup of the controller, refer to the ArubaOS Quick Start Guide for the software version installed

on your controller.

Pre-Installation Checklist

Before installing your AP-275, be sure that you have the items listed below:

Gigabit Ethernet cable of required length

IEEE 802.3at compliant PoE source or AC power source

Aruba Mobility Controller configured and installed on the network

Layer 2/3 network connectivity to your AP

One of the following network services:

Aruba Discovery Protocol (ADP)

DNS server with an “A” record

DHCP Server with vendor specific options

Verifying Pre-Installation Connectivity

Before you install APs in a network environment, make sure that the APs will be able to locate and connect

to the controller when they are powered on.

Specifically, you must verify the following conditions:

When connected to the network, each AP is assigned a valid IP address.

APs can locate the controller.

EU Statement:

Lower power radio LAN product operating in 2.4 GHz and 5 GHz bands. Please refer to the ArubaOS User Guide for

details on restrictions.

Produit réseau local radio basse puissance operant dans la bande fréquence 2.4 GHz et 5 GHz. Merci de vous

referrer au ArubaOS User Guide pour les details des restrictions.

Low Power FunkLAN Produkt, das im 2.4 GHz und im 5 GHz Band arbeitet. Weitere Informationen bezlüglich

Einschränkungen finden Sie im ArubaOS User Guide.

Apparati Radio LAN a bassa Potenza, operanti a 2.4 GHz e 5 GHz. Fare riferimento alla ArubaOS User Guide per

avere informazioni detagliate sulle restrizioni.

Aruba Networks, Inc. in compliance with governmental requirements, has designed the AP-270 Series such that

only authorized network administrators can change configuration settings. For more information about AP

configuration, refer to the ArubaOS Quick Start Guide and ArubaOS User Guide.

Access points are radio transmission devices and as such are subject to governmental regulation. Network

administrators responsible for the configuration and operation of access points must comply with local broadcast

regulations. Specifically, access points must use channel assignments appropriate to the location in which the

access point will be used.

AP-270 Series Outdoor Access Point | Installation Guide 9

Refer to the ArubaOS Quick Start Guide for instructions on locating and connecting to the controller.

Identifying Specific Installation Locations

You can mount the AP-270 Series access point on a wall or pole. Use the AP placement map generated by

Aruba’s RF Plan software application to determine the proper installation location(s). Each location should

be as close as possible to the center of the intended coverage area and should be free from obstructions or

obvious sources of interference. These RF absorbers/reflectors/interference sources will impact RF

propagation and should have been accounted for during the planning phase and adjusted for in RF plan.

Identifying Known RF Absorbers/Reflectors/Interference Sources

Identifying known RF absorbers, reflectors, and interference sources while in the field during the

installation phase is critical. Make sure that these sources are taken into consideration when you attach an

AP to its fixed location. Examples of sources that degrade RF performance include:

Cement and brick

Objects that contain water

Metal

Microwave ovens

Wireless phones and headsets

Installing the AP

Using the Mounting Kits

The AP-270 Series can be installed on a wall or attached to a pole by using mounting kits. These mounting

kits are available as accessories and are sold separately:

Service to all Aruba products should be performed by trained service personnel only.

SKU for Mounting Kits

Part Number Description

AP-270-MNT-V1 Long mounting kit for wall and vertical pole mounting, 300 mm from vertical mounting

asset.

AP-270-MNT-V2 Short mounting kit for wall and vertical pole mounting, 75 mm from vertical mounting

asset.

The mounting kits above support multiple AP models. All installation images below show the 275 AP.

For details on AP-270-MNT-V1 and AP-270-MNT-V2, please refer to the AP-270-MNT-V1 Installation Guide and

AP-270-MNT-V2 Installation Guide.

10 AP-270 Series Outdoor Access Point | Installation Guide

Figure 10 Mounting Bracket (AP-270-MNT-V1)

Figure 11 Mounting Bracket (AP-270-MNT-V2)

Mounting the AP to a Wall

1. Begin by marking the mounting points on the wall in the location you have selected.

a. Put the mounting bracket (included in the mount kit) on the installation position against the wall.

b. Using the mounting bracket as the template, mark four mounting points on the wall.

2. Use a drill to create four holes on the four markings you created in the previous step.

3. Insert a anchor bolt into each drilled hole. Anchor bolts are not included in the mount kit.

4. Place the mounting bracket over the anchor bolts and press the bracket against the wall.

5. Place the washers and nut onto the bolt’s threaded end and tighten the nut till the mounting bracket is

firmly attached to the wall as shown in Figure 12 or Figure 13.

Figure 12 Attaching the Mounting Bracket (AP-270-MNT-V1) to a Wall

To install

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Punto de acceso inalámbrico de Aruba

Aruba

Aruba AP-65-MNT Guía de inicio rápido

Aruba

Aruba AP-504 RW Manual de usuario

Aruba

Aruba AP-318 Manual de usuario

Aruba

Aruba 200 Series Manual de usuario

Aruba

Aruba 310 Series Manual de usuario

Aruba

Aruba AP-60 Manual de usuario

Aruba

Aruba 503H Manual de usuario

Aruba

Aruba Instant On AP15 Manual de usuario

Aruba

Aruba 570EX Series Manual de usuario

Aruba

Aruba 324 Manual de usuario

Aruba

Aruba AP22 Manual de usuario

Aruba

Aruba 303H Series Manual de usuario

Aruba

Aruba AP-68P Manual de usuario

Aruba

Aruba 387 Series Manual de usuario

Aruba

Aruba 207 Series Manual de usuario

Aruba

Aruba AP-224 Manual de usuario

Aruba

Aruba AP-60 Manual de usuario

Aruba

Aruba 630 Series Manual de usuario

Aruba

Aruba AP-375ATEX Series Manual de usuario

Aruba

Aruba 360 Series Manual de usuario

Aruba

Aruba AP-130 Series Manual de usuario

Aruba

Aruba 303 Series Guía del usuario

Aruba

Aruba AP-375EX Manual de usuario

Aruba

Aruba AP-80MB Manual de usuario

Manuales populares de Punto de acceso inalámbrico de otras marcas

D-Link

D-Link DWL-2100AP - AirPlus Xtreme G Manual de usuario

Ubiquiti

Ubiquiti NanoStation NSM2 Manual de usuario

Cisco

Cisco Aironet 1550 Series Manual de usuario

Advantek Networks

Advantek Networks AWN-AP-54MR Manual de usuario

IP-COM

IP-COM AP355 Manual de usuario

Buffalo

Buffalo AirStation WLA-L11G Manual de usuario

EnGenius

EnGenius EnStationACv2 Manual de usuario

D-Link

D-Link DAP-3662 Manual de usuario

xG Technology

xG Technology xMax CN1300 Manual de usuario

Widelink

Widelink ezWave WAP-1100 Series Manual de usuario

Edimax

Edimax CAP1200 Manual de usuario

Ubiquiti

Ubiquiti LBE-5AC-Gen2 Manual de usuario

LuXout Shades

LuXout Shades LUXSHADE MOTION Manual de usuario

CreatComm

CreatComm TB5F Manual de usuario

SineDigital

SineDigital MW-1500AP(H) Manual de usuario

TP-Link

TP-Link AP9650 V1 Manual de usuario

Draytek

Draytek VIGORAP 902 Manual de usuario

EnGenius

EnGenius EAP350 Manual de usuario
