Arris SURFboard SBG10-RB Manual de usuario

User Manual of Product 1:

ARRIS Surfboard SBG10-RB DOCSIS 3.0 Cable Modem &

AC1600 Dual Band Wi-Fi Router, Approved for Cox, Spectrum,

Xfinity & Others (RENEWED)

Wi-Fi Cable Modem

SBG6950AC2SBG6950AC2

SBG7400AC2SBG7400AC2

SBG7600AC2SBG7600AC2

QUICK START GUIDE

2 3

In the box

Wi-Fi cable modem

SBG6950AC2

SBG7400AC2

SBG7600AC2

Power adapter

Soware License

& Warranty card

Quick Start Guide

SBG6950AC2

SBG7400AC2

SBG7600AC2

Introduction

Status indicators

Front panel LEDs

LED status indicators

Get started

Set up your Wi-Fi network connection

3.1 Download ARRIS SURFboard® Manager mobile app

3.2 Connect using your Wi-Fi enabled device

Web Manager

4 5

Status indicators Front panel LEDs

6 7

5 GHz wireless connection is made

between the Wi-Fi cable modem and

your Wi-Fi device

2.4 GHz wireless connection is made

between the Wi-Fi cable modem and

your Wi-Fi device

Wi-Fi cable modem is connected to

the network

Upstream (send) and Downstream

(receive) status

Power is properly connected to the

Wi-Fi cable modem

Flash

LED status indicators

Power

Send

Receive

Online

2.4 GHz

Wireless

5 GHz

Wireless

Note: If the Send/Receive LED is ﬂashing, this indicates

that the ﬁrmware for your Wi-Fi cable modem is

updating. You may not be able to access the Internet

during the ﬁrmware update. To access the Internet,

please wait 10 to 15 minutes for the ﬁrmware update to

ﬁnish.

The SBG6950AC2, SBG7400AC2, and SBG7600AC2

do not support Digital Subscriber Line service (twisted

pair telephone phone service) and also do not support

Satellite Internet service.

Note: Detailed LED status information is available online in the

SBG6950AC2, SBG7400AC2, & SBG7600AC2 User Guide at

the ARRIS support website, www.arris.com/selelp.

8 9

This SURFboard device is a combination of DOCSIS 3.0

cable modem and four-port Ethernet router withWi-Fi. It

uses DOCSIS 3.0 technology to provide ultra high-speed

Internet access on yourWi-Fi home or small business

network.

Using the connection capabilities of the Wi-Fi cable

modem, you can connect your computer and other

network-enabled devices via the four Ethernet ports or

the 2.4 GHz and 5 GHz Wi-Fi connections.TheWi-Fi

cable modem connects to the existing coaxial cable

connection in your home.

Note: For Internet connections, you need a cable service

connection (coaxial cable line) with a cable Internet

service provider. The SBG6950AC2, SBG7400AC2, and

SBG7600AC2 will not operate with a Digital Subscriber

Line service (DSL) (twisted pair phone line) or Satellite

Internet service.

Get started

10 11

Connect a coaxial cable (not included) to a cable wall

outlet or an RF splier (not included) and to the Cable

connector on the rear of your Wi-Fi cablemodem.

Tighten the

connector by hand.

12 13

Connect the power adapter to the Power port on the

rear of your Wi-Fi cablemodem and then plug it into

an electrical wall outlet that is not controlled by a wall

switch to power on your Wi-Fi cable modem.

Your Wi-Fi cable modem

will automatically power

ON when the power

adapter is connected.

(Optional step) Connect an Ethernet cable (not

included) to any Ethernet port on the rear of your

Wi-Fi cable modem and the Ethernet port on your PC

or laptop.

Note:

Alternatively, you

can connect your PC or

laptop to the Internet

via your existing Wi-Fi

connection.

14 15

Check the front panel LEDs on your Wi-Fi cable

modem. Aer a brief pause, the ﬁrst three LEDs

should light up SOLID blue.

The 2.4 GHz and 5 GHz wireless

LEDs will light up SOLID when Wi-Fi

connectivity is available and ready.

Note: For Internet access, you will need a cable service

connection.

Activate your newWi-Fi cable modem; choose one of

the following options:

• Call your cable service provider.

• Connect to your cable operator’s activation web

site using your computer or laptop:

Power ON your computer or laptop and log in.

Enter your service provider’s web browser URL:

• Comcast/Xﬁnity: www.xnity.com/acvate

• Cox: www.cox.com/acvate

• Spectrum: spectrum.net/selnstall

16 17

Set up your Wi-Fi

network connection

Do the following to set up your Wi-Fi network

connection:

3.1 Download ARRIS SURFboard®Manager

3.2 Connect using your Wi-Fi enabled device

3.1

Download the iOS or android version of the ARRIS

SURFboard Manager mobile app for your iOS or

android Wi-Fi enabled device to set up your Wi-Fi

home or small business network connection.

Download ARRIS SURFboard® Manager mobile app
