Chapter 1

Conventions and Feedback

The following describes the typographical conventions and how to give feedback:

Typographical conventions

The following typographical conventions are used:

monospace

Denotes text that can be entered at the keyboard, such as commands,

file and program names, and source code.

monospace

Denotes a permitted abbreviation for a command or option. The

underlined text can be entered instead of the full command or option

name.

monospace italic

Denotes arguments to commands and functions where the argument is

to be replaced by a specific value.

monospace bold

Denotes language keywords when used outside example code.

italic Highlights important notes, introduces special terminology, denotes

internal cross-references, and citations.

bold Highlights interface elements, such as menu names. Also used for

emphasis in descriptive lists, where appropriate, and for ARM®

processor signal names.

Feedback on this product

If you have any comments and suggestions about this product, contact your

supplier and give:

• your name and company

Conventions and Feedback

ID120712 Non-Confidential

• the serial number of the product

• details of the release you are using

• details of the platform you are using, such as the hardware platform,

operating system type and version

• a small standalone sample of code that reproduces the problem

• a clear explanation of what you expected to happen, and what actually

happened

• the commands you used, including any command-line options

• sample output illustrating the problem

• the version string of the tools, including the version number and build

numbers.

Feedback on content

If you have comments on content then send an e-mail to

[email protected]

. Give:

• the title

• the number, ARM DUI 0482K

• if viewing online, the topic names to which your comments apply

• if viewing a PDF version of a document, the page numbers to which your

comments apply

• a concise explanation of your comments.

ARM also welcomes general suggestions for additions and improvements.

ARM periodically provides updates and corrections to its documentation on the ARM

Information Center, together with knowledge articles and Frequently Asked Questions (FAQs).

Other information

• ARM Information Center,

http://infocenter.arm.com/help/index.jsp

• ARM Technical Support Knowledge Articles,

http://infocenter.arm.com/help/topic/com.arm.doc.faqs/index.html

• ARM Support and Maintenance,

http://www.arm.com/support/services/support-maintenance.php.

• ARM Glossary, http://infocenter.arm.com/help/topic/com.arm.doc.aeg0014-/index.html

ID120712 Non-Confidential

Chapter 2

Setting Up Your Target

ARM Streamline Performance Analyzer is a system-wide visualizer and profiler for targets

running ARM Linux or Android native applications and libraries. Combining an ARM Linux

kernel driver, target daemon, and a graphical user interface, it transforms system trace and

sampling data into reports that present the data in both visual and statistical forms. Streamline

uses hardware performance counters with kernel metrics to provide an accurate representation

of system resources. Streamline supports Cortex™-A5, Cortex-A7, Cortex-A8, Cortex-A9,

Cortex-A15, ARM9™, ARM11™, and Qualcomm Snapdragon™Scorpion and Krait processors

running ARM Linux or Android.

The following topics describe how to set up your target to run Streamline:

•Setting up an ARM Linux target on page 2-2

•Setting up an Android target on page 2-6

•Recommended compiler options on page 2-10

•Mali setup for Streamline on page 2-11

Setting Up Your Target

ID120712 Non-Confidential

2.1 Setting up an ARM Linux target

These instructions are specific to targets running ARM Linux.

Note

You can locate all of the files provided by DS-5 by selecting Help → ARM Extras... from the

main menu.

2.1.1 Prerequisites

You must have the following tools on your host to build the Linux kernel and the gator driver:

• Linux kernel source code for the target platform. Streamline supports only Linux kernel

versions 2.6.32 and above.

• Either the cross compiler for building the Linux kernel or the ARM Linux GCC that

comes with DS-5.

Note

Streamline only supports hardware targets, not Real Time System Models (RTSMs). Streamline

can run on an RTSM, but an RTSM does not provide the cycle and timing information to make

the samples-generated data in the reports meaningful.

2.1.2 Load the gator daemon

The gator daemon and driver collect target metrics and then send them to your host machine.

To enable profiling, you must build and load the gator daemon on your target. Follow these steps

to build the gator daemon from the source archive:

1. Move to the directory that contains the gator daemon source:

cd .../gator/daemon-src

2. Enter the following commands to unzip the archive:

tar -xzf gator-daemon.tar.gz

Note

Make sure to untar this file in a directory in which you have write privileges.

3. Change directories to the newly created

gator-daemon

cd gator-daemon

4. Issue the make command to build

gatord

make

5. Move the newly created

gatord

to your host.

Note

You must build the gator daemon on your g++-enabled target or a Linux host. On a Linaro

Ubuntu target you must enter the following command to install g++:

apt-get install g++

Setting Up Your Target

ID120712 Non-Confidential

It is not possible to build the gator daemon on a Windows host.

2.1.3 Prepare and build your kernel

To prepare your kernel for use with Streamline, download one of the supported versions of the

Linux kernel, configure it to your target platform, customize it, and then build it. For instructions

on how to do this and the required kernel code, visit http://www.kernel.org

Add the following steps when compiling a kernel for use with Streamline:

• Enter the following command in your shell to export the cross compiler:

export CROSS_COMPILE=${CROSS_TOOLS}/bin/arm-linux-gnueabihf-

• To specify that this build is for an ARM architecture, enter the following command in your

shell:

export ARCH=arm

• Enter the following to build the configuration file specific to your platform:

make platform_defconfig

Replace platform_defconfig in the command with one of the configuration files located in

the

your_kernel/arch/arm/configs

directory appropriate for your platform or with a

configuration file provided by a vendor.

• To configure menus, enter the following in your shell:

make menuconfig

You must enable certain kernel configuration options to run Streamline. The location of

some of these options depends on your kernel version:

General Setup

Enable the Profiling Support option,

CONFIG_PROFILING

and the Kernel

performance event and counters option,

CONFIG_PERF_EVENTS

Kernel Hacking

Enable the Tracers option,

CONFIG_FTRACE

, and the Tracers → Trace process

context switches and events option,

CONFIG_ENABLE_DEFAULT_TRACERS

. You

must add the following options,

To populate the Mutex CPU Wait chart you must enable the Kernel

hacking → Mutex debugging: basic checks option,

CONFIG_DEBUG_MUTEXES

and.the Kernel hacking → Compile the kernel with debug info option,

CONFIG_DEBUG_KERNEL_INFO

. For more information on CPU wait time data and

charts in Streamline, see Timeline view charts on page 6-10.

Kernel Features

Enable the High Resolution Timer Support option,

CONFIG_HIGH_RES_TIMERS

and the Enable hardware performance counter support option,

CONFIG_HW_PERF_EVENTS

. Enable the Use local timer interrupts option,

CONFIG_LOCAL_TIMERS

, if you are using a Symmetric MultiProcessing (SMP)

target.

CPU Power Management

To enable the CPU Freq Timeline view chart,

gator

requires kernel version

2.6.38 or greater and that you define the CPU Frequency scaling → CPU

Frequency scaling option,

CONFIG_CPU_FREQ

Setting Up Your Target

ID120712 Non-Confidential

Note

The Trace context switches and events option,

CONFIG_ENABLE_DEFAULT_TRACERS

, is not be

visible if you have other Tracers configuration options enabled. Enabling other Tracers

configuration options is sufficient to turn on context switches and events and run

Streamline.

Note

The Trace process context switches and events option is not the only option that enables

tracing.

CONFIG_GENERIC_TRACER

CONFIG_TRACING

also work. The Trace process context

switches and events option may not be visible in menuconfig as an option if other trace

configurations are enabled. Enabling one of these other trace configurations works fine to

turn on tracing.

• Use the following command to build the image:

make -j5 uImage

You may verify all of your kernel options on a running system using

/proc/config.gz

, if it exists

on your system. For example, to confirm that

CONFIG_PROFILING

is enabled, enter:

zcat

/proc/config.gz | grep CONFIG_PROFILING

2.1.4 Build the gator module

To use Streamline with your ARM target, you may build the gator driver on a Linux host or build

it locally on your target.

DS-5 provides a

gator-driver.tar.gz

source archive. Assuming that you have unzipped the file

and that you have all of the required tools for building kernel modules, enter the following

command on your target to create the

gator.ko

module:

make -C kernel_build_dir M=`pwd` ARCH=arm CROSS_COMPILE=<...> modules

Note

You can build the gator module on your target. To do so, it is not necessary to include the ARCH

or CROSS_COMPILE parameters. Enter the following command on your target: make -C

kernel_build_dir M=`pwd`.

2.1.5 Run the gator daemon on your target

When all of the necessary files are in place, you can start the gator daemon.

To run

gatord

1. Copy

gatord

and

gator.ko

into the file system on the target.

2. To ensure

gatord

has execute permission, enter the following command:

chmod +x gatord

3. If

gatord

is in a different directory than

gator.ko

on the target, you must either:

• Insert the gator.ko module manually using the following command:

insmod gator.ko

• Include the path to

gator.ko

using the -m option of gatord. For example: ./gatord

-m /home/gator/gator.ko &.

Otros manuales para DSTREAM DS-5

Tabla de contenidos

Otros manuales de Hardware de computadora de ARM

ARM

ARM ARM7TDMI Manual de operación y mantenimiento

ARM

ARM Cortex A9 Manual del producto

ARM

ARM Cortex-A76 Core Manual del producto

ARM

ARM DSTREAM Instrucciones de uso

ARM

ARM DSTREAM-ST Manual de usuario

ARM

ARM DSTREAM-PT Manual de usuario

ARM

ARM DSTREAM-HT Manual de usuario

ARM

ARM PrimeCelL PL320 Manual del producto

ARM

ARM ARM946E-S Manual del producto

ARM

ARM ETB11 Manual del producto

ARM

ARM ARM926EJ-S Manual del producto

ARM

ARM MPS2 Manual del producto

ARM

ARM DSTREAM DS-5 Manual de usuario

ARM

ARM ARM9TDMI Manual del producto

ARM

ARM MPS3 Manual de usuario

ARM

ARM Cordio BT4 Radio IP Manual de usuario

ARM

ARM ARM710T Manual de usuario

ARM

ARM Cortex-M3 DesignStart Manual del producto

ARM

ARM DSTREAM-HT Manual de usuario

ARM

ARM DSTREAM Instrucciones de uso

ARM

ARM OKI ML671000 Manual de usuario

ARM

ARM Cortex-M3 DesignStart Manual del producto

ARM

ARM Cortex-M0 Manual del producto

ARM

ARM Cortex-A35 Manual del producto

Manuales populares de Hardware de computadora de otras marcas

EMC2

EMC2 VNX Series Manual del propietario

Panasonic

Panasonic DV0PM20105 Manual de usuario

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manual de usuario

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manual de usuario

Raidon

Raidon iT2300 Manual de usuario

National Instruments

National Instruments PXI-8186 Manual de usuario

Hauppauge

Hauppauge WinTV-HVR-2250 Manual de usuario

Kontron

Kontron CP6002 Manual de usuario

Manhattan

Manhattan 702843 Manual de usuario

Aphex

Aphex 230 Manual de usuario

AMD

AMD Phenom II Manual operacional

Intel

Intel NUC 12 Pro Manual de usuario

dbx

dbx Zone Pro 1260 Manual de usuario

Galaxy

Galaxy GHDX2-2430S-24F4D Manual de usuario

Intel

Intel AXXRMFBU4 Manual de usuario

Kontron

Kontron DIMM-PC/MD Manual de usuario

ST X-NUCLEO-SAFEA1B Instrucciones de funcionamiento

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manual de usuario
