Arecont Vision AV2325DNIR Manual de usuario

MicroBullet®

Installation Manual

Models

1080p

AV2325DNIR

AV2326DNIR

3 Megapixel

AV3325DNIR

AV3326DNIR

Available from A1 Security Cameras

www.a1securitycameras.com email:[email protected]

! ! Installation Manual

Page | 2support@arecontvision.com

+1.818.937.0700 877.CAMERA.8 www.arecontvision.com avsales@arecontvision.com

MicroBullet®

Contents

Package Contents!..................................................................................................................................................!3!

Camera Overview!...................................................................................................................................................!5!

Installation!................................................................................................................................................................!6!

Electrical Box Adapter!......................................................................................................................................!7!

Adjusting the Pan, Tilt and Focus!........................................................................................................................!8!

Camera Power Up!..................................................................................................................................................!9!

Camera Discovery, Setup, and Configuration!..................................................................................................!11!

Network Protocols!................................................................................................................................................!11!

General Remote Focus!........................................................................................................................................!13!

Refined Remote Focus!........................................................................................................................................!14!

AV IP Utility Focus Tab........................................................................................................................... 16

Mounting Templates!.............................................................................................................................................!17!

Support!...................................................................................................................................................................!18!

Available from A1 Security Cameras

www.a1securitycameras.com email:[email protected]

! ! Installation Manual

Page | 3support@arecontvision.com

+1.818.937.0700 877.CAMERA.8 www.arecontvision.com avsales@arecontvision.com

MicroBullet®

CAUTION!

1. Do not attempt to service a damaged unit yourself. Refer all servicing to qualified service

personnel.

2. Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/ANSI, and

with all local codes and authorities having jurisdiction. Wiring should be UL Listed and/or

Recognized wire suitable for the application.

3. Always use hardware e.g. screws, anchors, bolts, locking nuts etc. which are compatible with

mounting surface and of sufficient length and construction to insure a secure mount.

Package Contents

This equipment should be unpacked and handled with care. The original packaging is the safest

container in which to transport the unit and can be used if returning the unit for service. The packaging

contains:

Reference #

Description

1x Arecont Vision MicroBullet®camera

camera

3x M4x25mm Wood/ Metal Sheet Screw

3x M4x25mm Drywall/ Masonry Mounting Anchors

1x Camera Mounting Template

1x L Key

1x CD with Manual and Software

Available from A1 Security Cameras

www.a1securitycameras.com email:[email protected]

! ! Installation Manual

Page | 4support@arecontvision.com

+1.818.937.0700 877.CAMERA.8 www.arecontvision.com avsales@arecontvision.com

MicroBullet®

Warranty Information

Global (3 Year) Limited Warranty

ARECONT VISION warrants to Purchaser (and only Purchaser) (the “Limited Warranty”), that: (a) each

Product shall be free from material defects in material and workmanship for a period of thirty-six (36)

months from the date of shipment (the “Warranty Period”); (b) during the Warranty Period, the

Products will materially conform with the specification in the applicable documentation; (c) all licensed

programs accompanying the Product (the “Licensed Programs”) will materially conform with applicable

specifications. Notwithstanding the preceding provisions, ARECONT VISION shall have no obligation or

responsibility with respect to any Product that (i) has been modified or altered without ARECONT

VISION’s written authorization; (ii) has not been used in accordance with applicable documentation; (iii)

has been subjected to unusual stress, neglect, misuse, abuse, improper storage, testing or connection;

or unauthorized repair; or (iv) is no longer covered under the Warranty Period. ARECONT VISION

MAKE NO WARRANTIES OR CONDITIONS, EXPRESS, IMPLIED, STATUTORY OR OTHERWISE,

OTHER THAN THE EXPRESS LIMITED WARRANTIES MADE BY ARECONT VISION ABOVE, AND

ARECONT VISION HEREBY SPECIFICALLY DISCLAIMS ALL OTHER EXPRESS, STATUTORY AND

IMPLIED WARRANTIES AND CONDITIONS, INCLUDING THE IMPLIED WARRANTIES OF

MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, NON-INFRINGEMENT AND THE

IMPLIED CONDITION OF SATISFACTORY QUALITY. ALL LICENSED PROGRAMS ARE LICENSED

ON AN “AS IS” BASIS WITHOUT WARRANTY. ARECONT VISION DOES NOT WARRANT THAT (I)

THE OPERATION OF THE PRODUCTS OR PARTS WILL BE UNINTERRUPTED OR ERROR FREE;

(II) THE PRODUCTS OR PARTS AND DOCUMENTATION WILL MEET THE END USERS’

REQUIREMENTS; (III) THE PRODUCTS OR PARTS WILL OPERATE IN COMBINATIONS AND

CONFIGURATIONS SELECTED BY THE END USER; OTHER THAN COMBINATIONS AND

CONFIGURATIONS WITH PARTS OR OTHER PRODUCTS AUTHORIZED BY ARECONT VISION

OR (IV) THAT ALL LICENSED PROGRAM ERRORS WILL BE CORRECTED.

For RMA and Advance Replacement information visit http://www.arecontvision.com

Available from A1 Security Cameras

www.a1securitycameras.com email:[email protected]

! ! Installation Manual

Page | 5support@arecontvision.com

+1.818.937.0700 877.CAMERA.8 www.arecontvision.com avsales@arecontvision.com

MicroBullet®

Camera Overview

The MicroBullet®multi-megapixel camera series delivers 1080p or 3-megapixel resolutions in an

extremely compact design. These true day/ night cameras are available with a 2.8-8mm motorized lens,

day/night mechanical IR cut filter, and integrated IR LEDs. MicroBullet is ideal for applications with

normal to challenging lighting conditions regardless of the time of day.

MicroBullet megapixel IP cameras deliver professional surveillance, with ease of installation and set-up

for a wide variety of requirements. The remote focus and zoom motorized lens allows users to simply

click “Short-range Focus” or “Full-range Focus”, saving installers time and end users money. For

applications with strong backlighting, reflections from wet flooring or puddles, or contrast due to fog,

mist, or glare, wide dynamic range 1080p and 3MP models are available. MicroBullet features

CorridorView™for better coverage of hallways and corridors, and SNAPstream™(Smart Noise

Adaptation and Processing) to reduce bandwidth without impacting image quality.

MicroBullet megapixel IP cameras are IP66 rated for both indoor and outdoor applications. All models

feature an impact resistant cast-aluminum housing capable of withstanding the equivalent of 55 kg (120

lbs) of force. The MicroBullet is ONVIF (Open Network Video Interface Forum) Series S and PSIA

(Physical Security Interoperability Alliance) compliant, providing interoperability between network video

products regardless of manufacturer.

Available from A1 Security Cameras

www.a1securitycameras.com email:[email protected]

! ! Installation Manual

Page | 6support@arecontvision.com

+1.818.937.0700 877.CAMERA.8 www.arecontvision.com avsales@arecontvision.com

MicroBullet®

Installation

The MicroBullet®camera can be directly attached onto hard ceilings or walls including wood, plastic,

metal and concrete.

1. Determine a secure location to mount the camera.

2. Use the template, anchors, and screws provided to prepare the mounting provisions for the

camera installation.

3. Install four supplied dry wall anchors using the supplied mounting template.

4. Align four supplied screws with the dry wall anchors and McroBullet camera into place as

shown in Figure 1.

Figure 1

5. To configure the camera, reference the camera discovery, set-up and configuration section.

Available from A1 Security Cameras

www.a1securitycameras.com email:[email protected]

! ! Installation Manual

Page | 7support@arecontvision.com

+1.818.937.0700 877.CAMERA.8 www.arecontvision.com avsales@arecontvision.com

MicroBullet®

Electrical Box Adapter

AV-EBAS(sold separately) and MCD-EBA(sold separately) are used to attach the camera to a

common single, double or square electrical box.

1. Use the supplied machine screws from AV-EBAS/ MCD-EBA, match the mounting holes on AV-

EBAS/ MCD-EBA with the threaded holes on the electrical box. Ensure every threaded hole is

matched with a mounting hole.

2. Attach AV-EBAS/ MCD-EBA to the user supplied electrical box.

3. Attached MicroBullet camera to AV-EBAS/ MCD-EBA. Match the mounting holes on MicroBullet

camera with the threaded holes (#4) on AV-EBAS/ MCD-EBA as shown in Figure 2. Ensure

every threaded hole is matched with a mounting hole.

Figure 2: AV-EBAS and MCD-EBA

Available from A1 Security Cameras

www.a1securitycameras.com email:[email protected]

! ! Installation Manual

Page | 8support@arecontvision.com

+1.818.937.0700 877.CAMERA.8 www.arecontvision.com avsales@arecontvision.com

MicroBullet®

Adjusting the Pan, Tilt and Focus

1. Loose Hex screws on the camera bracket with the supplied Hex screw L-key, and then adjust

the pan, tilt, and rotation position to obtain the desired field of view as shown in Figure 3.

NOTE: Do not remove the screws!

!!!!!!!!!!!!!!!!!!! !

Figure 3: Loose Hex screws on the camera bracket to adjust the field of view

2. To adjust the zoom and focus, see the Remote Zoom/ Focus Section of this manual.

Available from A1 Security Cameras

www.a1securitycameras.com email:[email protected]

! ! Installation Manual

Page | 9support@arecontvision.com

+1.818.937.0700 877.CAMERA.8 www.arecontvision.com avsales@arecontvision.com

MicroBullet®

Camera Power Up

This product should be installed by a qualified service technician in accordance with the

National Electrical Code (NEC 800 CEC Section 60) or applicable local code.

1. Connect the camera to a PoE port on 100Mbps network PoE switch using an Ethernet cable as

shown in the image below.

Reference #

Description

PoE Connector

2. Connect the PoE switch to your computer’s network port using an Ethernet cable.

NOTE:&A&yellow&LED&on&the&rear&of&the&camera&illuminates&after&a&few&seconds.&&

•The flashing yellow LED indicates that a link to your computer has been established.

•A green LED will blink when the camera has been accessed.

Available from A1 Security Cameras

www.a1securitycameras.com email:[email protected]

! ! Installation Manual

Page | 10 support@arecontvision.com

+1.818.937.0700 877.CAMERA.8 www.arecontvision.com avsales@arecontvision.com

MicroBullet®

NOTE: Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/ANSI, and

with all local codes and authorities having jurisdiction. Wiring should be UL Listed and/or Recognized

wire suitable for the application.

LED

Status

Description

Yellow

Flashing

Link has been established.

Solid

Normal Operation.

Green

Flashing

Camera has been accessed. Normal operation.

Solid

N/A

None

No Connection.
