Archos Hello 7 Manual de usuario
Quick Start Guide
3EN
Joining us
twitter.com/archos
www.facebook.com/archos
Blog https://blog.archos.com/
http://faq.archos.com/
www.archos.com, click Support > After-sales support
www.archos.com, click Support > Downloads > Declaration of conformity
As we are often updating and improving our products, your device’s software may have
a slightly dierent appearance or modified functionality than presented in this quick start
guide.
4
2
3
4
789
5
1
6
Describing your device
1. ON/OFF
2. Camera cover
3. Volume +/-
4. Mic Mute
5. Back speaker
6. Non-skid pad
7. Micro SD slot
8. Micro USB port
9. DC-in charging port
5
14
11
10
12 13
EN
Describing your device
10. Microphones
11. Touch screen
12. Camera
13. LED light
14. Front speaker
Privacy
You can hide the
camera with the camera cover and turn
o the mic with the Mic Mute button.
Meaning of the LED indicator
-Red light: Mic deactivated
-No light: Mic activated
-Yellow light: Low battery
6
Starting up
Installing your ARCHOS Hello 7
1. First, plug in the charging cable into the DC-in port of the ARCHOS Hello 7.
2. Plug in the charger to a socket.
Note: your device is battery-powered. We advise you to keep it plugged.
We recommend to install the device on a plain surface.
Sleep Mode of your ARCHOS Hello 7
When your device is in sleep mode, you can still wake it up with your voice and launch
apps. To see the results, unlock your screen. You can set up the time when the device goes
in sleep mode. To do so, go to the Settings app.
Removing a home screen item:
Touch and hold it, slide your finger towards the top of the screen and drop it over the
Remove icon.
7EN
Starting up
Uninstalling an item
From the All apps screens, touch and hold it, slide your finger towards the top of the screen
and drop it over Uninstall bin.
Creating application folders
Drop one app icon over another on a home screen and the two icons will be combined.
Changing your wallpaper
Hold your finger on a home screen at an empty location, then choose from the list:
Wallpaper.
Widgets:
Hold your finger on a home screen at an empty location, then choose from the list: Widgets.
Securing your device
Define a lock screen to protect your privacy. Select the Settings app, then Security.
Choose a screen lock.
8
EN
Troubleshooting
-If your device is frozen:
Press the ON/OFF button for 10 seconds or use the reset button.
-If your device doesn’t turn on:
1. Charge your device.
2. Press the ON/OFF button for 10 seconds.
-If your device functioning is too slow:
Close all apps which are not currently used.
-If your WiFi reception is too low:
Make sure you are not far from the WiFi hotspot.
Reset and redefine your connection parameters.
Contact your WiFi connection provider.
-If your device has dysfunctions:
Reinitialize your device. Go to Settings > Backup & reset > Factory data reset. If you can’t
have access to the settings for any reason, consult our FAQs about the reinitialization
process.
For more answers about your technical diculties, do not hesitate to visit: faq.archos.com
9FR
Contactez-nous
twitter.com/archos
www.facebook.com/archos
Blog https://blog.archos.com/
http://faq.archos.com/
www.archos.com, cliquez Support > Service Après-vente
www.archos.com, click Support > Téléchargements > Déclaration de conformité
Des appareils compatibles ou/et des abonnements à des services complémentaires
peuvent être nécessaires pour profiter pleinement de votre ARCHOS Hello 7.
10
2
3
4
789
5
1
6
Description du ARCHOS Hello 7
1. ON/OFF
2. Cache
3. Volume +/-
4. Désactivation du micro
5. Haut-parleur arrière
6. Pad antidérapant
7. Emplacement Micro SD
8. Port Micro USB
9. Connecteur de charge
