Archos 79 Xenon Manual de usuario

ENEN

Table of contents

For more information, please consult the FAQs on www.archos.com. Make sure to read them before considering any

product return. Your deal may be no big deal. As we are often updating and improving our products, your device’s

software may have a slightly dierent appearance or modied functionality than presented in this Quick Start Guide.

Package contents...................................................................................................................................

Getting started........................................................................................................................................

Description of the device.....................................................................................................................

Inserting SIM & Micro-SD cards.........................................................................................................

3G & WiFi connection...........................................................................................................................

The AndroidTM interface.......................................................................................................................

Getting familiar with AndroidTM......................................................................................................

Troubleshooting...................................................................................................................................

Warranty

02-09-2013

last modification:

A79 Xenon

CONFIDENTIAL

DRAWING

Rev

scale1:1 mm

134,3

200

USB cable Charger

QSG booklet

Warranty,

legal & safety booklet

Package Contents

ARCHOS 79Xenon

ENEN

Getting Started

TIP:

To receive more complete service, please register your product.

From a computer, go to www.archos.com/register.

Charging 1. Charge your device by plugging your power cable into the

power connector. The ARCHOS device will start charging.

2. Press the Power button to turn on the device.

The charging indicator light is on when the battery is charging.

-You can use your ARCHOS whilst it charges.

-Let your device charge completely the rst time you use it.

-Use only the supplied charger.

When your device is completely discharged, you need to

charge it for at least 10 minutes before the charging battery

icon can be displayed.

02-09-2013

last modification:

A79 Xenon

CONFIDENTIAL

DRAWING

Rev

scale 1:1 mm

134,3

200

6 7

02-09-2013

last modification:

A79 Xenon

CONFIDENTIAL

DRAWING

Rev

scale 1:1 mm

134,3

200

02-09-2013

last modification:

A79 Xenon

CONFIDENTIAL

DRAWING

Rev

scale 1:1 mm

134,3

200

Description of the device

Webcam

Loudspeaker

Volume buttons

Camera

ON/OFF button

Micro-USB port

Headphone jack

Notch

Microphone

Loudspeakers

SIM TF

2 1

ENEN

Inserting SIM & Micro-SD cards

WARNING: Make sure to turn o your device before inserting the SIM & memory cards.

Opening

Use the notch to remove the back cover.

Do not bend or twist the back cover excessively. Doing so may damage the cover.

Inserting a SIM card

For your 3G SIM card, slide it facing downwards in the 2G/3G slot (slot 1).

Inserting a Memory card

Slide it facing downwards in the slot 2.

Closing

Replace the back cover clicking it back into position.

12G/3G SIM card

2Memory card

3G & WiFi connection

3G connection

To be able to access Internet, the mobile data icon must be

activated.

Activating the mobile data

1. Touch and hold the time & battery icons to reveal the status bar.

2. Pull the blue line down to display the status dashboard.

3. Touch the mobile data icon to activate it.

When the mobile data is activated, it turns blue.

If your device does not connect to your 3G provider’s network

Contact your 3G provider to obtain the connection parameters.

On your device, tap Settings.

Select Wireless & networks > More... > Mobile networks.

In Network operators, select your operator.

In Access Point Names, select the correct access point name and

enter the exact connection parameters.

TIP:

When you encounter connection problem’s, see the FAQs on www.

archos.com or contact your 3G network connection provider.

ENEN

WiFi connection

WARNING: Make sure that you are in a WiFi zone.

1. Touch and hold the time & battery icons to reveal the status bar.

2. Pull the blue line down to display the status dashboard.

3. Touch the “Settings” icon to open the settings menu.

4. In the “Wireless&networks”section, if the WiFi is o, slide the

WiFi switch to the“ON”position. Once the WiFi is on, the ARCHOS

will scan for WiFi networks in range.

5. Touch “WiFi” to display available networks.

6. Touch the name of network you want to connect to.

Private networks are shown with a lock icon and will require you

to enter your password.

TIPS:

-When entering a WiFi password, we recommend that you select

“Show password”so you can see the characters you are typing. To get

the correct WiFi password (or settings) for the network, contact the WiFi

network provider.

-To keep your WiFi connection ON when the device is on sleep, select

the Menu icon in the“WiFi”page. Then, select Advanced > Keep WiFi on

during sleep > Always.

4 6

The AndroidTM Interface

ENEN

GoogleTM Search

>Touch "Google" for text search or touch the microphone icon for voice search.

AndroidTM apps shortcuts

> Touch to start an application.

Permanent AndroidTM apps shortcuts

> Touch to start an application

Back button

Home button

Recent apps buttons

All Apps button

> Touch this icon to show all the applications and widgets installed on your ARCHOS. All

your downloaded applications are here.

The status bar

> Displays notications and quick settings

4 6

7 9

10 1211

The AndroidTM Interface

The Quick settings

1Current user*

2Percentage of battery remaining

3To access all your settings.

4To turn on/o your WiFi connection.

5To turn on/o your Bluetooth connection.

6To activate/deactivate your GPS location system.

7To activate/deactivate the data connection.

8To see how much data have been used

9To activate/deactivate all wireless connections,

especially when ying.

10 To adjust the screen brightness.

11 To set the screen timeout.

12 To activate/deactivate automatic screen orientation

as you turn your ARCHOS.

13 To set an audio prole.

*New multi-user support for tablets

lets different users have their own

separate, customizable spaces on a

single device. Add users in Settings

> Device.
