ENGLISH

P/N: 109860

NEED HELP?

As we are often updating and improving our products, your device’s software may have

a slightly different appearance or modified functionality than presented in this Quick Start Guide.

On our Website:See the Frequently Asked Questions section on http://arnovatech.com/faq

Contact our Technical Support Team: Visit http://arnovatech.com/support for e-mail support.

Please register your product before contacting Technical Support (see

Thank you for choosing this ARNOVA product. We hope that you will enjoy using it and that it will give you satisfaction for many

years to come. Once you unpack your ARNOVA product, we recommend that you take a few minutes to register it

(http://arnovatech.com/register).This will allow you to get access to ARNOVA technical support (http://arnovatech.com/support).

ÄOn the web at http://arnovatech.com/register

UserGuide_Arnova_7G2_109860_book.indd 1 01/06/2011 16:47:36

12 3

???

ENGLISH

DESCRIPTION OF THE DEVICE

Power/Lock: slide left and hold to switch on/off. Slide right to lock the device’s

touchscreen.

When you slide left and hold, a window appears with a list of options (when the product is on). Tap

on “Power Off” to fully shut down your ARNOVA. Tap on “Suspend” to put the device in standby

(and allow a quick start up when you next tap the screen).While the device is in suspend mode, slide

right to lock the device with its screen off. This can be useful if your ARNOVA is in your backpack, for

example, and you do not want to wake it up by touching the screen by accident.

Micro-SD card reader

Charging indicator: Red light: battery charging / Yellow: battery charged.

Loudspeakers

Headphone jack

Power connector: to connect the supplied power cable.

Micro-USB port: to connect your ARNOVA to your computer, using the included USB cable (to transfer files).You can also con-

nect a keyboard, a mouse or a mass storage USB device. Go on the Home screen, tap on the Menu icon , then select Settings/

USB Mode select.

If the Host port is off, tap on the Host port line to turn it on. Important: turn off the Host port after use.

Leg stand: pull it out, and it will allow your ARNOVA to stand by itself on a flat, stable surface.

IMPORTANT:

Your device is frozen.You can turn it off. Slide and hold to the left the ON/OFF button for 10 seconds or press the reset

button.

UserGuide_Arnova_7G2_109860_book.indd 2 01/06/2011 16:47:40

▲

EUR

ENGLISH

STARTING UP

Installation Wizard

The first time you start up your ARNOVA, the installation wizard will bring you through a few screens to help you set up

the principal settings: Language, country, time, etc.

Before using your ARNOVA for the rst time, completely charge the battery!

Charging the Battery

Connect the supplied power cable to the ARNOVA Power connector and to a wall outlet.

The ARNOVA device will turn on and start charging.The Power indicator light is red while the battery is charging. It will turn

yellow when the battery is fully charged.

UserGuide_Arnova_7G2_109860_book.indd 3 01/06/2011 16:47:42

www

ENGLISH

CONNECTING TO THE WIFI NETWORK

For this procedure to work, you need to be in a WiFi zone that will allow you to connect to it. Every time the ARNOVA is

in range of a network that you have already configured once, it will attempt to make a connection.

* For free access WiFi points, there is no need to enter any special information. For secured networks, you will need either a key (a series of numbers and/or letters)

of the type WEP, WPA, or WPA2. To obtain the exact connection parameters required, contact the Internet service provider.

To configure a new WiFi network, go on the Home screen, tap on the Menu icon , then

select Settings .

In the Settings screen, select Wireless & networks.

If the WiFi is off, tap on the Wi-Fi line to turn it on. Then select Wi-Fi settings. The ARNOVA

will scan for available WiFi networks and display them at the bottom of the screen.

Tap on the network you want to connect to, enter the required network information* and then tap on Connect.Your

ARNOVA will now attempt to establish a connection to that WiFi hot spot with the network parameters you entered.

UserGuide_Arnova_7G2_109860_book.indd 4 01/06/2011 16:47:44

▼

▼▼

ENGLISH

THE ARNOVA INTERFACE

Top bar of the Interface (varies according to the screen you are in)

Return to the

Home screen

Return to the

previous screen

Menu: gives menu options ac-

cording to the current screen.

Your ARNOVA device is equipped with a capacitive touchscreen. Use your finger pulp to navigate.

Status icons: (WiFi connection

status, battery level, etc.)

Notification icons: drag the top bar downwards

to reveal the notification messages (if any).

These are the default

Android™ shortcuts (Web

Browser, EMail, etc.). Tap on an

icon to open the correspond-

ing application.You can

customize the Home screen

by adding/removing shortcuts

and widgets, changing the

wallpaper, etc. See next page.

Home Screen

Application button

Tap on this icon to reveal all the An-

droid™ applications installed on your

ARNOVA (games, various tools, etc.).

You can copy them onto the Home

screen.You can get more Android™

applications from AppsLib .

Time Volume -/+

Settings shortcut

Web browser shortcut

UserGuide_Arnova_7G2_109860_book.indd 5 01/06/2011 16:47:45

ENGLISH

Customizing the Home screen items

-To add a Home screen item (shortcuts, widgets, etc.), hold your finger on the screen at an empty location, then choose from

the list.You can also tap on the Menu icon and select Add , at the bottom of the screen.

-To move a Home screen item, hold your finger onto it until it gets larger, then drag it to the desired location, and release

your finger.

-To remove a Home screen item, hold your finger onto it, drag it onto the recycle bin (while you’re holding an item, the

Applications tab, on the right side of the screen, turns into a recycle bin) and release your finger.

CUSTOMIZING YOUR PRODUCT

Changing the Settings:From the Home screen, tap on the Menu icon , tap on Settings

and choose a category: Wireless controls, Sound & display, Date & time, etc.

The extended Home screen

Slide your finger horizontally on

the screen to go to the left or right

side of the extended Home screen.

Adding more applications with APPSLIB :With the ARNOVA connected to the Internet, tap on

the AppsLib icon .This online library of free and purchasable applications has thousands of

fun games and useful applications to download and use.

UserGuide_Arnova_7G2_109860_book.indd 6 01/06/2011 16:47:46

ENGLISH

PLAYING MULTIMEDIA FILES

From the Home screen, tap on the video, audio or photo icon.

The ARNOVA will display a list of les or folders corresponding to the selected category.

Tap on an item to start playing it.

Only inVideo and Photo modes: to display/hide the on-screen controls, tap anywhere on the screen.

To pause or resume a video, tap on the icon / (bottom of screen).To go to any particular point in the video,

slide the progression bar to the desired point.

To play the next or previous song, tap on the icons / . Use the icons / and the progression bar as

in the video player screen (see above).

To start or pause a slide show, tap on the icon

.To view the next or previous photo, tap on the icons / .

Video

Music


UserGuide_Arnova_7G2_109860_book.indd 7 01/06/2011 16:47:48

USB

ENGLISH

TRANSFERRING MEDIA TO YOUR ARNOVA

COMPUTER

TURNED ON

Connect the supplied USB cable to the ARNOVA and to a running computer.

The ARNOVA will turn on. Within a few seconds the ARNOVA will appear as an icon on your computer.

You can transfer your media files to the ARNOVA either by copy/pasting them into the respective folders using Win-

dows® Explorer (or the Finder on a Mac®), or by using Windows Media® Player. Open Windows Media Player® and then

use the Sync tab to synchronize your music, videos, and photos onto your ARNOVA. See Windows Media Player®’s Help

to learn more about this.

Once all your file transfers are finished, close Windows® Explorer and any other program that may have read or written to

the ARNOVA. Click on the ‘safely remove’ icon in the system tray, next to the clock.You can now unplug the USB cable.

UserGuide_Arnova_7G2_109860_book.indd 8 01/06/2011 16:47:50

www

FRANÇAIS

ENREGISTREZ VOTRE PRODUIT !

ÄSur Internet : http://arnovatech.com/register

Merci d’avoir choisi ce produit ARNOVA. Nous espérons que vous aurez plaisir à l’utiliser et qu’il vous donnera satisfaction pendant de

nombreuses années. Après avoir déballé votre produit ARNOVA, nous vous conseillons de prendre quelques minutes pour l’enregistrer

(http://arnovatech.com/register). Cela vous permettra d’avoir accès au support technique ARNOVA (http://arnovatech.com/support).

BESOIN D’AIDE ?

Comme nous mettons à jour et améliorons régulièrement nos produits, le logiciel de votre appareil peut présenter une

interface ou des fonctionnalités légèrement différentes de celles décrites dans ce guide.

Sur notre site Web:Consultez la Foire Aux Questions (FAQ) sur http://arnovatech.com/faq

Contactez notre équipe d’assistance technique: Allez sur http://arnovatech.com/support pour une assistance par e-mail.

Veuillez enregistrer votre produit avant de contacter notre équipe d’assistance technique (voir

Enregistrez votre Produit

UserGuide_Arnova_7G2_109860_book.indd 9 01/06/2011 16:47:51

12 3

???

FRANÇAIS

DESCRIPTION DE L’APPAREIL

Marche/Arrêt/Verrouillage : Faites glisser vers la gauche et maintenez pour allu-

mer/éteindre. Faites glisser vers la droite pour verrouiller l’écran tactile.

Lorsque vous faites glisser ce bouton vers la gauche et le maintenez, une fenêtre apparaît avec une liste d’op-

tions (lorsque le produit est en marche). Appuyez sur“Eteindre” pour éteindre votreARNOVA complètement.

Appuyez sur “Mettre en veille” (Suspend) pour mettre l’appareil en veille (et permettre un redémarrage plus

rapide en touchant l’écran). Lorsque l’appareil est en veille, faites glisser le bouton vers la droite pour verrouiller

l’appareil avec l’écran éteint. Cela peut s’avérer utile si votreARNOVA se trouve dans votre sac à dos, par

exemple, et que vous ne voulez pas le réveiller en touchant l’écran par accident.

Lecteur de cartes Micro-SD

Témoin de charge - rouge : batterie en charge / jaune : batterie chargée

Haut-parleurs

Prise casque

Connecteur d’alimentation :pour connecter le câble d’alimentation fourni.

Port micro-USB :permet de connecter votre ARNOVA à un ordinateur, à l’aide du câble USB fourni

.Vous pouvez aussi connecter un

appareil USB de stockage de masse.

Sur l’écran d’accueil, appuyez sur l’icône de Menu , puis sélectionnez Paramètres/USB Mode

select. Si le Host port est désactivé, appuyez sur la ligne Host port pour l’activer.Important: désactiver le Host port après utilisation.

Béquille : sortez-la, et elle vous permettra de faire tenir votre ARNOVA sur une surface plane et stable.

IMPORTANT:

Votre produit ne réagit plus.Vous pouvez l’arrêter en actionnant pendant 10 secondes le bouton ON/OFF ou en utilisant

le bouton de réinitialisation (reset).

UserGuide_Arnova_7G2_109860_book.indd 10 01/06/2011 16:47:54
