ENGLISH

SOFTWARE UPDATE

The ARCHOS operating system (the system that runs your

device) is periodically updated to bring new features, improve-

ments and bug fixes. There are two main ways to update your

product’s software: directly on your ARCHOS if your device

can connect to a WiFi network (Menu >Settings>About

device>Firmware update), or with a computer (www.archos.

com/firmware).

ÄDirectly on your ARCHOS

ÄOn the web at www.archos.com/firmware

As we are often updating and improving our products, your device’s software may have

a slightly different appearance or modified functionality than presented in this Quick Start Guide.

Full Manual: To access the full manual, tap

on the User Manual application on the device

home screen or go to: www.archos.com/

support.

FAQs: To access the FAQs, your device must

be connected to the Internet: www.archos.com/

support.

Contact our Technical Support Team:

Visit www.archos.com/support for e-mail

support.

NEED HELP?

Thank you for purchasing this ARCHOS product.

This guide provides you key information to start using your

device.

To receive more complete service, please register your

product at Menu >Settings>About device>Online regis-

tration, or with a computer (www.archos.com/register).

Please make sure that the items shown below are included

in the package. Should an item be missing, please contact

the local retailer from which you purchased this product.

• Archos 80 G9

• Power adapter

• USB cable

• Warranty, legal & safety notices

PACKAGE CONTENTS

THANK YOU!

UserGuide_Archos80 G9_book.indd 1 17/06/2011 12:57:08

568

ENGLISH

DESCRIPTION OF THE DEVICE

Charging indicator (when power cable connected)

- light on: battery charging / blinking: battery charged

Mini-HDMI video output**

Headphones

Built-in microphone

Micro-SD card slot*

Micro-USB port: to connect your ARCHOS to your computer, using the included

USB cable to transfer files. You can also connect a keyboard, a mouse or a mass

storage USB device using the optional USB host adapter.

Power Button: press and hold to switch on/off.

To put your device in standby (and allow a quick start up), press the Power button

once. When you press and hold on the Power button, a window appears with a

list of options. Tap on “Power Off” > “Power Off” to fully shut down your ARCHOS.

Camera Volume buttons Loudspeaker 3

stick slot

► * Depending on model ** With optional Mini-HDMI to HDMI cable.

See the full user manual to learn more about the video output.

Hardware Reset: In the event that your ARCHOS freezes operation, you

can force the device to shut down by holding the button for 10 seconds.

810 11

TheAppsbutton-tondall

your installed applications

The Customize button - to add shortcuts,

widgets

The Customize button - to add shortcuts,

widgets

The Customize button - to add

shortcuts, widgets

The Home button - to return to the main

screen

The Back button - to go back to your

previous screen

Main Touchscreen buttons

UserGuide_Archos80 G9_book.indd 2 17/06/2011 12:57:16

EUR

ENGLISH

STARTING UP

►

See the full user manual to learn how to fully configure your ARCHOS device.

Charging the Battery

Before using your ARCHOS for the first time, completely charge the battery:

Connect the supplied USB cable to the ARCHOS and to the supplied USB power adapter.

Plug the USB power adapter into an outlet. The ARCHOS device will turn on and start charging.

The charging indicator light is on when the battery is charging. It will blink when the battery is charged.

IMPORTANT: Only charge your device with the USB power adapter.

Startup Wizard

The first time you start up your ARCHOS, the installation wizard will bring you through a few screens to help you set up the principal

settings: Language, country, time, etc.

Transferring files to your ARCHOS

Connect the supplied USB cable to the ARCHOS and to a running computer. The ARCHOS will turn on and ask you if you want to

connect it. Tap on Mount to connect it. Within a few seconds the ARCHOS will appear as an icon on your computer.

You can transfer your media files to the ARCHOS either by copy/pasting them into the respective folders using Windows®

Explorer (or the Finder on a Mac®), or by using Windows Media® Player (Sync tab).

Once all your file transfers are finished, close Windows® Explorer and any other program that may have read or written to the

ARCHOS. Click on the ‘safely remove’ icon in the system tray, next to the clock. You can now unplug the USB cable.

UserGuide_Archos80 G9_book.indd 3 17/06/2011 12:57:18

www

ENGLISH

CONNECTING TO A WIFI NETWORK

To configure a new WiFi network, go on the Home screen, tap on the Settings icon.

In the Settings screen, select Wireless & networks.

If the WiFi is off, tap on the Wi-Fi line to turn it on. Then select Wi-Fi settings. The ARCHOS will

scan for available WiFi networks and display them at the bottom of the screen.

Tap on the network you want to connect to. Then tap inside the Wireless password field to

make the virtual keyboard appear. We recommend that you select Show password, to be able

to see the characters you are typing.

Enter the required network information*, tap on Done, and then tap on Connect.

Your ARCHOS will now establish a connection to that WiFi access point.

For this procedure to work, you need to be in a WiFi zone that will allow you to connect to it. Every time the ARCHOS is in range of

a network that you have already configured once, it will attempt to make a connection.

* For free access WiFi points, there is no need to enter any special information. For secured networks, you will need either a key (a series of

numbers and/or letters) of the type WEP, WPA, or WPA2. Check with the Internet service provider to obtain the exact connection parameters.

UserGuide_Archos80 G9_book.indd 4 17/06/2011 12:57:19

ENGLISH

CONNECTING TO A 3G NETWORK

YourARCHOSdeviceisequippedwitha3Gstickslotonitsback.IttsonlywiththeArchosG93Gstick.Youcaninstantaneously

connect to a 3G network quickly and easily. And you can connect to the web in just a few seconds.

For this procedure to work, you

need to be in a 3G zone.

Remove the Archos G9 3G stick cap, and push

the unmarked side of the case towards the plug.

Insert the sim card into its slot. Make sure to insert it properly.

Put back the case.

On your ARCHOS device, remove the protective cover of the 3G stick slot.

Plug the Archos G9 3G stick. The device is automatically detected.

Follow the on-screen instructions.

NOTE: The Archos G9 3G stick is purchasable on www.archos.com or from your local retailer.

UserGuide_Archos80 G9_book.indd 5 17/06/2011 12:57:20

▼

ENGLISH

►S

ee the full manual for further information about the interface.

Notication icons

Touch the time in the System

bar,

-to open or respond to

notications,

-to close notications

When you rotate the product, the

built-in accelerometer will automatically

switch the screen between landscape

and portrait views.

Touch to activate

an item

Touch and hold

for an alternate

action

Drag an item to

change its position

Swipe up/down

to scroll through

a list

Double-tap

Touchwithyourngerpulp.

Totouchandholdanitem,touchtheitemanddonotliftyourngerpulp

until the action occurs.

To drag an item, touch and hold it for a moment, then without lifting your

ngerpulp,moveyourngerpulponthescreenuntiltheitemreaches

its destination.

Toswipe,touchthescreenandthenquicklymoveyourngertipsacross

thescreenwithoutliftingyourngertip.Donotpauseonthescreenwith

yourngertipsattheinitialpointofcontactoryoumaydraganitem.

Quickly tap the screen twice on a webpage or other application screen

to zoom.

Swipe left/right

to change the view

The System bar displays status icons (Time, WiFi connection status, battery level, etc.) and

notification icons.

THE ARCHOS INTERFACE

►

See the full user manual to learn how to fully configure your ARCHOS device.

Pinch In some apps (such as Maps), you can zoom in and out by placing two

ngersonthescreenatonceandpinchingthemtogether(tozoomout)

or spreading them apart (to zoom in).

Status icons

Touch the time in the system bar,

-to get details about the current date and

time, networking, and battery

-to have access to Quick settings (to view or

change the most common tablet settings

UserGuide_Archos80 G9_book.indd 6 17/06/2011 12:57:22

ENGLISH

THE ARCHOS INTERFACE

Preinstalled applications :

For your convienence, some applications have been preinstalled. You can get more applications via Android Market.

Main applications

Video:Stop halfway through a video and pick up where you

were watching just by tapping on the little “+” symbol, on the

rightofthelename.

Music: Slide your nger (vertically or horizontally) on

the album covers, on the left, to navigate more visually

through your albums.

Gallery: View your pictures as a photo wall and then

one-by-one, or as a running slideshow. Simply drag

your nger horizontally to jump from one photo to

another.

Android Market: use the market application by Google to

download free and paid applications.

Browser: Have multiple pages open at once to jump back

and forth between them.

Email:Allows for e-mail accounts of the type POP or IMAP.

Camera: Take still image photographs or video sequences.

At any time, simply tap on the thumbnail on the top right to

display the last-taken pictures.

The extended Home screen: Slide your finger horizontally on the screen to navigate between the 5 panels of the extended Home

screen.

Changing the Settings: From the Home screen, tap on the

Settings icon and choose a category: Wireless & networks,

Sound & display, Date & time, etc.

UserGuide_Archos80 G9_book.indd 7 17/06/2011 12:57:25

TOUCHSCREEN FUNCTIONING

When touchscreen functioning is impaired, you can recalibrate your touchscreen.

- If you can access the Android interface

1. In the device homescreen, tap on Settings.

2. In the Settings screen, tap on Repair & Formatting at the bottom of the menu list.

3. In the Repair & Formatting screen, tap on Touchscreen Calibration.

A message will tell you to put your ARCHOS down.

4. Putthedeviceonaatsurface.

5. Tap on Calibrate the touchscreen.

Thecalibrationofthetouchscreenstarts.Donottouchtheproductuntilthecalibrationisnished.

IMPORTANT:Ifyoudonotputthedeviceonaatsurface(e.g.Table),thetouchscreencalibrationwillnotbesuccessful.

- If you do not have access to the Android interface

1. When turning on the device, hold down and press .

The ARCHOS Recovery screen is displayed.

Use to switch between options and to validate your selection.

2. Select Repair system and press .

3. In the Repair system screen, select Force touchscreen calibration and press .

4. Press againtoconrm.Andputyourproductonaatsurface.

Thecalibrationofthetouchscreenstarts.Donottouchtheproductuntilthecalibrationisnished.

IMPORTANT:Ifyoudonotputthedeviceonaatsurface(e.g.Table),thetouchscreencalibrationwillnotbesuccessful.

5. At the end of the calibration, press . The ARCHOS Recovery screen is displayed.

6. Select No. Your device will reboot. The touchscreen is now recalibrated.

National restrictions

ThisdeviceisintendedforhomeandofceuseinallEUcountries(andothercountriesfollowingtheEUdirective1999/5/EC)without

any limitation except for the countries mentioned below:

Country Restriction Reason/remark

Bulgaria None General authorization required for outdoor

use and public service

France Outdoor use lim-

ited to 10 mW e.i.r.p.

within the band

2454-2483.5 MHz

Military Radiolocation use. Refarming of the

2.4 GHz band has been ongoing in recent

years to allow current relaxed regulation. Full

implementation planned 2012

Italy None If used outside of own premises, general

authorization is required.

Luxembourg None General authorization required for network

and service supply (not for spectrum)

Norway Implemented This subsection does not apply for the geo-

graphical aera within a radius of 20 km from

the centre of Ny-Alesund

Russian Federation None Only for indoor applications

Note: Frequency 2454-2483.5MHZ are restricted to indoor use in France.

ENGLISH

UserGuide_Archos80 G9_book.indd 8 17/06/2011 12:57:25

National restrictions

ThisdeviceisintendedforhomeandofceuseinallEUcountries(andothercountriesfollowingtheEUdirective1999/5/EC)without

any limitation except for the countries mentioned below:

Country Restriction Reason/remark

Bulgaria None General authorization required for outdoor

use and public service

France Outdoor use lim-

ited to 10 mW e.i.r.p.

within the band

2454-2483.5 MHz

Military Radiolocation use. Refarming of the

2.4 GHz band has been ongoing in recent

years to allow current relaxed regulation. Full

implementation planned 2012

Italy None If used outside of own premises, general

authorization is required.

Luxembourg None General authorization required for network

and service supply (not for spectrum)

Norway Implemented This subsection does not apply for the geo-

graphical aera within a radius of 20 km from

the centre of Ny-Alesund

Russian Federation None Only for indoor applications

Note: Frequency 2454-2483.5MHZ are restricted to indoor use in France.

UserGuide_Archos80 G9_book.indd 9 17/06/2011 12:57:26

LEGAL AND SAFETY NOTICES

ENGLISH LEGAL AND SAFETY NOTICES p.2

FRANÇAIS MENTIONS LÉGALES ET CONSIGNES DE SÉCURITÉ p.8

DEUTSCH RECHTS- UND SICHERHEITSHINWEISE p.15

ESPAÑOL AVISOS LEGALES Y CONSIGNAS DE SEGURIDAD p.21

ITALIANO INFORMAZIONI LEGALI E SULLA SICUREZZA p.27

NEDERLANDS JURIDISCHE EN VEILIGHEIDSINFORMATIE p.33

2Legal_Booklet_PN106740V3 (3G in1 12Legal_Booklet_PN106740V3 (3G in1 1 26/09/2008 14:49:1726/09/2008 14:49:17

Otros manuales para 80 G9

Tabla de contenidos

Idiomas:

Otros manuales de Tableta de Archos

Archos

Archos Child Pad 101 Manual de usuario

Archos

Archos 80c Xenon Manual de usuario

Archos

Archos 101b Platinum Manual de usuario

Archos

Archos 502048 Manual de usuario

Archos

Archos 101 Xenon Manual de usuario

Archos

Archos 101c Neon Manual de usuario

Archos

Archos 8 Home Tablet Manual de usuario

Archos

Archos 9.7 xenon Manual de usuario

Archos

Archos 97 cobalt Manual de usuario

Archos

Archos 28 Manual de usuario

Archos

Archos 90 Cesium Manual de usuario

Archos

Archos 101 helium series Manual de usuario

Archos

Archos 101 TITANIUM Manual de usuario

Archos

Archos 96 Xenon Manual de usuario

Archos

Archos 7 Home Tablet Manual de usuario

Archos

Archos ChefPad Manual de usuario

Archos

Archos 501160 - 7 Internet Media Tablet Manual de usuario

Archos

Archos 101b Platinum Guía de instalación y uso

Archos

Archos 70 Titanium Manual de usuario

Archos

Archos 101b Xenon Manual de usuario

Archos

Archos 70 Platinum 3G Manual de usuario

Archos

Archos 48 Internet Tablet Manual de usuario

Archos

Archos 501778 Manual de usuario

Archos

Archos 70 Xenon Manual de usuario

Manuales populares de Tableta de otras marcas

Laser

Laser MID-1060 Guía del usuario

MUNBYN

MUNBYN IRT09J Guía de inicio rápido

Motorola

Motorola MC3090R - Win CE 5.0 Professional 520 MHz Manual de usuario

Dell

Dell Latitude ST Manual del propietario

Lenovo

Lenovo IdeaTab S6000L Manual del propietario

Venturer

Venturer WT9L11 Manual de usuario

EDUGEAR

EDUGEAR UnoBook Manual de usuario

Philips

Philips PI3210G/58 Manual de usuario

ADLINK Technology

ADLINK Technology IMT-BT Manual de usuario

TwinMOS

TwinMOS TwinTAB-T102D1 Manual de usuario

Getac

Getac E100 Manual de usuario

HANNspree

HANNspree HANNspad SN70T3 Manual de usuario

Philips

Philips PI3105W2/55 Manual de usuario

LG LG-V935 Manual de usuario

Zeki

Zeki TBDB763B Manual de usuario

Ricoh

Ricoh eQuill Manual de usuario

DT Research

DT Research DT365CT Instrucciones de montaje

MaxWest

MaxWest Nitro Phablet 9 Manual de usuario
