Aprilaire 8552 Manual de usuario

ELECTRONICTHERMOSTAT

Owner’sManual

MODEL 8552

5-2 Day Programmable

Thermostat

110-948 7/12/01 10:16 AM Page 1

OWNER’S MANUAL – TABLE OF CONTENTS

Energy Star®Program Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Setting Or Changing The Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Setting Or Changing The Weekday Program For Heating Mode . . . . . . . . . . . . . . . . . . . . . . . . . 5

Program Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Setting Or Changing The Weekend Program For Heating Mode . . . . . . . . . . . . . . . . . . . . . . . . . 9

Setting Cooling Temperatures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Reviewing Programmed Time Schedules And Temperature Settings . . . . . . . . . . . . . . . . . . . . 12

To Start Running The Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

For Best Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Thermostat Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

• Temperature Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

• Time Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

• Equipment Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Optional Settings For Additional Thermostat Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

In Case Of Power Failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Abo

hom

hav

In f

of t

hig

to o

Ene

utili

Acc

are

Apr

and

Pro

110-948 7/12/01 10:16 AM Page 2

– 1 –

Energy Star®Program Information

About half of all energy used by households goes to heating and cooling the

home. By selecting a programmable Aprilaire®Electronic Thermostat, you

have made a significant step toward conserving energy usage and costs,

while improving your indoor comfort.

In fact, the Aprilaire Electronic Thermostat Model 8552 has earned the “Energy Star®” designation

of the U.S. Environmental Protection Agency (EPA). This means that your Aprilaire Thermostat is a

highly efficient, cutting edge product that is good for the environment. It saves energy and costs less

to operate than similar products that do not qualify for the Energy Star label.

Energy Star products help you differentiate between standard efficiency and high efficiency products.

By using Energy Star products you are helping to prevent air pollution while saving money on your

utility bills.

According to the EPA, taking advantage of the times that a home is unoccupied or the occupants

are asleep, an Energy Star thermostat can reduce heating and cooling bills by as much as 30%. The

Aprilaire Thermostat has programmable capabilities that allow you full flexibility to set your heating

and cooling systems to meet your comfort and energy needs. As an Energy Star partner, Research

Products has determined that this product meets the Energy Star guidelines for energy efficiency.

110-948 7/12/01 10:16 AM Page 3

As part of the Energy Star program, your thermostat has been programmed with the following times and

temperatures. This has been done to achieve energy efficiency and lower energy bills. If you need to

modify your program schedule, see page 6.

– 2 –

TIME SCHEDULE

THERMOSTAT DESIRED

EVENT SYMBOL TEMPERATURE Mon Tue Wed Thu Fri Sat Sun

SETTING

Morning Heat = 70˚ 6:00 6:00 6:00 6:00 6:00 6:00 6:00

Cool = 78˚ am am am am am am am

Day Heat = 62˚ 8:00 8:00 8:00 8:00 8:00 8:00 8:00

Cool = 85˚ am am am am am am am

Evening Heat = 70˚ 5:00 5:00 5:00 5:00 5:00 5:00 5:00

Cool = 78˚ pm pm pm pm pm pm pm

Night Heat = 62˚ 10:00 10:00 10:00 10:00 10:00 10:00 10:00

Cool = 82˚ pm pm pm pm pm pm pm

Pro

time

110-948 7/12/01 10:16 AM Page 4

– 3 –

:00

IMPORTANT: READ ALL INSTRUCTIONS THOROUGHLY

Programming your Aprilaire Thermostat is done in three easy steps: setting the clock, setting the event

times, and setting your desired temperatures.

Setting Or Changing The Clock

Step 1: If you are currently in Daylight Saving Time

(first Sunday in April thru fourth Sunday in October),

press the DST button and “ “ will appear in the

lower right-hand corner of the display.

Step 2: Press the CLOCK button and “Mo”

(or another day of the week) will flash. Use the

DECREASE or INCREASE button to

change the flashing symbol to the current day

of week.

110-948 7/12/01 10:16 AM Page 5

– 4 –

Step 3: Press the CLOCK button again and “12:” (hours)

and “AM” or “PM” will flash. Use the DECREASE or

INCREASE button to change the flashing symbol

to the current hour making sure the hour has the proper

AM or PM designation.

Step 4: Press the CLOCK button and “:00” (minutes) will

flash. Use the DECREASE or INCREASE button

to change the flashing symbol to the current minute.

Step 5: Press the CLOCK button again. The clock is now

set and the current time appears on the display.

Pro

in y

wil

set

the

and

tem

Sat

bef

tim

hav

rea

110-948 7/12/01 10:16 AM Page 6

s)or

ill

tton

Setting Or Changing The

Weekday Program For Heating Mode

Programming your AprilaireElectronic Thermostat involves selecting the temperature you want

in your home and selecting the time you want it to be that temperature. Your Aprilaire Thermostat

will allow a maximum of 4 time schedules per day. Each time schedule is known as an “event.” The

Morning event is typically when you wake up and is the first event of the day. The Day event is typically

set when you leave for work. The Evening event is typically set when you come home from work and

the Night event is set when you go to bed. Each event will have 2 temperatures, 1 heating temperature

and 1 cooling temperature. The cooling temperature must be at least 2 degrees higher than the heating

temperature. Your Aprilaire Thermostat allows 1 program for Monday through Friday and 1 program for

Saturday and Sunday. Complete the chart on page 6 with your desired temperatures and time schedules

before beginning programming:

NOTE: It will take some time for your heating or cooling system to reach the desired temperature

when returning from a setback. Therefore, it is suggested you set your program time before the actual

time you want your home to reach the desired temperature. For example, if you get up at 7:00 AM and

have a 6 degree setback, set your Morning event at 6:00 AM to be sure the desired temperature is

reached by 7:00 AM.

– 5 –

110-948 7/12/01 10:16 AM Page 7

– 6 –

PROGRAM SCHEDULE

TIME SCHEDULE

THERMOSTAT DESIRED MONDAY – SATURDAY &

EVENT SYMBOL TEMPERATURE FRIDAY SUNDAY

SETTING

Morning Heat =

Cool =

Day Heat =

Cool =

Evening Heat =

Cool =

Night Heat =

Cool =

NOTE: While programming you must press a button at least every 15 seconds or the thermostat will revert back to the

operational mode. If this happens, simply repeatedly press the PROGRAM button until you get back to where you left

off. The information you have already entered has been retained.

NOTE: If consecutive events have the same temperature, you can skip an event by simultaneously pressing the

PROGRAM and MODE buttons. Press and release the PROGRAM button to advance to the next event.

110-948 7/12/01 10:16 AM Page 8

– 7 –

Step 1: Press and release the MODE button until the word

“HEAT” and the “ ” heating symbol appear on the display.

Step 2: Press and release the

PROGRAM button – “Mo Tu

We Th Fr”; Morning event

symbol “ ”;

flashing “12:” (or some

other hour); and flashing “AM” or “PM” will appear on the

display. You are now setting the time you want your heating

or cooling equipment to come on in the morning.

Step 3: Press the DECREASE button or INCREASE

button to set the desired hour for the Morning “ ” event.

Step 4: Press and release the PROGRAM button – “:00”

(or some other minutes) will flash.

the

eft

110-948 7/12/01 10:16 AM Page 9

Step 5: Press the DECREASE button or INCREASE

button to set the desired minutes for the Morning “”

event (program starting times are set in ten-minute

increments).

Step 6: Press and release the PROGRAM button – the current

heating temperature will begin to flash. You are now setting

the heating temperature you desire in the morning.

Step 7: Press the DECREASE button or INCREASE

button to set the desired heating temperature for the Morning “ ” event.

Step 8: Press and release the PROGRAM button – the Day “ ” event symbol will appear. You are

now setting the time and heating temperature you want throughout the day.

Step 9: Repeat steps 2-6 to complete programming for the Day “ ” event.

Step 10: Press and release the PROGRAM button – the Evening “ ” event symbol will appear.

You are now setting the time and heating temperature you want during the evening.

Ste

You

Ste

“Sa

“12

app

and

Ste

pro

Eve

hea

– 8 –

110-948 7/12/01 10:16 AM Page 10
