Apricorn VEL-SOLO Manual de usuario

Compatible with 2.5” SATA III

SSD (& HDD)

Backwards compatible with

SATA II SSDs

Uses a single PCIe 2.0 x1 slot

Auxiliary SATA III port

for additional expansion

Ideal for use as a boot disk or

scratch disk

Includes Apricorn’s EZ Gig

Cloning Software with Data

Select

Supports Win XP, Vista, 7

Visit our web site at www.apricorn.com or call 1-800-458-5448

Desktop SSD

Upgrade Kit

Looking to take your desktop computer to the next level?

The Velocity Solo is the easiest way to add the speed of Solid

State and SATA III to your desktop

Upgrade your system to latest SATA III interface (6Gbs) and add a high speed SSD

to boost the performance to the max. Easy to install, the Velocity Solo is an industry

standard PCIe 2.0 card designed to add a 2.5” Solid State Drive (SSD) via a super fast SATA

III connection. At 6Gbs, SATA III is twice as fast as SATA II and takes full advantage of the

latest SSD. The Solo also provides an additional SATA III data connection that can be used

to connect to another SSD or HDD to provide unparalleled capacity and performance. The

Solo is bundled with Apricorn’s EZ Gig Cloning software with Data Select. Data Select provides

a simple method to deselect data folders from the cloning

process which is helpful when migrating from a large HDD to a

smaller SSD and perfect for creating a Boot Disk. This gives you

the option to run your OS and applications from a fast, smaller

SSD boot drive, while keeping your documents and media les on

your original hard drive.

Simple to Install

The Velocity Solo takes just minutes to install. Simply connect your

Solid State Drive to the Velocity Solo SATA III connnector and

slide into an available PCIe slot in your desktop. Once installed,

download and run Apricorn’s EZ Gig cloning software and your

upgradeiscomplete. ForadditionalcapacityusetheauxiliarySATA

III connector for a superfast connection to an additional hard drive

or solid state drive.

SATA III

Connector

Auxiliary

for

Expansion

PCIe Gen 1/Gen 2 (x1, x2, x4 or x8 slot)

SATA

Data Cable

Disk Drive

SATA III Connector

for expansion to

another SATA drive

Any SATA Drive

2.5” or 3.5” / HDD or SSD

(Power cable required)

PCIe

2.0

Ultra-fast

Connection

Data transfer

speeds up to

500

MB / sec

For more information on Apricorn’s Velocity Solo and other innovative

Apricorn products visit our web site at www.apricorn.com or call 1-800-458-5448

*One gigabyte (GB) = one billion bytes; accessible capacity will be less and actual capacity depends on the operating environment and formatting.

Features

Compatible with 2.5” SATA III SSD (& HDD)

Uses a single PCIe 2.0 x1 slot (Also compatible with PCIe 1.0)

Auxiliary SATA III port for additional expansion

Backwards compatible with SATA II and SATA I SSDs

Ideal for use as a boot disk or scratch disk

Includes Apricorn’s EZ Gig Cloning Software with Data

Select

TRIM Compatible and can access capacities in excess of

2.2TB (if the Operating System supports TRIM)

PC: Supports Win XP, Vista, 7

Target applications:

• Scratch Disks for Design Applications

• High resolution image editing and manipulation

• Photo editing and retouching

• Video editing and post processing

• Gaming

Specications

Box Contents Velocity Solo

Quick Start Manual

Data Transfer Rates SATA III speeds up to 6Gb/s

Interface SATA III (SATA II backwards

compatible)

Dimensions 5.25 x 4.75 x 0.67 in

13.2 x 11.9 x 17 mm

Warranty 1 year limited / 30 day money

back guarantee

System Requirements Desktop system with

PCIe 2.0 X1 slot (PCIe 1.0 X1 slot)

Options Available

May be bundled with an SSD

Ordering info

Ordering Information Apricorn Part Number:

VEL-SOLO

Connecting your SSD to the

Velocity Solo Card

Slide your SSD

onto the SATA

connector on the

Velocity Solo Card.

Use mounting

screws to secure

the drive in place.

SATA connector

Figure 2. Connecting the Velocity Solo

to a HDD or SSD

SATA

Data Cable

SATA III Connector for expansion

to another SATA drive

Connect to your

computer’s

power supply

Power cable

AnySATA Drive

2.5” or 3.5” /

HDD or SSD

DiskDrive

Power cable

SATA cable

SATA connector

Power connector

Optional - Connecting an additional

drive to the Velocity Solo SATA III

connector

PCIe Gen1/Gen2 (x1, x2, x4or x8slot)

Figure 1. Installing the Velocity Solo

on PCIe Gen 1 / Gen 2 slot
