Aplex APC-3284A Manual de usuario

APC-3x84A /APC-3x85AUser Manual

APC-3x84A/APC-3x85A

(with motherboard SBC-7106)

User Manual

Release Date Revision

Aug. 2015V1.3

Aplex Technology, Inc.

15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan

Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail: aplex@aplex.com.tw URL: www.aplextec.com

APC-3x84A /APC-3x85AUser Manual

Revision History

Reversion

Date

Descriptions

1.0

2013/10/03

Official Version

1.1

2013/10/21

Modify CPU, 12.1”LCD, dimensions, and touch interface Spec.

1.2

2014/10/30

17”and 19”change motherboard to SBC-7106A

1.3

2015/08/11

Modify IO Port Serial/Parallel, 12.1”LCD, operating

temperature, motherboard and Expansion slot spec., add

power consumption spec.

APC-3x84A /APC-3x85AUser Manual

Warning!___________________________

This equipment generates, uses and can radiate radio frequency energy

and if not installed and used in accordance with the instructions manual, it may

cause interference to radio communications. It has been tested and found to

comply with the limits for a Class A computing device pursuant to FCC Rules,

which are designed to provide reasonable protection against such interference

when operated in a commercial environment. Operation of this equipment in a

residential area is likely to cause interference in which case the user at his own

expense will be required to take whatever measures may be required to correct

the interference.

Disclaimer

This information in this document is subject to change without notice. In no event

shall Aplex Technology Inc. be liable for damages of any kind, whether incidental or

consequential, arising from either the use or misuse of information in this

document or in any related materials.

Electric Shock Hazard –Do not operate the machine with its back cover

removed. There are dangerous high voltages inside.

APC-3x84A /APC-3x85AUser Manual

Packing List

Accessories (as ticked) included in this package are:

□AC power cable

□Driver & manual CD disc

□Other.___________________(please specify)

Safety Precautions

Follow the messages below to prevent your systems from damage:

◆Avoid your system from static electricity on all occasions.

◆Prevent electric shock. Don‘t touch any components of this card when

the card is power-on. Always disconnect power when the system is not

in use.

◆Disconnect power when you change any hardware devices. For instance,

when you connect a jumper or install any cards, a surge of power may

damage the electronic components or the whole system.

APC-3x84A /APC-3x85AUser Manual

Table of Contents

Revision History………………………………………………………………………………….1

Warning!/Disclaimer…………………………………………………………………………..2

Packing List/Safety Precautions…………………………………………………………..3

Chapter 1 Getting Started

1.1 Features……………………………………………………..….……………………..6

1.2 Specifications…………………..…………………………………………………….6

1.3 Dimensions…………………………..……………...………………………….......8

1.4 Brief Description of APC-3x84A/APC-3x85A……..…………….………9

Chapter 2 Hardware

2.1 Mainboard………..………..…….………………………………..…………..…..11

2.2 Motherboard Specifications….…………………………..………………...11

2.3 Jumpers Setting and Connectors.............................................15

Chapter 3 BIOS Setup

3.1 Operations after POST Screen…...............................................21

3.2 BIOS Setup Utility…..................................................................22

3.3 Main Settings…........................................................................23

3.4 Advanced Settings....................................................................24

3.5 Chipset Settings.......................................................................30

3.6 Boot Settings............................................................................34

3.7 Security Settings......................................................................37

3.8 Save and Exit Settings..............................................................38

Chapter 4 Installation of Drivers

4.1 Intel Chipset Driver.………………………………...…………………..………41

4.2 Intel Graphics Media Accelerator Driver...…………………………….44

4.3 Intel (R) Network Adapter……..……………………………………………..47

4.4 Realtek ALC662 HD Audio Driver Installation…….………….………49

APC-3x84A /APC-3x85AUser Manual

Chapter 5 Touch Screen Installation

5.1 Windows 2000/XP USB Driver Installation for PenMount 6000

Series………………………..……………………………………………………….51

5.2 Software Functions..................................................................55

Figures

Figure 1.1: Dimensions of APC-3284A/APC-3285A……..……………..…8

Figure 1.2: Dimensions of 3584A/APC-3585A……………………………...8

Figure 1.3: Front View of APC-3X84A…………..……………………………...9

Figure 1.4: Rear View of APC-3X84A…………..……….……………………...9

Figure 1.5: Front View of APC-3X85A………………….……………………..10

Figure 1.6: Rear View of APC-3X85A……………………………………..……10

Figure 2.1: Mainboard Dimensions………………………………….……......13

Figure 2.2: Jumpers and Connectors Location_ Board Top………….14

Figure 2.3: Jumpers and Connectors Location_ Board Bottom……14

APC-3x84A /APC-3x85AUser Manual

Chapter 1 Getting Started

1.1 Features

Fanless Design

Intel® Atom D2550 1.8G Processor

Onboard 2GB DDR3 800 MHz, 4GB is for option

11~32V DC wide-ranging power input

5 sides IP 65

5-Wire Resistive Touch Screen

1.2 Specifications

APC-3284A/85A

APC-3584A/85A

System

CPU

Intel® Atom Processor D2550 1.8G

Motherboard

SBC-7106

System Chipset

Intel NM10 Express

System Memory

Onboard DDR3 2GB (Default), option 4GB

IO Port

USB

4 x USB 2.0 type A

Serial/Parallel

1 x RS-232/422/485 DB-9 selectable, COM1, default RS-485

1 x RS-232 DB-9, COM2

1 x RS-232 DB-9, COM5

Audio

1 x MIC, Line-out, Line-in phone jack

LAN

2 x GbE LAN RS-45

Power

1 x 3-pin terminal block connector

1 x Power switch on/off

Storage Space

HDD

1 x 2.5”HDD space

Movable Device

1 x Internal SD slot onboard

Expansion

On board expansion

bus

1 x Mini PCIe half size

Option wifi/BT with Antenna

Display

APC-3x84A /APC-3x85AUser Manual

Display Type

12.1”color TFT-LCD

15”color TFT-LCD

Max. Resolution

800 x 600

1024 x 768

Max. Color

262K

16M

Luminance (cd/m²)

350

400

Viewing Angle

160 (H) / 140 (V)

160 (H) /145 (V)

Contrast Ratio

800 : 1

Backlight Lifetime

50,000 hrs

Touch Screen

Type

Resistive Touch

Interface

Default RS-232

Light Transmission

80%

Power

Power Input

11~32V DC

Power Consumption

Max: 15.6W (3284A)

Max: 16.7W (3285A)

Max: 21.7W (3584A)

Max: 21.4W (3585A)

Mechanical

Construction

Stainless Steel (APC-3x84A)

Steel/Black (APC-3x85A)

IP Rating

5 sides IP65

Mounting

VESA mount 75 x 75

Dimension

330 x 260 x 51 mm

398 x 319 x 51.8 mm

Net Weight (Kgs)

4.3 Kg (APC-3284A)

4 Kg (APC-3285A)

6.9 Kg (APC-3584A)

6.5 Kg (APC-3585A)

Environmental

Operating

Temperature

0~50°C (with HDD)

-20~60°C (with Industrial SSD for 15”)

Storage Temperature

-30~70°C

Storage Humidity

10 to 90% @ 40°C , non-condensing

Certification

CE / FCC Class A

Operating System

Support

Microsoft Windows 7 Pro for Embedded, Windows Embedded

Standard 7

APC-3x84A /APC-3x85AUser Manual

1.3 Dimensions

Figure 1.1: Dimensions of APC-3284A/APC-3285A

Figure 1.2: Dimensions of APC-3584A/APC-3585A

APC-3x84A /APC-3x85AUser Manual

1.4 Brief Description of APC-3x84A/APC-3x85A

The APC-3x84A/APC-3X85A is the fanless and low power consumption panel-mount

industrial panel pc with 12”/15” TFT LCD. It powered by Intel ® Atom Processor D2550

1.8G. The panel PC comes with a rich variety of functions and peripherals. It comes

with 1 x 2.5-inch hard disk drive and 1 x Internal SD slot for data storage , support

DDR3 2GB 800 MHz(4GB is for option), support rich I/O, wide range 11~32V DC input, it

can ensure simplified connectivity to a variety of external peripheral devices. The OS

supports Microsoft Windows 7 pro for embedded, Windows embedded standard 7. The

unit deal for a wide range of applications for food/chemical industry, medical,

restaurant/kitchen applications, storage management and information segment and

so on.

Figure 1.3: Front View of APC-3X84A

Figure 1.4: Rear View of APC-3X84A
