Aplex APC-3296P Manual de usuario

APC-3296P

21.5”6th Generation Intel® CoreTM i5-6300U IP66K/IP69K Stainless Steel Panel PC

User Manual

Release Date Revision

Aug. 2016 V1.0

Aplex Technology, Inc.

15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan

Tel: 886-2-82262881 Fax: 886-2-82262883 URL: www.aplextec.com

APC-3296P User Manual

Revision History

Reversion

Date

Description

1.0

2016/08/15

Official Version

APC-3296P User Manual

Warning!________________________

Caution

Risk of explosion if the battery is replaced with an incorrect type.

Batteries should be recycled where possible. Disposal of used batteries must be in

accordance with local environmental regulations.

Disclaimer

This information in this document is subject to change without notice. In no event

shall Aplex Technology Inc. be liable for damages of any kind, whether incidental or

consequential, arising from either the use or misuse of information in this document

or in any related materials.

Electric Shock Hazard –Do not operate the machine with its back cover removed.

There are dangerous high voltages inside.

This equipment generates, uses and can radiate radio frequency energy and

if not installed and used in accordance with the instructions manual, it may cause

interference to radio communications. It has been tested and found to comply

with the limits for a Class A computing device pursuant to FCC Rules, which are

designed to provide reasonable protection against such interference when

operated in a commercial environment. Operation of this equipment in a

residential area is likely to cause interference in which case the user at his own

expense will be required to take whatever measures may be required to correct

the interference.

APC-3296P User Manual

Packing List

Accessories (as ticked) included in this package are:

□Adaptor

□Driver & manual CD disc

□Other.___________________(please specify)

APC-3296P User Manual

Safety Precautions

Follow the messages below to prevent your systems from damage:

◆Avoid your system from static electricity on all occasions.

◆Prevent electric shock. Don‘t touch any components of this card when

the card is power-on. Always disconnect power when the system is not

in use.

◆Disconnect power when you change any hardware devices. For instance,

when you connect a jumper or install any cards, a surge of power may

damage the electronic components or the whole system.

APC-3296P User Manual

Table of Contents

Revision History…………………………………………………………………………………………………….1

Warning................................................................................…………………………….…2

Caution/Disclaimer……..……………………………………………………………………………………..…2

Packing List…………………………………….……………………………………………………………………..3

Safety Precautions…………………………………………………………………….…..……………………..4

Chapter 1 Getting Started

1.1 Features………………………..………………………...…………………………..7

1.2 Specifications…………………...………………………………………………….7

1.3 Dimensions………………………....……………………………………………...9

1.4 Brief Description of APC-3296P………….………………………….……10

1.5 VESA Mounting…………………....…………..………………………….……11

Chapter 2 Hardware

2.1 Motherboard Specifications..…………………...……………..………....12

2.2 Features…..…..…………………………..…………………………………………14

2.3 Hardware Installation…………………..……………………………………...17

2.4 Jumper Settings………………………….…………………………………..……22

2.5 Rear Panel I/O Ports……………….……………………………………………32

2.6 I/O Connectors……………………….……………………………………………38

Chapter 3 BIOS Setup

3.1 Overview…………………………………...…….……...…………………………55

3.2 Main Menu………………………………………………………………………….57

3.3 Advanced……..……………………………………..………………………………58

3.4 Security……………….……………………………………………………………...69

3.5 Boot………………………………………………………….………………………...70

3.6 Exit………………………………………………………………….…………………..72

3.7 Updating the BIOS….…………………………………….……………………..72

Chapter 4 Installation of Drivers

4.1 Intel(R) AtomTM SoC Chipset.……..…..……...………….………………78

4.2 Intel(R) VGA Chipset..……………………………………………….……......80

4.3 Intel(R) LAN Driver…….…..………………………………………..………....83

4.4 Audio Driver…………………………………………………………………………86

APC-3296P User Manual

4.5 Intel USB 3.0 Driver (For Windows 7 and Windows 8)….……..88

4.6 Framework 4.5.2 (For Windows 7)……….………………………………91

4.7 Intel Management Engine Driver………….………………………………93

4.8 IO Driver (For Windows 8 and Windows 10)..………………………96

Chapter 5 Touch Screen Installation

5.1 Windows 7/8.1/10 Universal Driver Installation for PenMount

6000 Series..............................……….………………………………....100

5.2 Software Functions…………………………………………..……………….104

Figures

Figure 1.1: Dimensions of APC-3296P…………..………………....……………......9

Figure 1.2: Front View of APC-3296P…………………..…………………………….10

Figure 1.3: Rear View of APC-3296P………………………………………………..…10

Figure 1.4: APC-3296P VESA Mounting….…………………………………………..11

Figure 2.1: Motherboard Dimensions………………………………………….…….17

APC-3296P User Manual

Chapter 1 Getting Started

1.1 Features

6th Generation Intel® CoreTM i5-6300U

Dual Channel DDR3L 204-pin SODIMM up to 16GB 1333/1600MHz

Totally IP66/IP69K M12 Connector

SUS304 Grade Stainless Steel Enclosure (SUS 316 optional)

Full Flat Bezel and Fanless Design

Projected Capacitive Touch

12V DC Power Input

1.2 Specifications

APC-3296P

System

CPU

Intel Core i5-6300U/Celeron 3955U (option)

Memory

2 x DDR3L 204-pin SODIMM up to 16GB 1333/1600MHz

IO Port

USB

1 x M12 8-pin for 2 x USB 2.0

(1 x USB 3.0 for option)

Serial/Parallel

1 x M12 8-pin RS-232/422/485 for COM1

1 x M12 8-pin RS-232 for COM2

LAN

1 x M12 8-pin for LAN1

Power

1 x M12 3-pin DC power

Option

1 x LAN2 for option

Storage Space

Storage

1 x 2.5" SATA HDD or SSD

Expansion

Expansion Slot

1 x Full-size Mini PCIe (PCIe/USB/SATA)

1 x Full-size Mini PCIe (PCIe/USB)

For option WLAN/BT Module and Antenna at system rear side

Display

Display Type

21.5”color TFT LCD

Max. Resolution

1920 x 1080

Max. Color

16.7M

Luminance(cd/m²)

250

APC-3296P User Manual

Contrast Ratio

3000: 1

Viewing angle

178(H) / 178(V)

Backlight Lifetime

30,000 hrs

Touch Screen –Projected Capacitive Touch

Interface

USB

Light Transmission

Over 90%

Power

Power Input

12V DC

Power Consumption

MAX: 32.5W

Mechanical

Construction

Stainless Steel SUS304 (SUS316 for option)

IP Rating

Total IP66 & IP69K Design

Mounting

VESA Mount 100 x 100

Dimensions

571 x 362 x 55 mm

Net Weight

15 Kg

Environmental

Operating temperature

0~45°C

Storage temperature

-30~70°C

Storage humidity

10 to 90% @ 40°C, non- condensing

Certification

CE / FCC Class A

Operating System

Support

Windows 7 Professional for Embedded Systems,

Windows 7 Ultimate for Embedded System,

Windows Embedded 8.1 Pro,

Windows Embedded 8.1 Industry pro

Windows 10 IoT Enterprise

APC-3296P User Manual

1.3 Dimensions

Figure 1.1: Dimensions of APC-3296P
