AOpen 10/100Mbps
SOHO Switch
(AOW-605 5-port
AOW-608 8-port)
User’s Guide
OpenLink™To Communications
AOpen SOHO Series
•Aopen SOHO Series provides high-speed and easy
access to the LAN and Intranet, especially great for
SOHO(Small Office/Home Office) environment.
AOH-605
•5-port SOHO 10/100Mbps Fast Ethernet Hub
AOH-608
•8-port SOHO 10/100Mbps Fast Ethernet Hub
AOW-605
•5-port SOHO 10/100Mbps Switch Hub
AOW-608
•8-port SOHO 10/100Mbps Switch Hub
FCC Warning
This equipment has been tested and found to comply
with the regulations for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference when the equipment is operated in a
commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not
installed and used in accordance with this user’s guide,
may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely
to cause harmful interference, in which case the user will
be required to correct the interference at his own
expense.
CE Mark Warning
This is a Class B product. In a domestic environment, this
product may cause radio interference, in which case the
user may be required to take adequate measures.
VCCI Mark Warning
P/N:6012-0001116
TABLE OF CONTENTS
PACKAGE CONTENT...................................................1
ABOUT THIS GUIDE.....................................................2
OVERVIEW ...................................................................2
INTRODUCTION...........................................................5
FAST ETHERNET TECHNOLOGY.......................................5
SWITCHING TECHNOLOGY ..............................................5
FEATURES....................................................................6
HARDWARE DESCRIPTION ........................................8
FRONT PANEL...............................................................8
REAR PANEL.................................................................9
LED INDICATORS........................................................10
CONNECTING THE SWITCH......................................12
PC TO SWITCH ...........................................................12
HUB TO SWITCH..........................................................12
A. 10BASE-T Hub..................................................13
B. 100BASE-TX Hub..............................................13
HUB WITHOUT UPLINK (MDI-II) PORT ............................13
A. Using straight cable ...........................................13
B. Using crossover cable........................................14
SWITCH TO SWITCH (OTHER DEVICES)............................14
A. Using straight cable ...........................................14
B. Using crossover cable........................................14
PORT SPEED & DUPLEX MODE.....................................15
2
TECHNICAL SPECIFICATIONS..................................16
APPENDIX A:RJ-45 PIN SPECIFICATION .................18
PACKAGE CONTENT
Open the shipping cartons of the AOpen SOHO Switch
and carefully unpacks its contents. The carton should
contain the following items:
•One AOpen SOHO 10/100M Fast Ethernet Switch
(AOW605/AOW608)
•One external power adapter
•This User’s Guide
If any item is found missing or damaged, please contact
your local reseller for replacement.
4
ABOUT THIS GUIDE
This manual provide all the information you need of how
to install and operate AOpen SOHO 10/100M Fast
Ethernet Switch (AOW-605/AOW-608).
Overview
•Chapter 1, Introduction. Describes the AOpen
SOHO Switches and its features.
•Chapter 2, Hardware Description. Explains the
front panel, rear panel and LED indicators of the
Switch.
•Chapter 3, Connecting the Switch. Describes how
you can connect the Switch to your Ethernet
network.
•Chapter 4, Technical Specifications. Lists the
technical (general, physical and environmental,
and performance) specifications of the Switch.
•Appendix A, RJ-45 Pin Specification. Describes
the RJ-45 receptacle/connector and the straight
and crossover cable connector.
INTRODUCTION
This chapter describes the features of this AOpen SOHO
Switch and some background information about
Ethernet/Fast Ethernet switching technology.
Fast Ethernet Technology
A number of high-speed LAN technologies have been
proposed to provide greater bandwidth and improve
client/server response times. Among them, 100BASE-T
(Fast Ethernet) provides a non-disruptive, smooth
evolution from the current 10BASE-T technology.
100Mbps Fast Ethernet is a new standard specified by
the IEEE 802.3 LAN committee. It is an extension of the
10Mbps Ethernet standard with the ability to transmit and
receive data at 100Mbps, while maintaining the
CSMA/CD Ethernet protocol. Since the 100Mbps Fast
Ethernet is compatible with all other 10Mbps Ethernet
environments, it provides a straightforward upgrade and
takes advantage of the existing investment in hardware,
software, and personnel training.
Switching Technology
Switching is a cost-effective way of increasing the total
network capacity available to users on a local area
network. A switch increases capacity and decreases
network loading by dividing a local area network into
different segments, which don’t compete with each other
for network transmission capacity.
6
The switch acts as a high-speed selective bridge
between the individual segments. Without interfering
with any other segments, it automatically forwards traffic
that needs to go from one segment to another. By doing
this the total network capacity is multiplied, while still
maintaining the same network cabling and adapter cards.
For Fast Ethernet networks, a switch is an effective way
of eliminating problems of chaining hubs beyond the
“two-repeater limit.”A switch can be used to split parts of
the network into different collision domains, making it
possible to expand your Fast Ethernet network beyond
the 205-meter network diameter limit for 100BASE-TX
networks. Switches are also ideal for bridging between
the existing 10Mbps networks and the new 100Mbps
networks.
Today switches are an ideal solution to most kinds of
local area network congestion problems.
Features
AOpen SOHO Switch was designed for easy installation
and high performance in a SOHO environment where
traffic on the network and the number of users increases
continuously.
With its small, compact size was specifically designed for
small to middle workgroups. This AOpen SOHO Switch
can be installed where space is limited; moreover, they
provide immediate access to a rapidly growing network
through a wide range of user-reliable functions.
