AOpen MX3W Pro Guía de configuración

Open

MX3W

DOC. NO. : MX3W-OL-E0001A

Open

This Online Manual is in PDF format, we recommend using Adobe Acrobat Reader 4.0 for online

viewing, it is included in Bonus CD disc or you can get free download from Adobe web site.

Although this Online Manual is optimized for screen viewing, it is still capable for hardcopy printing,

you can print it by A4 paper size and set 2 pages per A4 sheet on your printer. To do so, choose

File > Page Setup and follow the instruction of your printer driver.

Thanks for the help of saving our earth.

Open

This page gives you a quick procedure on how to install your system. Follow each step accordingly.

1Installing CPU and Fan

2 Installing System Memory (RIMM)

3 Connecting Front Panel Cable

4 Connecting IDE and Floppy Cable

5 Connecting ATX Power Cable

6 Connecting Back Panel Cable

7 Power-on and Load BIOS Setup Default

8 Setting CPU Frequency

9 Reboot

1010

10 Installing Operating System (such as Windows 98)

1111

11 Installing Driver and Utility

Open

Motherboard Map

FDC

JP27 Housing Speaker

Intel 810 Chipse

2X AGP On Chip

JP28 KB/MS Wakeu

Batter

-less

4Mb Flash BIOS

Virus Protection

Wake on Time

Multi-Languare BIOS

WOL Wakeup on LAN

Resettable Fuse

PC99 Back Panel

Low ESR capacitor

Jumper-less Design

Over-current Protection

Thermal Protection

CPU Fan Connector

System Voltage & Fan

Monitoring

ATX Power Connector

AC Power Auto Recovery

Housing Fan

WOM Wakeup on Modem

Panel Connector

PC100 DIMM

Sus

end to RAM

ATA 33/66 IDE

Suspend to HDD

Modem Audio

CD Audio

JP12 Onboard Sound

AMR

RAM Power LED

COM2 Serial Port

SB-Link Connecto

JP23 AGP/FSB Clock Ratio

Turbo AGP

IrDA

JP14 Clear CMOS

Open

Socket 370 : Celeron

Model

Name Chipset FC-PGA

ATA-66 Display

Cache FSB Max

FSB Audio

Onboard

MX3W-LIntel 810L    155

MX3WIntel 810

DC-100   100155

MX3W-VIntel 810   100155

Open

Graphics Memory Control

Hub (GMCH)

100 MHz FSB

CPU

. PC100

Memory Bus

DIMM

PCI Bus

PCI Card I/O Control Hub

(ICH) ATA 33/66

IDE Bus

4Mb BIOS ROM

HDD/CDROM

USB

Clock Generator

LPC I/F

Low Pin

Count

Super I/O

Floppy

Serial port, Printer and

PS/2 KB/Mouse

AC97 Link

AMR Card

Hub Link

Audio

CODEC

MIC, Line-in and

Speaker

2X AGP

Open

This chapter describes jumpers, connectors and hardware devices of this motherboard.

Note: Electrostatic discharge (ESD) can damage your processor, dis

drives, expansion boards, and other components. Always observe the

following precautions before you install a system component.

1.Do not remove a component from its protective packaging until yo

are ready to install it.

2.Wear a wrist ground strap and attach it to a metal part of the syste

unit before handling a component. If a wrist strap is not available,

maintain contact with the system unit throughout any procedure

requiring ESD protection.

Open

You can clear CMOS to restore system default setting. To clear the CMOS, follow the procedure

below.

1. Turn off the system and unplug the AC power.

2. Remove ATX power cable from ATX power connector.

3. Locate JP14 and short pins 2-3 for a few seconds.

4. Return JP14 to its normal setting by shorting pins 1-2.

5. Connect ATX power cable back to ATX power connector.

Tip: When should I Clear CMOS?

1. Boot fail because of overclocking…

2. Forget password…

3. Troubleshooting…

Normal Operation

(default) Clear CMOS

Open

This jumper is used to enable or disable Keyboard/Mouse Wake Up function. If you select Enable,

you can decide the wake up mode from BIOS Setup > Integrated Peripherals > Power On Function.

To implement this function, the power supply 5V standby current must be greater than 800mA. Note

that only PS/2 mouse supports Wake on Mouse function.

Disable Enable

Tip: You have to wait for system to

successfully boot from operation system

(such as Windows or DOS) before the

Wake-On-Keyboard/Mouse can take effect.

This is because the information of how to

support this function must be stored into

Super I/O Controller and then you can use it

for next power on.

1 2 3 1 2 3

Open

Super I/O Controller

ATX standby power

Keyboard PS2 Mouse

BIOS
