AOpen EPC945-M8 Manual de usuario

Safety Precautions

Read and follow the content of the Safety Precautions carefully so that you will not cause

damages to yourself or the system.

1. Pay attention to the warnings and notes in this manual to avoid causing unexpected

damages.

2. If you want to wipe the system with a wet cloth, make sure the power cord is

disconnected. We strongly suggest not to wipe the system with chemical detergent or

sprayed detergent.

3. When moving the system, do not put the system on uneven, unsteady or slanting

surfaces.

4. Do not put water cups or beverages near the PC system to protect the system from

being damaged by liquids.

5. There are ventilating holes on the backboard of the computer case to dissipate heat

from the machine. You should pay attention to the position of the PC so that the

ventilating holes will not be blocked. Meanwhile, do not put your PC on something

not sturdy enough – like rug or bed mattress – to ensure smooth air flow for heat

dissipation.

6. Before plugging on power, make certain the electric voltage in your area complies

with that of the PC. If you are uncertain, consult your PC dealer or power company

first.

7. Do not place your PC on power cords. Do not leave the power lines in tangles which

may cause people to stumble.

8. It normally takes several power sockets to meet the need of a PC system. Make sure

the extension power line is capable of handling the total power load for all equipment.

In other words, the combined amperage of all electrical appliances on the same

extension line must not exceed the strength of electric currents or the fuse of the

extension line.

9. When your PC system runs into problems, do not try to fix it unless you possess

adequate technical know-how concerning hardware installation and system

maintenance. It would advisable to seek assistance from qualified maintenance

personnel so as to avoid improper disassembling.

10. When encountering the following more dangerous situations, unplug the power to

shut down the system and then seek help from professional technicians to fix the

problems:

* When liquids find their way into the equipment.

* When the PC is soaked by rain.

* When power cords or power sockets are damaged.

* When the PC system falls to the ground and is damaged.

* When some problems cannot be solved even after you installed the system according to

the manual or the troubleshooting procedures.

Disposal Instruction

For better protection of our earth, please don't throw this electronic device into municipal

trash bin when discarding. To minimize pollution and ensure utmost protection of the

global environment, please recycle the product.

For more information about the collection and recycling of Waste Electrical and

Electronic Equipment (WEEE) , you are invited to visit our homepage at

www._____.com under “Green Products”.

Safety Instructions

Safety Caution Concerning Battery:

Use the battery according to the manufacturer’s recommendation. When replacing battery,

use the battery which conforms to the manufacturer’s specifications. When disposing the

batteries, dispose the batteries to a recycle center which is designated by your local

authority to process batteries. Follow all your local authority’s safety and waste disposal

regulations in disposing the batteries.

Safety Caution Concerning Laser Products:

This equipment, built with DVD and/or CD disc drives using laser beam to read or write

data on optical discs, is classified as “Class 1 laser product”. While the laser optical drive

is reading data from or writing data to an optical disc, do not force open the disc drive

door. Press the Eject button to retrieve the optical disc only after the in-use indicator goes

off.

Table of Contents

Chapter 1 Getting Started....................………………………………………………….5

System Overview …………………………………………………………………………5

Features …………………………………………………………………………………...5

Unpacking Your System ………….………………..……………………………………...6

The Front View ………………..…………………………………………………….……7

USB 2.0 Card Reader ……………………………………………………………………7

Input/Output Ports and Buttons on Front Panel ………………………………….…..….9

The Rear View ……………………………………………………………………….… 9

TV Outputs …………………………….………………………………………………..12

The Remote Control …………………..………………………………………………...13

Chapter 2 Install and Disassemble System…………………………………………..15

Install the CPU ……………………………………………………………………….…15

Remove the Top Cover…..…………………………………………………….……… 15

Remove the Link Bar …………………………………………………………..……. 16

Remove the CPU Cooler ……………………………………………..……………… 17

Begin to Install the CPU…………………………………….……………..………… 17

Install CPU on Socket T………………………………………………………………………18

Install CPU to Socket 754…………………………………………………………………….19

Install CPU to Socket 479…………………………………………………………………….20

Install CPU to Socket 939…………………………………………………………………….22

Install Memory Modules ……………………………………………………………… 22

Disassemble Optical Disc Drive …………………………………….……………...… 22

Install Optical Disc Drive ………………………………………..…………………… 24

Disassemble Hard Disc Drive ………………………………………………………… 27

Lift the Drive Cage …………………………………………………………………… 28

Install Hard Disc Drive ………………………………………………………………. 28

Chapter 3 Turn on the Power…………..…………………………………………… 30

Appendix………………………………………………………………………………34

Install OS into Serial ATA Hard Disc……………… ………………………......… 34

RAID Driver Installation Guide………………..………………………………..… 35

Introduction to Jumper Settings and Other Connectors ……………………………… 37

Chapter 1 Getting Started

System Overview

Thank you for purchasing XC REC 8, an entertainment PC (ePC). The system unit is

designed to integrate the functions of the following appliances:

1. DVD player

2. Personal video recorder

3. Audio CP player

4. Internet Set-top box

5. FM tuner

6. AC3 decoder

7. PC game console

To fully make use the functions mentioned above, the user needs to get the Media Center

Edition (MCE) software provided by Microsoft Corp. With the MCE, a user can turn the

system unit into a Media Center PC and his/her home into a digital entertainment center.

Features

1. The product is the first smallest ViiV desktop ePC with a size of 430 x 89 x 300 mm.

2. The system is built with Intel 130W dual core CPU, 945G, ICH7DH chipset, and Intel LAN

technology.

3. It is designed to be the first smallest ViiV desktop ePC in compliance with VCR standard

size, and fit into any audio/video racks or cabinets.

4. The first smallest ViiV desktop ePC with a power supply of 375W.

5. The first smallest ViiV desktop ePC that supports two 3.5-in hard disc drives and one 5.25-in

optical disc drive.

6. The first smallest ViiV desktop ePC that supports four slots.

7. The first smallest ViiV desktop ePC that supports the micro ATX form factor.

8. The first smallest ViiV desktop ePC that supports Intel 8xx dual core 130W CPU which is

designed to be cooled with four heat-pipes and an extra large 95 mm fan.

9. The first smallest ViiV desktop ePC that supports multiple video outputs including VGA,

YPbPr, S-Video, composite video, SCART (optional for Europe), and D4 (optional for

Japan).

10. The first smallest ViiV desktop ePC that supports multiple high quality audio outputs

including 7.1-channel surround sound, digital audio SPDIF input, and SPDIF output.

11. The first smallest ViiV desktop ePC that supports DMA and ViiV platforms and 1080i high

definition TV output which enables large screen TV display sharp images.

Unpacking Your System

Upon unpacking your system, you will see the following items:

1. Power cable 2. A remote control

3. Two AA type battery 4. 7.1-channel audio cable

5. 2-channel RCA adaptor 6. S-Video cable

7. Utility CD 8. ADD2 card (option)

9. MCE TV card (option)

Because the system is delivered as a bare system, a user is offered the choice to install the

CPU, memory module, hard disc drive, and optical disc drive. In order to install these

optional devices, a user needs to know how to disassemble the system unit. Before

disassembling the system unit, a user needs to get familiarized with the housing.

The Front View

The power button of the unit is covered under a slim panel near the bottom of the front

panel. When facing the front panel, you can locate an eject button which releases the

cover of the optical disc drive and the card reader. You can locate other indicators such as

HDD, Record, and remote control indicators. The infrared censor for the remote control

is located below the remote control indicator.

USB 2.0 Card Reader

Located next to the optical disc drive is a USB 2.0 23-in-1 memory card reader. A user

can open the cover of the memory card reader by pushing the upper right corner of the

cover.

Power

Card Reader

Optical Device

Eject Button

Sensor

HDD indicator Remote Control indicator

Supports flash memory card format including:

Slot 1:

zSM/SMC interface

zMMC1/MMC2/MMC4.0 (1 bit)

zSecure Digital Card

zMS/MS(MG)

zMS PRO/MS PRO (MG)

zMemory Stick ROM

zMS Select

zXD

with adapter

zMS Duo/MS Duo (MG)

zMS PRO Duo/ MS PRO Duo (MG)

zMini-SD

zRS-MMC

zT-flash

Slot 2:

Compact Flash Card type I

Compact Flash Card type II

IBM Micro-drive

Input/Output Ports and Buttons on Front Panel

Input/Output ports and buttons on the front panel are concealed under a slim cover near

the bottom edge of the front panel. A user can push both ends of the slim cover to open it.

The Rear View

A user can locate the input/output (I/O)connectors, power switch, and power source

connector on the rear panel. These I/O ports include the connectors for PS2 keyboard and

mouse, the printer (parallel) port, VGA, USB 2.0, IEEE 1394, LAN, and COM ports.

Worldwide:

Volume

Stop/Eject

Play/Pause

USB

1394

Phone

MIC

SPDIF Out

7.1-ch Audio

LAN

USB

VGA

COM1

Keyboard

Add2 Card (DVI out)

S-video (connect to red head)

Composite out (connect to yellow head)

Power button

Y/Pb/P

COAXIAL

Mouse

Japan:

Note: The system supports either Y/Pb/Pr video output or D4 output. If a user intends to

use both connectors at the same time, the display screen will not work properly.

Europe:

7.1-ch Audio

LAN

USB

VGA

COM1

Keyboard

Add2 Card (DVI out)

S-video (connect to red head)

Composite out (connect to yellow head)

Y/Pb/Pr

D4 out (Japan only)

COAXIAL

7.1-ch Audio

LAN

USB

VGA

COM1

Keyboard

Add2 Card (DVI out)

COAXIAL

SCART out (Europe only)

Mouse
