ANTAIRA LMP-0501 Series Manual de usuario

Antaira Industrial Ethernet Switches

LMP-0501 Series User Manual V1.0

LMP-0501 Series

5-Port Industrial PoE+ Managed Ethernet Switches

4*10/100Tx (30W/Port), 1*100Fx, 48~55VDC Power Input

User Manual

Version 1.0

Antaira Industrial Ethernet Switches

LMP-0501 Series User Manual V1.0

This document contains information, which is protected by copyright. Reproduction, adaptation or translation

without prior permission is prohibited, except as allowed under the copyright laws.

Trademark Information

Antaira is a registered trademark of Antaira Technologies, LLC, Microsoft Windows and the Windows logo are the

trademarks of Microsoft Corp. NetWare is the registered trademark of Novell Inc. WMM and WPA are the

registered trademarks of Wi-Fi Alliance. All other brand and product names are trademarks or registered

trademarks of their respective owners.

translation without prior permission of Antaira Technologies, LLC is prohibited, except as allowed under the

Disclaimer

Antaira Technologies, LLC provides this manual without warranty of any kind, expressed or implied, including but

not limited to the implied warranties of merchantability and fitness for a particular purpose. Antaira Technologies,

LLC may make improvements and/or changes to the product and/or specifications of the product described in this

manual, without prior notice. Antaira Technologies, LLC will not be liable for any technical inaccuracies or

typographical errors found in this guide. Changes are periodically made to the information contained herein and

will be incorporated into later versions of the manual. The information contained is subject to change without prior

notice.

Antaira Industrial Ethernet Switches

LMP-0501 Series User Manual V1.0

iii

FCC Warning

This equipment has been tested and found to comply with the limits for a Class-A digital device, pursuant to Part 15 of the FCC

rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This

equipment generates, uses, and can radiate radio frequency energy. It may cause harmful interference to radio

communications if the equipment is not installed and used in accordance with the instructions. However, there is no guarantee

that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Caution: Any changes or modifications not expressly approved by the grantee of this device could void the user's

authority to operate the equipment.

CE Mark Warning

This is a Class-A product. In a domestic environment this product may cause radio interference in which case the

user may be required to take adequate measures.

Industrial Ethernet Switches

Industrial Grade PoE Managed Ethernet Switches

User Manual

Version 1.0 (November 2014)

This manual supports the following models:

LMP-0501-M

LMP-0501-M-T

LMP-0501-ST-M

LMP-0501-ST-M-T

This document is the current official release manual. Please check our website (www.antaira.com) for any

updated manual or contact us by e-mail ([email protected]).

LMP-0501-S3

LMP-0501-S3-T

LMP-0501-ST-S3

LMP-0501-ST-S3-T

Antaira Industrial Ethernet Switches

LMP-0501 Series User Manual V1.0

Table of Contents

1. Introduction................................................................. 1

1.1 Product Overview............................................... 1

1.2 Product Software Features ................................ 1

1.3 Product Hardware Features............................... 2

1.4 Package Contents.............................................. 2

1.5 Safety Precaution............................................... 3

2. Hardware Description................................................. 4

2.1 Physical Dimensions.......................................... 4

2.2 Front Panel ........................................................ 5

2.3 Top View............................................................ 5

2.4 LED Indicators ................................................... 6

2.5 Ethernet Ports.................................................... 7

2.6 2.6 Fiber Port ..................................................... 7

2.7 Cabling............................................................... 8

2.8 Wiring the Power Inputs..................................... 9

2.9 Wiring the Fault Alarm Contact.......................... 9

3.Mounting Installation ................................................ 10

3.1 DIN-Rail Mounting............................................ 10

3.2 Wall Mounting .................................................. 11

4.Hardware Installation................................................ 12

4.1 Installation Steps.............................................. 12

5.Web Management...................................................... 13

Antaira Industrial Ethernet Switches

LMP-0501 Series User Manual V1.0

5.1 Web Console Configuration............................. 13

5.1.1 About Web-Based Management................. 13

5.2 Basic Setting.................................................... 14

5.2.1 System Information..................................... 14

5.2.2 Admin &Password....................................... 15

5.2.3 IP Setting..................................................... 16

5.2.4 System Time............................................... 17

5.3 Port Management ............................................ 18

5.3.1 Port Status .................................................. 18

5.3.2 Port Configuration....................................... 18

5.4PoE (Power-over-Ethernet)............................... 19

5.4.1 PoE Configuration....................................... 19

5.4.2 Ping Alarm................................................... 20

5.4.3 PoE Schedule ............................................. 21

5.5 ERPS ............................................................... 21

5.5.1 ERPS Status............................................... 22

5.5.2 ERPS Configuration.................................... 23

5.5.3 Before Configuring ERPS........................... 24

5.5.3.1 Scenario A –RPL Configured Architecture26

5.5.3.2 Scenario B –Non-Configured Architecture29

5.6 Spanning Tree ................................................. 30

5.6.1 RSTP Status ............................................... 31

5.6.2 RSTP Configuration.................................... 31

5.6.3 MSTI Status ................................................ 33

Antaira Industrial Ethernet Switches

LMP-0501 Series User Manual V1.0

5.6.4 MSTI Configuration..................................... 34

5.7. 802.1Q VLAN.................................................. 36

5.7.1 802.1Q VLAN settings ................................ 36

5.7.2 802.1Q VLAN Settings................................ 37

5.8. IGMP Snooping............................................... 37

5.8.1 IGMP Settings............................................. 38

5.8.2 IGMP Snooping Status Table ..................... 38

5.9 QoS (Traffic Prioritization)................................ 39

5.9.1 QoS Classification....................................... 39

5.9.2 CoS Mapping .............................................. 40

5.9.3 ToS Mapping............................................... 41

5.10 Port Mirroring ................................................. 42

5.11 SNMP............................................................. 43

5.11.1 SNMP Agent ............................................. 43

5.11.2 SNMP Trap Setting................................... 44

5.12 System Warning............................................. 44

5.12.1 Syslog Setting........................................... 45

5.12.2System Event Log...................................... 46

5.12.3 SMTP Setting............................................ 46

5.12.4 Event Selection......................................... 47

5.12.5 Fault Alarm................................................ 48

5.13MAC Table...................................................... 48

5.13.1 MAC Address Table.................................. 48

5.13.2 MAC Table Configuration ......................... 49

Antaira Industrial Ethernet Switches

LMP-0501 Series User Manual V1.0

vii

5.14 Maintenance .................................................. 49

5.14.1 Upgrade .................................................... 49

5.14.2 Reboot....................................................... 50

5.14.3 Default....................................................... 50

5.15 Configuration.................................................. 50

5.15.1 Save.......................................................... 51

5.15.2 Backup & Store......................................... 51

5.15.3 Auto Load & Backup ................................. 52

5.16 Logout............................................................ 53

6.Command Line Interface Management ................... 53

6.1 About CLI Management................................... 53

7. Technical Specifications.......................................... 71

Antaira Industrial Ethernet Switches

LMP-0501 Series User Manual V1.0

1. Introduction

Antaira Technologies’ industrial managed switches come with a pre-installed “user friendly” web

console interface, which allows users to easily configure and manage the units, whether one is using

a serial console and command line interface(CLI) commands like Telnet, SSH, HTTP (Web GUI) or

simple network management protocols (SNMP).

1.1 Product Overview

Antaira’s LMP-0501 series is a 5-port industrial PoE+ managed Ethernet switch that is

embedded with four 10/100Tx Ethernet ports that support either IEEE802.3af or IEEE802.3at for

a maximum of 30 watts per port, and one 100Fx (SC or ST type) fiber port in a multi-mode(2Km)

or single-mode (30Km) option. It is a fully manageable industrial Ethernet switch that supports the

standard Layer 2 Ethernet configurable settings. This product series is IP30 rated and DIN-rail

mountable. There are two operating temperature models, either the STD: -10°C to 70°C, or the

EOT: -40°C to 75°C. It also provides high EFT and ESD protection for any industrial networking

application within factory automation, ITS, power/utility, water wastewater, and any other outdoor

or harsh environment.

1.2 Product Software Features

Network Redundancy

STP, RSTP, MSTP, ITU-T G.8032 Ethernet Ring Protection Switch (ERPS) for

network redundancy

Network Management

Web UI based management, SNMP v1/v2, Serial Console

Qos, traffic classification QoS, Cos, bandwidth control for Ingress and Egress,

broadcast storm control, Diffserv

IEEE802.1q VLAN, port-based VLAN support

IGMP snooping v1/v2, IGMP filtering / throttling, IGMP query up to 256 group

Supports RMON, MIB II, port mirroring, event syslog, DNS, NTP/SNTP, SSH/SSL,

TFTP.

Advanced PoE Ports Management (auto ping check)

Auto powered device (PD) detection

Auto reset (cycle power to unresponsive PD)

Antaira Industrial Ethernet Switches

LMP-0501 Series User Manual V1.0

PoE ports weekly power scheduling

Port Configuration

Status, statistics, mirroring, rate limiting, event syslog

Event Handling

Event notification by Email: Cold/Warm Start, Power Failure, Authentication, SNMP

trap and Fault Alarm Relay Output

Software Upgrade via TFTP and HTTP

Configuration Backup –USB Port

1.3 Product Hardware Features

System Interface and Performance

All RJ-45 ports support Auto MDI/MDI-X Function

Embedded 4*10/100Tx (PSE 30W/Port) RJ45 Ports, and 1*100Fx (SC/ST) fiber ports

with multi-mode (2Km) or single-mode (30Km)

Store-and-forward switching architecture

8K MAC address table

Power line EFT protection: 2,000VDC; Ethernet ESD protection: 6,000VDC

Power Input

DC 48~55V redundant with a 6-pin removal terminal block

One user programmable alarm relay contact

Operating Temperature

Standard operating temperature models: -10°C to 70°C

Extended operating temperature models: -40°C to 75°C

Case/Installation

IP-30 protection metal housing

Installation in pollution degree to environment

DIN-Rail and wall mount design

1.4 Package Contents

1–LMP-0501 series: 5-Port industrial PoE+ managed Ethernet switch, with 4*10/100Tx

(30W/Port) RJ45 ports, and 1*100Fx (SC/ST) fiber ports.

1-Product CD

2-Wall mounting brackets and screws

1-RJ45 to DB9 Serial Console cable

1-DC cable –18 AWG & DC jack 5.5x2.1mm

Antaira Industrial Ethernet Switches

LMP-0501 Series User Manual V1.0

1.5 Safety Precaution

Attention: If the DC voltage is supplied by an external circuit, please use a protection

device on the power supply input. The industrial Ethernet switch’s

hardware specs, ports, cabling information, and wiring installation will be

described within this user manual.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cambiar de ANTAIRA

ANTAIRA

ANTAIRA LMX-1802G-M12-10G-SFP-67-110 Series Manual de usuario

ANTAIRA

ANTAIRA LMP-1002G-10G-SFP-24 Manual de usuario

ANTAIRA

ANTAIRA LMX-0501G-SFP-V2 Series Manual de usuario

ANTAIRA

ANTAIRA LNX-0602 series Manual de usuario

ANTAIRA

ANTAIRA LMP-0501-24-V2 Series Manual de usuario

ANTAIRA

ANTAIRA LNP-0800-T Manual de usuario

ANTAIRA

ANTAIRA LNX-C800 Series Manual de usuario

ANTAIRA

ANTAIRA LNX-1802G Manual de usuario

ANTAIRA

ANTAIRA LMP-1202M-SFP-24 Series Manual de usuario

ANTAIRA

ANTAIRA LNX-1204G-10G-SFP Manual de usuario

ANTAIRA

ANTAIRA LNP-0800G-M12-67-24 Manual de usuario

ANTAIRA

ANTAIRA LNP-0702G-SFP Series Manual de usuario

ANTAIRA

ANTAIRA LNX-2004G-SFP Series Manual de usuario

ANTAIRA

ANTAIRA LMP-0602 V2 Series Manual de usuario

ANTAIRA

ANTAIRA LMP-1204G-SFP-bt-24 Series Manual de usuario

ANTAIRA

ANTAIRA LMP-0602-M-V2 Manual de usuario

ANTAIRA

ANTAIRA LNP-C800G Series Manual de usuario

ANTAIRA

ANTAIRA LNX-2012GN-SFP Manual de usuario

ANTAIRA

ANTAIRA LMP-2004G-SFP Series Manual de usuario

ANTAIRA

ANTAIRA LNP-1002G-SFP-24 Series Manual de usuario

ANTAIRA

ANTAIRA LNX-C500G Series Manual de usuario

ANTAIRA

ANTAIRA LMP-1802G-SFP Series Manual de usuario

ANTAIRA

ANTAIRA LMX-1802G-SFP Series Manual de usuario

ANTAIRA

ANTAIRA LMX-1802G-M12-10G-SFP-67 Series Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
