Anritsu Site Master S113C Manual de usuario

Site Master

S113C, S114C,

S331C, S332C,

Antenna, Cable and

Spectrum Analyzer

User's Guide

Hand-Held Tester for Transmission Lines

and other RF Components

WARRANTY

The Anritsu product(s) listed on the title page is (are) warranted against defects in

materials and workmanship for one year from the date of shipment.

Anritsu's obligation covers repairing or replacing products which prove to be defec-

tive during the warranty period. Buyers shall prepay transportation charges for

equipment returned to Anritsu for warranty repairs. Obligation is limited to the origi-

nal purchaser. Anritsu is not liable for consequential damages.

LIMITATION OF WARRANTY

The foregoing warranty does not apply to Anritsu connectors that have failed due to

normal wear. Also, the warranty does not apply to defects resulting from improper or

inadequate maintenance by the Buyer, unauthorized modification or misuse, or op-

eration outside the environmental specifications of the product. No other warranty is

expressed or implied, and the remedies provided herein are the Buyer's sole and

exclusive remedies.

TRADEMARK ACKNOWLEDGMENTS

MS-DOS, Windows, Windows 95, Windows NT, Windows 98, Windows 2000 and

Windows ME are registered trademarks of the Microsoft Corporation.

Anritsu and Site Master are trademarks of Anritsu Company.

NOTICE

Anritsu Company has prepared this manual for use by Anritsu Company personnel

and customers as a guide for the proper installation, operation and maintenance of

Anritsu Company equipment and computer programs. The drawings, specifications,

and information contained herein are the property of Anritsu Company, and any un-

authorized use or disclosure of these drawings, specifications, and information is

prohibited; they shall not be reproduced, copied, or used in whole or in part as the

basis for manufacture or sale of the equipment or software programs without the

prior written consent of Anritsu Company.

October 2001 10580-00060

Table of Contents

Chapter 1 - General Information

Introduction..................................1-1

Description ..................................1-1

Standard Accessories.............................1-1

Options ....................................1-2

Optional Accessories .............................1-2

Performance Specifications .........................1-3

Preventive Maintenance ...........................1-6

Calibration ..................................1-6

InstaCal Module ...............................1-7

Annual Verification..............................1-7

Chapter 2 - Functions and Operations

Introduction..................................2-1

Test Connector Panel.............................2-1

Front Panel Overview ............................2-2

Function Hard Keys .............................2-3

Keypad Hard Keys ..............................2-4

Soft Keys ...................................2-6

Power Monitor Menu ............................2-15

Symbols ...................................2-19

Self Test ...................................2-19

Error Codes .................................2-19

Self Test Errors ..................................2-19

Range Errors ...................................2-21

InstaCal Error Messages .............................2-22

Battery Information.............................2-24

Charging a New Battery ..........................2-24

Charging the Battery in the Site Master.....................2-24

Charging the Battery in the Optional Charger .................2-24

Battery Charge Indicator .............................2-25

Battery Life ....................................2-25

Important Battery Information .........................2-26

Chapter 3 - Getting Started

Introduction..................................3-1

Power On Procedure .............................3-1

Select the Frequency or Distance ......................3-2

Calibration ..................................3-2

Calibration Verification ..............................3-3

Manual Calibration Procedure ..........................3-4

InstaCal Module Verification ...........................3-5

InstaCal Module Calibration Procedure .....................3-6

Calibration with the Test Port Extension Cable .................3-6

Setting the Scale................................3-7

Auto Scale ......................................3-7

Amplitude Scale...................................3-7

Save and Recall a Setup ...........................3-7

Saving a Setup ...................................3-7

Recalling a Setup ..................................3-8

Save and Recall a Display ..........................3-8

Saving a Display ..................................3-8

Recalling a Display .................................3-8

Set the Distance and Cable Type .........................3-9

Changing the Units .................................3-9

Changing the Display Language..........................3-9

Printing....................................3-10

Printing a Screen .................................3-10

Printer Switch Settings ..............................3-11

Using the Soft Carrying Case........................3-12

Chapter 4 - Cable & Antenna Measurements

Introduction..................................4-1

Line Sweep Fundamentals ..........................4-1

Information Required for a Line Sweep ..................4-2

Typical Line Sweep Test Procedures ....................4-3

System Return Loss Measurement ........................4-3

Insertion Loss Measurement............................4-4

Distance-To-Fault (DTF) Transmission Line Test ................4-8

Antenna Subsystem Return Loss Test ......................4-10

Chapter 5 - Spectrum Analyzer Measurements

Introduction..................................5-1

Occupied Bandwidth .............................5-1

Channel Power Measurement ........................5-2

Channel Power Measurement with the Site Master ...............5-2

Adjacent Channel Power Measurement ..................5-4

Out-of-Band Spurious Emission Measurements ..............5-6

In-Band/Out-of-Channel Measurements ..................5-7

Field Strength Measurement.........................5-8

Antenna Calculations.............................5-9

Chapter 6 - Power Measurement

Introduction..................................6-1

Power Measurement .............................6-1

Chapter 7 - Site Master Software Tools

Introduction..................................7-1

Features ....................................7-1

System Requirements.............................7-1

Installation ..................................7-2

Communication Port Setting............................7-2

Interface Cable Installation ............................7-3

Using Software Tools .............................7-3

Downloading Traces from the Site Master .................7-3

Plot Capture..................................7-4

Plot Properties ................................7-4

Trace Overlay or Plot Overlay...........................7-5

Saving Traces ....................................7-5

Custom Cable List .................................7-6

Entering Antenna Factors .............................7-7

Uploading Antenna Factors ............................7-8

Creating a Database ................................7-8

Printing Formats ..................................7-8

Appendix A - Reference Data

Coaxial Cable Technical Data........................A-1

Appendix B - Windowing

Introduction .................................B-1

Examples ...................................B-1

iii/iv

Chapter 1

General Information

Introduction

This chapter provides a description, performance specifications, optional accessories, pre-

ventive maintenance, and calibration requirements for the Site Master models S113C,

S114C, S331C, and S332C. Throughout this manual, the term Site Master will refer to the

models S113C, S114C, S331C, and S332C.

Model Frequency Range

S113C

S114C

S331C

S332C

2 to 1600 MHz

2 to 1600 MHz, 100 kHz to 1600 MHz Spectrum Analysis

25 to 4000 MHz

25 to 4000 MHz, 100 kHz to 3000 MHz Spectrum Analysis

Description

The Site Master is a hand held SWR/RL (standing wave ratio/return loss), and Distance-To-

Fault (DTF) measurement instrument that includes a built-in synthesized signal source. All

models include a keypad to enter data and a liquid crystal display (LCD) to provide graphic

indications of SWR or RL over the selected frequency range and selected distance. The Site

Master is capable of up to 2.5 hours of continuous operation from a fully charged

field-replaceable battery and can be operated from a 12.5 dc source. Built-in energy conser-

vation features can be used to extend battery life over an eight-hour work day.

The Site Master is designed for measuring SWR, return loss, or cable insertion loss and lo-

cating faulty RF components in antenna systems. Power monitoring is available as an op-

tion. Site Master models S114C and S332C include spectrum analysis capability. The

displayed trace can be scaled or enhanced with frequency markers or limit lines. A menu

option provides for an audible “beep” when the limit value is exceeded. To permit use in

low-light environments, the LCD can be back lit using a front panel key.

Standard Accessories

The Software Tools PC-based software program provides a database record for storing

measurement data. Site Master Software Tools can also convert the Site Master display to a

Microsoft Windowsä95/98/NT4/2000/ME workstation graphic. Measurements stored in

the Site Master internal memory can be downloaded to the PC using the included null-mo-

dem serial cable. Once stored, the graphic trace can be displayed, scaled, or enhanced with

markers and limit lines. Historical graphs can be overlaid with current data, and underlying

data can be extracted and used in spreadsheets or for other analytical tasks.

The Site Master Software Tools program can display all of the measurements made with the

Site Master (SWR, return loss, cable loss, distance-to-fault) as well as providing other func-

tions, such as converting display modes and Smith charts. Refer to Chapter 7, Software

Tools, for more information.

1-1

The following items are supplied with the basic hardware.

·Soft Carrying Case

·AC-DC Adapter

·Automotive Cigarette Lighter 12 Volt DC Adapter,

·CDROM disk containing the Software Tools program. This program contains Fault Lo-

cation (DTF) and Smith Chart functions

·Serial Interface Cable (null modem type)

·InstaCal Module

·One year Warranty (includes battery, firmware, and software)

·User's Guide

Options

·Option 5 — Add Power Monitor

Optional Accessories

·Anritsu Precision N (m) Open/Short/Load, 42 dB, Part No. OSLN50LF

·Anritsu Precision N (f) Open/Short/Load, 42 dB, Part No. OSLNF50LF

·Anritsu Precision N (m) Short/Open, Part No. 22N50

·Anritsu Precision N (f) Short/Open, Part No. 22NF50

·Site Master Precision N (m) Load, 42 dB, Part No. SM/PL

·Site Master Precision N (f) Load, 42 dB, Part No. SM/PLNF

·7/16 (m) Precision Open/Short/Load, Part No. 2000-767

·7/16 (f) Precision Open/Short/Load, Part No. 2000-768

·Adapter, Precision N (m) to N (m), Part No. 34NN50A

·Adapter, Precision N (f) to N (f), Part No. 34NFNF50

·Adapter, 7/16 (f) to N (m), Part No. 510-90

·Adapter, 7/16 (f) to N (f), Part No. 510-91

·Adapter, 7/16 (m) to N (m), Part No. 510-92

·Adapter, 7/16 (m) to N (f), Part No. 510-93

·Adapter, 7/16 DIN (m) to 7/16 DIN (m), Part No. 510-96

·Adapter, 7/16 DIN (f) to 7/16 DIN (f), Part No. 510-97

·Armored Test Port Extension Cable, 1.5 meter, N (m) to

N (f), Part No. 15NNF50-1.5C

·Armored Test Port Extension Cable, 3.0 meter, N (m) to

N (f), Part No. 15NNF50-3.0C

·Armored Test Port Extension Cable, 5.0 meter, N (m) to

N (f), Part No. 15NNF50-5.0C

·Armored Test Port Extension Cable, 1.5 meter, N (m) to

N (m), Part No. 15NN50-1.5C

1-2

Chapter 1 General Information

·Armored Test Port Extension Cable, 3.0 meter, N (m) to

N (m), Part No. 15NN50-3.0C

·Armored Test Port Extension Cable, 5.0 meter, N (m) to

N (m), Part No. 15NN50-5.0C

·Armored Test Port Extension Cable, 1.5 meter, N (m) to

7/16 DIN (f), Part No. 15NDF50-1.5C

·Armored Test Port Extension Cable, 1.5 meter, N (m) to

7/16 DIN (m), Part No. 15ND50-1.5C

·RF Detector, 1 to 3000 MHz, N(m) input connector, 50 Ohms, Part No. 5400-71N50

·RF Detector, 0.01 to 20 GHz, N(m) input connector, 50 Ohms, Part No. 560-7N50B

·Transit Case for Site Master, Part No. 760-215A

·Antenna SMA (f), 50 W, 1.71 to 1.88 GHz, Part No. 2000-1030

·Antenna SMA (f), 50 W, 1.85 to 1.99 GHz, Part No. 2000-1031

·Antenna SMA (f), 50 W, 2.4 to 2.5 GHz, Part No. 2000-1032

·Antenna SMA (f), 50 W, 806 to 869 MHz, Part No. 2000-1034

·Antenna SMA (f), 50 W, 896 to 941 MHz, Part No. 2000-1035

·HP Deskjet 350 Printer, Part No. 2000-766

·Serial-to-Parallel Converter Cable (use with the HP 350 Printer), Part No. 2000-753

·Seiko DPU-414 Thermal Printer, Part No. 2000-754 (U.S.) or

2000-761 (Europe)

·US Adapter (use with the DPU-414 Printer),

Part No. 2000-1002

·Europe Adapter (use with the DPU-414 Printer)

Part No. 2000-1003

·Japan Adapter (use with the DPU-414 Printer)

Part No. 2000-1194

·Battery Pack (use with the DPU-414 Printer)

Part No. 2000-1004

·Serial Interface Cable (use with the DPU-414 Printer),

Part No. 2000-1012

·Thermal Paper (use with the DPU-411/DPU-414 Printer),

Part No. 2000-755

·Rechargeable Battery, NiMH

Part No. 633-27

·Battery Charger with universal power supply, NiMH only

Part No. 2000-1029

Performance Specifications

Performance specifications are provided in Table 1-1, on the following page.

1-3

Chapter 1 General Information

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Equipo de prueba de Anritsu

Anritsu

Anritsu MD8470A Hoja de especificaciones

Anritsu

Anritsu 3656B W1 Manual de usuario

Anritsu

Anritsu Network Master Series Manual de usuario

Anritsu

Anritsu MG369 A Series Manual de usuario

Anritsu

Anritsu MT8852B Manual del propietario

Anritsu

Anritsu MP1590B Manual de usuario

Anritsu

Anritsu MP2110A BERTWave Manual de usuario

Anritsu

Anritsu MT9812B Manual de usuario

Anritsu

Anritsu MT1000A Network Master Pro Manual de usuario

Anritsu

Anritsu Precision AutoCal 36585 Series Manual de usuario

Anritsu

Anritsu InterferenceHunter MA2700A Manual de usuario

Anritsu

Anritsu Site Master S113B Manual de usuario

Anritsu

Anritsu MT1000A Network Master Pro Manual de usuario

Anritsu

Anritsu MD8480A Manual de usuario

Anritsu

Anritsu MP1590B Manual de usuario

Anritsu

Anritsu MS8608A Manual de usuario

Anritsu

Anritsu MT1000A Network Master Pro Manual de usuario

Anritsu

Anritsu MT9810A Manual de usuario

Anritsu

Anritsu Network Master Series Manual de usuario

Anritsu

Anritsu MX900030A Manual de usuario

Anritsu

Anritsu SQA-R MP1900A Manual de referencia

Anritsu

Anritsu MT9810B Manual de usuario

Anritsu

Anritsu 693 B Series Manual de usuario

Anritsu

Anritsu Network master Pro Manual de usuario

Manuales populares de Equipo de prueba de otras marcas

SMART

SMART KANAAD SBT XTREME 3G Series Manual de usuario

Agilent Technologies

Agilent Technologies BERT Serial Manual de usuario

Agilent Technologies

Agilent Technologies N3280A Manual de usuario

Vernier

Vernier Go Direct Voltage Manual de usuario

Lifeloc

Lifeloc R.A.D.A.R. Manual de usuario

Fluke

Fluke T5-600 Instrucciones de funcionamiento e instalación

Mercury

Mercury TSL01 Manual de usuario

MAHA

MAHA MBT Series Manual de usuario

Fuji Electric

Fuji Electric P-61 Manual de usuario

ETC

ETC SealerAtor Manual de usuario

Skyfine

Skyfine ETHYWAY V2 Manual de usuario

Appion

Appion G5 Twin Manual de usuario

PCB Piezotronics

PCB Piezotronics 8159-0112A Manual de usuario

BW Technologies

BW Technologies MicroDock II Manual de usuario

Sun Nuclear

Sun Nuclear 1027 Manual de usuario

Biomark

Biomark HPR LITE READER Manual de usuario

Hioki

Hioki 3169-20 Manual de usuario

Ashcroft

Ashcroft ATE-100 Manual de usuario
