AmScope UHM210-11 Manual de usuario
UHM210-11 Digital Microscope
Introducon
This manual applies to the UHM210-11 digital microscope. The informaon in this manual is provided to help you famil-
iarize yourself with the assembly and use of the products. Please read thoroughly before using the products, and keep
this manual with the product for reference.
v1.0.20220725
Safety
Before using your AmScope microscope, please read the following safety precauons carefully to avoid causing damage to
your AmScope product, or injury to yourself or others.
Turn o power if the instrument exhibits unusual or dangerous behavior such as eming smoke or unusual odors. These
can be indicaons of electrical problems, in which case the instrument should be disconnected from any power source if
safe to do so. Other indicators can be a loud buzzing sound or crackling. Contact AmScope to report such behavior.
Do not use around ammable liquids or gases. Electric instruments can ignite ammable substances which could result
in an explosion or re.
Do not use in a wet environment. Electrical components of the instrument can discharge when exposed to water, poten-
ally resulng in damage to the instrument, or injury to yourself or others.
Only use the provided power adapter or authorized replacement. Incompable power adapters can cause damage to the
instrument. If you should lose the included power adapter, please contact AmScope for informaon about a replacement.
Do not dismantle. Dismantling can result in damage to the instrument, and potenal exposure to dangerous materials or
electric current.
Noces
AmScope reserves the right to change specicaons of the hardware and soware at any me without noce. Connuous
eorts are made to improve performance and reliability, which can result in changes to design and compability. Please
contact AmScope for any concerns regarding such changes.
Proposion 65 Noce for California Residents
Cables included with the products described in this manual can expose you to chemicals including lead,
which is known by the state of California to cause cancer, birth defects or other reproducve harm. Visit
www.P65Warnings.ca.gov for more informaon.
Contents
Specicaons.......................................................................................................................................................... 4
What’s In The Box................................................................................................................................................... 5
The Control Panel ................................................................................................................................................... 6
Operaon ............................................................................................................................................................... 7
Arculang Arm ................................................................................................................................................... 7
Focus .................................................................................................................................................................... 8
Illuminaon .......................................................................................................................................................... 8
Operang Mode: HDMI.......................................................................................................................................... 9
Recording Media .................................................................................................................................................. 9
Imaging Modes................................................................................................................................................... 10
Photo and Video Modes .................................................................................................................................................. 10
Photo and Video Sengs Menus Page 1/5........................................................................................................................................................... 11
Photo Sengs Menu Page 2/5 ............................................................................................................................................................................. 12
Video Sengs Menu Page 2/5.............................................................................................................................................................................. 13
Photo and Video Sengs Menus Page 3/5........................................................................................................................................................... 14
Photo and Video Sengs Menus Page 4/5........................................................................................................................................................... 15
Photo and Video Sengs Menus Page 5/5........................................................................................................................................................... 16
Playback Mode................................................................................................................................................................. 17
Playback Menu...................................................................................................................................................................................................... 18
Operang Mode: PC ............................................................................................................................................. 19
UHM210-11 User Guide UHM210-11 User Guide
4amscope.com
180mm
215mm
208mm
UHM210-11 User Guide
5
amscope.com
Specicaons
Model UHM210-11
Opcal Magnicaon 0.11X-0.79X
Working Distance 44mm-230mm
Depth of Field 0.8mm-6.5mm
Sensor IMX291 (color)
Sensor Type CMOS
Sensor Opcal Format 1/2.8”
Acve Recording Pixels 2.07M (1920 x 1080)
Pixel Size 2.9µm x 2.9µm
Acve Sensor Area 5.57mm x 3.13mm
Shuer electronic rolling shuer
Sensivity 1300mV @ 1/30s (f/5.6)
Video Resoluons 1920x1080 30fps, 1280x720 60fps
File Formats JPG (photo), MOV (video)
Recording Media MicroSD up to 128GB
I/O Mini-HDMI (video out), USB-C (data and power)
Ring Light 1 18 LED
Ring Light 2 13 LED
Power Requirements DC 5V 900mA over USB
What’s In The Box
The UHM210-11 standard ouit includes:
• One microscope on arculang stand
• One HDMI cable
• One USB cable
• One power adapter (AC to USB)
UHM210-11 User Guide UHM210-11 User Guide
6amscope.com
The Control Panel
USB Type C
Power/PC Connection
Zoom In / Up
HDMI Out
Zoom Out / Down
MicroSD Slot
Mode / OK / Reticle
Power Switch
Power Indicator Light
Menu / Freeze
Wired Control Input
Cature / Record
Decrease
Focal Length
Increase
Focal Length
Diuse Illumination
Direct Illumination
UHM210-11 User Guide
7
amscope.com
Operaon
This microscope can be used as a standalone device when paired with an HDMI monitor, or as a USB device when
connected to a PC. When connected to a PC using USB, the microscope will enter PC mode, taking precedence over the
standalone funcons.
Arculang Arm
The arculang arm can be adjusted around three joints to posion the microscope at virtually any angle and posion
within the reach of the arm. All joints are locked simultaneously using the locking knob. Before adjusng the arm, be
sure to support the microscope with a hand. Next loosen the locking knob unl the arm joints are loose enough to easily
move. Posion the microscope as desired, then ghten the locking knob. Avoid extending the arm beyond the rear edge
of the support plate, as this could lead to the microscope pping over.
UHM210-11 User Guide UHM210-11 User Guide
8amscope.com
Focus
The microscope’s focus is mechanically controlled using a knob on the control panel. Rotang the knob clockwise will
extend the working distance to focus on objects farther away. Rotang the knob counter-clockwise will reduce the work-
ing distance to focus on closer objects. Magnicaon is also aected by these adjustments, increasing as the working
distance is shortened.
Illuminaon
The microscope is equipped with two independent ring lights. Each ring light is controlled by a separate knob on the side
of the microscope. While the microscope is connected to a power source, the ring lights will operate independent of the
microscope’s power switch. The knob engraved with the number 1 controls the outer ring light which provides diuse
illuminaon which is suitable for most observaon as it more even. The knob engraved with the number 2 controls the
inner ring light which provides direct illuminaon which is well-suited for viewing surface details such as scratches and
textures. Rotate either knob clockwise to increase brightness, or counter-clockwise to decrease brightness.
UHM210-11 User Guide
9
amscope.com
Operang Mode: HDMI
To operate in HDMI mode, the microscope must be aached to a power supply using the included USB cable. The cable
has a type-C connector on one end, and a type-A connector on the other. The USB-C connector must be connected to the
microscope’s USB/Power port. To power the microscope using AC power, plug the included AC-USB adapter into an AC
outlet, then plug the USB cable’s type-A connector into the USB port on the adapter. Alternavely, a 5V USB power bank
can be used as long as it can supply at least 900mA. In this case, the USB cable’s type-A connector would plug directly
into one of the power bank’s type-A USB ports.
To connect this microscope to an HDMI monitor, television, or other compable viewing device, use the included HDMI
cable or another compable cable with the appropriate connectors. The included cable has a mini-HDMI connector on
one end, and a standard HDMI connector on the other. Plug the mini-HDMI connector into the microscope’s HDMI port.
Plug the other end into the viewing device’s HDMI input. Move the microscope’s power switch to the “I” (on) posion.
Aer a few seconds, a live image will be displayed on the screen.
While in HDMI mode, the microscope uses internal soware to capture images and video, as well as to control the imag-
ing device’s sengs. Several icons may be displayed on the screen, displaying such things as the imaging mode, expo-
sure, white balance, and media status. The icons will be hidden aer 10 seconds of inacvity, but will display again when
a control buon is pressed.
Recording Media
In order to capture or play photos/videos in any mode, a formaed MicroSD card must be inserted into the MicroSD slot.
When compable media is present, the icon will be displayed. If no compable media is found, the icon will be
displayed.
Captured photos will be automacally saved in JPEG format to the MicroSD card using a sequenal naming convenon:
photo_00001.jpg, photo_00002.jpg, etc.. Captured videos will be automacally saved in MOV format to the MicroSD
card using a sequenal naming convenon: video_0001.jpg, video_0002.jpg, etc..
This microscope is compable with MicroSD cards up to 128GB. In the case that a 64GB or larger card is not recognized
by this device, and the formang funcon does not work, it is recommended to format the card as FAT32 using a com-
puter.
UHM210-11 User Guide UHM210-11 User Guide
10 amscope.com
Imaging Modes
This microscope has three imaging modes: Photo, Video, and Playback. Each mode will have access to sengs and func-
ons which are accessed by using the control panel. The control buons may have dierent funcons depending on the
mode and which screen is currently displayed. Addionally, pressing and holding certain buons for 2 seconds will ac-
vate specic funcons depending on the mode. While no menu is displayed, pressing the right buon will cycle through
the imaging modes.
Photo and Video Modes
Photo and Video modes allow you to view live video and capture images. An assortment of sengs and funcons are
available in both modes to opmize image quality and user experience. Some sengs or funcons are exclusive to their
respecve modes. The control panel’s buons provide the same funconality in both modes aside from the Capture
buon which saves sll images in Photo mode, and starts or stops recording in Video mode.
Zoom In / Up
Menu / Freeze
Capture Image
Zoom Out / Down
OK / Reticle
When the menu is closed, the buons control the following funcons:
Press the center buon to capture a photo (Photo mode) or to start/stop recording (Video mode).
Press the top buon to increase digital zoom up to 4X.
Press the boom buon to decrease digital zoom.
Press the le buon to open the sengs menu.
Press and hold the le buon for 2 seconds to freeze the image.
Press and hold the right buon for 2 seconds to display a recle.
When the menu is open, the buons control the following funcons:
Press the top buon to navigate up.
Press the boom buon to navigate down.
Press the le buon to exit the current seng or menu.
Press the right buon to select a menu or opon.
