AmScope SE400 Series Manual de usuario

SE400

Series

User’s Manual

SE400

Series

abl

Contents

Before Use..........................................................................................3

Introduction ............................................................................................................. 3

Safety Precautions ................................................................................................... 4

Parts .............................................................................................. 5

SE400 .................................................................................................................. 5

Definition of Parts ............................................................................................... 6

Getting Started ............................................................................ 8

Assembly .................................................................................................................. 8

Operation .................................................................................... 9

Setting p ................................................................................................................... 9

Attaching a Camera ............................................................................................. 9

Maintenance/Precautions ..................................................................................... 10

Specifications.............................................................................. 11

Specifications ......................................................................................................... 11

Optional Accessories ............................................................................................. 11

Technical Terms & Concepts .......................................................................... 12

Troubleshooting........................................................................ 13

Common Issues (Optical) .................................................................................. 13

Common Issues (Mechanical) ........................................................................... 14

SE400

Series

Before

Use

Introduction

Congratulations on the purchase of your new AmScope microscope!

This manual is designed for the SE400 series microscopes.

Please take a few minutes to familiarize yourself with the features and functions of your new mi-

croscope.

If you’d like more information on microscopes, parts, or accessories, please visit our website at:

www.iScopeCorp.com

We highly recommend you study this manual thoroughly before operating the microscope and

that you keep it on hand for future reference.

If you have additional questions or need assistance, please send ius an email at:

info@amscope.com

SE400

Series

Before

Use

Safety Precautions

As the microscope is a precision instrument, always handle it with care, avoiding impact

or abrupt movement during transportation. Do not shake the package.

Do not place the microscope in direct sunlight or in high heat. Keep it indoors in a dry

and clean place with temperatures between 32-100 degrees F (0-40 degrees C), and in

maximum relative humidity of 85%.

Avoid touching the lenses on the objectives and the eyepieces so that oil and dirt from

your fingerprints do not obstruct your view.

Before turning the power on, make sure that the power supply voltage is consistent with

the voltage of your microscope (for units with built in illumination).

SE400

Series

Parts

SE400

Eyepieces

Top Light

Pillar Boom Stand

Boom Arm

Locking Knobs

Objective

Focusing Knob

Power Switch

Dust Cover

SE400

Series

Parts

Definition of Parts

AdjustableTrinocularPort

Threaded port with adjustable length of attachment of digital or video camera

Boom Stand

Stand for the microscope that allows the head to be moved in physical space in various directions

Continuous Zoom

A microscope head with a knob to change magnification through a range

Dimmer

Controls the amount of light that escapes from the illumination source

Diopter

Allows the focus to be perfected for both eyes, independent of each other

Fixed Power

Microscope head whose objectives are pre-set at certain levels and changed by rotating the objective

FocusingKnob

sed to move the microscope head vertically to bring the sample into focus

FrostedGlass Plate

A clear plate with frosted finish to provide a bottom light source for translucent samples

GooseneckIlluminator

Illuminator independent of the unit that allows movement of one or two necks for controlled lighting

Head Lock Screw

Screws the microscope head into place

Magnification Knob

Changes the magnification of the lenses on a continuous zoom microscope

SE400

Series

Parts

Microscope Head

Contains the objective lens, eyepiece ocular tubes, and prisms used to magnify

Ocular Tube

Tube designed to hold the eyepieces or camera in place

Opaque Stage

Opaque plate to provide a contrasting background for viewing a sample with ease

Ring Light

An illuminator that mounts directly onto the objective to emit even light on the sample below

Simul-FocalMicroscopeHead

Head containing a focus adjustment for a trinocular port camera to simultaneously to match the eyepieces

Table Stand

A stand which sits on the table and holds the head directly above the sample without moving

SE400

Series

Getting

Started

Assembly

First, take the styrofoam container out of the cardboard carton and lay it on its side, paying attention to which

side is labeled up. Remove the tape and open the container carefully so as to avoid dropping and damaging the

optical items. Check carefully to ensure that all parts and accessories are intact.

Check the packing list to ensure that you’re received all items.

Stereo Microscope Body & Stand

5x Widefield Eyepieces (X models only)

10x Widefield Eyepieces (Typically these come on the microscope)

15x Widefield Eyepieces (Y models only)

20x Widefield Eyepieces (Z models only)

Dust Cover

Tungsten Light Source

Tension Adjustment Wrench

Remove the microscope body from the box and remove the plastic protective covering. The body of the micro-

scope is composed of the head of the microscope and the base.

Insert the vertical pillar into the base if not already installed. Wrap the cable around the top to avoid slack in

the cable if desired.

Insert the boom into the joint and secure. Attach light to the head via inserting it in the rear of the head of the

microscope.

Remove the eyetube caps and drop the desired eyepieces into the eyepiece ocular tubes. Be sure to avoid

touching the lens to ensure no artifacts appear in your image.

Remove the cap from the objective lens.

Plug in the microscope and turn it on.

SE400

Series

Operation

Setting Up

Once you have placed your sample on the base below the objective, center the sample as best as possible. A slide

is neither needed nor required for a stereo microscope, although they can be used if desired. If using a slide, use

the stage clips to hold it in place.

Select which magnification setting you would like to achieve by using the 10x eyepieces for the 10x setting, or

using one of the other eyepieces included with an X, Y, or Z model.

With both eyes open, look into the eyepieces. Adjust the interpupillary distance by holding the eyepiece tubes

and rotating the eyepiece tubes either towards or away from each other until only one circle of light is seen by both

eyes.

Focus the microscope on the sample by using the focusing knob on the arm of the microscope.

Center the object in the field of view once you have achieved focus.

Attaching a Camera

Remove the eyepiece from the microscope. You may need to unscrew the locking screw on the microscope ocu-

lar tube to remove the eyepiece.

Slide in the 23mm to 30.5mm adapter included with your CMOS camera.

Insert the camera into the 23mm side of the adapter.

SE400

Series

Operation

Maintenance/Precautions

All glass surfaces must be kept clean. Fine dust on the optical surface should be blown off using a hand blower or

gently wiped off with a soft lens paper tissue/nonabrasive lint free cloth.

Carefully wipe off oil or fingerprints on the lens surfaces using tissue moistened with a small amount of lens

cleaner (we recommend Sparkle brand optical cleaner).

Do not use Sparkle to clean other elements of the microscope. Use a neutral detergent on any plastic or painted

surfaces.

Do not assemble or disassemble the microscope’s electrical components yourself without advisement from one of

our technicians. Doing so will void your warranty unless by advisement of one of our technicians to do so.

After use, cover the microscope with the provided dust cover.

Keep your AmScope microscope in a dry, clean location in order to prevent rust or other damages.
