AmScope M620 Series Manual de usuario

M620

Series

User’s Manual

M620

Series

abl

Contents

Before Use........................................................................................................... 3

Introduction.............................................................................................3

Safety Precautions ..................................................................................4

Parts............................................................................................................... 5

M620.................................................................................................5

Definition of Parts ............................................................................... 6

Getting Started ...........................................................................................7

Assembly.................................................................................................7

Operation ...................................................................................................8

Setting Up.................................................................................................. 8

Focusing ..................................................................................................8

Adjusting The Diaphragm................................................................... 8

Attaching a Camera / Changing Eyepieces...........................................8

Setting the Stage’s Stop-Limit ...............................................................9

Maintenance/Precautions .................................................................... 10

Specifications..............................................................................................11

Specifications....................................................................................... 11

Optional Accessories........................................................................... 12

Objectives..........................................................................................13

Eyepieces ............................................................................................. 13

Technical Parameters ...............................................................................14

Electrical System...............................................................................14

Technical Terms & Concepts ..........................................................15

Troubleshooting.......................................................................................16

Common Issues.................................................................................... 16

Common Issues (Continued).............................................................17

M620

Series

Before

Use

Introduction

Congratulations on the purchase of your new AmScope microscope! This manual is designed for the

M620 series microscopes. It comes with a professional monocular head, double layer mechanical

stage, coarse & fine focusing, and LED illumination. There are eight magnification settings: 40X,

64X, 100X, 160X, 400X, 640X, 1000X & 1600X. This microscope is an ideal instrument for bacterial,

biological, and pharmaceutical researches.

Please be sure to take a few minutes to familiarize yourself with the features and functions of your

new

AmScope microscope.

If you’d like more information on microscopes, parts, or accessories, please visit our website at:

www.amscope.com

We highly recommend you study this manual thoroughly before operating the microscope and

that

you keep it on hand for future reference.

If you have additional questions or need assistance, please send us an email at:

info@amscope.com

M620

Series

Before

Use

Safety Precautions

As the microscope is a precision instrument, always handle it with care, avoiding impact

or abrupt movement during transportation. Do not shake the package.

Do not place the microscope in direct sunlight or in high heat. Keep it indoors in a dry

and clean place with temperatures between 32-100 °F (0-40 °C), and in

maximum

relative humidity of 85%.

Avoid touching the lenses on the objectives and the eyepieces so that oil and dirt from

your fingerprints do not obstruct your view.

Before turning the power on, make sure that the power supply voltage is consistent with

the voltage of your microscope.

M620

Series

Parts

M620

Eyepiece

Ocular Tube

Rotating Monocular Head

Nosepiece Turret

Objectives

Limit Stop

Stage

StageClips

Condenser

Fine Focusing

Knob

Illuminator Lens Coarse Focusing

Knob

M620

Series

Parts

Definition of Parts

BaseIlluminatorLens

Directs the light source towards the slide

Focusing Knob

Used to bring the slide into the sight and focus

Disc Iris Diaphragm

Controls the amount of light that hits the slide from the base illuminator

Dimmer

Controls the amount of light that escapes from the base lens

Limit Stop Knob

Limits the upward movement of the mechanical stage in order to avoid damaging the slide and objective

Nosepiece

Houses the objective lenses

Rotating Monocular Head

Houses the eyepiece and optics of the microscope

M620

Series

Getting

Started

Assembly

First, take the styrofoam container out of the cardboard carton and lay it on its side, paying attention

to which

side is labeled up. Remove the tape and open the container carefully so as to avoid dropping

and damaging the

optical items. Check carefully to ensure that all parts and accessories are intact.

Check the packing list to ensure that you’re received all items:

One Monocular Microscope Body & Head

Four Objectives (4x, 10x, 40x, 100x)

10x Widefield Eyepieces

16x Widefield Eyepieces (for -A models only)

20x Widefield Eyepieces (for -B models only)

25x Widefield Eyepieces (for -C models only)

One Dust Cover

Note: LED models do not have a spare bulb, as the LED bulbs do not need replacing.

Remove the microscope body from the box and remove the plastic protective covering. The body of

the micro-

scope is composed of the base, the stage, the arm, and the nosepiece.

Screw the objectives into the microscope nosepiece from the lowest magnification to the highest,

again avoiding touching the lenses.

Plug in the microscope and turn it on. If no light emerges from the light source, adjust the

dimmer knob on

the side of the base.

M620

Series

Operation

Setting Up

Place the specimen to be studied on a glass slide (or use a prepared slide). Place it on the stage,

holding it snugly

in place with the metal slide holders (clips) of the mechanical stage.

Center the specimen over the stage opening, lining it up with the light and the objective lens.

To adjust the illumination, slowly turn the dimmer on the right side of the base until the desired

intensity of

light is achieved.

Focusing

Turn the nosepiece to choose an objective. It is easiest to use the lowest magnification first (4x

objective) to lo-

cate and focus on the specimen. As you move up in magnification you may need to

refocus the image a little each

time.

Being focusing by first looking with one eye through the eyepiece without the diopter. Close your

other eye. Use

the coarse focusing knob to adjust the height of the stage until the sample comes into

clear focus.

Note: You may loosen the limit-stop knob (located on the read of the stage) in order to give yourself the

full range

of motion for fine tuning the focus.

Once the image is clear in your field of view, you will want to use the fine focusing knob to tune it for

best results.

Note: Please be careful when moving the mechanical stage if you need to re-center the sample, or if

moving the

stage very close to the objectives. The limit stop is designed to prevent impact between

objective and slide, so when

it is off you will be able to damage the microscope.

Adjusting the Diaphragm

1. By changing the aperture (hole size) of the iris diaphragm, you can adjust the background brightness.

Adjust the

aperture of the iris diaphragm by rotating the disc underneath the stage to the desired

aperture.

Attaching a Camera / Changing Eyepieces

1. To remove the 10x eyepiece included on the microscope, you will need to remove the small metal

screw on the

ocular tube just under where the eyepiece connects to the tube. To do so, you will need a

1mm flathead precision

screwdriver (much like what you would use to adjust eye glasses).

M620

Series

Operation

Setting the Stage’s Stop-Limit

To adjust the stop limit on the stage, unlock it by unscrewing the lower nut. The stop limit is located at the rear

of the stage.

Once tension is released on the nut by rotating it counter clockwise, you may adjust the upper thumb screw to

move the limit up or down as desired.

Lock the limit stop nut back into place after the desired stage height is achieved.

M620

Series

Operation

Maintenance/Precautions

All glass surfaces must be kept clean. Fine dust on the optical surface should be blown off using a can of com-

pressed air or gently wiped off with a soft lens paper tissue/nonabrasive lint free cloth.

Carefully wipe off oil or fingerprints on the lens surfaces using tissue moistened with a small amount of lens

cleaner (we recommend Sparkle brand optical cleaner).

Do not use Sparkle to clean other elements of the microscope. Use a neutral detergent on any plastic or painted

surfaces.

Do not assemble or disassemble the microscope’s electrical components yourself without advisement from one of

our technicians. Doing so will void your warranty unless by advisement of one of our technicians to do so.

After use, cover the microscope with the provided dust cover.

Keep your AmScope microscope in a dry, clean location in order to prevent rust or other damage.

To change batteries with this unit, use the included allen wrench (hexagonal shaped L-tool) to undo the door hex

screw on the base. Use 3 AAA batteries with the unit.

The unit can be used as a recharger for AAA batteries specified as rechargeable only. Please do not use standard

batteries in the unit with the charger plugged in to avoid damage.
