Amprobe PXP-A Manual de usuario

5XP-A

15XP-A

35XP-A

Compact Digital Multimeters

Users Manual

English

99 Washington Street

Melrose, MA 02176

Fax 781-665-0780

TestEquipmentDepot.com

2A MAX

FUSED

CAT 600V

CAT 1000V

CAT 300V

COM A

MAX

1000V

750V

Hz Temp

400

1000

35XP-A

RANGE NON

CONTACT

VOLTAGE

HOLD

auto-off

°C

OFF

°F

1832 400

35XP-A

CMY

pn2728995_frontispiece_press.pdfPage 1 8/28/2006 11:29:22 AM

XP Series Digital Multimeters

Contents

Safety Information ..............................................................................................2

Symbols Used in this Manual .............................................................................3

Making Measurements........................................................................................3

Verify Instrument Operation.............................................................................3

Range Selection...............................................................................................3

Correcting an Overload (0o or -0o) Indication W............................................3

Measuring DC Voltage See Figure -1- .....................................................3

Measuring AC Voltage See Figure -2- .....................................................4

Preparing for Current Measurements...............................................................4

Measuring DC Current See Figure -3- .....................................................4

Measuring AC Current See Figure -4- .....................................................4

Measuring Resistance See Figure -5- .....................................................5

Testing for Continuity See Figure -6- .....................................................5

Testing Diodes See Figure -7- .....................................................5

Measuring Capacitance (35XP-A only) See Figure -8-..................................5

Measuring Temperature (35XP-A only) See Figure -9-.................................6

Measuring Frequency (35XP-A only) See Figure -10-...................................6

Measuring NCV (Non-Contact Voltage) See Figure -11- ...........................6

Testing Battery Voltage (5XP-A only) See Figure -12-..................................6

Testing Logic Levels (15XP-A only) See Figure -13- ....................................7

Additional Features .............................................................................................7

Input Test Lead Warning..................................................................................7

MIN MAX Measurements (Model 5XP-A only).................................................7

Auto Power Off (Models 15XP-A and 35XP-A only).........................................7

HOLD Measurements.......................................................................................7

Product Maintenance..........................................................................................8

Cleaning...........................................................................................................8

Troubleshooting...............................................................................................8

Battery and Fuse Replacement See Figure -14- .......................................8

Repair .................................................................................................................9

Specifications ...................................................................................................10

2A MAX

FUSED

CAT 600V

CAT 1000V

CAT 300V

COM A

MAX

1000V

750V

200mA MAX

FUSED

BATT 1.5V

BATT 9V

CAT 600V

CAT 1000V

CAT 300V

VCOM mA

MAX

1000V

750V

LOGIC

15XP-A

RANGE NON

CONTACT

VOLTAGE HOLD

5XP-A

MIN MAX NON

CONTACT

VOLTAGE HOLD

1000750 200200

2020

200

20k

200k

20M

200m

20m

200

auto-off

OFF

200

20m

1.5V 9V

200

BATT

35XP-A

15XP-A5XP-A

2A MAX

FUSED

CAT 600V

CAT 1000V

CAT 300V

COM A

MAX

1000V

750V

Hz Temp

400

1000

RANGE NON

CONTACT

VOLTAGE HOLD

auto-off

˚C

OFF

˚F

1832 400

35XP-A

Safety Information

•The XP Series Digital Multimeters conform to EN61010-1, Rev-2; CAT I 1000 V,

CAT II 600 V, CAT III 300 V, class 2 and pollution deg.2; CSA 22.2 -1010-1.

•This instrument is EN61010-1 certified for Installation Category I (1000V). It

may only be used to make measurements on energy limited circuits within

equipment and not directly connected to mains.

•This instrument is EN61010-1 certified for Installation Category II (600 V). It is

recommended for use with local level power distribution, appliances, portable

equipment, etc, where only smaller transient overvoltages may occur, and not

for primary supply lines, overhead lines and cable systems.

•This instrument is EN61010-1 certified for Installation Category III ( 300 V). It is

recommended for use in distribution level and fixed installations, as well as

lesser installations, and not for primary supply lines, overhead lines and cable

systems.

•Do not exceed the maximum overload limits per function (see specifications)

nor the limits marked on the instrument itself. Never apply more than 1000 V

dc/750 V ac rms between the test lead and earth ground.

•Inspect the DMM, test leads and accessories before every use. Do not use any

damaged part.

•Never ground yourself when taking measurements. Do not touch exposed

circuit elements or test probe tips.

•Do not operate the instrument in an explosive atmosphere.

•Exercise extreme caution when: measuring voltage >20 V // current >10 mA //

AC power line with inductive loads // AC power line during electrical storms //

current, when the fuse blows in a circuit with open circuit voltage >1000 V //

servicing CRT equipment.

•Always measure current in series with the load – NEVER ACROSS a voltage

source. Check fuse first. Never replace a fuse with one of a different rating.

•Remove test leads before opening the case.

Symbols Used in this Manual

B Battery WRefer to the manual

TDouble insulated XDangerous Voltage

FDirect Current JEarth Ground

BAlternating Current RAudible tone

I Fuse )Canadian Standards Association

Complies with EU

directives zNon-contact Voltage

Making Measurements

Verify Instrument Operation

Before attempting to make a measurement, verify that the instrument is operational

and the battery is good. If the instrument is not operational, have it repaired before

attempting to make a measurement.

Range Selection

In addition to autoranging (Models 15XP-A and 35XP-A only) you can manually

select and lock a range by pressing the RANGE button. RANGE appears on the

display to indicate that manual ranging is active and the range is locked. When

appropriate, each subsequent press of the range button steps the meter to the next

higher range. When the highest range is reached the next press returns the meter

to the lowest range. To return to autoranging press the RANGE button. If RANGE

still shows on the display, autoranging is not available for the selected function.

Use autorange for all initial measurements. Then, when appropriate, use the RANGE

button to select and lock a range.

XWWarning

To avoid electrical shock while manual ranging, use the display

annunciators to identify the actual range selected.

Correcting an Overload (0o or -0o) Indication W

An 0o or -0o indication may appear on the display to indicate that an overload

condition exists. For voltage and current measurements, an overload should be

immediately corrected by selecting a higher range. If the highest range setting does

not eliminate the overload, interrupt the measurement until the problem is identified

and eliminated. The 0o indication is normal for some functions; for example,

resistance, continuity, and diode test.

Measuring DC Voltage See Figure -1-

1. Set the Function Switch to v.

2. Select the desired RANGE. The default DC voltage range is 2 V on the 15XP-A

and 4 V on the 35XP-A.

3. Connect the test leads: Red to E, Black to COM.

4. Connect the test probes to the circuit test points.

5. Read the display, and, if necessary, correct any overload (0o) conditions.

Measuring AC Voltage See Figure -2-

1. Set the Function Switch to V.

2. Select the desired RANGE. The default AC voltage range is 2 V on the 15XP-A

and 4 V on the 35XP-A.

3. Connect the test leads: Red to E, Black to COM.

4. Connect the test probes to the circuit test points.

5. Read the display, and, if necessary, correct any overload (0o) conditions.

Preparing for Current Measurements

•Turn off circuit power before connecting the test probes.

•Allow the meter to cool between measurements, if current measurements

approach or exceeds 2 amps.

•A warning tone sounds if you connect a test lead to a current input while a

current function is not selected.

•Open circuit voltage at the measurement point must not exceed 1000 V.

•Always measure current in series with the load. Never measure current across a

voltage source.

Measuring DC Current See Figure -3-

1. Set the Function Switch to a current function, µA, mA, or A.

2. Select the desired RANGE (5XP-A only).

3. Connect the test leads: Red to mA or A, Black to COM.

4. Turn off power to the circuit being measured.

5. Open the test circuit (X) to establish measurement points.

6. Connect the test probes in series with the load (to the measurement points).

7. Turn on power to the circuit being measured.

8. Read the display, and, if necessary, correct any overload (0o or -0o) conditions.

Measuring AC Current See Figure -4-

1. Set the Function Switch to a current function and range, µA, mA, or A.

2. Select the desired RANGE (5XP-A only).

3. Connect the test leads: Red to mA or A, Black to COM.

4. Turn off power to the circuit being measured.

5. Open the test circuit (X) to establish measurement points.

6. Connect the test probes in series with the load (to the measurement points).

7. Turn on power to the circuit being measured.

8. Read the display, and, if necessary, correct any overload (0o) conditions.

Measuring Resistance See Figure -5-

1. Set the Function Switch to Ω.

2. Select the desired RANGE (5XP-A, 15XP-A).

3. Connect the test leads: Red to E, Black to COM.

4. Turn off power to the circuit being measured. Never measure resistance across

a voltage source or on a powered circuit.

5. Discharge any capacitors that may influence the reading.

6. Connect the test probes across the resistance.

7. Read the display. If 0o appears on the highest range, the resistance is too large

to be measured or the circuit is an open circuit.

8. (15XP-A) The 2000 MΩ range has a fixed 10-count offset in the reading. For

example, when measuring 1100 MΩ, the display reads 1110. The 10 residual

must be subtracted to obtain the actual value of 1100 MΩ

Testing for Continuity See Figure -6-

1. Set the Function Switch to R.

2. Connect the test leads: Red to E, Black to COM.

3. Turn off power to the circuit being measured.

4. Discharge any capacitors that may influence the reading.

5. Connect the test probes across the resistance or the two points of test.

6. Listen for the tone that indicates continuity (< 40 Ω).

Testing Diodes See Figure -7-

1. Set the Function Switch to G.

2. Connect the test leads: Red to E, Black to COM.

3. Turn off power to the circuit being measured.

4. Free at least one end of the diode from the circuit.

5. Connect the test probes across the diode.

6. Read the display. A good diode has a forward voltage drop of about 0.6 V. An

open or reverse biased diode will read 0o.

Measuring Capacitance (35XP-A only) See Figure -8-

1. Set the Function Switch to the P function.

2. Connect the test leads: Red to h, Black to COM.

4. Turn off power to the circuit being measured.

5. Discharge the capacitor using a 100 kΩresistor.

6. Free at least one end of the capacitor from the circuit.

7. Connect the test probes across the capacitor.

8. Read the display.

Measuring Temperature (35XP-A only) See Figure -9-

1. Set the function switch to appropriate °C or °F range.

2. Connect the K-type thermocouple to a TEMP adapter (XR-TA).

Match the polarity of the adapter to the polarity of the thermocouple.

3. Connect the TEMP adapter to the E and COM inputs.

Note: The 35XP-A is compatible with all K-type thermocouples. The K-type bead

thermocouple supplied with the meter is not intended for contact with liquids or electrical

circuits.

4. Expose the thermocouple to the temperature to be measured.

5. Read the display.

Measuring Frequency (35XP-A only) See Figure -10-

1. Set the Function Switch to Hz.

2. Connect the test leads: Red to Hz, Black to COM.

3. Connect the test probes to the signal source.

4. Read the display.

Measuring NCV (Non-Contact Voltage) See Figure -11-

1. Range switch may be set to OFF or any function/range.

2. Test leads are not used for the NCV test.

3. Press the NCV button. The display goes blank, a tone sounds and the red LED

next to the NCV button on the front panel lights up to verify that the instrument

is operational. While pressing the button, hold the top-center of the meter z

(sensor location) close to the conductor/circuit in question.

4. If a voltage in the range of 70 to 600 V ac is present, a tone sounds and the red

LED next to the NCV button on the front panel lights up.

Testing Battery Voltage (5XP-A only) See Figure -12-

1. Set the Function Switch to the appropriate BATT setting, 1.5 V or 9 V.

2. Connect the test leads: Red to BATT 1.5 V or BATT 9 V, Black to COM.

3. Connect the test probes across the battery. The meter applies an appropriate

load to the battery.

4. Read the display. A good 1.5 volt battery should measure >1.2 V, and a good

9 volt battery should measure > 7.2 V.

Testing Logic Levels (15XP-A only) See Figure -13-

The 15XP-A tests logic levels for TTL logic. The meter displays 0o plus a ∧for a

high-level (true) condition. The meter beeps and displays an 0o and a ∨for a

low-level (false) condition. See Specifications for the logic 1 and logic 0 voltage

limits. Out-of-limits indications are displayed as 0o only, no ∧,∨ or beep occur.

1. Set the Function Switch to LOGIC.

2. Connect the test leads: Red to E, Black to COM.

3. Connect the black lead to logic common.

4. Connect the red lead to the logic test point.

5. Read the display.

Additional Features

Input Test Lead Warning

The meter emits a continuous tone when a test lead is placed in the mA or Ainput

jack and the Function/Range Switch is not set to a correct current position. (If the

meter is connected to a voltage source with leads connected for current, very high

current could result). All current ranges are protected by fast acting fuses.

MIN MAX Measurements (Model 5XP-A only)

The MIN MAX feature reads and updates the display to show the maximum or

minimum value measured after you press the MIN MAX button.

Pressing the MIN MAX button for less than 1 second will put the meter into a mode

of displaying the maximum or minimum readings. Each time the button is pressed,

the meter will cycle to the next display mode. Press the MIN MAX button for more

than 1 second to disable this feature.

Auto Power Off (Models 15XP-A and 35XP-A only)

Auto Power Off is a battery saving feature that puts the meter into a sleep mode if

the Function/Range Switch has not changed position in the last 10 minutes. To

wake the meter turn the Function/Range Switch to another position.

The Auto Power Off feature can be disabled to keep the meter from going to sleep.

To disable the Auto Power Off feature use the following procedure:

1. Set the Function Switch to OFF.

2. Press and hold the Range button while turning the Function Switch from OFF

to the desired function.

3. Release the Range button. The Auto Power Off feature will remain disabled until

the meter is turned off and then on.

HOLD Measurements

The HOLD button causes the meter to capture and continuously display a

measurement reading. To use the HOLD feature make a measurement, and then,

after the reading has stabilized, momentarily press the HOLD button. You can

remove the test leads and the reading will remain on the display. Pressing the

HOLD button again releases the display.

Product Maintenance

Cleaning

To clean the meter, use a soft cloth moistened with water. To avoid damage to the

plastic components do not use benzene, alcohol, acetone, ether, paint thinner,

lacquer thinner, ketone or other solvents to clean the meter.

Troubleshooting

If the meter appears to operate improperly, check the following items first.

1. Review the operating instructions to ensure the meter is being used properly.

2. Inspect and test the continuity of the test leads.

3. Make sure the battery is in good condition. The low battery symbol M

appears when the battery falls below the level where accuracy is guaranteed.

Replace a low-battery immediately.

4. Check the condition of the fuses if the current ranges operate incorrectly.

Battery and Fuse Replacement See Figure -14-

XWWARNING

To avoid electrical, shock remove the test leads from both the

meter and the test circuit before accessing the battery or the

fuses.

To replace the fuse:

1. Remove the 2 rear-case screws.

2. Separate the case.

3. Remove and replace the 2 A fuse (15XP-A or 35XP-A) or 0.315 fuse (5XP-A).

4. Reassemble the meter.

Fuse:

Fast Blow 2 A/1000 V, minimum interrupt rating 30 kA (6 x 32 mm)

(Amprobe®FP200).

Fast Blow 0.315 A/1000 V minimum interrupt rating 30 kA (6.3 x 32 mm)

(Amprobe®FP300)

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Multímetro de Amprobe

Amprobe

Amprobe CDM-1 Manual de usuario

Amprobe

Amprobe AM-1E Manual de usuario

Amprobe

Amprobe ACD-10 TRMS-PLUS Manual de usuario

Amprobe

Amprobe ACD-11 Manual de usuario

Amprobe

Amprobe AM-560 Manual de usuario

Amprobe

Amprobe AM535 Manual de usuario

Amprobe

Amprobe 30XR-A-D Manual de usuario

Amprobe

Amprobe PM53A Manual de usuario

Amprobe

Amprobe AM-1250 Manual de usuario

Amprobe

Amprobe AM-120 TRMS Manual de usuario

Amprobe

Amprobe 38XR-A Manual de usuario

Amprobe

Amprobe AM-140 Manual de usuario

Amprobe

Amprobe AM-500 Manual de usuario

Amprobe

Amprobe ACD-14 PLUS Manual de usuario

Amprobe

Amprobe AU92 Manual de usuario

Amprobe

Amprobe AM-140-A Manual de usuario

Amprobe

Amprobe 38XR-A Manual de usuario

Amprobe

Amprobe 30XR-A Manual de usuario

Amprobe

Amprobe AC71B Manual de usuario

Amprobe

Amprobe 34XR-A Manual de usuario

Amprobe

Amprobe DM73C Manual de usuario

Amprobe

Amprobe ACDC-3000 Manual de usuario

Amprobe

Amprobe 5XP-A Manual de usuario

Amprobe

Amprobe ACDC-400 Manual de usuario

Manuales populares de Multímetro de otras marcas

Agilent Technologies

Agilent Technologies 34420A Manual de usuario

Fluke

Fluke 83 Manual de usuario

Hameg

Hameg HM 8012 Manual de usuario

Mastech

Mastech MY70 Manual de usuario

Steren

Steren MUL-300 Manual de usuario

Somogyi Elektronic

Somogyi Elektronic home SMA 92 Manual de usuario

Gossen MetraWatt

Gossen MetraWatt METRAmax 6 Manual de usuario

PeakTech

PeakTech 4000 Manual de uso y cuidado

YOKOGAWA

YOKOGAWA 90050B Manual de usuario

Gossen MetraWatt

Gossen MetraWatt METRALINE DMM16 Manual de usuario

Fluke

Fluke 8846A Manual de operación y mantenimiento

Tempo Communications

Tempo Communications MM200 Manual de usuario

Elenco Electronics

Elenco Electronics CM-1555 Manual de usuario

Mastech

Mastech MS8238C Manual de usuario

SDAR

SDAR 830A, 830B, 830D, 830C Manual de usuario

RS PRO

RS PRO RS-9519BT Manual de usuario

BGS technic

BGS technic 8890 Manual de usuario

Morris

Morris 57074 Manual de usuario
