Ameriwood HOME 9610407COM Manual de usuario

9610407COM

BookcasewithDoors

‐Unitcantipovercausingsevereinjuryordeath.

‐Anchorunittostudinwall(ifinstructedto).

‐DoNotallowchildrentoclimbonunit.

‐Putheavyitemsonlowershelvesordrawers.

B349610407COM1

THISINSTRUCTIONBOOKLETCONTAINS

IMPORTANT

SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.

WARNING

FollowAmeriwoodHome

Tube

You

DateofPurchase___/___/___

LotNumber:

DoNotReturnThisProduct!

Contactourcustomerserviceteamforhelpfirst.

Call:1‐800‐489‐3351(tollfree)

Monday‐Friday9am‐5pmCST

Visit:www.ameriwoodhome.com AssemblyDifficultyMeter

Easy Tough

ContactUs!

HelpfulHints

2

ameriwoodhome.com

DoNOTreturnthisproduct!

Contactourfriendlycustomerserviceteamfirstforhelp.

Callus!

1‐800‐489‐3351

Monday‐Friday

9am‐5pmCST

Visitameriwoodhome.comtoviewthe

limitedwarrantyvalidintheU.S.andCanada.

AssemblyTips

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.



‐Identify,sortandcountthepartsbeforeattemptingassembly.



‐Compressiondowelsarelightlytappedinwithahammer.



‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.



‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe

outeredge.



‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.



‐Backpanelmustbeusedtomakesureyourunitissturdy.



‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.



‐Neverpush,pull,ordragyourfurniture.

Tube

You

Tube

You

PEOPLENEEDEDFORASSEMBLY:1‐2

ESTIMATEDASSEMBLYTIME:1HOUR

3

ameriwoodhome.com

BeforeYouStart



Quick

Tip

Assembly



CamLockFasteningSystem

ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.

Tube

You

Readthrougheachstepcarefullyandfollowtheproperorder



Separateandcountallyourpartsandhardware



Giveyourselfenoughroomfortheassemblyprocess



Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.



4

ameriwoodhome.com

BoardIdentification

Notactualsize

Tube

You

LeftPanel

39610407010

RightPanel

39610407020

Top

39610407030 Bottom

39610407040

FixedShelf

39610407050 AdjustableShelf

39610407060 Apron

39610407070 KickPanel

39610407080

Door

39610407090

LegA

39610407100

LegB

39610407110

LegC

39610407120

LegD

39610407130

This piece is paperboard construction.

It is not made from wood, but is

required for the assembly of your unit.

BackPanel

K961040700

ABCD

EFG H

KLM

5

ameriwoodhome.com

Tube

You

BoardIdentification

This piece is paperboard construction.

It is not made from wood, but is

required for the assembly of your unit.

6

ameriwoodhome.com

PartList

ActualSize

Tube

You

NotActualSize

(x12)

#A22620

cam lock

(x12)

#A22610

cam bolt

(x12)

#A22920

connector

(x12)

#A21660

wood dowel

(x4)

#A17400

7/8" bolt

(x12)

#A22910

connector bolt

(x2)

#A52926

handle

(x34)

#A12210

1/2" pan head

(x4)

#A80250

shelf support

(x9)

#A53600

angle bracket

(x12)

#A21110

nail

(x2)

#A89210

bumper

78910

(x4)

#A65640

hinge

(x1)

#A84050

safety bracket kit

14a

14b

14c

14d

loosen to separate hinge from plate

7

ameriwoodhome.com

STEP1

Tube

You

(x2)

#A22620

125

(x4)

#A22610

(x2)

#A21660

finishededge

Proper orientation of CAM LOCK

Tip

Assembly

Quick

8

ameriwoodhome.com

STEP2

Tube

You

Youwillneedtotaptheconnector

(3)withahammertofullyinsert.

Besuretheconnectorispositioned

asshownbeforepushingintohole.

(x6)

#A22920

9

ameriwoodhome.com

STEP3

Tube

You

125

(x2)

#A22620

(x4)

#A22610

(x2)

#A21660

finishededge

Proper orientation of CAM LOCK

Tip

Assembly

Quick

10

ameriwoodhome.com

STEP4

Tube

You

(x6)

#A22920

Youwillneedtotaptheconnector

(3)withahammertofullyinsert.

Besuretheconnectorispositioned

asshownbeforepushingintohole.
